BOMANN EBK 958 User manual

Please read the instructions and keep them in a safe place!
07/2013
OPERATING INSTRUCTIONS
BUILT-IN
GLASS-CERAMIC HOB
EBK 958



- 19 -

- 20 -
TABLE OF CONTENTS
TABLE OF CONTENTS ........................................................................20
INTRODUCTION ..................................................................................21
GENERAL ADVICE ..............................................................................21
Structure of the safety instructions ...................................................21
Limitation of liability ...........................................................................21
Copyright ...........................................................................................21
Intended use ......................................................................................22
SAFETY INSTRUCTIONS....................................................................22
Instructions for safe use of the appliance ...........................................23
Avoiding damage to the appliance ....................................................24
DESCRIPTION OF THE APPLIANCE ..................................................24
Hob ....................................................................................................24
Control panel ....................................................................................24
Description of the functions ...............................................................25
Specifcations ....................................................................................25
INSTALLATION ....................................................................................26
Unpacking the appliance ...................................................................26
Requirements of the installation location ...........................................27
Installation .........................................................................................28
Electrical connection .........................................................................29
OPERATION ........................................................................................30
General instructions for operation ......................................................30
Selection of the correct cookware ......................................................30
Turning the appliance ON/OFF ..........................................................31
Turning a Cooking Zone ON/OFF.......................................................31
Turning the Dual Cooking Zone ON/OFF ...........................................32
Using the timer ..................................................................................32
Canceling the timer setting ................................................................33
Other timer use ..................................................................................33
Turning the child lock ON ...................................................................33
Turning the child lock OFF .................................................................33
CLEANING AND MAINTENANCE ......................................................34
REPAIRS .............................................................................................34
TROUBLESHOOTING .........................................................................35
DISPOSAL ................................................................................35
Packaging Materials ..........................................................................35
Waste Appliances ..............................................................................36

- 21 -
INTRODUCTION
Please read the operating instructions carefully before operating
the appliance. They include important safety instructions for in-
stallation, operation, and maintenance of the appliance. Improper
use of the appliance can be dangerous, especially for children.
Keep the operating instructions handy for later reference. Hand them over to
any subsequent owner. Please contact your dealer or customer service for
questions not answered in these operating instructions.
GENERAL ADVICE
Structure of the Safety Instructions
All safety instructions in these instructions are provided with a warning sym-
bol. They indicate possible dangers in advance and provide advice on how
the hazards can be prevented.
WARNING
Used for a potentially dangerous situation that could lead to se-
vere injuries or death.
► To prevent the danger, follow the instructions listed here.
NOTE
A note contains additional information facilitating use of the ap-
pliance.
Limitation of Liability
We shall not be liable for damages and consequential damages in case of:
• Failure to follow the operating instructions,
• use other than intended use,
• incorrect or unsuitable handling or cleaning,
• incorrectly performed repairs,
• unauthorized modications,
• use of unsuitable add-ons or accessories.
Copyright
This document is subject to copyright. Any reproduction or reprinting, even
excerpts thereof, as well as reproduction of the illustrations, even if altered,
is permitted only with the written consent of the manufacturer.

- 22 -
Intended use
This appliance is intended exclusively for non-commercial use in enclosed
rooms for warming and preparation of food in domestic quantities with use of
suitable cookware. The appliance must be installed in a work surface.
Any other or further use, for example for heating of rooms, shall be consid-
ered as not intended.
WARNING
If not used as intended or otherwise, this appliance can cause
hazards.
► Only use the appliance as intended.
► Follow the procedures described in the operating instructions.
Claims of any kind due to damage from use other than that intended are ex-
cluded.
SAFETY INSTRUCTIONS
WARNING
Danger from electrical current!
Contact with live leads or components can be fatal! Follow the
safety instructions below to prevent hazards from electrical cur-
rent:
► The connection of the appliance must satisfy the relevant
standards and regulations and may only be performed by an
authorized specialist.
► The appliance may not be used if the glass surface has cracks
or is broken.
► The use of high-pressure cleaners or steam jet cleaners is
prohibited. Ingress of liquids can lead to electric shock.
►Modifications or changes to the appliance are not permitted
for safety reasons.
WARNING
Risk of Burning on hot surfaces
Touching the glass-ceramic surface and/or the cookware can
lead to severe burns.
► Do not touch the glass-ceramic surface during operation.
► Touch the cookware only on heat-insulated parts or use suit-
able heat protection.
► The hobs are still hot after turning off. Before touching the
glass-ceramic surface, use the residual heat indication to
check whether the hobs are still hot.

- 23 -
WARNING
Risk of Fire!
Overheated fats and oils can ignite easily.
► Never walk away from fats and oil when heating them.
► If fat/oil ignites, never extinguish it with water. Immediately
cover with a lid or a plate. Turn off the hob and allow the
cookware to cool down.
Instructions for safe use of the appliance
• This appliance can be used by children of age 8 or older and by persons
with reduced physical, sensory, or mental abilities, or lack of experience,
and/or knowledge, when they are supervised or have been instructed con-
cerning safe use of the appliance and have understood the resulting dan-
gers.
• Children may not play with the appliance. Cleaning and user maintenance
may not be performed by children.
• To avoid danger, do not place the glass-ceramic hob under water.
• Do not heat pots without food on the glass-ceramic hob, as this can lead
to malfunctions or hazards.
• To prevent the risk of explosion, do not heat sealed food (for example, in
tins) if unopened.
• Do not place metal objects (like knives, forks, spoons, and lids) on the
hob, as they can become hot.
• Do not use the appliance in the immediate vicinity of heat sources (gas or
kerosene stoves).
• Do not store detergents or easily inammable materials under the appli-
ance.
• Turn off the appliance after use and do not rely on automatic recognition
(automatic switch off).
• Do not repair the appliance yourself, but contact an authorized specialist
or customer service.
• Do not use the glass-ceramic hob as a storage area.
• The electrical safety of the hob is guaranteed only when it is connected to
a correctly installed earthed socket. In cases of doubt, have the domestic
wiring checked by an electrician. The manufacturer shall not be liable for
damages caused by missing or short-circuited earth connections (for ex-
ample electric shock).
• The mains connection may only be replaced by an electrician familiar with
the local regulations and the additional regulations of the local power sup-
ply company and compliance with them.

- 24 -
Avoiding damage to the appliance
• Do not place rough or uneven equipment onto the hob to prevent damage.
• Clean the glass-ceramic hob regularly to prevent build-up of dirt or its in-
gress into the appliance housing.
• Always avoid dropping hard or pointed objects onto the glass plate. The
ceramic glass is susceptible to mechanical stresses like impacts or blows
and can be damaged by them.
• The hob may not be used as a storage or support area.
• Periodically check that the air inlet under the hob is not blocked by foreign
objects (glass, paper, etc.).
DESCRIPTION OF THE APPLIANCE
Hob
Control panel
1 Cooking zone1
1100/2000 W
2 Cooking zone 2
1000/2200 W
3 Cooking zone 3
1800 W
4 Cooking zone 4
1200 W
5Glass-ceramic plate
6 Control panel
1 Power control
2 Timer control
3 Turning the Dual
Cooking Zone ON/
OFF
4 Child lock
5 ON/OFF button

- 25 -
Description of the Functions
The glass-ceramic hob has four cooking zones heated by electrical heating
coils under the glass-ceramic plate. The power of each cooking zone can
be adjusted in nine levels. The hob is operated via touch-sensitive buttons
on the control panel. The current operating status is shown on displays. The
glass-ceramic hob can be kept clean easily because of the smooth surface.
Overheating Protection
A thermostat monitors the inside of the appliance. If maximum temperatures
are exceeded, the appliance is turned off automatically to prevent damage.
Residual Heat Indication
After the appliance has been turned off, the display of the corresponding
cooking zone shows the symbol ‘H” (residual heat) when the temperature of
the cooking zone is still high enough to cause burns when touched. When
the temperature has dropped sufciently, the residual heat indication of the
respective cooking zone goes out.
Automatic Switch off
The integrated automatic switch off automatically turns off the appliance, if
you forget to turn off the hob. The switch off times of the different power lev-
els are shown in the following table:
Power level 1 2 3 4 5 6 7 8 9
Switch-off time (hours) 8 8 8 4 4 4 2 2 2
Child Lock
The appliance has a child lock to prevent children from accidentally turning
the appliance on.
Specications
Type designation EBK 958
Supply voltage 220-240V~/400 V 3N~ 50/60 Hz
Input power 6500-7800W / 7200 W
External dimensions (W x H x D) 770 x 55 x 520 mm
Installation dimensions (W x D) 750 x 495 mm
Weight (net/gross) 11.5 kg / 13.5 kg
Connection line cable type H05VV-F

- 26 -
Cable cross section 5x2.5 mm² with connection to 220-240 V
Number of cooking zones 4
Cooking zone 1 Dual cooking zone
Size 165 mm / 270 x 165 mm
Power 1100/2000 W
Cooking zone 2 Dual cooking zone
Size 140 mm / 200 mm
Power 1000/2200 W
Cooking zone 3 Single cooking zone
Size 200 mm
Power 1800 W
Cooking zone 4 Single cooking zone
Size 165 mm
Power 1200 W
Scope of delivery Glass-ceramic hob EBK 958
4 x mounting bracket,
operating instructions (D, GB)
Manufacturer information - We reserve the right to improve the product.
INSTALLATION
Unpacking the Appliance
The packaging must be undamaged. Check the appliance for transport dam-
age. A damaged appliance may not be operated. In the case of damage,
contact your dealer.
WARNING
Danger of suffocation!
Packaging parts (for example foils, Styrofoam) can be danger-
ous for children.
► Keep packaging materials away from children.
• Remove the protective foil from the appliance.
Requirements of the installation location
• The appliance may only be installed next to higher kitchen furniture, appli-
ances, or walls on one side.
• The appliance should not be installed directly next to refrigerators or freez-

- 27 -
ers. Their power consumption will be increased unnecessarily by the pro-
duced heat.
• A space of at least 50 mm must remain free for cooling under the entire
cut-out space for the appliance. No heat-sensitive items (base cabinet,
drawer, etc.) may be located in this space. Any existing side walls or draw-
er boxes must be removed or cut out accordingly.
• The work surface must be at least 30 mm thick and 620 mm deep, must
be level, and must be sealed on the wall side against liquid overow.
• The glass-ceramic hob must be framed on all sides by at least 50 mm of
work surface.
• The work surface, back walls, veneers, plastic coatings, and glues used
must be sufciently heat-resistant (up to 100 °C).
• The cut-out space may be max. 750 x 495 mm.
• The appliance shall be installed so that sufcient air circulation is assured
(refer to the following gure).
Min. dimensions for suf-
cient air circulation:
A Distance to wall
cabinets
760 mm
B Free space
under the hob
50 mm
C Distance to the
wall
30 mm
D Air inlet 30 mm
E Air outlet 10 mm

- 28 -
Installation
• Cut the work surface according to the above drawing.
NOTE
Before sawing, cover the outer edge of the cutout with wide ad-
hesive tape to prevent traces of the saber jig saw on the work
surface.
• Seal the cut surfaces with special temperature-resistant lacquer, silicon, or
cast resin to prevent swelling of the work surface from moisture.
• Place the glass-ceramic hob with the glass side facing down onto a stable
base. Use a suitable base to prevent scratching of the glass-ceramic sur-
face. The hob must not be subjected to any forces.
• Connect the connection cable to the appliance as described in the chapter
Electric Connection.
• Insert the appliance with the operation panel at the front into the cutout.
Make sure that the distance to the cutout is the same on all four sides.
• Mount the hob with the four supplied holders onto the work surface. De-
pending on the thickness of the work surface, the holders can be installed
in two ways (refer to the following gure).
Dimensions:
A 750 mm
B 495 mm
X Min. 50 mm
L 770 mm
W 520 mm
H 55 mm
D 51 mm

- 29 -
Electric Connection
WARNING
Danger from electrical current!
Connection to the mains may only be performed by authorized
certied electrician in compliance with the relevant VDE regula-
tions.
► Have the electric connection performed only by an authorized
specialist.
► Before the start of work, disconnect and isolate all poles of the
input line.
Connection Conditions
• Before making the connection, conrm that the power supply conforms to
the information on the name plate on the underside of the appliance.
• The supply line must have an isolating device for all poles with a contact
gap of at least 3 mm in the house installation (fuses, circuit breaker, or
contactor).
• The appliance must be grounded via an earth conductor.
• A rubber-sheathed cable H05VV-F with wire end ferrules and correspond-
ingly rated cross section must be used as the mains connection cable
(EN60335: 3 x 6 mm2, 5 x 2.5 mm2or 4 x 2.5 mm2).
• Protection against accidental contact must be guaranteed. For increased
safety, an FI circuit breaker with a trip current of 30 mA should be connect-
ed between the appliance and the mains.
• Connection to a domestic socket (230 V/16 A) and the use of multiple
sockets is not permitted.
• The connection cable must not be bent or clamped.
Mains Connection
The appliance is designed for two connection types (refer to the following g-
ure):

- 30 -
AC 220 to 240 V three-phase current 380 to 415 V
L N PE L1 L2 N PE
OPERATION
General Instructions for Operation
• Operation of the appliance is performed via buttons on the control panel of
the appliance.
• The buttons respond to a light touch. No pressure is required.
• The appliance reacts best to touching the buttons with the tip of a nger
and dry hands.
• A short beep sounds when a touch is registered.
• Always make sure that the control panel is clean and dry. Objects or a thin
lm of uid can make the operation difcult.
Selection of the correct cookware


Use only cookware with a completely
flat bottom or with a slight concave
surface (the bottom expands when
heated). In this way, the heat is trans-
ferred optimally.
The bottom of the cookware should
be the same size as the hob and
should be centered on the hob.
íÜêÉÉJéÜ~ëÉ ÅìêêÉåí PUM íç QNR s ^` OOM íç OQM s
iN iO k mb i k mb

- 31 -

To prevent scratches, do not slide
the cookware over the glass-ceramic
hob, but rather lift it.
Turning the Appliance ON/OFF
• Touch the ON/OFF switch on the control panel of the
appliance to turn the appliance on. After turning on, a
beep sounds and all indicators light for one second.
Now the appliance is in standby mode.
NOTE
► If you do not select a further function within one minute, the
appliance is turned off automatically.
► The hob can be turned off at any time by touching the ON/
OFF switch.
Turning a Cooking Zone ON/OFF
• Place suitable cookware onto the cooking zone to be
used. Make sure that the surface of the cooking zone
and the bottom of the cookware are clean and dry.
• Select the desired heating level from 1 to 9 with the but-
tons or assigned to the desired cooking zone. You
can change the setting at any time during cooking.
• The setting is changed steplessly by touching the button
or continuously.
• To turn off the cooking zone, touch the respective button
, until the indicator “0” appears.
• As an alternative, touch the buttons and at the
same time; the power is set back to level 0 and the
cooking zone is turned off.

- 32 -
Turning the Dual Cooking Zone ON/OFF
NOTE
►This function is available only for cooking zones 1 and 2.
► You can only use the center section (A) of the respective hob
or both sections (B) together.
Cooking zone 1 Cooking zone 2
• Select the desired heating setting with the buttons or
assigned to the desired cooking zone.
• Press the button ◎to turn on the dual cooking zone.
• nd the set heating setting are shown alternately.
• To turn off the dual cooking zone, press the button ◎.
Using the Timer
• Select the desired heating setting with the buttons
or assigned to the desired cooking zone.
• Set the timer between 1 and 99 minutes with the but-
tons or .
• Each time or is touched, the set time is changed
by one minute. By continuously touching button or
, the set time is changed in steps of 10 minutes.
• After the timer has been set, the timer display ashes
for 5 seconds. A red dot next to the cooking level indi-
cates that a timer has been set for this cooking zone.
The display shows the remaining time.

- 33 -
Canceling the Timer Setting
• Touch the buttons and at the same time to can-
cel the timer. The timer display shows “--”.
NOTE
► In timer mode, the power level can be changed without chang-
ing the time setting.
► The timer function is canceled when the appliance is turned
off.
► After the set time, the cooking zone is turned off automatically.
Other Timer Use
• The hob must be turned on and no cooking zone may be
selected.
• Touch the button Timer Setting. The display shows “--”
and the timer can be set.
• Setting the timer for other use is done as described in
Timer as Time Switch.
• After the set time has passed, a beep sounds for 30 sec-
onds, and the display shows “--”.
Turning the Child Lock ON
The appliance has a lock function to prevent unintended operation.
Touch the button “Child Lock” , the appliance is locked and the display
shows “Lo”.
Turning the Child Lock OFF
Make sure that the appliance is turned on.
Touch the button “Child Lock” for approximately 3 seconds to cancel the
lock.
NOTE
► When the child lock is activated, all buttons other than the
ON/OFF button are locked. The appliance can be operated
again only after unlocking.

- 34 -
CLEANING AND MAINTENANCE
WARNING
Danger from electrical current!
In the case of incorrect cleaning, moisture can get into the
inside of the appliance, and this can lead to electric shock.
► Never clean the appliance with high-pressure or steam
cleaners.
► The appliance must be dry before it is operated again.
Notes for Cleaning
• Always clean the hob after cooking. This ensures that food residue will not
burn in.
• Turn the appliance off and allow the hob to cool down sufciently before
you start cleaning.
• Use only detergents suitable for glass-ceramics. Follow the cleaning in-
structions on the package.
• Do not use aggressive cleaning agents, scouring agents, or scratching
sponges.
• Use a glass scraper (not included) to remove excessive dirt. Use the glass
scraper only on the glass-ceramic surface and not on the frame.
• Periodically use a glass-ceramics cleaner that seals the glass-ceramics
surface and protects the hob.
REPAIRS
WARNING
Danger from incorrect repair!
A wrongly or incorrectly performed repair causes a hazard
for the user and the invalidation of the warranty.
► Repairs on electrical appliances may only be performed
by qualied specialists.
► A damaged mains cord may only be replaced by an elec-
trician.

- 35 -
TROUBLESHOOTING
The design of the appliance assures trouble-free operation and a long life.
Should problems still occur, the following table will help to nd and eliminate
minor problems:
Problem Possible cause Repair
The hob cannot be
turned on.
The power supply is
interrupted.
Check the distribution board of
the appliance. Use other appli-
ances to check for a power fail-
ure. When you have checked
everything and the problem still
persists, call customer service
or an electrician.
The buttons no longer
respond.
The child lock is ac-
tive.
Unlock the control panel.
The buttons react very
poorly when touched.
The control surface
is damp.
Make sure that the control pan-
el area is dry and that you use
the nger tip for operation.
Some pots and pans
make crackling noises.
This can be caused
by the design of the
cookware.
This does not indicate a fault.
If a problem still persists after following the steps above, please contact your
distributor and/or a technician.
DISPOSAL
Packaging Materials
The packaging protects the appliance from transport damage. The packaging
materials have been selected to be environmentally friendly and disposed of
in an environmentally friendly manner and thus can be recycled. Returning
the packaging to the material cycle saves raw materials and reduces waste.
Dispose of no longer needed packaging materials according to the relevant
local regulations. The materials used are:
• Corrugated cardboard/Cardboard (mainly from waste paper)
• Moulded parts made of PS (foamed polystyrene free of FCKW)
• Foils and bags of PE (polyethylene)
• Straps made from PP (polypropylene)

- 36 -
Waste Appliances
The symbol of the garbage bin on the product or the accompany-
ing paperwork shows that this appliance must not be handled as
household waste. Instead, it should be brought to the collection
point for recycling of electrical and electronic appliances. Dis-
posal must be according to the relevant local regulations. For fur-
ther information, contact the local authorities or a waste disposal
company.
Are you interested in other Bomann products? Please visit our website:
www.bomann.de


- 37 -

www.bomann.de
- 38 -
