Bomma dew drops User manual

o Installation Manual for Floor Light Fixtures Don’t throw away!
dew drops
Design by Boris Klimek
1
2
3
45
6

Introduction
• Please read this user’s manual carefully prior to installation and follow its instructions
and recommendations.
• The installation of the floor light requires one person.
• For safety reasons, as well as for warranty purposes, it is forbidden to use this product in
breach of this manual and other purposes stipulated in this manual.
• Prior to assembly, use an appropriate circuit breaker to turn off electricity.
• All interventions regarding the wiring of the light fixture may only be carried out by a
qualified electrician.
• Prevent children or persons with lowered sensory or psychological abilities from handling
the light fixture, as it contains small and fragile pieces that could be dangerous when
inappropriately handled or ingested.
• The producer bears no liability for damage caused by improper installation.
• The dimensions and weight of glass parts may differ slightly due to manual production.
• All Bomma products are made from hand-blown lead-free crystal. Any small bubbles,
non-melts and inhomogeneities in the glass are not a reason for complaint. This is a
characteristic feature of this traditional craft.
• Thanks to the manual process of blowing underlay glass, each piece is an original.
Individual products may vary slightly in intensity, hue or even color. This is an
accompanying characteristic of the underlay glass technology.
• The surface of the mounting may also include minor imperfections due to manual
production.
• The floor light is intended for interior lighting.
Components included in the package
• Glass parts of the light fixture (6x)
• Mounting including dimmable light sources
• Installation manual
• Maintenance instructions
• Gloves
Technical parameters, specifications
• Voltage rate: 34 V DC, 600 mA
• Protection: IP 20
• Input rate: 21,5 W
• Cable length: 70,8 inch
• Weight: ~ 66 lb
• Size: 12,8 x 11,9 inch, H 63,9 inch
• Light source: LED MCOB (6x) 21,5W (+-5%) 600mA, 1260 lm
• Class: II.
Dimming: TRIAC, CASSAMBI

1
Upon opening, first determine that there was no damage occurred during transport and
that the light fixture is complete. Otherwise, please contact your seller immediately, as
later claims may not be considered.
Assemble the lighting fixture according to the manual, recognizing that its installation
wiring may only be carried out by a qualified electrician following general legal
regulations.
Place the mounting frame base 1on a level surface.
1
1

Screw the glass parts 4onto the threads of the light sources 3on the mounting 2.
Find an inspiration on the first page of this manual for the layout of the individual glass
sizes.
Congratulations! You may now reconnect the power and turn the light on.
When dismantling, first turn off the light and disconnect from the power supply. Then
follow the above steps in reverse order. Use the original or similar packaging for possible
later transport of the light fixture to prevent damage.
2
3
4
2

Maintenance
• When unpacking, assembling and
cleaning the product, handle the
individual parts with extra care, especially
the glass parts which are very fragile.
• The assembly and wiring of the luminaire
must be carried out by an authorized
person.
• The floor luminaire is intended for indoor
use.
• Do not cover the light source or touch the
light source when the light is on.
• Do not make any repairs or changes to
the components. Contact a specialist
service center.
• Do not use any spare parts which have
not been supplied or approved by the
manufacturer (except for light sources).
• Do not expose the luminaire to an
unsuitable environment where it might
get damaged (water, heat, frost).
• Warning: the luminaire may in some
parts have sharp edges which may
cause injury. Take extra care when
moving in close proximity to them.
• Any cleaning and maintenance should
be carried out with the luminaire
switched off and preferably disconnected
(please mind this warning throughout the
installation.)
• When changing a bulb, always disconnect
the luminaire from the power supply.
• It is recommended to install pendant
luminaires in more than one person.
• After installing the luminaire, check that it
is correctly and securely fixed to its base.
• Do not expose the luminaire to
unreasonable loads, protect the luminaire
from mechanical damage.
• The light source heats up during
operation. Before starting any operation,
wait until the light source cools down
spontaneously _do not expose to rapid
cooling_.
• Halogen light sources must not come
into contact with oily materials, so do not
touch them with bare hands. Install them
using clean textile gloves or a clean cloth.
To clean a halogen bulb, it is best to use
alcohol-based products.
• When replacing the bulb, use the
same or recommended light source
(information about the type is on the
label or in the installation instructions).
• Do not hang any other components
on the luminaire in conflict with the
manufacturer’s installation instructions.
• Pay attention to checking all parts before
their installation. Damaged components
and glass parts _fragmentation, cracks_
can cause bodily injury to persons in their
vicinity.
• Contact the manufacturer if a serious
problem occurs during cleaning or
maintenance of the luminaire.
• Any other manipulation with the
luminaire should be carried out by
qualified personnel or directly by the
manufacturer.

Cleaning
• Any cleaning and maintenance should be
carried out with the luminaire switched
off and preferably disconnected.
• When cleaning, wear white gloves
made of soft cotton cloth. In particular,
do not touch the plated crystal without
gloves. This will prevent the formation of
impressions, loss of luster and color.
• Use a soft duster to clean the metal
parts. Metal parts can be cleaned with
dry or dampened duster in lukewarm
demineralized water. When cleaning the
parts, do not under any circumstances
use solvents, technical gasoline, technical
cleaners, peroxides or alkalis. Avoid
alcoholic agents, which could cause the
change of surface color.
• Clean the bulb with a soft damp cotton
cloth, an anti-static soft-bristled brush or
a vacuum cleaner on the low setting.
• Clean the stainless steel surfaces with
special products, sold for this purpose.
• To clean the glass parts, use a mild
cotton cloth, dry or moistened in
lukewarm demineralized water, or a
duster. Immediately after cleaning, dry
the product completely so that no drops
of water remain on the product, and
carefully hang it back up.
• Take extra care when cleaning the
individual parts of the luminaire that
cannot be disconnected. Excessive
handling might result in loosening or
chipping.
• Do not use a dishwasher to wash any
removable parts of the luminaire.
Important notice
• The manufacturer accepts no liability
for damage resulting from improper
installation, improper handling of the
luminaire, including installation combined
with accessories other than those
recommended by the manufacturer.
• The manufacturer accepts no liability for
damage resulting from unprofessional
tampering with the fixings and safety
features of the luminaire or for damage
to the product caused by improper
power supply voltage, storage or use of
the luminaire in damp environment.
• Do not store the floor luminaire in a
damp environment, near a boiler, trap or
other sources of steam. Do not place the
luminaire over a bathtub in bathrooms
and do not touch the luminaire if you are
in contact with water.
• The manufacturer reserves the right to
make minor variations in the design of
the luminaire without prior notice.

bomma.cz
Date of packagingControl
Disposal
Upon the expiration of the product’s shelf life, proceed in accordance to legal regulations
for environmental protection and public health safety.
Waste Materials Catalog
Number Category Name
10 11 11* N Waste glass
in small particles
and glass powder
containing heavy metals
10 11 12 O Waste glass other than those
mentioned in 10 11 11
17 04 01 O Copper, bronze, brass
17 04 05 O Iron and steel
20 01 01 O Paper and cardboard
15 01 05 O Composite packaging
Contact
BMRC GROUP s.r.o.
Hvězdova 1716/2b
140 78 Praha
Czech Republic
[phone]
[e-mail]
www.bomma.cz
Instagram bomma_cz
Facebook bommacz
1 06. 2022
