Bomma Pebbles User manual

bomma Installation Manual for Floor Light Fixtures
pebbles
Design by Boris Klimek

Introduction
• Please read this user’s manual carefully prior to installation and follow its instructions
and recommendations.
• The installation of the floor light requires one person.
• For safety reasons, as well as for warranty purposes, it is forbidden to use this product in
breach of this manual and other purposes stipulated in this manual.
• Prior to assembly, use an appropriate circuit breaker to turn off electricity.
• All interventions regarding the wiring of the light fixture may only be carried out by a
qualified electrician.
• Prevent children or persons with lowered sensory or psychological abilities from handling
the light fixture, as it contains small and fragile pieces that could be dangerous when
inappropriately handled or ingested.
• The producer bears no liability for damage caused by improper installation.
• The dimensions and weight of glass parts may differ slightly due to manual production.
• All Bomma products are made from hand-blown lead-free crystal. Any small bubbles,
non-melts and inhomogeneities in the glass are not a reason for complaint. This is a
characteristic feature of this traditional craft.
• Thanks to the manual process of blowing underlay glass, each piece is an original.
Individual products may vary slightly in intensity, hue or even color. This is an
accompanying characteristic of the underlay glass technology.
• The surface of the mounting may also include minor imperfections due to manual
production.
• The Pebbles collection is inspired by natural stones, so the individual glasses may have
an uneven color and a veined appearance.
• The floor light is intended for interior lighting.
Components included in the package
• Hand-blown glass part (2x – 4x according to the type of the light fixture)
• Mounting
• Dimmable light source
• Installation manual
• Maintenance instructions
• Gloves
Technical parameters, specifications
• Voltage rate: 230 V/A.C. 47 - 63 Hz
• Protection: IP 20
• Input rate (size S): 18 W / 350mA
• Input rate (size L): 25,5 W / 500mA
• Cable length: 3 m
• Weight Pebbles S: 18 kg
• Size Pebbles S: dia. 320 mm, H 740 mm
• Weight Pebbles L: 28 kg
• Size Pebbles L: dia. 400 mm, H 1350 mm
• Class: I.
Recommended light source (size S): LED module 18W
Recommended light source (size L): LED module 26W
Recommended transformer (size S): Mean Well PCD-25-350B
Recommended transformer (size L): Mean Well PCD-40-500B

1
Upon opening, first determine that there was no damage occurred during transport and
that the light fixture is complete. Otherwise, please contact your seller immediately, as
later claims may not be considered.
Assemble the lighting fixture according to the manual, recognizing that its installation
wiring may only be carried out by a qualified electrician following general legal
regulations.
Place the plate 1on a flat surface and gradually slide the glass parts 3onto the tube 2.
It is not necessary to follow the order of shapes presented on our website www.bomma.cz.
You can assemble the light fixture according to your imagination.
1
3
2
1

Screw the end cap 4into the thread at the end of the tube.
Congratulations! You may now reconnect the power and turn the light on.
When dismantling, first turn off the light and disconnect from the power supply. Then
follow the above steps in reverse order. Use the original or similar packaging for possible
later transport of the light fixture to prevent damage.
2
4

Maintenance
• When unpacking, installing and cleaning
your fixture, handle the individual
components with outmost care,
particularly the glass parts, which are
very fragile.
• Assembly and electric installation must
be carried out by certified electricians.
• Floor lights are intended for interiors.
• Do not cover nor touch the light source
while the light is on.
• Do not attempt any repairs or changes
to the components. Always contact our
specialized service.
• Spare parts that are not supplied or
approved by the producer may not be
used.
• The light source is tailor-made, so it
is not possible to buy an adequate
replacement freely. If a service change
is required, please contact us at info@
bomma.cz. If the light source is destroyed
due to incorrect electrical installation, it is
not possible to claim warranty for service
replacement.
• Do not expose the light fixture to
unsuitable environments where it could
become damaged (water, frost, heat).
• Ensure appropriate access (ladder,
scaffolding, aerial work platform) prior
to maintenance or cleaning floor lights,
in order to comfortably reach and safely
handle the light fixture.
• Note: in some areas, the lighting fixture
may have sharp edges that may cause
injury. Beware while in immediate
proximity of the fixture.
• Perform cleaning and all maintenance
with the light turned off, ideally entirely
disconnected. Respect this rule for the
entire duration of installation.
• The installation of the floor light requires
one person.
• After installation check whether the light
fixture is properly set in its base.
• Do not expose the light to inappropriate
strain and protect it from mechanical
damage.
• When in operation, the light source
becomes hot. Prior to any handling, wait
for the light source to naturally cool down
and do not expose it to fast cooling.
• Do not hang any other components on
the light fixture, other than those listed in
the installation manual.
• Pay attention to checking all parts prior to
their installation. Damaged components
and glass parts (fragmentation, cracks)
may cause personal injuries to persons
moving within its proximity.
• Should any serious problem occur during
cleaning or maintenance, do not hesitate
to contact the producer.
• Any other handling of the floor light
fixture should be performed by a
qualified technician or directly by the
producer.

Cleaning
• All cleaning and maintenance must be
carried out when the power is off, ideally
entirely disconnected.
• When cleaning, use fine-fabric gloves.
Particularly avoid handling metal-
coated crystal without gloves to avoid
fingerprints and loss of gloss.
• Use soft cloths to clean metal parts. Such
parts may be cleaned with a dry cloth or
a cloth dampened in warm water with a
mild detergent. Avoid the use of solvents
or technical benzene to clean metal
parts. Avoid alcohol-based cleaners that
may cause changes of surface colors.
• Clean fine-steel surfaces with products
sold especially for this purpose.
• To clean the glass parts, use products in
concentrations recommended by their
producers. Immediately after cleaning,
dry the light fixture and hang it again.
• When cleaning glass parts, a concentrate
of 90% water and 10% vinegar may also
be used. Fill up a clean spray-bottle with
this mixture. Use cotton gloves, apply the
solution to one of them and gently wipe
the parts requiring cleaning. Immediately
dry the cleaned surfaces with the other
glove. Give particular care to cleaning
individual parts of the light that cannot
be dismantled. Inappropriate handling
may cause loosening or chipping of
these parts.
• Avoid cleaning removable parts of the
light fixture in a dishwasher.
Important notice
• The producer bears no responsibility
for damage caused by unprofessional
installation or inappropriate handling
of the light fixture, including installation
with accessories other than those
recommended by the producer.
• The producer bears no responsibility
for damage caused by unprofessional
interventions into the mounting and
safety features of the light fixture,
including damage to the product by
inappropriate power supply, storage
or use of the light fixture in a humid
environment.
• Do not place the light fixture in humid
environments, such as near a boiler or
other sources of water vapor. Do not
place the lighting fixtures in shower
eclosures or above bathtubs and never
touch them when you are in contact with
water.
• The producer reserves the right to make
minor changes to the construction of the
light fixture without prior notice.

bomma.cz
Date of packagingControl
Disposal
Upon the completion of the technicalworking life of the light fixture and its disconnecting
from power supply, dismantle and separate the individual parts. Hand over the separated
parts to the appropriate organizations responsible for waste disposal.
Waste Materials Catalog
Number Category Name
10 11 11* N Waste glass
in small particles
and glass powder
containing heavy metals
10 11 12 O Waste glass other than those
mentioned in 10 11 11
17 04 01 O Copper, bronze, brass
17 04 05 O Iron and steel
20 01 01 O Paper and cardboard
15 01 05 O Composite packaging
Contact
Bohemia Machine Ltd.
1177 Zámecká St.
58291 Světlá nad Sázavou
Czech Republic
[phone]
[e-mail]
www.bomma.cz
Instagram bomma_cz
Facebook bommacz
