tagarno Backlight User manual

VERSION: 2.0 | 2019-06-15
Digital Microscope Solutions
1. YOU HAVE RECEIVED
MANUAL | BACKLIGHT
Basic control boxBacklight
2. CONNECTING
Power supply
Connect the backlight and power supply to
the control box. Please connect correctly
before use
Connect the power supply to a power plug
CONTENTS
1. YOU HAVE RECEIVED 1
2. CONNECTING 1
3. OPERATION 2

- +
3. OPERATION
Left Switch: ECO on/off
Right Switch: Sound on/off
The switches can be turned on/off using a
harp object, eg. pen or screwdriver.
Note! Before changing the ECO and Sound
switches, do not forget to unplug the control
box.
Always make sure that the power cord is connected correctly and the brightness is set to the desired value.
TECHNICAL SPECIFICATIONS
Illuminated area dimensions are 180x120 mm.
The total product dimensions are 215x170 mm.
Light intensity: 16000 Lux
Power saving/ECO mode
After 20 minutes of not using the intensity
buttons, the intensity is automatically
reduced to 10% of the maximum.
A short press on the “+” or “-” button
will reset the control box to the original
intensity.
Turn the control box and LED light on by
pressing the “+” or “-” button.
Control the light intensity by pressing the
“+” or “-” button.
Turn the control box off by pressing the “+”
and “-” buttons down simultaneously for
one second before letting go.
When turning the control box back on, it will
automatically use the last used setting.
EQUIPMENT DISPOSAL
This equipment is marked with the crossed out wheeled bin symbol to indicate that this equipment must
not be disposed of with unsorted waste.
