BonsenKitchen HM3901 User manual

www.bonsenkitchen.com
OperationInstructions
Model: HM3901
Hand Mixer

Contents
IMPORTANT SAFEGUARDS
NOTES ON THE CORD PLUG
PACKAGE CONTENTS
TECHNICAL DETAILS
KNOW YOUR HAND MIXER
INSTRUCTION FOR HAND MIXER
SPEED CONTROL GUIDE
CLEANING AND MAINTENANCE
TROUBLESHOOTING
WARRANTY CLAIM PROCEDURE
ENVIRONMENT FRIENDLY DISPOL
1
2
2
2
3
4-6
7
8
9
9
9
..........................................................................................
..........................................................................................
......................................................................................................
....................................................................................................
...............................................................................................
........................................................................................
............................................................................
.................................................................................
..............................................................................
.....................................................................................................
..................................................................................

1
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions.
2. To protect against risk of electrical shock, do not put Hand Mixer in
water or other liquid.
3. Close supervision is necessary when any appliance is used by or near
children.
4. Unplug Hand Mixer from the outlet when not in use, before putting on
or taking off parts, and before cleaning.
5. Avoid contacting moving parts. Keep hands, hair, clothing, as well as
spatulas and other utensils away from all accessories during operation
to reduce the risk of injury to persons and/or damage to the Hand
Mixer.
6. Do not operate the Hand Mixer with a damaged cord or plug, or after
the Hand Mixer malfunctions, or is dropped or damaged in any manner.
Return the Hand Mixer to the nearest Authorized Service Center for
examination, repair, or electrical or mechanical adjustment.
7. The use of attachments not recommended or sold by KitchenAid may
cause fire, electric shock, or injury.
8. Do not use the Hand Mixer outdoors.
9. Do not let cord hang over edge of table or counter.
10. Do not let cord contact hot surface, including the stove.
11. Remove any accessories from Hand Mixer before washing.
12. SAVE THESE INSTRUCTIONS.

2
NOTES ON THE CORD PLUG
PACKAGE CONTENTS
This appliance has a polarized plug (one blade is wider than the other). To reduce
the risk of electric shock, this plug will fit in a polarized outlet only one way. If the
plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician. Do not modify the plug in any way.
1 motor unit
2 turbo beater
2 dough hooks
Check the delivery contents for completeness immediately after unpacking.
Remove all packaging materials and plastic film from the appliance.
TECHNICAL DETAILS
120VAC, 60Hz, 250W
NOTE:
This Hand Mixer has a polarized plug (one blade is wider than the other).To
reduce the risk of electric shock, this plug will fit in a polarized outlet only
one way. If the plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. Do not modify the plug in any
way. This product is designed for household use only.

3
1. Comfort designed handle
2. Easy-to-use speed control
3. Oversized beater ejector button
4. Turbo button
5. Non-tip heel rest
6. Swivel lock power cord
7. Air vents
8. Stainless Steel Turbo Beater accessory
9. Stainless Steel Dough hook accessory
KNOW YOUR HAND MIXER
Turbo Beater is used for cookie dough and cake batter.
Dough Hooksis used for yeast bread doughs.
12 34
5
6
7
89

4
INSTRUCTION FOR HAND MIXER
1) Make sure the Hand Mixer is unplugged
from the electrical outlet.
2) Paired accessories (beaters, optional
dough hooks) include one accessory with
a collar (D), and one without (C). Single
accessories come with a collar (D) (liquid
blending rod) or without (C) (whisk).
WARNING
Unplug mixer before touching beaters.
Failure to do so can result in broken bones, cuts or bruises.
IMPORTANT:
Be sure to read and follow the specific instructions in this manual for
proper use of the Hand Mixer.
1. Attaching the accessories
CD

5
A
B
3) Insert the accessory shaft with the
collar (D) into the larger opening (B)
of the hand mixer. Align the flanges
on the shaft with the slots in the
opening. Push to lock into place.
4) Insert the accessory without a collar (C)
into the smaller opening (A). Align and
push to lock into place.
D
B
NOTE:
An accessory shaft without a collar may be used in either opening (A or B).
Those with a collar may only be used in the larger opening (B).
1) If the Hand Mixer is running, stop the
Hand Mixer by sliding the Power switch
to “0”. Then unplug from the electrical
outlet.
2) Press the ejector button to release the
accessories from the Hand Mixer, then
remove them.
2. Removing the accessories

6
1) Make sure the Speed Control is in the
“0” position by sliding it towards the left
as far as possible. Then plug the Hand
Mixer into an electrical outlet.
2) Start mixing at the lowest speed by
sliding the Speed Control forward to the
first position mark, which is Speed 1.
3. Operating the speed control
This bonsenkitchen Hand Mixer will beat faster and more thoroughly than most other
electric hand mixers. Therefore, the beating time in most recipes must be adjusted to
avoid over beating. Beating time is faster due to larger beater sizes.To help determine the
ideal beating time, observe the batter or dough and beat only until it has the desired
appearance described in your recipe, such as “smooth and creamy”. To select the best
beating speeds, use the “Speed control guide” section.
3) To increase the Hand Mixer speed, slide
the Speed Control towards the right. To
decrease the Hand Mixer speed, slide
the Speed Control towards the left. See
“Speed control guide” section.
4) When finished, slide speed control to “0”.
Unplug the Hand Mixer before removing
the accessories.

7
SPEED CONTROL GUIDE
The 5-speed Hand Mixer should always be set on the lowest speed to start mixing. Move
to higher speeds as needed.
NOTE:
The Turbo Beater accessories are not designed for mixing and kneading
bread dough.
Speed
Attachment
Description
0
Turn off the Hand Mixer.
1
For slow stirring, combining, and starting
all mixing procedures.
2
Use this speed to stir in nuts, chocolate
chips, shredded cheese, onions, olives,
and other chunky ingredients. Mix flour
and other dry ingredients with liquids or
other moist mixtures. Helps avoid
ingredient splash out.
3
Combine heavy cream cheese mixtures.
Mash squash.
4
Combine heavy cream cheese mixtures.
Mash squash.Blend butter and sugar.
Mix muffins, quick breads, cake batters,
and frostings.
5
Beat egg whites and meringue mixtures.
Whip heavy cream and mousse
mixtures.

8
CLEANING AND MAINTENANCE
1. Cleaning the Hand Mixer body
WARNING:
Electrical Shock Hazard Do not put in water. Doing so can result in death
or electrical shock.
NOTE:
Do not immerse Hand Mixer in water.
1) Always unplug Hand Mixer before
cleaning. Wipe power cord and cord
strap with damp cloth. Dry with a soft
cloth.
2) Wipe Hand Mixer with a damp cloth. Dry
with a soft cloth.
2. Cleaning the accessories
Always remove beaters from Hand Mixer before cleaning. Wash in dishwasher, or by hand
in warm, soapy water. Rinse and wipe dry.

9
WARRANTY CLAIM PROCEDURE
To ensure quick processing of your case, please observe the following instructions: Please
have the till receipt and the item number (S/N: 12345) available as proof of purchase.
You will find the item number as a sticker on the rear or bottom of the appliance. If
malfunctions or other defects occur, please contact our customer service listed either by
telephone or by email.
If you request any further assistance, please contact us:
Customer service: [email protected]
1-888-965-8032
This product must not be disposed together with the domestic waste. This product has to
be disposed at an authorized place for recycling of electrical and electronic appliances. By
collecting and recycling waste, you help save natural resources, and make sure the product
is disposed in an environmental friendly and health way.
ENVIRONMENT FRIENDLY DISPOL
TROUBLESHOOTING
If Hand Mixer malfunctions or fails to operate, first try the solutions suggested here and
possibly avoid the cost of service.
1. Is the Hand Mixer plugged in?
2. Is the fuse in the circuit to the Hand Mixer in working order? If you have a circuit
breaker box, make sure the circuit is closed.
3. Try unplugging the Hand Mixer, then plug it back in.
If the problem cannot be fixed with the steps provided in this section, then contact
bonsenkitchen.com or an Authorized Service Center.
See the “Warranty and service” section for additional details. Do not return the Hand
Mixer to the retailer – they do not provide service.

10
Register your product at www.bonsenkitchen.com
to get more perks!
: 5805C Peachtree Corners East
Norcross, GA, 30092
: [email protected]
Follow us @bonsenkitchen
Bonsen Electronics Inc.
: 1-888-965-8032
