boplan FLEX IMPACT FLIP 120M Assembly instructions

INSTALLATION SHEET
For more information, please visit www.boplan.com
Rev: 24 March 2022 4:22 pm
PL1200-....-....
FLIP 120M
For more information, please visit www.boplan.com
Rev: 24 March 2022 4:22 pm
31
64
2
5
Mark locationRemove liner of CID
Move
Assemble and put the product in place
according to the desired layout
Stick the CID in place on all the posts
against the wall marked in red
Mark holes
Required Tools
Included Optional
Ø 12mm
Ø 10mm
Chalk
line
ø12.5
x100
M12
x100
Washer
(⌀44x4mm)
Flex
Cap CID
Optional CID
Impact Wrench
>500 Nm
+ extension part
+ socket sw15

For more information, please visit www.boplan.com
Rev: 24 March 2022 4:22 pm
14
13
12
15Install second post
fold the CID down and place inside the prole
Continue building one post at a time
until fully assembled
Install rst end post. Torque = 80 Nm Assemble rail and second post
65
6
65
6
7 8
910 11
Drill holes (⌀10x95mm)
At the locations of both end posts (only), mark the holes that will
hold the reinforcing wedge anchors.
Drill holes for the reinforcing anchors (⌀12x90mm)
Insert the reinforcing wedge
anchors
Remove nuts and bolts from
wedge anchors
45
16 Attach ex caps to posts. Take notice of the wedge on the cap for the correct orientation.
1
1
2
2
3
Ø10
Ø12
95
90
Fold and hold CID
Slide rail over
Optional: CID
min.
25 mm
