bora M Pure User manual

EN
Operating and installation instructions M Pure
005311-10001

70 bora.com
Contents
1 General information 72
1.1 Validity of the operating and
installation instructions .....................72
1.2 Liability ...............................................72
1.3 Product conformity ............................72
1.4 Presentation of information...............72
1.4.1 Safety and warning instructions.......... 72
1.4.2 Figures ................................................ 73
2 Safety 74
2.1 Intended use....................................... 74
2.2 People with limited abilities...............74
2.3 General safety instructions................75
2.4 Safety information for installation..... 77
2.4.1 Safety instructions –
cooktop extractor installation ............. 78
2.4.2 Safety information for cooktop
installation .......................................... 79
2.5 Safety instructions – operation.........80
2.5.1 Safety instructions –
cooktop extractor operation ............... 81
2.5.2 Safety instructions –
cooktop operation............................... 82
2.6 Safety instructions –
cleaning and maintenance.................84
2.6.1 Safety instructions – cleaning and
maintenance of cooktop extractors .... 84
2.6.2 Safety instructions – cleaning and
maintenance of cooktops.................... 85
2.7 Safety instructions –
repairs, servicing and spare parts.....85
2.8 Safety instructions –
disassembly and disposal .................. 86
3 Technical data 87
3.1 M Pure................................................. 87
3.1.1 PURMA appliance dimensions............. 87
3.1.2 PURMU appliance dimensions ............ 88
4 Appliance description 89
4.1 Model description............................... 89
4.2 System description ...........................89
4.2.1 Structure............................................. 89
4.2.2 Operating panel................................... 89
4.2.3 Symbols .............................................. 90
4.2.4 7-segment display............................... 90
4.2.5 Lighting ............................................... 91
4.2.6 Sounds................................................ 91
4.3 How the cooktop extractor works.....91
4.4 How the induction cooktop works ....91
5 Functions and operation 93
5.1 General operating instructions..........93
5.2 Touch control......................................93
5.3 Function overview ..............................93
5.4 Operating the system.........................93
5.4.1 Switch on/off...................................... 93
5.4.2 Short-time timer.................................. 94
5.5 Cooktop extractor functions..............94
5.5.1 Setting the fan power levels................ 94
5.5.2 Fan power setting ............................... 94
5.5.3 Automatic extractor function .............. 94
5.5.4 Switching the fan off ........................... 95
5.5.5 Automatic after-run............................. 95
5.5.6 Filter service display ........................... 95
5.6 Cooktop functions ..............................95
5.6.1 Pan size recognition ............................ 95
5.6.2 Selecting a cooking zone .................... 95
5.6.3 Setting cooking zone power levels ...... 95
5.6.4 Cooking zone power setting................ 96
5.6.5 Automatic heat up function................. 96
5.6.6 Cooking zone timer ............................. 96
5.6.7 Pause function .................................... 97
5.6.8 Heat retention function ....................... 97
5.6.9 Bridging function................................. 97
5.6.10 Automatic bridging function................ 97
5.6.11 Switching off the cooking zone ........... 98
5.7 Safety features ...................................98
5.7.1 Child lock ............................................ 98
5.7.2 Operating lock..................................... 98
5.7.3 Cleaning lock ...................................... 98
5.7.4 Residual heat indicator........................ 98
5.7.5 Safety shut-down ................................ 98
5.7.6 Overheating protection ....................... 99
6 User menu 100
6.1 Menu item 1:
volume of the acoustic signals ........100
6.2 Menu item 2: Child lock ...................100
6.3 Menu item 3: Show filter status
and reset filter service display.........101
6.4 Menu item 4: Duration of the
automatic after-run function............101
6.5 Menu item 5:
Touch zone reaction speed ..............101
6.6 Menu item 6: LED test......................102
6.7 Menu item 7:
Permanent pan size recognition ......102
6.8 Menu item 8:
Show software/hardware version...102
6.9 Menu item 9: Safety shut-down.......102
6.10 Menu item A: Super simple mode....103
6.11 Menu item 0:
Reset to factory settings..................103

bora.com 71
7 Cleaning and maintenance 104
7.1 Cleaning agents................................104
7.2 Cooktop and extractor care.............104
7.3 Cleaning the cooktop .......................104
7.4 Cleaning the cooktop extractor.......105
7.4.1 Cleaning the air inlet nozzle and
stainless steel grease filter ............... 105
7.4.2 Removing liquids from the appliance 105
7.5 Cleaning the air guiding housing .....106
7.6 Replace the activated
charcoal filter ...................................106
8 Troubleshooting 109
9 Installation 110
9.1 General installation instructions .....110
9.1.1 Simultaneous operation of the
cooktop extractor in the exhaust air
mode with a fireplace dependent
upon the air supply in the room ........ 110
9.2 Scope of delivery..............................111
9.3 Tools and aids...................................111
9.4 Assembly instructions......................111
9.4.1 Installation clearances ...................... 111
9.4.2 Minimum unit dimensions ................. 111
9.4.3 Information on kitchen units ............. 111
9.5 Worktop cut-out ...............................112
9.5.1 Cut-out dimensions........................... 112
9.6 Installing the appliance in
exhaust air mode..............................112
9.6.1 Preparing kitchen units for the
exhaust air model.............................. 113
9.6.2 Installation dimensions ..................... 113
9.6.3 Preparing the appliance .................... 113
9.6.4 Inserting the cooktop........................ 114
9.6.5 Securing the cooktop........................ 114
9.6.6 Connecting the appliance to the
duct system ...................................... 114
9.7 Installing the appliance in
recirculation mode ...........................115
9.7.1 Recirculation of air from the
kitchen unit....................................... 115
9.7.2 Installation variants (A and B) for
recirculation appliances .................... 115
9.7.3 Preparing the kitchen unit for
installation variant A ........................ 116
9.7.4 Installation dimensions for
installation variant A ......................... 116
9.7.5 Preparing the kitchen unit for
installation variant B ......................... 116
9.7.6 Installation dimensions for
installation variant B ......................... 117
9.7.7 Preparing the appliance .................... 117
9.7.8 Extending the telescopic pull-out of
the air purification box ...................... 117
9.7.9 Inserting the cooktop – recirculation 118
9.7.10 Securing the cooktop........................ 119
9.7.11 Making a connection with the
back panel in installation variant A.... 119
9.7.12 Inserting the activated charcoal filter 119
9.8 Connecting the power supply ..........120
9.9 Initial operation ................................121
9.9.1 Dealer and service menu................... 121
9.9.2 Menu item B: Extraction system
configuration..................................... 122
9.9.3 Menu item C: Power management .... 122
9.9.4 Menu item D: Demo mode ................ 122
9.9.5 Function test..................................... 123
9.10 Sealing the appliance .......................123
9.11 Handover to user..............................123
10 Decommissioning,
disassembly and disposal 124
10.1 Decommissioning .............................124
10.2 Disassembly......................................124
10.3 Environmentally-friendly disposal ...124
10.3.1 Disposal of transport packaging........ 124
10.3.2 Disposal of accessories..................... 124
10.3.3 Disposal of the old appliance ............ 124
11 Warranty, technical service,
spare parts, accessories 125
11.1 BORA manufacturer’s warranty .......125
11.1.1 Warranty extension ........................... 125
11.2 Service ..............................................125
11.3 Spare parts .......................................126
11.4 Accessories.......................................126
12 Product data sheets 127
12.1 PURMA - Cooktop extractor product
data sheet .........................................127
12.2 M Pure - Cooktop product data
sheet .................................................128

General information
EN
72 bora.com
1 General information
These instructions contain important information to
protect you from injury and prevent damage to the
appliance. Please read these instructions carefully
before installing or using the appliance for the first time.
Other documents apply alongside these instructions.
Please by all means adhere to all documents that form
part of the scope of delivery.
Assembly, installation and commissioning must always
occur in line with national laws, regulations and
standards. The work must be performed by qualified
specialists who know and comply with the additional
regulations of the local energy supply companies.
All safety and warning information as well as the
handling instructions in the accompanying documents
must be observed.
Please keep these instructions in a safe place and pass
them on to the next owner where applicable.
1.1
Validity of the operating and
installation instructions
These instructions apply to several appliance versions.
It is therefore possible that some of the features
described do not apply to your appliance. The details of
the figures contained herein may differ from some
appliance versions and are to be understood as
schematic diagrams.
1.2
Liability
. BORA Holding GmbH, BORA Vertriebs GmbH & Co KG,
BORA APAC Pty Ltd and BORA Lüftungstechnik GmbH –
hereinafter referred to as BORA – do not assume any
liability for damage arising from disregard for or non-
adherence to the documents included in the scope of
delivery!
Furthermore, BORA shall not be held liable for damage
caused by improper installation or failure to observe the
safety and warning information!
1.3
Product conformity
Directives
The appliances meet the following EU/EC directives:
T 2014/30/EU EMC Directive
T 2014/35/EU Low Voltage Directive
T 2009/125/EC Ecodesign Directive
T 2011/65/EU RoHS Directive
1.4
Presentation of
information
We use standard formatting, numbering, symbols, safety
instructions, terms and abbreviations so that you can
work quickly and safely when using this manual. The
article described in these instructions is hereinafter also
referred to as an appliance.
Instructions are indicated with an arrow.
u Always follow all instructions in the prescribed order.
Enumerations are indicated with a bullet point at the
start of the line:
T Enumeration 1
T Enumeration 2
Information notes point to special features that
must be taken into account.
1.4.1
Safety and warning
instructions
The safety and warning instructions in this manual are
emphasised with symbols and signal words. Safety and
warning instructions are structured as follows:
öDANGER
Type and source of danger
Results of non-compliance
u Measures to minimise risk
Please note:
T warning symbols draw attention to a high risk of
injury.
T The signal word indicates the severity of that risk.

General information EN
bora.com 73
Warning
symbol
Signal
word
Risk
Danger Indicates an immediate,
hazardous situation which
causes death or serious injury
if not respected.
Warning Indicates a potentially
hazardous situation which can
cause death or serious injury if
not respected.
Caution Indicates a potentially
hazardous situation which can
cause death or serious injury if
not respected.
Note Indicates a potentially
hazardous situation which can
cause property damage if not
respected.
Tab.1.1 Meaning of the warning symbols and signal
words
1.4.2
Figures
All measurements are provided in millimetres.

Safety
EN
74 bora.com
2 Safety
The appliance complies with the stipulated safety requirements. The user is responsible for the safe use of the
appliance, cleaning and maintenance. Improper use can lead to personal injury and damage to property.
2.1
Intended use
The appliance is solely intended for preparing food in private households.
This appliance is not intended for:
T outdoor use
T heating rooms
T cooling, ventilating or dehumidifying rooms
T use in mobile installation sites such as motor vehicles, ships or aeroplanes
T use with an external timer or a separate remote control system
T use at altitudes of over 2000m (metres above sea level)
T use when not fully installed
Any other use or any use that goes beyond that which is described here is classed as unintended.
BORA does not assume any liability for damages caused by incorrect installation, improper use or incorrect
operation.
All misuse is prohibited!
2.2
People with limited abilities
Children
The appliance can be used by children aged 8 and over if they are supervised or have been instructed how to use the
appliance safely and understand the resultant risks. Children must not play with the appliance.
u Use the childproofing feature in order to prevent children from switching on the appliance or changing the settings
when they are unattended.
u Supervise children in the vicinity of the appliance.
u Do not store any items that could be of interest to children in storage spaces above or behind the appliance.
Otherwise, they will be tempted to climb onto the appliance.
Any work involving cleaning and maintenance must not be carried out by children unless they are
supervised at all times while doing so.
People with reduced physical, sensory or mental capacities
The appliance can be used by people with reduced physical, sensory or mental capacities or a lack of experience
and/or knowledge if they are supervised or have been instructed how to use the appliance safely and understand the
resultant risks. Operation can be restricted using the child lock.

Safety EN
bora.com 75
öDANGER
Risk of burns from hot cookware and food
Handles projecting over the edge of the worktop are asking to be grabbed.
u Keep children away from hot cooking zones or ensure they are supervised at all times.
u Do not turn pot and pan handles so they stick out beyond the work surface.
u Make sure that hot pots and pans cannot be pulled down.
u If necessary, use suitable stove guards or covers.
u Only use stove guards and covers that are approved by the appliance
manufacturer; otherwise, there is a risk of accidents.
u To choose a suitable stove guard, contact your specialist retailer or the
BORA Service Team.
2.3
General safety instructions
öDANGER
Packaging components are a choking hazard
Packaging components (e.g. film, polystyrene) can be life-threatening for children.
u Store all packaging components out of reach of children.
u Dispose of the packaging properly and immediately.
öDANGER
Risk of electric shock or injury from damaged surfaces
The underlying electronics can be exposed or damaged due to fissures, fractures
or cracks in appliance surfaces (e.g. damaged glass), particularly in the vicinity of
the operating unit. This can cause an electrical shock. Furthermore, a damaged
surface can cause injuries.
u Do not touch the damaged surface.
u If there are any cracks, fissures or fractures, switch the appliance off immediately.
u Securely disconnect the appliance from the mains using the circuit breaker,
fuses, automatic circuit breakers or contactor.
u Contact the BORA Service Team.
öWARNING
Risk of injury or damage due to incorrect components or unauthorised
modifications
Incorrect components can lead to personal injury or damage to the appliance.
Modifications, additions or alterations to the appliance can lead to safety risks.
u Only use original components.
u Do not make any modifications, additions or alterations to the appliance.

Safety
EN
76 bora.com
öWARNING
Risk of injury due to mechanical damage on the appliance
Mechanical damage (e.g. cracks, deformation, separation of adhesive seals,
etc.) to the appliance, as well as to cables and accessories can cause injuries.
u Do not operate the appliance.
u Do not try to repair or replace damaged components yourself.
u Contact the BORA Service Team.
CAUTION
Appliance components can cause injury if dropped
Appliance components can cause injury if you drop them.
u Place any appliance components that have been removed in a safe place
near the appliances.
u Ensure that no components removed from the appliances can fall on the floor.
CAUTION
Risk of injury from heavy lifting
If not handled correctly, carrying and installing appliances can cause injury to
the limbs or torso.
u If necessary, carry and install the appliance with another person.
u Use appropriate aids to prevent damage or injury.
CAUTION
Damage from improper use
The appliance surfaces must not be used as work or storage surfaces. This can
damage the appliances (particularly in the case of hard and sharp objects).
u Never use the appliances as work or storage surfaces.
u Keep hard or sharp objects away from the appliance surfaces.
PLEASE NOTE
Faults and errors
In the event of faults or incorrect use, error messages will be displayed.
u In the case of faults and errors, follow the instructions in the
“Troubleshooting” chapter.
u In the event of any faults or errors that are not mentioned, switch the
appliance off and contact BORA Service.

Safety EN
bora.com 77
PLEASE NOTE
Appliance damage caused by pets
Pets may damage the appliance or injure themselves.
u Keep pets away from the appliance.
2.4
Safety information for installation
öDANGER
Risk of injury from incorrect assembly
Failure to observe the installation instructions can lead to injury.
u The appliance must only be installed and assembled by trained specialists
who are familiar with and comply with the standard national regulations and
supplementary regulations of the local utility companies.
u The appliance may only be installed with the power disconnected.
u Work on electrical components must only be conducted by trained electrical
personnel.
u Conduct all work extremely attentively and conscientiously.
u Before handing the appliance or system over to the end user, ensure that it
has been correctly installed.
öDANGER
Risk of electric shock from damaged appliance
A damaged appliance can cause an electric shock.
u Check the appliance for visible damage prior to installation.
u Do not install or connect any damaged appliances.
u Do not operate any damaged appliances.
öDANGER
Risk of electric shock from incorrect stripping of cables
Incorrect stripping of the connection cable to external switching devices results
in a risk of electric shock.
u Ensure that the connection cable is secured with the strain relief clamp
within the control unit.
u Ensure that the stated stripping lengths are adhered to.

Safety
EN
78 bora.com
PLEASE NOTE
Appliance damage caused by incorrect wiring
The electrical safety of the appliance is only guaranteed if it is connected to a
protective conductor system that has been installed in line with regulations.
u Work on electrical components must only be conducted by trained electrical
personnel.
u Ensure that this basic safety precaution is met. The appliance must be
suitable for the regional voltage and frequency.
u Check the information on the identification plate and in the event of
deviations, do not connect the appliance.
u Do not connect the appliance to the mains until the duct system has been
installed or the recirculation filter has been fitted.
u Only use the connection cables supplied.
PLEASE NOTE
Appliance damage caused by incorrect installation clearances
Failure to adhere to installation clearances can lead to damage to the appliance
and kitchen units, as well as restricted functions.
u During installation maintain the minimum clearance stated in the Installation
chapter.
2.4.1
Safety instructions – cooktop extractor installation
öDANGER
Risk of smoke inhalation
When the cooktop extractor is used in exhaust air mode, it draws in air from
the room it is installed in and from neighbouring rooms. Without sufficient air,
there will be a drop in air pressure. When used at the same time as a fireplace
that is dependent on the air in the room, noxious gases can be sucked into the
living areas from the chimney or outlet shaft.
u Make sure that there is always a sufficient air supply.
u Only use reliable, tried-and-tested switching devices, (e.g. window contact
switch, low pressure warning device) and have them approved by a qualified
expert (certified chimney sweep).

Safety EN
bora.com 79
öWARNING
Risk of injury due to turning fan wheel
There is a risk of injury while the fan is turning.
u Only install the device with the power disconnected.
u Connect both sides of the fan to the duct system before commissioning.
CAUTION
Risk of injury due to turning fan wheel
There is a risk of the vicinity of the fan being reached in the case of short air
channels.
u Never reach through the air outlet into the vicinity of the fan.
u Always install fans so that it is not possible to touch them via the air outlet.
u In the case of air channels shorter than 900 mm between the fan and air
outlet, install a guard to prevent access.
u Activated charcoal filters do not provide sufficient protection.
2.4.2
Safety information for cooktop installation
öDANGER
Risk of electric shock from damaged power supply cable
If the power supply cable is damaged (e.g. during installation or by coming into
contact with hot cooking surfaces), this can cause an (lethal) electric shock.
u Make sure that the connection cable does not become trapped or damaged.
u Make sure that the power supply cable does not come into contact with hot
cooking surfaces.
öDANGER
Risk of electric shock from incorrect mains connection
Connecting the appliance to the mains incorrectly poses a risk of electric
shock.
u Make sure that the appliance has a fixed connection to the mains voltage.
u Make sure that the appliance is connected to a properly installed protective
conductor system.
u Make sure that technical equipment is provided to enable all of the
appliance’s poles to be disconnected from the mains with a contact opening
width of at least 3mm (circuit breaker and automatic circuit breakers, fuses,
contactor).

Safety
EN
80 bora.com
2.5 Safety instructions – operation
öDANGER
Risk of fire from overheated oil or fat
Oil or fat in the pot can quickly heat up and ignite.
u Never leave the appliance unattended when cooking with oil or fat.
u Never extinguish oil and fat fires with water.
u Switch off the appliance.
u Extinguish the fire using a pan lid or a fire blanket, for example.
öWARNING
Risk of burning from hot appliances
Certain appliances and their exposed parts become hot during use. They
should be left to cool down completely after switching off. Touching hot
surfaces can cause serious burns.
u Do not touch hot appliances.
u Pay attention to the residual heat indicator.
öWARNING
Risk of burns due to power cut
During or after a power cut a cooktop that was previously in operation may still
be hot.
u Do not touch the appliance while it is still hot.
u Keep children away from the hot appliance.
öWARNING
Risk of burning and fire from hot objects
The appliance and its exposed parts are hot during operation and the cooling
phase. Objects in contact with hot appliance components heat up very quickly
and can cause severe burns (this particularly applies to metal objects such as
knives, forks, spoons, lids or appliance components) or catch fire.
u Do not place any items on the appliance.
u Please use suitable accessories (pot holders, oven gloves).
u Do not simply rely on the pan size recognition function on induction
cooktops; always switch the appliance off after use.

Safety EN
bora.com 81
CAUTION
Damage caused by hot cookware
Hot cookware can damage certain components in the appliance.
u Do not put hot cookware down in the area of the operating panel or cooktop
display.
u Keep hot cookware away from the air inlet nozzle.
PLEASE NOTE
Appliance damage
Incorrect use may cause damage to the appliance.
u Make sure that the base of the cookware as well as the appliance surfaces
are clean and dry.
u Always lift (do not drag) cookware to prevent scratching and abrasion on the
appliance surface.
u Do not use the appliance as a storage surface.
u Always switch off the appliance after use.
2.5.1
Safety instructions – cooktop extractor operation
öDANGER
Risk of smoke inhalation
When the cooktop extractor is used in exhaust air mode, it draws in air from
the room it is installed in and from neighbouring rooms. Without sufficient air,
there will be a drop in air pressure. When used at the same time as a fireplace
that is dependent on the air in the room, noxious gases can be sucked into the
living areas from the chimney or outlet shaft.
u Make sure that there is always a sufficient air supply.
u Only use reliable, tried-and-tested switching devices, (e.g. window contact
switch, low pressure warning device) and have them approved by a qualified
expert (certified chimney sweep).
öWARNING
Fire risk from flambéing
While the cooktop extractor is working, it sucks up grease from cooking.
Flambéing food can cause the grease to catch fire.
u Clean the cooktop extractor regularly.
u Never work with a naked flame while the cooktop extractor is running.

Safety
EN
82 bora.com
CAUTION
Damage caused by objects or paper suctioned in
Small and light items, such as cleaning cloths made from material or paper, can
be suctioned into the cooktop extractor. This can damage the fan or impair the
exhaust performance.
u Do not store any items or paper on the cooktop extractor.
u Only operate the integrated cooktop extractor with the grease filter fitted.
CAUTION
Damage caused by grease and dirt deposits
Grease and dirt deposits can prevent the cooktop extractor from functioning
properly.
u Never use the cooktop extractor without a correctly fitted stainless steel
grease filter.
PLEASE NOTE
Increased humidity
When cooking, additional moisture is released into the ambient air. In
recirculation mode, only a slight amount of moisture is removed from the
cooking vapour.
u When using the recirculation mode, ensure a sufficient supply of fresh air,
e.g. by opening a window.
u Ensure a normal and comfortable room climate (humidity of 45 – 60%), e.g.
by opening natural ventilation openings or using domestic ventilation
systems.
2.5.2
Safety instructions – cooktop operation
öDANGER
Danger of fire caused by leaving the cooktop unattended
Oil or fat in the pot can quickly heat up and ignite.
u Never leave oil or fat to heat up unattended.
u Never extinguish oil and fat fires with water.
u Switch off the cooktop.
u Extinguish the fire using a pan lid or a fire blanket, for example.

Safety EN
bora.com 83
öDANGER
Danger of explosion caused by flammable liquids
Flammable liquids in the vicinity of a cooktop can explode and cause serious
injury.
u Do not spray aerosols near the appliance when it is in use.
u Do not place any flammable liquids in the vicinity of a cooktop.
öWARNING
Risk of burns from hot liquids boiling over
Unattended pans can boil over allowing hot liquids to escape.
u Keep an eye on pans when cooking.
u Avoid over-cooking.
u Always switch off the appliance after use.
öWARNING
Risk of burns from hot steam
Liquid between the cooking zone and cookware base can evaporate and cause
burns.
u Make sure that the cooking zone and the cookware base are always dry.
PLEASE NOTE
Damage caused by sugary and salty foods
Sugary and salty foods and juices can damage the hot cooking zone.
u Make sure sugary and salty foods or juices do not get onto the cooking zone
while it is hot.
u Remove sugary and salty foods and juices from the hot cooking zone
immediately.
CAUTION
Electromagnetic radiation
Effect on pace makers, hearing aids and metal implants. Induction cooktops
generate a high-frequency electromagnetic field in the area of the cooking
zones. The cooking zones may affect pacemakers, hearing aids or metal
implants negatively or disturb their function when in close proximity.
u If in doubt, contact the manufacturer of your medical device or your doctor.

Safety
EN
84 bora.com
2.6 Safety instructions – cleaning and maintenance
PLEASE NOTE
Appliance damage due to soiled appliances
Dirt can lead to damage, restriction of functions, or bothersome odours.
u Clean the appliance regularly.
u Remove dirt immediately.
u When cleaning, only use non-abrasive detergents to prevent scratching and
abrasion on the surface.
u When cleaning, ensure that no water penetrates the appliance. Use only a
slightly damp cloth. Never spray the appliance with water. Water penetration
can cause damage.
u Do not use a steam cleaner for cleaning. Steam can cause a short circuit on
live parts and thus lead to property damage.
u Please follow all instructions in the “Cleaning and Maintenance” chapter.
2.6.1
Safety instructions – cleaning and maintenance of cooktop extractors
öDANGER
Risk of fire from fat deposits
The risk of fire can be increased by failure to clean the grease filter properly
and on a regular basis, or if the filter change is overdue.
u Clean and replace the filter at regular intervals.
öWARNING
Risk of injury when opening the bottom housing cover
There is a risk of injury while the fan is turning.
u Switch off the appliance and disconnect it from the mains before removing
covers in the vicinity of the fan.
öWARNING
Risk of injury due to turning fan wheel
If the fan wheel is turning during a filter change, this may result in injuries.
u Ensure that the appliance is switched off before changing the activated
charcoal filter.

Safety EN
bora.com 85
PLEASE NOTE
Appliance damage and malfunctions
Soiled ventilation openings can lead to component damage and malfunctions.
u Keep all ventilation openings open and clean.
2.6.2
Safety instructions – cleaning and maintenance of cooktops
öWARNING
Risk of burns from hot surfaces
There is a risk of burns when cleaning hot cooktops.
u Only clean the cooktops once they have cooled.
u Pay attention to the residual heat indicator.
2.7
Safety instructions – repairs, servicing and spare parts
öDANGER
Risk of injury when carrying out repairs
Insufficient expertise can lead to injury when carrying out repairs.
u The appliance must only be repaired and serviced by trained specialists who
are familiar with and comply with the standard national regulations and
supplementary regulations of the local utility companies.
u Safely disconnect the appliance from the mains supply.
u Work on electrical components must only be conducted by trained electrical
personnel.
u A damaged power supply cable must be replaced by a suitable power supply
cable.
öWARNING
Risk of injury or damage from improper repairs
Incorrect components can lead to personal injury or damage to the appliance.
Modifications, additions or alterations to the appliance can lead to safety risks.
u Only use original spare parts for repairs.
u Do not make any modifications, additions or alterations to the appliance.

Safety
EN
86 bora.com
2.8 Safety instructions – disassembly and disposal
öDANGER
Risk of injury during disassembly
Insufficient expertise can lead to injury when disassembling the appliance.
u It must only be disassembled by trained specialists who are familiar with and
comply with the standard national regulations and supplementary
regulations of the local utility companies.
u Safely disconnect the appliance from the mains supply.
u Work on electrical components must only be conducted by trained electrical
personnel.
öDANGER
Risk of electric shock from incorrect disconnection
Incorrectly disconnecting the appliance from the mains results in a risk of
electric shock.
u Safely disconnect the appliance from the mains supply.
u Use an authorised measuring device to ensure that there is no power to the
appliance.
u Do not touch exposed contacts on the electronic unit as they may contain
residual charge.
öDANGER
Risk of electric shock from residual charge
Electrical components in the appliance can contain residual charge and cause
an electric shock.
u Do not touch any exposed contacts.

Technical data EN
bora.com 87
3 Technical data
3.1 M Pure
Parameter Value
Multiphase supply voltage 380–415 V 2N/3N
Single-phase supply voltage 220–240V
Frequency 50–60 Hz
Maximum power consumption 7600W
(4400W/3600W)
Three-phase power supply/
fuse protection
3 x 16 A
Two-phase power supply/
fuse protection
2 x 16A
Single-phase power supply/
fuse protection
1 x 32 A
(1 x 20 A /1 x 16 A)
Dimensions
(width x depth x height)
760 x 515 x 199 mm
Weight
(incl. accessories/packaging)
21.8 kg (PURMA)
23.6 kg (PURMU)
Cooktop
Surface material Glass ceramic
Cooktop power levels 1–9, P
Front left cooking zone size Ø 210 mm
Front left cooking zone output 2300 W
Front left cooking zone
power setting output
3000 W
Rear left cooking zone size Ø 175 mm
Rear left cooking zone output 1400 W
Rear left cooking zone
power setting output
2100 W
Front right cooking zone size 230 x 230 mm
Front right cooking zone output 2100 W
Front right cooking zone
power setting output
3000 W
Rear right cooking zone size 230 x 230 mm
Rear right cooking zone output 2100 W
Rear right cooking zone
power setting output
3000 W
Exhaust air system
Cooktop extractor power levels 1–9, P
Exhaust air connection BORA Ecotube
Recirculation system
Parameter Value
Cooktop extractor power levels 1–9, P
Size of exhaust opening (W x H) 445 x 137 mm
Activated charcoal filter service life 150 hrs (1 year)
Tab.3.1 Technical data for M Pure
3.1.1
PURMA appliance dimensions
Fig.3.1 PURMA appliance dimensions top view
Fig.3.2 PURMA appliance dimensions front view
Fig.3.3 PURMA appliance dimensions side view

Technical data
EN
88 bora.com
3.1.2 PURMU appliance
dimensions
Fig.3.4 PURMU appliance dimensions top view
Fig.3.5 PURMU appliance dimensions front view
Fig.3.6 PURMU appliance dimensions side view
