bora Professional PKA3 User manual

EN
P3XUMEN-100
www.bora.com
Operating instructions BORA Professional 3.0 system
Cooktop extractor and cooktops
1044130 - 48

EN
2
www.bora.com
5 Overview of features and functions 20
6 Functions and operation 21
6.1 Knob operation....................................................................21
– Operating the knob ring .................................................... 21
– Operating the touch surface ............................................. 21
6.2 Switching the system on and off ......................................21
– Switching on ..................................................................... 21
– Switching off ..................................................................... 21
6.3 Operating the cooktop extractor.......................................22
6.3.1 General operating instructions for the cooktop extractor ....22
6.3.2 Setting the fan power level..................................................22
6.3.3 Extractor power setting .......................................................22
6.3.4 Automatic after-run..............................................................22
6.4 Cooktop extractor function menu.....................................22
– Calling up the function menu ............................................ 23
6.4.1 Automatic extractor function...............................................23
– Activating the automatic extractor function ...................... 23
– Deactivating the automatic extractor function .................. 23
6.4.2 Short-time timer/egg timer (system function) ...................23
– Activating the short-time timer (egg timer)........................ 24
– Setting the time and starting the short-time timer
(egg timer)......................................................................... 24
– Time lapsed....................................................................... 24
– Switching off the short-time timer (egg timer) early.......... 24
6.4.3 Childproofing feature (system function)..............................24
– Permanently activating the childproofing feature .............. 24
– Deactivating the childproofing feature
for a cooking session ........................................................ 25
– Permanently deactivating the childproofing feature .......... 25
6.4.4 Cooktop extractor cleaning function ..................................25
– Activating the cooktop extractor cleaning function........... 25
– Closing the cover flap to start a cooking session.............. 25
– Deactivating the cooktop extractor cleaning function....... 25
6.4.5 Filter service life and filter service display
(only in recirculation mode).................................................25
– Displaying the remaining filter service life......................... 26
– Resetting the filter service life early .................................. 26
– Deactivating the filter service display
for a cooking session ........................................................ 26
– Resetting the filter service display..................................... 26
6.5 Operating the cooktops......................................................26
6.5.1 General operating instructions for cooktops ......................26
6.5.2 Special operating instructions for the
Tepan stainless steel grill PKT3...........................................27
6.5.3 Setting cooking zone power levels......................................27
– Increasing the power level................................................. 27
– Reducing the power level .................................................. 27
– Setting the temperature on the
Tepan stainless steel grill PKT3 ......................................... 27
6.5.4 Cooktop power setting ........................................................27
6.5.5 Bridging function (only on PKFI3 and PKT3) .......................28
– Activating the bridging function......................................... 28
– Deactivating the bridging function..................................... 28
6.5.6 Pause function (system function)........................................28
6.5.7 Pan size recognition (only on PKFI3, PKI3, PKIW3) ............29
6.6 Function menu ....................................................................29
– Calling up the function menu ............................................ 29
1 General information 4
1.1 Liability................................................................................... 4
1.2 Validity of the operating and installation instructions...... 4
1.3 Product conformity............................................................... 4
1.4 Data protection .....................................................................4
1.5 Presentation of information................................................. 4
2 Safety 5
2.1 Use as intended .................................................................... 5
2.2 People with limited abilities.................................................5
2.3 General safety instructions..................................................5
2.4 Safety instructions – operation........................................... 6
2.5 Safety instructions – cleaning and maintenance.............. 8
2.6 Safety instructions – repairs, servicing and spare parts ... 9
3 Energy labelling 10
4 Appliance description 11
4.1 Model description ...............................................................11
– BORA Professional 3.0 cooktop extractors ....................... 11
– BORA Professional 3.0 cooktops ...................................... 11
4.2 Control knob........................................................................11
– How it works ..................................................................... 11
– Structure........................................................................... 11
– Operating elements........................................................... 11
– Control knob display ......................................................... 11
– Control knob assignment.................................................. 12
4.3 Cooktop extractor appliance description.........................12
– Installation variations......................................................... 12
– Cooktop extractor display and symbols ............................ 12
4.3.1 Structure of the cooktop extractors....................................12
– Cooktop extractor PKA3/PKA3AB.................................... 12
– Cooktop extractor system PKAS3/PKAS3AB ................... 13
– Grease filter components.................................................. 13
4.3.2 Sensors ................................................................................13
4.3.3 Interface for external devices..............................................13
4.3.4 USB port for servicing .........................................................13
4.4 Cooktop appliance description..........................................14
– Display and symbols.......................................................... 14
– Layout and size of the cooking zones ............................... 14
4.4.1 How induction cooktops work (PKFI3, PKI3, PKIW3) .........16
– Power levels ...................................................................... 16
– Suitable cookware............................................................. 16
– Noises............................................................................... 17
4.4.2 How the Hyper and HiLight cooktops work
(PKC3, PKCB3, PKCH3)........................................................17
– Power levels ...................................................................... 17
– Suitable cookware............................................................. 17
4.4.3 How the Tepan stainless steel grill PKT3 works .................17
– Power adjustment and temperature ranges ...................... 17
4.5 Safety devices .....................................................................18
– Anti-trap protection .......................................................... 18
– Safety shut-down .............................................................. 18
– Residual heat indicator...................................................... 19
– Overheating protection...................................................... 19
– Childproofing feature......................................................... 19
Table of Contents

EN
3
www.bora.com
8 Cleaning and maintenance 37
8.1 Cleaning agents...................................................................37
– Cleaning products for glass ceramic cooktops ................. 37
– Cleaning products for the Tepan stainless steel grill ......... 37
8.2 Cleaning the cooktop extractor.........................................37
– Cover flap cleaning position.............................................. 37
– Removing the cover flap, grease filter and filter tray ......... 37
– Fitting the cover flap, grease filter and filter tray............... 38
– Removing the maintenance tray........................................ 38
– Installing the maintenance tray ......................................... 38
– Cleaning the components ................................................. 39
– Ending the cooktop extractor cleaning process ................ 39
8.2.1 Replacing the recirculated air filter .....................................39
8.3 Cleaning the cooktops........................................................39
8.3.1 Cleaning glass ceramic cooktops........................................39
8.3.2 Cleaning Tepan stainless steel grill surfaces ......................39
8.4 Looking after your cooktops..............................................40
8.5 Cleaning the control knobs................................................40
– Cleaning the knob ring...................................................... 40
– Cleaning the touch surface and the knob housing............ 40
9 Troubleshooting 41
9.1 Cooktop extractor troubleshooting...................................41
9.2 Cooktop troubleshooting ...................................................42
10 Warranty, technical service,
spare parts, accessories 43
10.1 BORA manufacturer’s warranty.........................................43
10.1.1 Warranty extension..............................................................43
10.2 Service .................................................................................43
10.3 Spare parts ..........................................................................43
10.4 Accessories..........................................................................44
11 Notes 45
6.6.1 Additionalringswitching–2-ring,3-ring,roaster
(only on PKC3, PKCB3, PKCH3)...........................................29
– Activating additional rings
(2-ring/3-ring additional switching)................................... 29
– Deactivating additional rings ............................................. 30
6.6.2 Variable heat retention function (not on PKT3) ..................30
– Activating the heat retention function ............................... 30
– Increasing or reducing the active heat retention level....... 30
– Deactivating the heat retention function........................... 30
6.6.3 Timer function/automatic cut-off (not on PKT3)................31
– Activating cooking zone timers ......................................... 31
– Setting the time and starting the timer ............................. 31
– Changing active timers...................................................... 31
– Switching the timer off early ............................................. 31
– Time lapsed....................................................................... 31
6.6.4 Automatic heat up function (not on PKT3) .........................32
– Activating the automatic heat up function......................... 32
– Deactivating the automatic heat up function early............ 32
– Time lapsed....................................................................... 32
6.6.5 Cleaning function (only on PKT3) ........................................33
– Activating the cleaning function........................................ 33
– Deactivating the cleaning function.................................... 33
7 Configuration menu 34
– Menu overview.................................................................. 34
7.1 How to use the menu .........................................................34
– Calling up the menu.......................................................... 34
– Selecting and confirming menu items............................... 34
– Making, confirming and saving settings............................ 34
– Closing the menu.............................................................. 34
7.2 Initial operation ...................................................................34
7.2.1 Basic configuration ..............................................................34
– Menu item C3: exhaust air or recirculation mode
(incl. filter unit selection)................................................... 34
– Menu item C4: operation with or without a wall sleeve
(only in exhaust air mode)................................................. 35
– Menu item CA: number of fans installed........................... 35
7.3 Description of the other menu items................................35
– Menu item C0: volume of the acoustic signals ................. 35
– Menu item C1: demo mode.............................................. 35
– Menu item C2: speed of the cover flap motors................. 35
– Menu item C5: manual operation of the
cover flap motors .............................................................. 35
– Menu item C6: switching fan PWM values........................ 35
– Menu item C7: installation of left cooktop 0°/180°........ 35
– Menu item C8: installation of right cooktop 0°/180°...... 35
– Menu item C9: pause function activated/deactivated...... 36
– Menu item Cb: software update........................................ 36
– Menu item Cc: data export ............................................... 36
– Menu item Cd: software version indicator ........................ 36

EN
4
General information
www.bora.com
1 General information
Data can only be read out manually via your cooktop extractor.
This decision is therefore your responsibility.
These saved data then enable a rapid error search and
troubleshooting in the event of servicing.
1.5 Presentation of information
We use standard formatting, numbering, symbols, safety
instructions, terms and abbreviations so that you can work
quickly and safely when using this manual.
The term “appliance” is used to refer to cooktops, cooktop
extractors or cooktops with integrated cooktop extractor.
Instructions are indicated with an arrow.
XXAlways follow all instructions in the prescribed order.
Enumerations are indicated with a bullet point at the start of
the line:
XO Enumeration 1
XO Enumeration 2
i Information notes point to special features that must be
taken into account.
Safety and warning instructions
The safety and warning instructions in this manual are
emphasised with symbols and signal words.
Safety and warning instructions are structured as follows:
ÿ
WARNING SYMBOL AND SIGNAL WORD!
Type and source of danger
Results of non-compliance
XX Measures to minimise risk
Please note:
XO warning symbols draw attention to a high risk of injury.
XO The signal word indicates the severity of that risk.
Warning
symbol
Signal word Risk
üDanger Indicates an immediate, hazardous
situation which causes death or
serious injury if not respected.
üWarning Indicates a potentially hazardous
situation which can cause death or
serious injury if not respected.
Caution Indicates a potentially hazardous
situation which can cause minor
injury or damage to property if not
respected.
Tab. 1.1 Meaning of the warning symbols and signal words
These instructions contain important information to protect you
from injury and prevent damage to the appliance.
Please read these instructions carefully before installing or using
the appliance for the first time.
Other documents apply alongside these instructions.
Please by all means adhere to all documents that form part of
the scope of delivery.
Assembly and installation may only be carried out by trained
specialists and taking into account the applicable laws,
regulations and standards. All safety and warning information
as well as the handling instructions in the accompanying
documents must be observed.
1.1 Liability
BORA Holding GmbH, BORA Vertriebs GmbH & Co KG, BORA
APAC Pty Ltd and BORA Lüftungstechnik GmbH – hereinafter
referred to as BORA – does not assume any liability for damage
arising from disregard for or non-adherence to the documents
included in the scope of delivery!
Furthermore, BORA shall not be held liable for damage caused
by improper installation or failure to observe the safety and
warning instructions!
1.2 Validity of the operating and
installation instructions
These instructions apply to several appliance versions. It is
therefore possible that some of the features described do not
apply to your appliance. The details of the figures contained
herein may differ from some appliance versions and are to be
understood as schematic diagrams.
1.3 Product conformity
Directives
The appliances meet the following EU/EC directives:
2014/30/EU EMC Directive
2014/35/EU Low Voltage Directive
2009/125/EC Ecodesign Directive
2011/65/EU RoHS Directive
1.4 Data protection
During operation your cooktop extractor saves pseudonymised
data such as menu settings entered by you, operating hours
of the individual technical units and the number of functions
selected. Furthermore, your cooktop extractor documents errors
in combination with the number of operating hours.

EN
5
Safety
www.bora.com
2 Safety
People with reduced physical, sensory or
mental capacities
The appliance can be used by people with reduced
physical, sensory or mental capacities or a lack of
experience and/or knowledge if they are supervised
or have been instructed how to use the appliance
safely and understand the resultant risks. Operation
can be restricted using the childproofing feature.
ÿDANGER!
Risk of burns from hot cookware and food
Handles projecting over the edge of the worktop
are asking to be grabbed.
XX Keep children away from hot cooking zones or
ensure they are supervised at all times.
XX Do not turn pot and pan handles so they stick
out beyond the worktop.
XX Make sure that hot pots and pans cannot be
pulled down.
XX If necessary, use suitable stove guards or
covers.
XX Only use stove guards and covers that are
approved by the appliance manufacturer;
otherwise, there is a risk of accidents.
XX To choose a suitable stove guard, contact your
specialist supplier or the BORA Service Team.
2.3 General safety instructions
ÿDANGER!
Packaging components are a choking hazard
Packagingcomponents(e.g.lm,polystyrene)can
be life-threatening for children.
XX Store all packaging components out of reach of
children.
XX Dispose of the packaging properly and
immediately.
The appliance complies with the stipulated safety
requirements. The user is responsible for the safe
use of the appliance, cleaning and maintenance.
Improper use can lead to personal injury and damage
to property.
2.1 Use as intended
The appliance is solely intended for preparing food in
private households.
This appliance is not intended for:
XO
outdoor use
XO
heating rooms
XO
cooling, ventilating or dehumidifying rooms
XO
use in mobile installation sites such as motor
vehicles, ships or aeroplanes
XO
use with an external timer or a separate remote
control system (except for emergency shutdown)
XO
use at altitudes of over 2,000 m (metres above sea
level).
Any other use or any use that goes beyond that which
is described here is classed as unintended.
i BORA does not assume any liability for
damages caused by improper use or incorrect
operation.
All misuse is prohibited!
2.2 People with limited abilities
Children
The appliance can be used by children aged 8 and
over if they are supervised or have been instructed
how to use the appliance safely and understand
the resultant risks. Children must not play with the
appliance.
XX Use the childproofing feature in order to prevent
children from switching on the appliance or
changing the settings when they are unattended.
XX Supervise children in the vicinity of the appliance.
XX Do not store any items that could be of interest to
children in storage spaces above or behind the
appliance. Otherwise, they will be tempted to
climb onto the appliance.
i Any work involving cleaning and maintenance
must not be carried out by children unless they
are supervised at all times while doing so.

EN
6
Safety
www.bora.com
CAUTION!
Risk of injury from heavy lifting
If not handled correctly, carrying and installing
appliances can cause injury to the limbs or torso.
XX If necessary, carry and install the appliance with
another person.
XX Use appropriate aids to prevent damage or
injury.
CAUTION!
Damage from improper use
The appliance surfaces must not be used as
work or storage surfaces. This can damage the
appliances (particularly in the case of hard and
sharp objects).
XX Never use the appliances as work or storage
surfaces.
XX Keep hard or sharp objects away from the
appliance surfaces.
Faults and errors
XX In the case of faults and errors, follow the
instructions in the “Troubleshooting” chapter.
XX In the event of any faults or errors that are not
mentioned, switch the appliance off and contact
BORA Service.
Pets
XX Keep pets away from the appliance.
2.4 Safety instructions – operation
XX Make sure that the base of the cookware as well
as the appliance surfaces are clean and dry.
XX Always lift (do not drag) cookware to prevent
scratching and abrasion on the appliance surface.
XX Do not use the appliance as a storage surface.
XX Switch off the appliance after use.
ÿWARNING!
Risk of burning from hot appliances
Certain appliances and their exposed parts become
hot during use (e.g. cooktops). They should be
left to cool down completely after switching off.
Touching hot surfaces can cause serious burns.
XX Do not touch hot appliances.
XX Pay attention to the residual heat indicator.
ÿDANGER!
Risk of electric shock or injury from damaged
surfaces
The underlying electronics can be exposed or
damagedduetossures,fracturesorcracksin
appliance surfaces (e.g. damaged glass ceramic),
particularly in the operating area. This can cause
an electric shock. Furthermore, a damaged surface
can cause injuries.
XX Do not touch the damaged surface.
XX If there are any cracks, fissures or fractures,
switch the appliance off immediately.
XX Safely disconnect the appliance from the mains
using the LS switch, fuses, automatic circuit
breakers or contactor.
XX Contact BORA Service.
ÿWARNING!
Risk of injury from damaged components
Damaged components that cannot be removed
without tools can cause injuries.
XX Try not to repair or replace damaged
components yourself.
XX Contact BORA Service.
ÿWARNING!
Risk of injury or damage due to incorrect
components or unauthorised modifications
Incorrect components can lead to personal
injuryordamagetotheappliance.Modications,
additions or alterations to the appliance can lead to
safety risks.
XX Only use original components.
XX Do not make any modifications, additions or
alterations to the appliance.
CAUTION!
Appliance components can cause injury if
dropped
Appliance components (e.g. pan supports,
operatingcontrols,covers,greaselters,etc.)can
cause injury if dropped.
XX Place any appliance components that have been
removed in a safe place near the appliances.
XX Ensure that no components removed from the
appliances can fall on the floor.

EN
7
Safety
www.bora.com
CAUTION!
Damage caused by grease and dirt deposits
Grease and dirt deposits can prevent the cooktop
extractor from functioning properly.
XX Never use the cooktop extractor without a
correctly fitted stainless steel grease filter.
Special safety instructions for using the
exhaust air mode
ÿDANGER!
Risk of smoke inhalation
When the cooktop extractor is used in exhaust
air mode, it draws in air from the room it is
installed in and from neighbouring rooms. If there
isinsu󹩴cientairsupply,lowpressurewilloccur.
Whenusedatthesametimeasareplacethat
is dependent on the air in the room, noxious
gases can be sucked into the living areas from the
chimney or outlet shaft.
XX Make sure that there is always a sufficient air
supply.
XX Only use reliable, tried-and-tested switching
devices, (e.g. window contact switch, low
pressure warning device) and have them
approved by a qualified expert (certified chimney
sweep).
Special safety instructions for using the
recirculation mode
When cooking, additional moisture is released into
the ambient air. In recirculation mode, only a slight
amount of moisture is removed from the cooking
vapour.
XX When using the recirculation mode, ensure a
sufficient supply of fresh air, e.g. by opening a
window.
XX Ensure a normal and comfortable room climate
(humidity of 45–60%), e.g. by opening natural
ventilation openings or using domestic ventilation
systems.
XX After every use in recirculation mode, switch the
cooktop extractor to a low power level for about
20 minutes or activate the automatic after-run
function.
ÿWARNING!
Risk of burning and fire from hot objects
The appliance and its exposed parts are hot during
operation and the cooling phase. Objects placed on
the appliance heat up very quickly and can cause
severe burns (this particularly applies to metal
objects such as knives, forks, spoons,
lids or cooktop extractor covers).
XX Do not place any items on the appliance.
XX Please use suitable accessories (pot holders,
oven gloves).
CAUTION!
Damage caused by hot cookware
Hot cookware can damage certain components in
the appliance.
XX Do not put hot cookware down in the area of the
cooktop display.
XX Keep hot cookware away from the air inlet
nozzle.
2.4.1 Safety instructions – cooktop
extractor operation
ÿWARNING!
Fire risk from flambéing
While the cooktop extractor is working, it sucks up
grease from cooking. Flambéing food can cause
thegreasetocatchre.
XX Clean the cooktop extractor regularly.
XX Never work with a naked flame while the
cooktop extractor is running.
CAUTION!
Risk of injury from moving cover flap
There is a risk of injury when the electrical cover
apismoving.
XX Do not put your hands inside the cooktop
extractor while the cover flap is moving.
CAUTION!
Damage caused by objects or
paper suctioned in
Small and light items, such as cleaning cloths made
from material or paper, can be suctioned into the
cooktop extractor. This can damage the fan or
impair the exhaust performance.
XX Do not store any items or paper on the cooktop
extractor.
XX Only operate the integrated cooktop extractor
with the grease filter fitted.

EN
8
Safety
www.bora.com
CAUTION!
Damage caused by sugary and salty foods
Sugary and salty foods and juices can damage the
hot cooking zone.
XX Make sure sugary and salty foods or juices do
not get onto the cooking zone while it is hot.
XX Remove sugary and salty foods and juices from
the hot cooking zone immediately.
Special safety instructions for the operation of
induction cooktops
Effect on pace makers, hearing aids and metal
implants:
induction cooktops generate a high-frequency
electromagnetic field in the area of the cooking
zones. The cooking zones may affect pacemakers,
hearing aids or metal implants negatively or disturb
their function when in close proximity. A reduced
function of the pacemaker is unlikely.
XX If in doubt, contact the manufacturer of your
medical device, or your doctor.
2.5 Safety instructions – cleaning
and maintenance
The appliance must be cleaned at regular intervals.
Dirt can lead to damage, restriction of functions, or
bothersome odours. In the worst case scenario, this
can become a hazard.
XX Remove dirt immediately.
XX When cleaning, only use non-abrasive detergents
to prevent scratching and abrasion on the surface.
XX When cleaning, ensure that no water penetrates
the appliance. Use only a slightly damp cloth.
Never spray the device with water. Water
penetration can cause damage!
XX Do not use a steam cleaner for cleaning. Steam
can cause a short circuit on live parts and thus
lead to property damage.
XX Please follow all instructions in the “Cleaning and
Maintenance” chapter.
2.4.2 Safety instructions – cooktop
operation
XX Do not simply rely on the pan size recognition
function on induction cooktops; always switch the
appliance off after use.
ÿDANGER!
Danger of fire caused by leaving the cooktop
unattended
Oil or fat in the pot can quickly heat up and ignite.
XX Never leave oil or fat to heat up unattended.
XX Never extinguish oil and fat fires with water.
XX Switch off the cooktop.
XX Extinguish the fire using a pan lid or a fire
blanket, for example.
ÿDANGER!
Danger of explosion caused by flammable
liquids
Flammable liquids in the vicinity of a cooktop can
explode and cause serious injury.
XX Do not spray aerosols near the appliance when
it is in use.
XX Do not place any flammable liquids in the
vicinity of a cooktop.
ÿWARNING!
Risk of burns from hot liquids boiling over
Unattended pans can boil over allowing hot liquids
to escape.
XX Keep an eye on pans when cooking.
XX Try not to let them boil over.
ÿWARNING!
Risk of burns from hot steam
Liquid between the cooking zone and the pan base
can evaporate and cause burns.
XX Make sure that the cooking zone and the pan
base are always dry.
ÿWARNING!
Risk of burns due to power cut
During or after a power cut, a cooktop that was
previously in operation may still be hot even though
there is no indication of residual heat.
XX Do not touch the cooktop while it is still hot.
XX Keep children away from the hot cooktop.

EN
9
Safety
www.bora.com
Special safety instructions for cooktop
extractor cleaning and maintenance
XX Keep the ventilation openings in the unit below
open and clean.
ÿWARNING!
Risk of fire from fat deposits
Theriskofrecanbeincreasedbyfailuretoclean
thegreaselterproperlyandonaregularbasis,or
ifthelterchangeisoverdue.
XX Clean and replace the filter at regular intervals.
Special safety instructions for cooktop cleaning
and maintenance
XX Whenever possible, clean the cooktops after every
use.
XX Only clean the cooktops when they have cooled
down.
XX Use the cleaning function to clean the Tepan
stainless steel grill.
2.6 Safety instructions – repairs,
servicing and spare parts
i The appliance must only be repaired and
serviced by trained specialists who are familiar
with and comply with the standard national
regulations and supplementary regulations of
the local utility companies.
i Work on electrical components must only be
conducted by trained electrical personnel.
XX Before any repair work, safely disconnect the
appliance from the mains supply.
ÿWARNING!
Risk of injury or damage from improper repairs
Incorrect components can lead to personal
injuryordamagetotheappliance.Modications,
additions or alterations to the appliance can lead to
safety risks.
XX Only use original spare parts for repairs.
XX Do not make any modifications, additions or
alterations to the appliance.
i A damaged power supply cable must be
replaced by a suitable power supply cable. This
may only be done by an authorised member of
the After Sales Service team.

EN
10
Energy labelling
www.bora.com
3 Energy labelling
Product information according to delegated regulation (EU) no. 65/2014 and regulation (EU) no. 66/2014.
PKA3ELDEN-005
EN
www.bora.com
Energy labelling PKA3/PKA3AB
Product information according to delegated regulation (EU) no. 65/2014 and regulation (EU) no. 66/2014.
Manufacturer
Model identification
BORA
PKA3/PKA3AB
Symbol
Value Unit
Energy consumption
Annual energy consumption AEChood
26,3 kWh/a
Energy efficiency class –
A++ –
Energy efficiency index EEIhood
35,2 –
Flow volume
Fluid dynamic efficiency FDEhood
36,9 –
Fluid dynamic efficiency class –
A –
Minimum air flow in normal use –
269 m³/h
Maximum air flow in normal use –
598 m³/h
Maximum air flow on intensive or boost setting (power
setting)
Qmax
613 m³/h
Measured air flow rate at best efficiency point QBEP
283,7 m³/h
Measured air pressure at best efficiency point PBEP
507,3 Pa
Measured electric power input at best efficiency point WBEP
108,3 W
Time increase factor f
0,7 –
Lighting
Lighting efficiency LEhood
* lx/W
Lighting efficiency class –
* –
Nominal power of the lighting system WL
* W
Average illumination of the lighting system on the
cooking surface
Emiddle
* lx
Grease filtering
Grease filtering efficiency GFEhood
83,7 %
Grease filtering efficiency class –
C –
Noise
Airborne acoustical A-weighted sound power emissions
at minimum speed available in normal use
–
47 dB(A) re_1pW
Airborne acoustical A-weighted sound power emissions
at maximum speed available in normal use
–
65 dB(A) re_1pW
Airborne acoustical A-weighted sound power emissions
on intensive or boost setting (power setting)
–
65 dB(A) re_1pW
Sound pressure level at minimum speed available in
normal use**
–
33 LpA in dB re 20 µPa
Sound pressure level at maximum speed available in
normal use**
–
52 LpA in dB re 20 µPa
Sound pressure level on intensive or boost setting
(power setting)**
–
52 LpA in dB re 20 µPa
Power consumption
Power consumption in off mode Po
0,18 W
Power consumption in standby mode Ps
* W
Energy labelling
* Not applicable to this product.
** Voluntary information
The sound pressure level has been determined from a distance of 1 m (distance-dependent level recording)
on the basis of the sound power level established in EN 60704-2-13.
PKA3ELDEN-005
EN
www.bora.com
Energy labelling PKA3/PKA3AB
Product information according to delegated regulation (EU) no. 65/2014 and regulation (EU) no. 66/2014.
Manufacturer
Model identification
BORA
PKA3/PKA3AB
Symbol Value
Unit
Energy consumption
Annual energy consumption AEChood 26,3
kWh/a
Energy efficiency class – A++
–
Energy efficiency index EEIhood 35,2
–
Flow volume
Fluid dynamic efficiency FDEhood 36,9
–
Fluid dynamic efficiency class – A
–
Minimum air flow in normal use – 269
m³/h
Maximum air flow in normal use – 598
m³/h
Maximum air flow on intensive or boost setting (power
setting)
Qmax 613
m³/h
Measured air flow rate at best efficiency point QBEP 283,7
m³/h
Measured air pressure at best efficiency point PBEP 507,3
Pa
Measured electric power input at best efficiency point WBEP 108,3
W
Time increase factor f 0,7
–
Lighting
Lighting efficiency LEhood *
lx/W
Lighting efficiency class – *
–
Nominal power of the lighting system WL*
W
Average illumination of the lighting system on the
cooking surface
Emiddle *
lx
Grease filtering
Grease filtering efficiency GFEhood 83,7
%
Grease filtering efficiency class – C
–
Noise
Airborne acoustical A-weighted sound power emissions
at minimum speed available in normal use
– 47
dB(A) re_1pW
Airborne acoustical A-weighted sound power emissions
at maximum speed available in normal use
– 65
dB(A) re_1pW
Airborne acoustical A-weighted sound power emissions
on intensive or boost setting (power setting)
– 65
dB(A) re_1pW
Sound pressure level at minimum speed available in
normal use**
– 33
LpA in dB re 20 µPa
Sound pressure level at maximum speed available in
normal use**
– 52
LpA in dB re 20 µPa
Sound pressure level on intensive or boost setting
(power setting)**
– 52
LpA in dB re 20 µPa
Power consumption
Power consumption in off mode Po0,18
W
Power consumption in standby mode Ps*
W
Energy labelling
* Not applicable to this product.
** Voluntary information
The sound pressure level has been determined from a distance of 1 m (distance-dependent level recording)
on the basis of the sound power level established in EN 60704-2-13.
PKA3ELDEN-005
EN
www.bora.com
Energy labelling PKA3/PKA3AB
Product information according to delegated regulation (EU) no. 65/2014 and regulation (EU) no. 66/2014.
Manufacturer
Model identification
BORA
PKA3/PKA3AB
Symbol
Value
Unit
Energy consumption
Annual energy consumption AEChood
26,3
kWh/a
Energy efficiency class –
A++
–
Energy efficiency index EEIhood
35,2
–
Flow volume
Fluid dynamic efficiency FDEhood
36,9
–
Fluid dynamic efficiency class –
A
–
Minimum air flow in normal use –
269
m³/h
Maximum air flow in normal use –
598
m³/h
Maximum air flow on intensive or boost setting (power
setting)
Qmax
613
m³/h
Measured air flow rate at best efficiency point QBEP
283,7
m³/h
Measured air pressure at best efficiency point PBEP
507,3
Pa
Measured electric power input at best efficiency point WBEP
108,3
W
Time increase factor f
0,7
–
Lighting
Lighting efficiency LEhood
*
lx/W
Lighting efficiency class –
*
–
Nominal power of the lighting system WL
*
W
Average illumination of the lighting system on the
cooking surface
Emiddle
*
lx
Grease filtering
Grease filtering efficiency GFEhood
83,7
%
Grease filtering efficiency class –
C
–
Noise
Airborne acoustical A-weighted sound power emissions
at minimum speed available in normal use
–
47
dB(A) re_1pW
Airborne acoustical A-weighted sound power emissions
at maximum speed available in normal use
–
65
dB(A) re_1pW
Airborne acoustical A-weighted sound power emissions
on intensive or boost setting (power setting)
–
65
dB(A) re_1pW
Sound pressure level at minimum speed available in
normal use**
–
33
LpA in dB re 20 µPa
Sound pressure level at maximum speed available in
normal use**
–
52
LpA in dB re 20 µPa
Sound pressure level on intensive or boost setting
(power setting)**
–
52
LpA in dB re 20 µPa
Power consumption
Power consumption in off mode Po
0,18
W
Power consumption in standby mode Ps
*
W
Energy labelling
* Not applicable to this product.
** Voluntary information
The sound pressure level has been determined from a distance of 1 m (distance-dependent level recording)
on the basis of the sound power level established in EN 60704-2-13.
PKAS3ELDEN-005
EN
www.bora.com
Energy labelling PKAS3/PKAS3AB
Product information according to delegated regulation (EU) no. 65/2014 and regulation (EU) no. 66/2014.
Manufacturer
Model identification
BORA
PKAS3/PKAS3AB
Symbol
Value
Unit
Energy consumption
Annual energy consumption AEChood
28,0
kWh/a
Energy efficiency class –
A+
–
Energy efficiency index EEIhood
39,8
–
Flow volume
Fluid dynamic efficiency FDEhood
34,3
–
Fluid dynamic efficiency class –
A
–
Minimum air flow in normal use –
221
m³/h
Maximum air flow in normal use –
558
m³/h
Maximum air flow on intensive or boost setting (power
setting)
Qmax
670
m³/h
Measured air flow rate at best efficiency point QBEP
296,7
m³/h
Measured air pressure at best efficiency point PBEP
417,0
Pa
Measured electric power input at best efficiency point WBEP
100
W
Time increase factor f
0,8
–
Lighting
Lighting efficiency LEhood
*
lx/W
Lighting efficiency class –
*
–
Nominal power of the lighting system WL
*
W
Average illumination of the lighting system on the
cooking surface
Emiddle
*
lx
Grease filtering
Grease filtering efficiency GFEhood
74,7
%
Grease filtering efficiency class –
D
–
Noise
Airborne acoustical A-weighted sound power emissions
at minimum speed available in normal use
–
46
dB(A) re_1pW
Airborne acoustical A-weighted sound power emissions
at maximum speed available in normal use
–
67
dB(A) re_1pW
Airborne acoustical A-weighted sound power emissions
on intensive or boost setting (power setting)
–
70
dB(A) re_1pW
Sound pressure level at minimum speed available in
normal use**
–
34
LpA in dB re 20 µPa
Sound pressure level at maximum speed available in
normal use**
–
55
LpA in dB re 20 µPa
Sound pressure level on intensive or boost setting
(power setting)**
–
58
LpA in dB re 20 µPa
Power consumption
Power consumption in off mode Po
0,18
W
Power consumption in standby mode Ps
*
W
Energy labelling
* Not applicable to this product.
** Voluntary information
The sound pressure level has been determined from a distance of 1 m (distance-dependent level recording)
on the basis of the sound power level established in EN 60704-2-13.
Tab. 3.1 Energy labelling
* Not applicable to this product.
** Voluntary information
The sound pressure level has been determined from a distance of 1 m (distance-dependent level recording)
on the basis of the sound power level established in EN 60704-2-13.

EN
11
Appliance description
www.bora.com
4 Appliance description
i How it works and its functions are described in more
detail in the Operation chapter.
Structure
4
3
5
2
1
Fig. 4.1 Control knob structure
[1] Knob housing
[2] Universal nut
[3] Control knob display
[4] Knob ring
[5] Wave spring
Operating elements
2
1
Fig. 4.2 Control knob operating elements
[1] Knob ring
[2] Touch surface
Control knob display
3
1
2
4
Fig. 4.3 Control knob display elements
[1] Timer/egg timer indicator
[2] Rear cooking zone indicator
[3] Multi-function display
[4] Front cooking zone indicator
XXObserve all safety and warning information during operation
(see the Safety chapter).
4.1 Model description
BORA Professional 3.0 cooktop extractors
The cooktop extractors PKA3/PKA3AB and PKAS3/PKAS3AB
are the central components of the whole system and can be
combined with all BORA Professional 3.0 cooktops.
i Up to 2 cooktops can be connected to each cooktop
extractor.
Model Long name and description
PKA3 BORA Pro cooktop extractor (flexible system with
separate control unit)
PKA3AB BORA Pro cooktop extractor All Black (flexible
system with separate control unit)
PKAS3 BORA Pro cooktop extractor system with
integrated fan (compact system with integrated
control unit and integrated fan)
PKAS3AB BORA Pro cooktop extractor system with
integrated fan All Black (compact system with
integrated control unit and integrated fan)
Tab. 4.1 Cooktop extractor model description
BORA Professional 3.0 cooktops
The cooktops PKFI3, PKI3, PKIW3, PKC3, PKCB3, PKCH3,
PKT3 and PKG3 are the modular components of the BORA
Professional 3.0 system.
Model Long name and description
PKFI3 BORA Pro surface induction cooktop
PKI3 BORA Pro induction cooktop
PKIW3 BORA Pro induction wok cooktop
PKC3 BORA Pro HiLight cooktop 3-ring/2-ring
PKCB3 BORA Pro HiLight cooktop 3-ring/roaster
PKCH3 BORA Pro Hyper cooktop 1-ring/2-ring
PKT3 BORA Pro Tepan stainless steel grill with
2 cooking zones
PKG3 BORA Pro gas cooktop
Tab. 4.2 Cooktop model description
i The gas cooktop PKG3 contains separate operating and
installation instructions and is not described in any more
detail here.
4.2 Control knob
How it works
The cooktop extractor and cooktops are operated with a control
knob. The power levels and functions are controlled by turning
the knob ring and pressing the touch surface.

EN
12
Appliance description
www.bora.com
i If the cooktop extractor is used in a recirculating air
system, when a power level is set the operating time
is automatically deducted from the recirculation filter
service life. The remaining filter service life can be seen
in the menu under menu item A (see Operation chapter).
Cooktop extractor display and symbols
i The fan power levels, extractor functions and system
functions are shown in the cooktop extractor control
knob display.
Control knob display Meaning
0
Appliance is switched off
1 – 9
Power levels
P
Power setting
A
Automatic extractor function
t
Short-time timer (egg timer)
001 – 120
Time display
L
Childproofing feature
1 1
pulsating Pause function
F
Filter service display
F flashing Filter service display
n
Automatic after-run
c
Cover flap cleaning position
E ... Error message (see the Troubleshooting
chapter)
C
Configuration menu
Tab. 4.3 Cooktop extractor 7-segment display
4.3.1 Structure of the cooktop extractors
Cooktop extractor PKA3/PKA3AB
7
6
5
4
3
2
1
Fig. 4.5 Cooktop extractor PKA3/PKA3AB
[1] Cover frame
[2] Holding plate
[3] Curved duct piece
[4] Straight duct piece
[5] Universal control unit
[6] Control knob
[7] Cover flap
Control knob assignment
54321
Fig. 4.4 Control knob assignment
[1] Control knob for left cooktop, front cooking zone
[2] Control knob for left cooktop, rear cooking zone
[3] Control knob for cooktop extractor
[4] Control knob for right cooktop, front cooking zone
[5] Control knob for right cooktop, rear cooking zone
4.3 Cooktop extractor appliance
description
Installation variations
Depending on what you opted for when purchasing, the cooktop
extractor can be operated as an exhaust air or recirculation
model.
Exhaust air mode
The air suctioned away is purified by the grease filter and
expelled into the open air via a duct system.
The exhaust air must not be expelled into:
XO a smoke or exhaust gas flue that is in operation
XO a shaft used for the aeration of rooms where fireplaces are
installed.
If the exhaust air is to be directed into a smoke or exhaust gas
flue that is not in use, the installation must be checked and
approved by the responsible heating engineer.
i If the cooktop extractor is used in an exhaust air system,
the extractor power is automatically increased for the
first 20 seconds when set on a lower power level (wall
sleeve function).
Recirculation mode
The air suctioned away is purified by the grease filter and an
activated charcoal filter and fed back into the room in which the
appliance is installed.
To prevent odours in recirculation mode, an odour filter must be
used. For hygiene and health reasons, this must be replaced at
the recommended intervals (see the Cleaning and maintenance
chapter).
i In recirculation mode, ensure sufficient ventilation and
aeration to expel humidity.

EN
13
Appliance description
www.bora.com
4.3.2 Sensors
The cooktop extractor is equipped with sensors in the area of
the cover flap and the grease filter.
Cover flap position sensor
The cover flap sensor detects the position of the cover flap.
XO If the cover flap is closed, the cooktop extractor is
deactivated.
XO If the cover flap is open, the cooktop extractor can be used.
XO If the cover flap has been removed, the cooktop extractor can
be used.
Grease filter position sensor
The grease filter sensor detects whether the grease filter has
been fitted correctly. If the grease filter is missing or has been
fitted incorrectly, the cooktop extractor is deactivated.
i If the grease filter is removed, for example, for cleaning,
the cover flap can still be closed.
4.3.3 Interface for external devices
The internal interface can be used for extended control options.
This has a Home In and a Home Out contact (see the Installation
chapter).
XO The Home In contact can be used for the signal input from
external switch devices (e.g. window contact switch).
XO The Home Out contact can be used to control external
installations (e.g. electrically opening wall sleeves).
4.3.4 USB port for servicing
The system has a USB port for servicing. This port is only
suitable for mass storage devices (USB sticks). These USB sticks
must be formatted with the FAT32 data system.
i The USB port is only designed for updates or data export
and only has sufficient power supply for these processes.
It is not possible to charge devices or carry out other
functions.
Cooktop extractor system PKAS3/PKAS3AB
6
5
4
3
2
1
Fig. 4.6 Cooktop extractor system PKAS3/PKAS3AB
[1] Cover frame
[2] Holding plate
[3] Control unit
[4] Fan housing with fan
[5] Control knob
[6] Cover flap
Grease filter components
4
3
2
1
Fig. 4.7 Grease lter components
[1] Cover flap
[2] Stainless steel grease filter
[3] Filter tray
[4] Maintenance tray

EN
14
Appliance description
www.bora.com
Layout and size of the cooking zones
Cooktop PKFI3
1
4
3
2
230
230230
Fig. 4.8 Layout of cooktop PKFI3 and size of the cooking
zones
[1] Front surface induction cooking zone
[2] Rear surface induction cooking zone
[3] Rear cooking zone display
[4] Front cooking zone display
Cooktop PKI3
1
4
3
2
230
165
Fig. 4.9 Layout of cooktop PKI3 and cooking zone dimensions
[1] Front induction cooking zone
[2] Rear induction cooking zone
[3] Rear cooking zone display
[4] Front cooking zone display
4.4 Cooktop appliance description
Display and symbols
i The power levels and cooking functions of each cooking
zone are shown in the control knob display on the
corresponding control knob.
i The cooktops PKFI3 and PKI3 also have a 7-segment
cooktop display for each cooking zone. Power levels and
operating functions respectively are shown directly on
the cooktop.
Control knob display
Indicator Meaning
0
Cooktop is switched off
1
–
9
Power levels
ßp
Power setting
8
0
–
2
5
0
Temperature indicator on Tepan stainless steel
grill (PKT3)
H
Residual heat indicator
L
Childproofing feature
e.g.
1
+
2
1
+
2
Bridging function active
(only on PKFI3 and PKT3)
v
,
Pan size recognition
(only on PKFI3, PKI3, PKIW3)
e.g.
5
,
/
5
:
/
5
*
Rings active (only on PKC3, PKCB3, PKCH3)
,
v
/
:
v
/
*
v
Heat retention levels active
Timer function active
A
Automatic heat up function
e.g.
A
5
Automatic heat up function active
123
123
Cleaning function active (only on PKT3)
E
... Error message (see the Troubleshooting chapter)
Tab. 4.4 Cooktop control knob display
Cooktop display
(only on PKFI3 and PKI3)
Indicator Meaning
0
Cooktop is switched off
1
–
9
Power levels
ßp
Power setting
H
Residual heat indicator
L
Childproofing feature
1 1
Pause function
v
,
Pan size recognition
A
Automatic heat up function
,
/
:
/
*
Heat retention levels active
E
... Error message (see the Troubleshooting chapter)
Tab. 4.5 Cooktop display

EN
15
Appliance description
www.bora.com
Cooktop PKCB3
1
2
120
180
290
121
235
Fig. 4.12 Layout of cooktop PKCB3 and cooking zone
dimensions
[1] 3-ring front cooking zone
[2] 2-ring rear cooking zone
Cooktop PKCH3
1
2
200
235 120
Fig. 4.13 Layout of cooktop PKCH3 and cooking zone
dimensions
[1] 1-ring Hyper front cooking zone
[2] 2-ring rear cooking zone
Cooktop PKIW3
1
540
Fig. 4.10 Layout of cooktop PKIW3 and cooking zone
dimensions
[1] Induction cooking zone
Cooktop PKC3
1
2
120
180
120
200
235
Fig. 4.11 Layout of cooktop PKC3 and cooking zone dimensions
[1] 3-ring front cooking zone
[2] 2-ring rear cooking zone

EN
16
Appliance description
www.bora.com
Activity Power
level
Melting butter and chocolate, breaking up gelatine
1
Keeping sauces and soups warm, soaking rice
1
–
3
Cooking potatoes, pasta, soups and ragouts, steaming
fruit, vegetables and fish, defrosting food
2
–
6
Frying in coated pans, moderate frying (without
overheating the fat) of pork cutlets or fish
6
–
7
Heating up fat, browning fish, cooking thickened
sauces and soups, making omelettes
7
–
8
Bringing large amounts of liquid to the boil, searing
steaks
9
Heating up water
ßp
Tab. 4.6 Recommendations for power levels
The specifications provided in the table are standard values.
Depending on the cookware and filling quantity, it is
recommended to either decrease or increase the power level.
Suitable cookware
i The heating and heat-through times for the cookware
base, as well as the cooking results, are significantly
influenced by the structure and material of the cookware.
Cookware with this symbol is suitable for induction
cooktops. The cookware used for the induction cooktop
must be made of metal, feature magnetic properties and
possess an ample base.
Suitable cookware is made of:
XO stainless steel with a magnetisable base
XO enamelled steel
XO cast iron
Appliance Cooking zone Minimum diameter
PKFI3 front
rear
120mm
120mm
PKI3 front
rear
120mm
90mm
PKIW3 Wok 210mm
Tab. 4.7 Minimum cookware diameter
i The BORA induction wok pan HIW1 is ideal for the
induction wok cooktop PKIW3 and is available as an
accessory.
XXPerform a magnet test if necessary. If a magnet sticks to the
base of the utensils, they are normally induction compatible.
XXPay attention to the cookware base. The base of the
cookware should not show any sign of curvature (exception:
wok cooktop PKIW3). Due to incorrect hob temperature
monitoring, this curvature may cause the cookware to
overheat. To avoid scratching the cooktop, the base of the
cookware must not have any sharp grooves or sharp edges.
XXPlace the cookware (without a mat or similar) directly onto the
glass ceramic.
Tepan stainless steel grill PKT3
1
2
232,5232,5
465
295
Fig. 4.14 Layout of Tepan stainless steel grill PKT3 and cooking
zone dimensions
[1] Front grilling zone
[2] Rear grilling zone
4.4.1 How induction cooktops work
(PKFI3, PKI3, PKIW3)
An induction coil is located underneath an induction cooking
zone. If the cooking zone is switched on, this coil creates a
magnetic field that acts directly on the base of the pot thus
heating it up. The cooking zone is only indirectly heated up by
the heat emitted by the pot. Cooking zones with induction only
work if the cookware has a magnetisable base.
Induction automatically takes into account the size of the
cookware used which means that only the area in the cooking
zone covered by the base of the pot is heated up.
XXObserve the minimum pot base diameter (see table 4.7).
Power levels
The high power output of induction cooktops results in the very
quick heating up of cookware. In order to avoid burning food,
slight adjustment is needed in comparison to conventional cooking
systems when selecting the power level.

EN
17
Appliance description
www.bora.com
Suitable cookware
i The heating and heat-through times for the cookware
base, as well as the cooking results, are significantly
influenced by the structure and material of the cookware.
Cookware with this symbol is suitable for radiant heating
elements. The cookware used for radiant heating
surfaces must be metal and have good heat conducting
properties.
Suitable cookware is made of:
XO stainless steel, copper or aluminium
XO enamelled steel
XO cast iron
XXPay attention to the cookware base. The bottom of the
cookware should not show any sign of curvature. Due to
incorrect hob temperature monitoring, this curvature may
cause the cookware to overheat. To avoid scratching the
cooktop, the base of the cookware must not have any sharp
grooves or sharp edges.
XXPlace the cookware (without a mat or similar) directly onto the
glass ceramic.
4.4.3 How the Tepan stainless steel grill PKT3
works
Under each grilling zone there is a heating element. When a
grilling zone is switched on, the heating element generates heat
that directly heats the grill surface.
Power adjustment and temperature ranges
The power is adjusted via temperature ranges that are shown in
the operating panel display in °C (temperature indicator).
Temperature in °C Meaning
C
(= 70 °C) Cleaning temperature
8
0
–
2
3
0
Power levels (in 10°C increments)
2
4
0
–
2
5
0
Power setting
Tab. 4.9 Tepan stainless steel grill temperatures
The power output of the Tepan stainless steel grill heats food
extremely quickly. A slight adjustment is needed in comparison
to conventional cooking systems when selecting the temperature
in order to avoid burning food.
Noises
The following noises may occur in the cookware when using
induction cooking zones, depending on the material and the
finish of the base:
XO Humming may occur when using a high power level. This
decreases or disappears when the power level is decreased.
XO Crackling or whistling may occur due to cookware bases being
made of different materials (e.g. sandwich base).
XO Clicking sounds may occur during electronic switching
procedures, especially at low power levels.
XO Whirring may occur when the cooling fan is switched on. In
order to increase the service life of the electronic system,
the cooktop is equipped with a cooling fan. The cooling fan
switches on automatically if the cooktop is used intensively.
You will hear a whirring sound. The cooling fan may continue
running after the appliance has been switched off.
4.4.2 How the Hyper and HiLight cooktops
work (PKC3, PKCB3, PKCH3)
Under the cooking zone is a radiant heating element with a
heating tape. When the cooking zone is switched on, the heating
tape generates radiant heat, which radiates to the cooking zone
and heats it up.
Power levels
Activity Power level
Melting butter and chocolate, breaking up gelatine
1
Keeping sauces and soups warm, soaking rice
1
–
3
Cooking potatoes, pasta, soups and ragouts,
steaming fruit, vegetables and fish, defrosting food
2
–
6
Frying in coated pans, moderate frying (without
overheating the fat) of pork cutlets or fish
6
–
7
Heating up fat, browning fish, cooking thickened
sauces and soups, making omelettes
7
–
8
Cooking large amounts of liquids, grilling steaks
and heating water
9
Grilling steaks and heating up water
ßp
Tab. 4.8 Recommendations for power levels
The specifications provided in the table are standard values.
Depending on the cookware and filling quantity, it is
recommended to either decrease or increase the power level.
Power setting on cooktop PKCH3
The front cooking zone (Hyper zone) on the Hyper cooktop
PKCH3 is fitted with a temporary power setting.
XO
ßp
is shown in the control knob display.
The power setting can be used in order to quickly heat up large
quantities of water. If the power setting is activated, the cooking
zones will run at extra high power. After 10 minutes, the cooking
zone is automatically switched back to power level
9
.

EN
18
Appliance description
www.bora.com
PKC3, PKCB3, PKCH3:
Power levels Safety shut-down after hours:minutes
1
6:00
2
6:00
3
5:00
4
5:00
5
4:00
6
1:30
7
1:30
8
1:30
9
1:30
(only in the case of the Hyper zone on the PKCH3)
Tab. 4.12 Safety shut-down on the different power levels
PKT3:
Temperature Safety shut-down after hours:minutes
1
5
0
8:24
1
6
0
6:24
1
7
0
5:12
1
8
0
4:12
1
9
0
3:18
2
0
0
2:12
2
1
0
2:12
2
2
0
1:48
2
3
0
1:18
2
4
0
/
2
5
0
0:10
Tab. 4.13 Safety shut-down on the different power levels
Safety shut-down on the different heat retention levels
PKFI3, PKI3, PKIW3, , PKC3, PKCB3, PKCH3:
Heat retention level Switch off after hours:minutes
1 (
,
v
) 8:00
2 (
:
v
) 8:00
3 (
*
v
) 8:00
Tab. 4.14 Safety shut-down on the different heat retention levels
PKT3:
Heat retention temperature Switch off after hours:minutes
80–140°C 8:00
Tab. 4.15 Safety shut-down on the different heat retention levels
XXSwitch the cooking zone back on if you want to put the
cooking zone back into operation (see the Operation chapter).
Activity Temperature in °C
Steaming fruit, e.g. apple slices,
peach halves, banana slices
160 – 170
Browning chopped vegetables, fried eggs,
veal, poultry
180 – 190
Browning breaded or battered fish,
pancakes, sausages, pork, lamb
190 – 200
Browning potato fritters, prawns,
corn on the cob and escalopes
200 – 210
Fast browning beef, fish, meatballs 220 – 230
Browning steaks 240 – 250
Tab. 4.10 Temperature recommendations (the specications
provided in the table are standard values)
4.5 Safety devices
Anti-trap protection
The electrical cover flap on the cooktop extractor has anti-trap
protection.
If the cover flap is obstructed when opening or closing, it
automatically stops moving. The cover flap returns to its start
position (see the Operation chapter).
Safety shut-down
If an appliance is switched on but is not used for a predefined
time, it is automatically switched off.
Cooktop extractor
The cooktop extractor is automatically switched off after an
operating time of 120 minutes without any change to the power
level.
Cooktops
Each cooking zone is switched off automatically when the cooking
zone exceeds the maximum operating duration on one power level
or heat retention level.
H
is displayed (Residual heat indicator).
Safety shut-down on the different power levels
PKFI3, PKI3, PKIW3:
Power levels Safety shut-down after hours:minutes
1
8:24
2
6:24
3
5:12
4
4:12
5
3:18
6
2:12
7
2:12
8
1:48
9
1:18
ßp
0:10
Tab. 4.11 Safety shut-down on the different power levels

EN
19
Appliance description
www.bora.com
Residual heat indicator
i While
H
is displayed (residual heat indicator), do not
touch the cooking zone or place any heat-sensitive
objects on top of it. Risk of burns and fire!
After switching it off, the cooking zone remains hot.
H
is displayed (Residual heat indicator).
After a sufficient cooling period the indicator will go out
(Temperature < 60°C or < 50°C on the Tepan stainless steel
grill).
Overheating protection
i If the cooktop overheats, the power is reduced or the
cooktop is switched off completely.
The appliance is fitted with overheating protection. The
overheating protection can be triggered if:
XO cookware is heated up empty;
XO oil or fat is heated on high power;
XO a hot cooking zone is switched on again after a power cut.
Whilst the overheating protection is active, one of the following
steps is taken:
XO the activated power setting is switched back to the previous
level;
XO the power setting
ßp
can no longer be switched on;
XO the set power level is reduced;
XO the cooktop switches off completely.
After a sufficient cooling period, the cooktop can be used again.
Childproofing feature
The childproofing feature prevents the appliance from being
switched on accidentally.
XO
L
is displayed.
The childproofing feature can only be activated when all the
cooking zones are switched off (see the Operation chapter).
i If a single cooktop is operated without a cooktop
extractor, removal of the knob ring can prevent the
appliance from being switched on accidentally or without
permission.

EN
20
Overview of features and functions
www.bora.com
5 Overview of features and functions
i The full range of functions is only available for BORA Professional 3.0 system cooktops in combination with the cooktop
extractors PKA3 and PKAS3/PKAS3AB.
BORA Professional 3.0 system Cooktop extractors Cooktops
Appliance features PKA3 PKAS3 PKAS3AB PKFI3 PKI3 PKIW3 PKC3 PKCB3 PKCH3 PKT3
Electronic power adjustment 33 3333333
Power level display 33 3333333
Interface communication 3 3
Electrical cover flap with position sensor 3 3
Stainless steel grease filter 3 3
Grease filter position sensor 3 3
USB port for servicing 3 3
Pan size recognition 333
Cooktop display 3 3
Temperature display 3
System functions
Short-time timer (egg timer) 3 3
Pause function 33 3333333
Additional cooktop extractor functions
Extractor power setting 3 3
Automatic extractor function 3 3
Automatic after-run 3 3
Filter service display 3 3
Additional cooktop functions
Cooktop power setting 3 3 3 3*3
Timer function 3 3 3 3 3 3
Automatic heat up function 3 3 3 3 3 3
Variable heat retention function 3 3 3 3 3 3
Pan size recognition 3 3 3
Additional ring switching (2-ring additional
switching)
3** 3** 3**
Additional ring switching (3-ring additional
switching)
3*3*
Bridging function 3 3
Cleaning function 3
Safety features
Childproofing feature 33 3333333
Safety shut-down 33 3333333
Anti-trap protection 3 3
Active error monitoring 33 3333333
Residual heat indicator 3333333
Overheating protection 3333333
Tab. 5.1 Function overview
* only on the front cooking zone ** only on the rear cooking zone
i You can see a more detailed description of the functions in the next chapter Functions and operation.
