Video | DINION AN 5000
DINION AN 5000
www.boschsecurity.com
960H
uUltra high resolution 960H sensor
uHigh Dynamic Range to see bright and dark details
simultaneously
uDetail enhancement
uBilinx communication for remote set-up and control
uEasy to install
The DINION 5000 family combines high resolution with
high dynamic range in a true day/night analog camera.
The high performance 960H 1/3-inch CCD sensor with
a resolution of 720TVL, the high dynamic range engine,
and the advanced image processing technology
combine together to provide a detailed image with
outstanding accuracy in color reproduction even under
harsh lighting conditions. True day/night performance
ensures the highest image quality possible at any time,
day or night. The camera is easy to install and offers
the best solution for demanding scene conditions.
System overview
The camera is supplied ready to operate – simply
attach the separately available lens, connect video and
then power. Six distinct pre-programmed operational
modes are stored in the camera. Recall the mode that
suits your application for optimized performance. The
lens wizard ensures accurate back-focusing for
perfectly sharp pictures at all times. For especially
challenging situations where fine tuning or special
settings are required, the camera parameters can be
individually set using the control buttons on the side
of the camera and an Onscreen Display (OSD).
Functions
Detail in extreme lighting
In harsh lighting, the difference between the brightest
and the darkest parts of a scene can be extreme. To
produce a clear picture in these conditions, the CCD
sensor in the camera generates two images; one long
exposure to resolve details in the scene’s darkest
areas, and one short exposure to resolve details in the
scene’s brightest areas. The advanced image
processing technology in the camera combines these
dual shutter images, mixing pixels from each exposure
to produce the most detailed image possible. The
superior wide dynamic range for all lighting conditions
reveals details previously unseen.
Day/Night mode
The day/night mode provides enhanced night viewing
by increasing the IR sensitivity. The IR filter can switch
from color to monochrome automatically by either
sensing the illumination level or via the alarm input.
The filter can be switched manually via the alarm
input, through the camera menu or via the Bilinx
coaxial control interface. An internal through-the-lens
IR detector enhances the monochrome mode stability,
as it prevents reverting to the color mode when IR
illumination is dominant. IR contrast is also measured
and used to handle reflected IR light in outdoor
scenes.

Ease of installation
The lens wizard helps focus the lens at the maximum
opening to ensure proper back-focus is maintained
throughout the 24-hour cycle. No special tools or
filters are required.
Six independent, pre-programmed operating modes
support typical applications, but are fully
programmable for individual situations. Switching
between modes is easy via Bilinx or the external alarm
input.
Several other features are available that make
installation easy:
• Power and alarm cable connectors which can be
removed even when the camera is mounted.
• A built-in test pattern generator produces signals to
test and fault-find cables.
• A multi-language On-Screen Display (OSD).
• A high efficiency power supply improves maximum
operating temperature
Cable compensation is used to avoid the need for
amplifiers in long distance coaxial connections up to
1000 m (3000 ft). It can prevent the image quality
degradation caused by signal losses from long cable
lengths.
Bilinx technology
Bilinx is a bidirectional communication capability
embedded in the video signal of this camera. Installers
can check status, change camera settings and even
update firmware from virtually anywhere along the
video cable. Bilinx reduces service and installation
time, provides for more accurate set-up and
adjustment, and improves overall performance. In
addition, Bilinx uses the standard video cable to
transmit alarm and status messages, providing
superior performance without additional installation
steps.
Ideal picture performance
There are many settings available to help fine-tune the
picture performance to match your installation
environment. These include:
• Smart BLC – automatically and dynamically
compensates for strong backlight
• Peak White Invert – reduces glare from highlight
areas
• Contrast and sharpness – enhance details in bright or
misty scenes
• SensUp – sensitivity is dramatically enhanced by a
factor of 10
• Default shutter – improves the motion performance in
auto exposure mode
• Dynamic noise reduction – dynamically reduces noise
in the picture
Privacy masking
Fifteen different privacy zones allow specific parts of a
scene to be blocked. Pre-program any part of the
scene to be masked.
Video Motion Detection
The built-in video motion detector allows you to select
four programmable areas with sensitivity thresholds.
When motion is detected, alarms can be displayed in
the video signal, the output relay can be closed or an
alarm message can be transmitted via Bilinx.
Typical applications:
• Entrance foyer or lobby with glare
• Outdoor perimeters
– low light
– IR light
• Traffic monitoring
– highway
– traffic intersections
– emergency response coordination
• Tunnels
• Car parks (outdoor)
• Restricted access locations such as:
– prisons
– ports / freight terminals
– military facilities
– border control and homeland
• Casino and gambling centers
Certifications and approvals
Standards FCC Part15 Subpart B, Class B
EN 55022 class B
EN61000-3-2
EN61000-3-3,
EN 50130-4
EN 50121-4
Camera with 500 g (1.1 lbs) lens
according to IEC 60068-2-6
VBN-5085-C11/
VBN-5085-C21
EN60950-1,
UL60950-1 (2ND edition),
CSA C22.2 No. 60950-1-07 (2ND
edition)
VBN-5085-C51 EN60950-1
Product certifications CE, FCC, UL, cUL, C-tick
Marks CE, cULus, WEEE, PADS, RCM and China
RoHS
Region Certification
Europe CE
USA UL
FCC
Canada CSA
2 | DINION AN 5000

Installation/configuration notes
Dimensions
(2.323)59
(1.339)34
(3.346)85
(4.646)118
(4.803)122
(1.889)48
(2.638)67
1/4"-20 UNC
1/4"-20 UNC
mm (in)
DINION
Technical specifications
Electrical
Model No. Rated Voltage Rated Frequency
VBN-5085/11 12 VDC / 24 VAC 50 Hz
VBN-5085/21 12 VDC / 24 VAC 60 Hz
VBN-5085/51 230 VAC 50 Hz
Power Consumption 360 mA (12 VDC)
330 mA (24 VAC)
60 mA (230 VAC)
Image Sensor 960H, 1/3" DS CCD, sensor resolution
720TVL, WDR dual shutter
System PAL or NTSC
Total pixels (H x V) 1020 x 596 (PAL)
1020 x 508 (NTSC)
Effective pixels (H x V) 976 x 582 (PAL)
976 x 494 (NTSC)
Sensitivity (3200K, scene reflectivity 89%, F1.2)
Full video
(100 IRE)
Usable picture
(50 IRE)
Usable picture
(30 IRE)
Color 0.5 lx
(0.0465 fc)
0.09 lx
(0.00837 fc)
0.04 lx
(0.00372 fc)
Color
+ SensUp 10x
0.05 lx
(0.00465 fc
)
0.009 lx
(0.000837 fc)
0.004 l
(0.000372 fc)
Monochrome 0.2 lx
(0.0186 fc)
0.04 lx
(0.00372 fc)
0.02 lx
(0.00186 fc)
Monochrome
SensUp 10x
0.02 lx
(0.00186 fc
)
0.004 lx
(0.000372 fc)
0.002 lx
(0.000186 fc)
Signal-to-Noise Ratio >54 dB
Video Output Composite video 1 Vpp, 75 ohm
Synchronization Internal, Line Lock
Shutter Auto (1/50 [1/60] to 1/100000)
selectable, fixed, flickerless, default
Sensitivity Up Adjustable from Off up to 10x
Day/Night Color, Mono, Auto
Dynamic Engine XF-Dynamic, HDR, Smart BLC
Dynamic Range 94 dB (WDR)
Dynamic Noise
Reduction
2D-NR, 3D-NR
AGC AGC On or Off (0 – 40 dB) selectable
Smart BLC On/Off
Peak White Invert On/Off
White Balance ATW Indoor, ATW Outdoor, ATW hold and
Manual
Contrast Enhancement Low, Medium, High
Sharpness Sharpness enhancement level selectable
Alarm Output VMD or Bilinx
Alarm Input (TTL) Profile switching, +3.3 V nominal,
+40 VDC max.
3 | DINION AN 5000

Alarm Output Relay 30 VAC or +40 VDC, Max 0.5 A
continuous, 10 VA
Cable Compensation Up to 1000 m (3000 ft) coax without
external amplifiers (automatic set-up in
combination with Bilinx coaxial
communication)
Camera ID 17 character editable string, position
selectable
Test Pattern Generator Color bar, Raster, Impulse, Cross Impulse,
Cross hatch,
Lens Types Manual, DC-Iris
DC-iris drive: max. 50 mA continuous
Lens Mount CS (max lens protrusion 5 mm, 0.2 inch),
C-mount compatible with adapter ring
(optional)
Modes 6 preset programmable modes
Remote Control Bilinx coaxial bi-directional
communication
Video Motion Detection 4 areas, fully programmable
Privacy Masking 15 independent areas, fully programmable
E-Zoom Up to 16x
Digital Image Stabilizer On/Off
Controls OSD with soft-key operation
OSD Language English, French, German, Spanish,
Portuguese, Simplified Chinese, Russian
Mechanical
Dimensions (H x W x L) 58 x 66 x122 mm (2.28 x 2.6 x 4.8 inch)
without lens
Weight (12 VDC/
24 VAC)
500 g (1.10 lbs) without lens
Weight (230 VAC) 600 g (1.32 lbs) without lens
Color RAL 9007 Metallic Titanium
Tripod Mount Bottom (isolated) and top 1/4-inch
20 UNC
Environmental
Operating Temperature -20°C to +55°C (-4°F to 131°F)
Storage Temperature -40°C to +70°C (-40°F to +158°F)
Operating Humidity 20% to 93% RH
Storage Humidity up to 98% RH
Ordering information
DINION AN 5000
960H analog indoor WDR box camera. True day/night;
720 TVL; 4-zone motion detect; 15-zone privacy mask;
12VDC/24VAC; 50 Hz; PAL
Order number VBN-5085-C11
DINION AN 5000
960H analog indoor WDR box camera. True day/night;
720 TVL; 4-zone motion detect; 15-zone privacy mask;
12VDC/24VAC; 60 Hz; NTSC
Order number VBN-5085-C21
DINION AN 5000
960H analog indoor WDR box camera. True day/night;
720 TVL; 4-zone motion detect; 15-zone privacy mask;
230VAC; 50 Hz; PAL
Order number VBN-5085-C51
Accessories
LVF-5000C-D2811 Varifocal Lens
960H varifocal IR-corrected lens. 1/3" sensor; CS-
mount; 4-pin DC-iris; F1.4-360; 2.8 to 11 mm
Order number LVF-5000C-D2811
LVF-5000C-D0550 Varifocal Lens
960H varifocal IR-corrected lens. 1/3" sensor; CS-
mount; 4-pin DC-iris; F1.6-360; 5 to 50 mm; high
resolution; low distortion
Order number LVF-5000C-D0550
LTC 3664/31 Varifocal Lens
960H varifocal IR-corrected lens. 1/3" sensor; CS-
mount; 4-pin DC-iris; F1.0-360; 3 to 8 mm
Order number LTC 3664/31
EX12LED‑3BD‑8M Infrared Illuminator
Mini IR 850 nm illuminator. LED array; 3D Diffuser;
black; 17 m HFOV; 30º beam pattern
Order number EX12LED-3BD-8M
EX12LED‑3BD‑8W Infrared Illuminator
Mini IR 850 nm illuminator. LED array; 3D Diffuser;
black; 16 m HFOV; 60º beam pattern
Order number EX12LED-3BD-8W
EX12LED‑3BD‑9M Infrared Illuminator
Mini IR 940 nm illuminator. LED array; 3D Diffuser;
black; 17 m HFOV; 30º beam pattern
Order number EX12LED-3BD-9M
EX12LED‑3BD‑9W Infrared Illuminator
Mini IR 940 nm illuminator. LED array; 3D Diffuser;
black; 16 m HFOV; 60º beam pattern
Order number EX12LED-3BD-9W
TC8235GIT Ground Loop Isolation Transformer
Order number TC8235GIT
UPA-2430-60 Power Supply
Power supply for camera. 120 VAC, 60 Hz; 24 VAC,
30 VA Out
Order number UPA-2430-60
4 | DINION AN 5000

UPA-2420-50 Power Supply
Power supply for cameras. 220 VAC, 50 Hz In; 24 VAC,
20 VA Out
Order number UPA-2420-50
UPA-2450-50 Power Supply, 220 V, 50 Hz
Indoor power supply for camera. 220 VAC, 50 Hz In;
24 VAC, 50 VA Out
Order number UPA-2450-50
UPA-2450-60 Power Supply, 120 V, 60 Hz
Indoor power supply for camera. 120 VAC, 60 Hz In;
24 VAC, 50 VA Out
Order number UPA-2450-60
S1374 Adapter
Adapter to convert C mount lens to CS mount camera
Order number S1374
Software Options
VP‑CFGSFT Configuration Software
Configuration software for cameras using Bilinx. VP-
USB adaptor
Order number VP-CFGSFT
5 | DINION AN 5000
Represented by:
Americas: Europe, Middle East, Africa: Asia-Pacific: China: America Latina:
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: [phone]
Fax: [phone]
[email protected]
www.boschsecurity.us
Bosch Security Systems B.V.
P.O. Box 80002
5617 BA Eindhoven, The Netherlands
Phone: + 31 40 2577 284
Fax: [phone]
[email protected]
www.boschsecurity.com
Robert Bosch (SEA) Pte Ltd, Security
Systems
11 Bishan Street 21
Singapore 573943
Phone: [phone]
Fax: [phone]
[email protected]
www.boschsecurity.asia
Bosch (Shanghai) Security Systems Ltd.
203 Building, No. 333 Fuquan Road
North IBP
Changning District, Shanghai
200335 China
Phone [phone]
Fax: [phone]
www.boschsecurity.com.cn
Robert Bosch Ltda Security Systems Division
Via Anhanguera, Km 98
CEP 13065-900
Campinas, Sao Paulo, Brazil
Phone: [phone]
Fax: [phone]
[email protected]
www.boschsecurity.com
© Bosch Security Systems 2015 | Data subject to change without notice
10162979339 | en, V11, 24. Nov 2015
