Panasonic AGDVC60 - DIGITAL VIDEO CAMCORDER User manual

Mini
AG-
Mini-DV Camera-Recorder (NTSC)

Professional Quality and Performance...
...With the Shoulder-Held Stability Professionals Prefer
Professional Quality and Performance...
...With the Shoulder-Held Stability Professionals Prefer
The AG-DVC60 is a mobile, shoulder-
type DV camera-recorder in a rugged yet
lightweight carbon fiber alloy body with a Midnight
Black matte finish. Designed for professional use, this high-
performance workhorse stands at the top of its class in image quality,
sensitivity, framing flexibility and functions. The oversized shoulder pad
combines with a hand grip on the side of the lens to give you a firm, no-
slip grip. For shooting comfort, you can slide the large, field-spec
viewfinder to the right or left side as you prefer, and lock it in place.
With a multifunctional lens ring that controls the zoom, focus and
aperture, the AG-DVC60 has the same solid feel as your standard field
camera. And it gives you clear, stable images with minimal hand-shake, plus the
responsive action you need to start shooting on a moment's notice. A full-sized
stereo microphone is set at the top of the camera, above the lens – an ideal
position for capturing the sound from in front of the camera.

The AG-DVC60 is fully equipped to meet your everyday production needs. It comes standard
with terminals for connecting an optional stereo gun mic, and with XLR-type mic input
terminals for connecting either a hand mic or line recording. Add an optional Anton Bauer
adapter plate, and you can mount any of several heavy-duty Anton Bauer batteries to the
camera rear for extended shooting work. Or snap an Anton Bauer Ultra Light onto the shoe
built into the top of the handle, and you have all the light you need for high-level shooting
jobs. You can use the color LCD monitor and viewfinder at the same time. When using the
viewfinder for shooting, you can face the LCD monitor forward, where someone in front of
the camera can use it as a monitor when speaking or conducting an interview.
...And the System Flexibility Professionals Need

Wide-Angle, High-Magnification
16x Zoom Lens
The AG-DVC60's 16x optical zoom
lens answers a broad range of
shooting needs, delivering superb
results from 39.5mm wide angle all
the way to 632mm telephoto (both
35mm lens equivalents). In wide-
angle performance — critical in
broadcast and other professional
applications — this lens is tops in its
class. This new 16x optical zoom lens system uses low-dispersion glass
and aspherical lenses to reduce color aberration and boost resolution.
Use of a special multi-coating process dramatically reduces flare and
ghosts. The result: sharp, crisp, beautifully rendered pictures with vivid
colors, delicate nuances, and exceptional shading.
Optical Image Stabilizer Compensates for Hand Shaking
The AG-DVC60's advanced Optical Image Stabilizer (OIS) compensates
for hand shaking that occurs as you shoot. A gyro sensor detects hand-
shake and sends signals to a linear motor, which adjusts the lens to
compensate. Because this process takes place prior to the CCD image
capture (rather than in the downstream electronic processing), it
virtually eliminates any effect of hand-shake on resolution and screen
angle. The OIS can also be helpful when zooming or shooting in dim
lighting.
1/4-Inch, 410,000-Pixel 3CCD Image System:
High Sensitivity, Low Noise
To assure a level of picture quality
suitable for professionals, the AG-
DVC60 uses a 3CCD image system
that delivers the highest sensitivity in
its class. Its high S/N ratio and
extremely low noise (in darker areas
of a picture) combines with high
sensitivity to deliver excellent image
quality even when shooting indoors
under dim lighting. When shooting in
sunlight or under bright spotlights, this 3CCD system offers low smear.
12-bit A/D and RGB Gamma Processor
The AG-DVC60 features an A/D
converter that uses the same 12-bit
processing as broadcast-quality
camera-recorders. This, combined
with an RGB gamma processor that
uses Panasonic's unique gamma
curve function, helps assure high-
image-quality processing. In fact,
the AG-DVC60's A/D converter and
RGB gamma processor are the same
ones used in our popular AG-DVX100A, which has won acclaim as the
industry's highest image quality DV camera.
A Digital Zoom for Professionals
Engineered for professionals, the AG-DVC60 is
equipped with a digital zoom that instantly
magnifies the image by any of five fixed values
— 1.25x, 1.5x, 2x, 5x or 10x.
Use it together with the 16x
optical zoom lens, and you get
super-telephoto magnification
equivalent to a 160x zoom.
Image degradation during the
digital processing is particularly
low in the 1.25x magnification
mode, so you get superb zoom
quality all the way to 20x.
Movie Simulation Mode
The AG-DVC60 can capture and reproduce images that are strikingly
similar in tone to film images, thanks to Panasonic's unique Cine-Like
gamma curve and a 30-fps frame recording function that electronically
interpolates interlaced images to create frames with no time differences
between fields.* Settings for this mode are preset in the Movie-Like
scene file.
*The resulting images are not the same as native progressive images recorded with a progressive CCD.
High-Sensitivity Slow Shutter
The slow shutter function uses image
accumulation to allow shutter speeds with
frame rates reduced by half or more. The
accumulation method provides
bright-color images with less
noise than those captured using
conventional gain-up, so you get
the higher sensitivity needed for
nighttime shooting without
illumination. The slow shutter
function can also be used to
obtain movie-like effects.
16:9 Wide Recording
The aspect ratio can be set to either 4:3 or 16:9
to accommodate wide-image recording. In 16:9
recording, you can select either letterbox or
squeeze mode, giving you more
possibilities in downstream editing
and playback.
Outstanding Image Quality, Shoulder Mount Reliability, and Digital Recording Functions
NORM
CINE-LIKE
Output
Input
NORM
CINE-LIKE
Gamma Curve and Images (conceptual)
x 20 Zoom Image
Wide (x 1)
Slow Shutter Image
Gain Up Image
16:9 Squeeze
4:3
16:9 Letter Box
Optical Image Stabilizer
aspherical lens

Zero Lux IR Mode (Super
Nighttime Shooting System)
The AG-DVC60 offers B&W
recording in the dark using
infrared light. This opens the door
to a host of new possibilities in
nighttime monitoring, surveillance
and news gathering. The built-in
infrared light makes it possible to
record at a distance of about 16
feet** (5 m**). For greater
distances, you can add an optional
light that allows recording to approximately 98 feet** (30m**).
*According to Panasonic survey **According to Panasonic testing
Date/Time Superimpose Function
The AG-DVC60 can superimpose the date and time onto the video
signal as you shoot. This is especially useful and in many cases a
requirement for depositions, court reporting and surveillance
recordings. The date and time cannot be replaced during dubbing or
editing operations, as can happen with most other cameras.
Full Auto or Manual Shooting
Use the AG-DVC60 for either full auto or manual shooting. The
Auto/Manual switch turns the four auto functions — focus, shutter
speed, iris & gain, and white balance — on and off as desired. Manual
focusing is controlled by the large focus ring. You can also switch
between manual and auto focus by pushing the Focus button. For
added convenience, one of the user buttons can be assigned to turn
auto focus on and off.
Multi-Function Focus Ring
In Auto Focus, control over either the zoom or the iris & gain can be
allocated to the focus ring, letting you make quick, detailed adjustments
manually.
3 User-Assignable Buttons
The AG-DVC60 provides three user buttons that can be assigned to any
of 16 camera functions and three VCR functions. User button 1 is
positioned atop the hand grip for easy access when shooting with
one hand.
Camera functions: Push AF+Zoom, Push AF, White Balance,
AWB Lock, Backlight, Spotlight, Rec Check, Digital Zoom, White
Fade, Black Fade, Photoshot, Index, SNS (Super Nighttime
Shooting), EVF DTL, Lumi-Flick, AE Lock
VCR functions: Blank Search, Audio Dub, Index
WHITE BAL and SNS can be allocated to user button 1 only.
Focus Assist with One-Push Zoom
When a user button is assigned the
Push AF+Zoom
function
and the AG-DVC60 is in Auto Focus, the camera will continue
to zoom as long as you hold the button down, then return to
the original zoom position when you release it. This helps you
zoom and focus more quickly in manual shooting mode.
Four Scene Files
The AG-DVC60 can save four sets of camera settings as "scene
files" for instant recall later in similar shooting conditions. Scene
files 1 and 2 are freely settable. Files 3 and 4 are preset (see list below),
but you can change the values as desired.
1 SCENE 1: User setting (standard values)
2 SCENE 2: User setting (standard values)
3 B.PRESS: For sharper contrast in dark portions
4 MOVIE-LIKE: Movie Simulation Mode
Shooting Support Functions
•Backlight correction: Backlighting compensation can be assigned to a
user button for instant results.
•AE Lock:
Locks the subject brightness; can be assigned to a user button.
•Zebra: Displays an overexposure warning on the viewfinder and monitor
•Marker: Detects and displays the Video Brightness level in a very
useful, repeatable numerical value.
•Mode check: Displays the camera settings on the viewfinder and
monitor, for easy checking before you shoot.
•Zoom position: Displays the zoom position as a repeatable, numerical
representation in the viewfinder.
•Picture Effects:
Picture effects function includes Wipe, Mix, Fade and Still.
Recessed Trigger and Zoom Control on Upper Handle Grip
In addition to the lens grip, the upper
part of the handle grip contains both
the Rec Start/Stop button and a lens
zoom control. This design assures
easy shooting even at low angles or
when using a tripod. The zoom
speed can be set to any of three
speed levels or off.
2.5" Color LCD Monitor
The 2.5" color LCD monitor rotates 270 degrees, making it easy to shoot
at difficult angles and the Mirror mode makes it easy to record yourself.
The display is bright too, so even outdoors you get good visibility when
using the LCD to monitor footage or select settings from the menu.
Professional-Level Audio with XLR Line/Mic In
The AG-DVC60 comes equipped with a built-in stereo microphone and
with XLR-type audio input terminals on the rear panel. You can switch
audio channels 1 and 2 separately to either line or front mic input -
especially useful when recording interviews or narration.
Audio Level Meters
Two color audio level meters can be displayed in the viewfinder and
LCD monitor, making it easy to check the signal as you record.
*Image of Zero Lux IR Mode and
date/time superimpose.

Reliability, System Configuration and Accessories for the Professionals
Large Viewfinder
The AG-DVC60 viewfinder is as
large as those offered on many
broadcast cameras. A slide
mechanism lets you shift the
viewfinder to the left or right for
maximum comfort, then lock it in
place. Monochrome mode and a
detail enhance function are provided
for easier viewing and focusing. You can use the viewfinder and LCD
monitor at the same time.
Carbon Fiber Composite Body
The body of the AG-DVC60 is made
of carbon fiber composite. Carbon
fiber exhibits both high rigidity and
light weight. It lets the AG-DVC60
stand up to everyday work, with
solid reliability and durability, but it
won't weigh you down.
Automatic Head Cleaning
The AG-DVC60 provides the same
head cleaning function as our
DVCPRO models. The white roller
pad positioned to the right of the
head cylinder cleans the head each
time you load a tape, helping to
minimize dropouts and head
clogging.
IEEE 1394 Terminal with Synchro Lock
An IEEE 1394-compliant 4-pin DV terminal makes it easy to upload data
from the AG-DVC60, or to dub footage onto a DV recorder. This
terminal also features a new synchro lock function that lets you use the
AG-DVC60 to remotely start and stop an external DV device. Three
recording modes help protect against mistakes: record onto external
recorder only, record onto both AG-DVC60 and external recorder,
begin external recording when the AG-DVC60 tape ends.
More Features for Professionals
•Built-in SMPTE time code generator/reader
•Built-in SMPTE color bars - useful for setup
•Shutter: Maximum speed of 1/8,000 sec. When the AG-DVC60 is
recording a computer display, a synchro scan function matches the
shutter speed to the monitor to minimize flicker.
•Index: Insert index points as you shoot - convenient when searching
later (can be assigned to a user button)
•User File: Save sets of camera settings for instant recall
AG-B15
AC adapter kit
BT-LS1400
14" SD LCD Monitor
PV-DDC9
IEEE 1394 Interface cable
Battery Pack
Shoulder
strap
Wireless remote
control unit
AC adapter
Battery
AC cable
DC cable
AG-YRL30G
IR light
QR-DVC10
AntonBauer battery adapter
Included
ACCESSORIES
AG-DVC60
DV Cable(4P) (4P)
DV Recorder AG-DV2500

Model No. Capacity Operating
time with EVF
CGR-D16A/1B 1600m Ah 120 min.*
CGP-D28A/1B 2700m Ah 210 min.*
CGA-D54SE/1B 5400m Ah 420 min.*
AG-MC15P
stereo microphone
AG-LW4307P
Wide conversion lens
*approximate
Master Series Tape
AY-DVM63PQ Professional Series Tape
AY-DVM63MQ Master Series Tape
AY-DVMCLC Cleaning tape
Optional
Lens cap

Switches and connectors are arranged to allow easy use of many functions
Accessory shoe for
AG-YRL30G IR light or
AntonBauer Ultra light
2.5-inch LCD
Main control panel
Zoom lever
EVF slide and lock mechanism
XLR Audio In (CH1/CH2)
for Line/Mic input
DV (IEEE 1394) In/Out, S-Video In/Out, AV In/Out
REC Start/Stop button and
Zoom lever: Convenient when
using a tripod or for low-angle
shooting
Power On/Off, CAM/VTR
selector, REC Start/Stop
Sub-panel buttons, switches and Audio
level controls behind the LCD panel
User button 1: assignable
Accessory shoe
for AG-MC15P microphone
Built-in stereo microphone
16x zoom lens
Multi-function manual ring
(focus, zoom or iris)
Large Viewfinder
Large hand grip
Headphone terminal
Battery Pack
Camera remote terminal
Shoulder pad

[GENERAL]
Supply Voltage: DC 7.2/7.9 V
Power Consumption: 6.2 W (when viewfinder is used)
7.4 W (when LCD monitor is used)
Operating Temperature: 32°F to +104°F (0°C to +40°C)
Operating Humidity: 10% to 85% (no condensation)
Weight: Approx. 5.7 lb (2.6 kg)
Dimensions (WxHxD): 8-5/16" x 8-7/8" x 16-15/16" (211 x 224 x 431 mm)
[CAMERA]
Pick-up Device: 1/4-inch interline transfer type CCD x 3
Picture Elements: Total: 410,000 pixels
Effective: 380,000 pixels (horizontal pixel shift system)
Lens: F 1.6 (f = 4.1 to 65.6 mm), 43 mm diameter,
motorized/manual mode switching 16x zoom
(35 mm equivalent: 39.5 to 632 mm), with optical image stabilizer
Optical Color Separation: Prism system
ND Filter: Auto On/Off by IRIS
Gain Selection: 0, +3, +6, +9, +12, +15, +18 dB
Shutter Speeds: 1/4, 1/8, 1/15, 1/30 sec. (slow shutter)
1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000,
1/1500,1/2000,1/3000, 1/4000,1/8000 sec. (high speed shutter)
Synchro Scan Shutter Speeds: 1/60.3 to 1/250.0.sec.
Minimum luminance: 4 lux (F 1.6, 18 dB gain, 50 IRE video output)
[VTR]
Recording Format: DV (Digital Video SD)
Tape Used: 6.35 mm wide metal tape (mini DV cassette)
Recorded Video Signals: 525/60i (NTSC)
Recorded Audio Signals: PCM digital recording
16 bits: 48 kHz/2 channels, 12 bits: 32 kHz/4 channels
Recording Tracks: Digital video, audio signals: helical track
Time code: helical track (sub-code area)
Tape Speed: SP mode: 18.812 mm/sec., LP mode: 12.555 mm/sec.
Recording Time: SP mode: 60 minutes, LP mode: 90 minutes
(when AY-DVM60 is used)
FF/Rew Time: Approx. 140 sec. (when AY-DVM60 is used)
[AUDIO]
Sampling Frequency: 48 kHz/32 kHz
Quantizing: 16 bits/12 bits
Frequency Characteristics: 20 Hz to 20 kHz
Wow & Flutter: Below measurable limits
[VIDEO]
Sampling Frequencies: Y: 13.5 MHz, PB/PR: 3.375 MHz
Quantizing: 8 bits
Video Compression System: DCT + variable length code
Error Correction: Reed-Solomon product code
[CONNECTORS]
MIC IN: Stereo Mini jack (3.5 mm diameter), –70 dBV
XLR AUDIO IN: XLR x 2 (CH1/CH2), High impedance,
0/–60 dB, LINE/MIC selectable
VIDEO IN/OUT: RCA x 1, (input/output automatically switched)
analog composite input/output, 1.0 Vp-p, 75Ω
S-VIDEO IN/OUT: 4pin x 1, (input/output automatically switched)
Y: 1.0 Vp-p, C: 0.286 Vp-p, 75Ω
AUDIO IN/OUT: RCA x 2 (CH1, CH2) (input/output automatically switched)
In: –10 dBV high impedance, Out: –10 dBV low impedance
DV IN/OUT: 4-pin, IEEE 1394 standard, digital input/output
PHONES OUT: Stereo Mini jack (3.5 mm diameter)
REMOTE: Mini jack (2.5 mm diameter)
DC IN: 2P x 1, 7.9 V
[EQUIPMENTS]
Internal Microphone: Stereo microphone
Viewfinder: 0.44-inch LCD color viewfinder, 180,000 pixels
LCD Monitor: 2.5-inch LCD color monitor, 110,000 pixels
Internal Speaker: 20mm round shape, volume – or +
*The specifications given above were measured by playing back tapes recorded by the AG-DVC60 on standard VTRs.
Weight and dimensions shown are approximate. Specifications are subject to change without notice.
AG-DVC60 Specifications
SP-AGDVC60P1 31K407ZM-1 Printed in Japan
You Can Get the Professional Shooting Quality with the Shoulder-Held Stability And the System Flexibility
AG-DVC60
Matsushita Electric Industrial Co., Ltd.
Systems Business Group
2-15 Matsuba-cho, Kadoma, Osaka, 571-8503 Japan
Tel. [phone] Fax. [phone]
https://eww.pavc.panasonic.co.jp/pro-av/
Panasonic Systems Sales Taiwan Co.,Ltd.
5F, 2 Sec. 5 Hsin I Road Taipei, Taiwan, R.O.C
Tel. [phone] Fax. [phone]
Panasonic Korea Ltd.
Seohyun B/D, 1718-9, Seocho-Dong, Seocho-Gu,
Seoul, Korea
Tel. [phone] FAX. [phone]
Broadcast and Communication Company of Asia, Inc.
R-1902A Tektite Tower II Exchange Road Ortigas Center Posig
City, Philippines
Tel. [phone] Fax. [phone]
Panasonic de Mexico, S.A. de C.V.
Tel. [phone] Fax. [phone]
Panasonic Latin America S.A.
( Caribe,Centro America, Venezuela, Colombia, Ecuador, Bolivia,
Uruguay, Paraguay, Chile
)
Tel. [phone] Fax. [phone]
Panasonic del Peru S.A.
Tel. [phone] Fax. [phone]
Panasonic do Brasil Ltda
Tel. [phone] Fax. [phone]
PANASONIC BROADCAST & TELEVISION SYSTEMS COMPANY
DIVISION OF MATSUSHITA ELECTRIC CORPORATION OF AMERICA
www.panasonic.com/broadcast
Executive Office: One Panasonic Way 4E-7, Secaucus, NJ 07094
[phone]
EASTERN ZONE: One Panasonic Way 4E-7, Secaucus, NJ 07094
[phone]
Central Region: 1707 N Randall Road E1-C-1, Elgin, IL 60123 [phone]
WESTERN ZONE: 3330 Cahuenga Blvd W., Los Angeles, CA 90068
[phone]
Government Marketing Department:
52 West Gude Drive, Rockville, MD 20850 [phone]
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3 [phone]
www.panasonic.ca e-mail: [email protected]
Panasonic Sales Company
(Division of Matsushita Electric of Puerto Rico Inc.)
San Gabriel Industrial Park, 65th Infantry Ave., Km. 9.5, Carolina,
Puerto Rico 00630 [phone]
