Panasonic WV-NW502S User manual

Megapixel H.264 Vandal Resistant Network Camera featuring Super Dynamic
Key Features
• Multiple H.264 (High profile) streams and JPEG streams ensure
simultaneous real time monitoring and high resolution recording by
“UniPhier®” Panasonic’s proprietary System LSI platform.
• Full frame (Up to 30 fps) transmission at 1,280 x 960 image size (1.3 Megapixel mode)
• Super Dynamic and ABS (Adaptive Black Stretch) technologies
deliver 128x wider dynamic range compared to conventional cameras.
• Up to 3 Megapixel (2,048 x 1,536) JPEG stream (3 Megapixel mode, JPEG only)
• H.264 and MPEG-4 are selectable for system migration.
• High sensitivity with Day/Night function: 1.0 lux (Color), 0.08 lux
(B/W) at F1.2 (Wide,1.3 Megapixel mode)
• ABF (Auto Back Focus) ensures easy installation and stable focus in both color and B/W modes.
• Adaptive Digital Noise Reduction: Integration of 2D-DNR and 3D-
DNR ensures noise reduction in various conditions.
• Progressive scan ensures clear images with less motion blur and no
tearing even when the subject is moving.
• Superior color reproduction by primary (RGB) color filter
• Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
• Selectable light control modes: Outdoor / Indoor / ELC / Fixed electronic shutter
Outdoor / Indoor: Electronic shutter and ALC lens iris control are
automatically controlled depending on the mode and luminance level.
ELC: Up to 1/10,000 Electronic shutter is automatically applied for a fix iris lens.
Fixed electronic shutter: Up to 1/10,000 fixed electronic shutter can be selectable.
• VMD (Video Motion Detector) with 4 programmable detection areas,
15 steps sensitivity level and 10 steps detection size
• Face detection detect the position of human face, the information is
sent by XML or video stream.
• Meta data for VMD is supplied to work with the WJ-ND400 playback VMD function.
• Privacy Zone can mask up to 8 private areas, such as house windows and entrances/exits.
• 2x, 4x digital zoom controlled by browser
• Camera title display: Up to 20 alphanumeric characters on the browser, Up to 16
alphanumeric characters with three selectable character sizes embedded in the image
• Alarm sources including 3 terminal input, VMD and Panasonic alarm command can
trigger actions such as SD/SDHC memory recording, FTP image transfer, E-mail
notification, Indication on browser, Alarm terminal output, and Panasonic protocol output.
• Full duplex bi-directional audio allows interactive communication
between camera site and monitoring site.
• JPEG image compression ratio can be changed by alarm so that
higher quality image can be provided.
Super Dynamic
Megapixel Vandal Resistant
Fixed Dome Network Camera
WV-NW502S
WV-NW502S (12 V DC or PoE) WV-NW502S (12 V DC or PoE)
Optional Accessories
Smoke Dome Cover
WV-CW4S
Embedded Ceiling Mount Bracket
WV-Q169
Standard Accessories
• CD-ROM*1 .................................... 1 pc.
•
Installation Guide .......................... 1 pc.
• Code Label*2 ................................. 1 pc.
The followings are for installation.
• 2P Power Cable ............................ 1 pc.
• 4P Alarm Cable
............................. 1 pc.
• Camera Attachment ...................... 1 pc.
• Mount Bracket ............................... 1 pc.
• Base Cover ................................... 1 pc.
• Fixing Screws (M4 x 8 mm)
(1 piece of spare screw included) .... 5 pcs.
• Bit for tamperproof screw ............. 1 pc.
• Butyl tape ..................................... 1 pc.
*1 The CD-ROM contains Panasonic IP Setup Software,
viewer software "Network Camera View 4", and
Operation Instructions (PDF).
*2 This label may be required for network management.
The network administrator shall retain the code label.
• Prioritized stream control: One of the video streams can be prioritized
when multiple recorders or client PCs are accessing the camera so
that the recorder or the client PC can maintain the frame rate.
• SD/SDHC Memory card slot for manual recording, alarm recording
and backup upon network failure.
• H.264/MPEG-4 max. bit rate/client and Total bit rate control allows
flexible network traffic management. Frame rate priority mode controls
bit rate and compression ratio to provide the specified frame rate.
• Alarm log, Manual REC log, FTP error log saved in the SD/SDHC memory
card is displayed on the browser GUI and can be downloaded to the client
PC. Playback or Image data download through the log is also available.
• Internet mode: H.264/MPEG-4 images can be transmitted over HTTP protocol.
• Multi-language GUI and setup menu: English, French, Italian, Spanish, German,
Russian (PAL) / English, French (NTSC) * Installation required except for English
• IPv4/IPv6 protocol supported
• Analog Monitor output for easier installation
• IP66 rated water and dust resistant. Compatible with IEC60529
measurement standard.
• Dehumidification device for use in various weather conditions
• Vandal resistant mechanism for high reliability
• 2.8 ~ 8.0 mm, 2.8x Varifocal Auto Iris lens

http://panasonic.net/security/
Printed in Japan (2A-046DL)
DISTRIBUTED BY:
Trademarks and registered trademarks
–Microsoft, and Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.
–UniPhier is a registered trademark of Panasonic Corporation.
–"Super Dynamic", "SDII ", "SDIII ", "SD5", "SD5Link" and "i-Pro" logos are trademarks or registered trademarks of Panasonic Corporation.
Important
–Safety Precaution: carefully read the operating instructions and installation manual before using this product.
–Panasonic can not be responsible for network performance and/or other manufacturer products that reside on the network.
• All TV pictures are simulated.
• Weights and dimensions are approximate.
• Specifications are subject to change without notice.
• These products may be subject to export control regulations.
• All product pictures are NTSC models.
46(1-13/16")
130(5-1/8") 200(7-7/8")
83.5
(3-5/16")
8-ø5
8-ø12
Mounting Surface
138(5-7/16")
85(3-3/8")
85
(3-3/8")
138(5-7/16")
191.5(7-9/16")
SR52.5
WV-NW502
146(5-3/4")
52.5
(2-1/16")
41
(1-5/8")
1
52.5
(2-1/16")
ø164
(ø6-7/16")
191.5(7-9/16")
29
(1-1/8")
Enclosure
Inner Dome
Focus Adjustment Grip
Focus Lock Knob
Zoom Lock Knob
Tilt Adjusting Table
Network Cable
Alarm I/O Cable
Power Cable (12 V DC)
Audio Output Cable
Mic/Line Input Cable
Camera Attachment (accessory)
Mount Bracket (accessory)
Base Cover (accessory)
SDHC/SD Memory Card Slot
Tilting Lock Screw
Panning Lock Screw
Panning Table
Monitor Out Connector for
Adjustment
Link LED
Access LED
INITIAL SET Button
Auto Back Focus Button
SDHC/SD Memory Card
Error LED / ABF LED
Appearance
Unit: mm (inches)
Part Names and Functions
TV System NTSC PAL
Camera Image Sensor 1/3 inch interline transfer CCD
Effective Pixels 1,296 (H) x 976 (V) x2
Scanning Mode Progressive scan
Scanning Area 4.86 mm (H) x 3.65 mm (V)
Minimum
1. 3 Megapixel Color: 1.0 lux, B/W: 0.08 lux at F1.2 (Shutter: 1/30 s, AGC: High, SD: OFF),
Illumination mode Color: 0.06 lux, B/W: 0.005 lux at F1.2 (Shutter: 16/30 s, AGC: High, SD: OFF)
*1 3 Megapixel Color: 2.0 lux, B/W: 0.16 lux at F1.2 (Shutter: 1/30 s, AGC: High),
mode Color: 0.12 lux, B/W: 0.01 lux at F1.2 (Shutter: 16/30 s, AGC: High)
White Balance AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K)
Light Control Mode Outdoor: Automatic integration of ALC and ELC Indoor: Automatic integration of ALC
and ELC (up to 1/100 sec.) ELC: (up to 1/10,000 sec.) (ELC: only at Super Dynamic: OFF)
Shutter Speed Fix shutter: 3/100, 2/100, 1/100, 1/250, 1/500, 1/1,000, 1/2,000,
1/4,000, 1/10,000 (Only at Super Dynamic: OFF)
Super Dynamic ON / OFF (1.3 Megapixel mode only)
Dynamic Range 52 dB typical (Super Dynamic: ON, Light Control mode: Indoor)
Adaptive Black Stretch ON / OFF (Only at Super Dynamic: OFF)
AGC ON (LOW, MID, HIGH ) / OFF
Electronic Sensitivity UP OFF / AUTO (Max. 2x (2/30 s), 4x (4/30 s), 6x (6/30 s), 10x (10/30 s), 16x (16/30 s))
Black and White Mode Mode: AUTO1 / AUTO2 / AUTO3 / ON / OFF, Level: High / Low, with external control
Digital Noise Reduction High / Low
Video Motion Detection 4 areas, Sensitivity: 15 steps, Detection size: 10 steps
Privacy Zone Up to 8 zones, Gray / Mosaic
Up Side Down ON / OFF
Auto Image Stabilizer ON / OFF
Camera Title (OSD) Up to 16 alphanumeric characters (3 selectable character sizes)
Back Focus Adjustment
ABF / MANUAL, ABF mode upon CL/BW switching: AUTO / PRESET / FIX
Lens Vari Focal Length 2.8 mm ~ 8 mm
Angular Field of View H: 35.0°(Tele) ~ 100°(Wide), V: 26.2°(Tele) ~ 73.4°(Wide)
Maximum Aperture Ratio 1 : 1.2 (Wide) ~ 1 : 1.8 (Tele)
Focusing Range 0.3 m ~ ∞
Pan and Tilt
Panning Range: ±170°Tilting Range: ±75°Azimuth Range: ±100°
Browser Camera Control Brightness, AUX ON / OFF, Zoom (1x, 2x, 4x)
GUI Display Mode
Spot, Quad: Image from 16 cameras can be displayed in 4 different Quad
screens or 16 split screen (JPEG only). 20 characters camera title available.
Digital Zoom 1x, 2x, 4x Controlled by browser GUI
Camera Title Up to 20 alphanumeric characters
Clock Display
Time: 12H / 24H, Date: 5 formats on the browser, Summer time (Manual)
Alarm Control Reset
One Shot Capture A still picture will be displayed on a newly opened window.
Audio Mic (Line) Input: ON / OFF, Audio Output: ON / OFF
SD Memory Data Download Images recorded in the SD memory card can be downloaded.
GUI/Setup Menu Language English, French English, French, Italian,
(Installation required for French) Spanish, German, Russian
(Installation required except for English)
System Log Up to 100 (Internal), Up to 4,000 (SD memory) error logs
Supported OS
Microsoft®Windows Vista®Business SP1 32 bit, Microsoft®Windows®XP Home Edition/
Professional SP3, The language of the OS must be same as selected GUI language.
Supported Browser Windows®Internet Explorer®7.0 (Microsoft®Windows Vista®Business SP1 32 bit),
Microsoft®Internet Explorer®6.0 SP3 (Microsoft®Windows®XP Home Edition/Professional SP3)
Network Network IF 10Base-T / 100Base-TX, RJ-45 connector
1.3 Megapixel H.264: 1,280 x 960 / VGA (640 x 480) / QVGA (320 x 240), up to 30 fps
Resolution mode MPEG-4: VGA (640 x 480) / QVGA (320 x 240), up to 30 fps
*2
JPEG: 1,280 x 960 / VGA (640 x 480) / QVGA (320 x 240), up to 30 fps
3 Megapixel H.264: 1,280 x 960 / VGA (640 x 480) / QVGA (320 x 240), up to 15 fps
mode MPEG-4: VGA (640 x 480) / QVGA (320 x 240), up to 15 fps
JPEG: 2,048 x 1,536 / 1,280 x 960 / VGA (640 x 480), up to 15 fps
H.264 / Transmission Priority Constant bit rate / Frame rate
MPEG-4 Max. Frame Rate 1 / 3 / 5 / 7.5 /10 / 15 / 20* / 30* fps * 1.3 Megapixel mode only
*2 Max. 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 1,536 / 2,048 / 3,072 /
Bit Rate/Client 4,096 / 8,192* kbps / Unlimited * H.264 mode only
Image Quality LOW / NORMAL / FINE
Refresh Interval 0.1 fps ~ 30 fps
Transmission Type UNICAST / MULTICAST
JPEG Image Quality
10 steps
Transmission Type PULL / PUSH
Audio Compression G.726 (ADPCM) 32 kbps / 16 kbps
Audio Mode
OFF / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Authentication for Audio Level 1 only / Level 2 higher / All users
Total Bit Rate
64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 2,048 / 4,096 / 8,192 kbps / Unlimited
Supported Protocol IPv4: TCP/IP, UDP/IP, HTTP, RTSP, RTP, RTP/RTCP, FTP, SMTP, DHCP, DNS, DDNS,
NTP, SNMP IPv6: TCP/IP, UDP/IP, HTTP, RTP, FTP, SMTP, DNS, NTP, SNMP
FTP Client Alarm image transfer, Periodic image transfer, Active/Passive selectable (When the FTP
periodic transmission is failed, backup on an optional SDHC/SD memory card is available.)
No. of Simultaneous Users Up to 14 users (Depends on network conditions)
SDHC/SD Memory Card Manual REC / Alarm REC / Backup upon network failure
(Option) Compatible SD (SDHC) card: Panasonic 64 MB, 128 MB,
256 MB, 512 MB, 1 GB, 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB* model * SDHC card
TV System NTSC PAL
Alarm Alarm Source 3 terminal inputs, VMD, Command alarm
Alarm Log
With SDHC/SD memory card: 5,000 logs, Without SDHC/SD memory card: 1,000 logs
Alarm Actions SDHC/SD memory recording, E-mail notification, Alarm terminal output,
Indication on browser, FTP image transfer, Panasonic protocol output
Schedule Alarm / VMD / Access permission
Input / Monitor Output 1.0 V [P-P] / 75 Ω, NTSC 1.0 V [P-P] / 75 Ω, PAL
Output composite, RCA Jack composite, RCA Jack
Microphone/Line Input MIC IN and Line IN are selectable. ø3.5 mm stereo mini jack
(Cable) (monaural input) (Applicable microphone: Plug-in power type)
Supply voltage: 2.5 V ±0.5 V Input impedance: approx. 2 kΩ
Audio Output (Cable) ø3.5 mm stereo mini jack (monaural output) Line level
External I/O Terminals ALARM IN 1 / DAY/NIGHT IN, ALARM IN 2 / ALARM OUT,
(Cable) ALARM IN 3 / AUX OUT / EXPOSURE OUT
General Safety/EMC Standard
UL (UL60065), FCC (Part15 ClassA), CE (EN55022 ClassB, EN55024)
C-UL (CAN/CSA C22.2 No.60065),
DOC (ICES003 ClassA)
Power Source and 12 V DC: 630 mA, PoE (IEEE 802.3af): 7.6 W
Power Consumption
Ambient Operating –30 °C ~ +50 °C (–22 °F ~ 122 °F) *3,
Te mperature/Humidity 90 % or less (without condensation)
Water and Dust Resistance IP66, IEC60529 measuring standard compatible
Impact Protection IEC 60068-2-75 test Eh, 50J
Dimensions ø164 mm x 146 mm (H), 191.5 mm (W) (Base Cover)
(ø6-7/16" x 5-3/4" (H), 7-9/16" (W) (Base Cover))
Weight (approx.) 1.8 kg (4.0 lbs.) (with Mounting Bracket)
Specifications
*1 With standard Clear Dome Cover *2 H.264 and MPEG-4 are alternative.
*3 When turning on the power at –10 °C (14 °F) or lower, warming up (at least 1 hour) is required before operation and setting.
