Kodak PixPro SL25 User manual
SMART LENS Camera
User Manual
1
About this Manual
Thank you for purchasing the KODAK PIXPRO SMART LENS Camera. Please
carefully read this manual and keep it for future reference.
JK Imaging Ltd. reserves all rights of this document. No part of this published
manual may be reproduced, transmitted, transcribed, stored in a retrieval system
or translated into any language or computer language, in any form, by any
means, without the prior written permission of JK Imaging Ltd..
Alltrademarksmentionedinthismanualareusedforidenticationpurposesonly
and are properties of their respective owners and holders.
This manual is to introduce you how to operate this KODAK PIXPRO SMART
LENS Camera. JK Imaging Ltd. has tried its utmost to ensure the correctness
of all contents here, but reserves the right to modify. All of these contents are
subject to change without prior notice.
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK
Company Website: kodakpixpro.com
In this manual:
The memory card referred to in this manual is a microSD Card or microSDHC card.
2
INDUSTRY CANADA
This device complies with Canadian ISED.
This device complies with ISED’s licence-exempt RSSs. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
Le présent appareil est conforme aux CNR d’ ISED applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) le
dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter
tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement
indésirable.
Radiation Exposure Statement:
The product comply with the Canada portable RF exposure limit set forth for an uncontrolled
environment and are safe for intended operation as described in this manual. The further RF
exposure reduction can be achieved if the product can be kept as far as possible from the
user body or set the device to lower output power if such function is available.
Déclaration d’exposition aux radiations:Le produit est conforme aux limites d’exposition pour
les appareils portables RF pour les Etats-Unis et le Canada établies pour un environnement
non contrôlé.
Le produit est sûr pour un fonctionnement tel que décrit dans ce manuel. La réduction aux
expositions RF peut être augmentée si l’appareil peut être conservé aussi loin que possible
du corps de l’utilisateur ou que le dispositif est réglé sur la puissance de sortie la plus faible
si une telle fonction est disponible.
3
For Customers in Europe
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection
of electrical waste and electronic equipment in the European countries. Please do
not throw the equipment into domestic refuse. Please use the return and collection
systems available in your country for proper, safe disposal of this product.
”CE” mark indicates that this product complies with the European requirements for
safety, health, environment and customer protection. ”CE” marked cameras are
intended for sales in Europe.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 2014/53/EU.
The following test methods have been applied in order to prove presumption of conformity
with the essential requirements of the R&TTE Directive 2014/53/EU:
The frequency and maximum transmitted power in EU are listed as below:
2412MHz~2472MHz (Wi-Fi 2.4GHz) : 19.50dBm
- EN 60950-1/A12:2011+A2:2013
Safety of Information Technology Equipment
- EN 50566: 2013
Productstandardtodemonstratecomplianceofradiofrequencyeldsfromhandheldand
body- mounted wireless communication devices used by the general public (30 MHz — 6
GHz)
4
- EN 62209-2: 2010
Humanexposuretoradiofrequencyeldsfromhandheldandbodymountedwireless
communication devices — Human models, instrumentation, and procedures
Part2:Proceduretodeterminethespecicabsorptionrate(SAR)forwireless
communication devices used in close proximity to the human body (frequency range of 30
MHz to 6 GHz)
- EN 300 328 V2.1.1 (2016-11)
Wideband transmission systems; Data transmission equipment operating in the 2,4 GHz
ISM band and using wide band modulation techniques.
- EN 300 330 V2.1.1 (2017-02)
Short Range Devices (SRD); Radio equipment in the frequency range 9 kHz to 25 MHz
and inductive loop systems in the frequency range 9 kHz to 30 MHz
- Draft EN 301 489-1 V2.2.0 (2017-03)
Electromagnetic compatibility and Radio Spectrum Matters (ERM); Electro Magnetic
Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical
requirements.
- Draft EN 301 489-17 V3.2.0 (2017-03)
ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 17:
SpecicconditionsforBroadbandDataTransmissionSystems.
Manufacturer: Sintai Optical (Shenzhen) Co., Ltd
Address: Qiwei Ind Sec, 1st, 2nd,& 3RD Bldg, Lisonglang Village, Gongming Town,
Bao’an District, Shenzhen, Guangdong, China
5
For Customers in the U.S.A.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCCCaution:Anychangesormodicationsnotexpresslyapprovedbytheparty
responsible for compliance could void the user’s authority to operate this equipment.
6
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Radiation Exposure Statement:
This product complies with the FCC portable RF exposure limit set forth for an
uncontrolled environment and is safe for intended operation as described in this
manual. Additional RF exposure reduction can be achieved if the product can be kept
as far as possible from the user body or set the device to lower output power if such
function is available.
7
Safety Notes
Safety notes for this camera
Do not disassemble or repair this camera by yourself.
Do not drop the camera or allow it to hit solid objects.
To prevent the camera from being damaged by moisture, do not use or store the
camera in very humid environments, such as in rain or near bodies of water.
Turn the camera off, remove the battery and the memory card, and dry it within
24 hours if water accidentally comes in contact with the camera.
Do not use or store the camera in dusty places or on a beach to prevent dust or
sand from entering the camera, causing possible damage to it.
Do not use or store the camera in a hot environment or under direct sunlight.
Pleasedonotuseinplaceshavinghighintensitymagneticeld,electrostatic
and electric wave interference (for example near a microwave oven), which may
cause failure in receiving signals.
Before you remove the battery and memory card, the camera should be turned
off.
Advise to use soft lens cloth to regularly clean the camera’s body.
8
In cleaning the camera body, please don’t use corrosive cleaning agents or those
with alcohol or organic solvent.
If this camera is not in use for a long time, please keep it in a dry and clean
condition.
Our company will not pay compensation for any failure of playback of pictures or
videos caused by improper operation.
Whenusingyourcameraonanairplane,observetherelevantrulesspeciedby
the airline.
Do not place the product where it can be reached by infants and children.
Safety notes for battery
Please use a battery that is the same type as the one included.
Please use the attached charger to charge the battery.
If the liquid leaking from the battery contacts with your skin, please immediately
ushwithwaterandseekmedicaltreatment.Iftheliquidleaksintothecamera,
please contact the retailer.
Please dispose of the wasted battery in accordance with local (national or
regional) regulations.
To prevent the battery from being damaged, do not drop the battery or allow it to
hit solid objects or to be scratched by the objects.
9
Do not let the battery come in contact with metal objects (including coins) to avoid
short circuiting, discharging, excessive heat, or possible leakage.
Do not attempt to disassemble the battery.
Do not expose the battery to water. Always keep the battery contacts dry.
Donotheatthebatteryorthrowitintoaretoavoidapossibleexplosion.
Do not store the battery in a hot environment or in direct sunlight.
If an overheating happens during charging or use, please immediately stop
charging or using and then take out the battery with care in shutdown mode to
wait it for cooling.
If it is not used for a long time, please remove the battery for proper keeping.
In a colder environment, the performance of the battery could be noticeably
reduced.
Safety notes for memory card
A memory card is optional and is not included in the product package. It needs to
be purchased separately. Please use an original memory card which is Class 4 or
higher and has a capacity of 4GB to 32GB.
Beforeusingabrandnewmemorycard,pleaseformatthememorycardrst.
Do not make the memory card fall off from high places or hit by heavy objects to
prevent damaging it.
10
Do not attempt to disassemble or repair the memory card.
Do not expose the memory card to water. Always keep it dry.
Do not remove the memory card when the camera is turned on. Otherwise, the
memory card could be damaged.
Do not directly edit the data on the memory card. Copy the data to your PC
before you edit them.
When the camera is stored for a long period of time, be sure to download your
photos and remove the memory card. Store it in a dry environment.
DonotmodifythenameofthelesorfoldersofthememorycardusingyourPC.
Modifyingthelenamesmaycausethelestonotberecognizedonthecamera
or a possible error may occur.
A photo taken with the camera will be stored in the folder that is automatically
generated on the memory card. Do not store photos that are not taken using
this camera in these folders as the pictures cannot be recognized during the
playback.
11
ProductSpecications
Image Sensor 1/2.3” BSI CMOS
Total Pixels 16.76 Megapixels
Effective Pixels 16.35 Megapixels
Focal Length 4.3mm (Wide) ~ 107.5mm (Tele)
35mmlmequivalent 24mm (Wide) ~ 600mm (Tele)
F number F3.7 (Wide) ~ F6.2 (Tele)
Optical Zoom 25x
Focusing Range Normal:(Wide)60cm~∞,(Tele)250cm~∞
Macro:3cm~∞(WideOnly)
Anti-Handshake Optical Image Stabilization
12
Wi-Fi Yes (802.11 b/g/n)
NFC Yes
Remote Control Yes (via smart device)
File Format
Still Image: Exif 2.3 (JPEG)
Movie: MP4 [Image: H.264; Audio: AAC(Stereo)]
Power Rechargeable Li-ion Battery LB-052, 3.7V 880mAh,
In-Camera Charging
Shooting Capability Approx. 210 Shots (Based on CIPA Standards)
Operation
Environment Temperature: 0 ~ 40°C, Humidity: 0 ~ 90%
Dimensions (W×H×D) Approx.71.0×58.6×65.2mm (Based on CIPA
Standards)
Weight Approx. 210g (Body only)
13
Getting Ready
Accessories Included
Your camera box should contain the camera model you purchased along with the
following accessories. If anything is missing or appears to be damaged, please contact
your retailer.
▪Rechargeable Li-ion battery
▪AC adapter
▪Micro USB cable
▪Wrist strap
▪Quick start guide
▪Service card
▪Warranty card
14
Part Names
1 Microphone 6 Speaker
2 Power Button 7 Zoom Lever
3 NFC Mark 8 Shutter Button
4 Battery Cover 9 Tripod Socket
5 Wrist Strap Buckles
After turning the camera on, you may move the camera's zoom lever to
zoom, and press the shutter button to take photos.
15
Installation of Wrist Strap
It is recommended to use the wrist strap to prevent the camera falling off during use.
Please install it on the camera and then wear it around your hand per the diagram
below.
16
Installing Battery and Memory Card
1. Open the battery cover.
2. Insert the battery into the battery
compartment according to the negative
and positive directions as illustrated in the
picture. Push the battery down until it locks
in place.
17
3. Insert the memory card into the memory
card slot as shown in the diagram. Push
it down until it locks in place.
4. Close the battery cover.
When you insert a memory card,
make sure the notch of the card
matches the markings on the top of
the card slot.
To remove your memory card, open
the battery cover, gently press the
memory card to eject it and remove it
carefully.
18
Charging Battery
For charging, you may use the included AC
Adapter and Micro USB cable to charge
the camera when it is off. You also may
connect the Micro USB cable to computer
for charging.
The camera will only charge while
powered off. If the camera is turned
on while connected to power, normal
camera functions will be available for
use, but the camera will not charge
until it is turned off.
Charging indicator
Charging indicator:
Steady orange: Charging.
The indicator will go out
oncechargingisnished,
and the camera will be
powered off automatically.
19
Connect the smart device
Install APP
Download a dedicated installation package from the application store corresponding to
the device (APP name: PIXPRO Remote Viewer) and then install it.
Your smart device operating system version needs to be iOS 7 or higher, or
Android 4.2 or higher. If not, please upgrade your smart device before using the
APP.
Wi-Fi connection (Android system and iOS system)
1. Press the power button to turn the camera on.
2. Enable the Wi-Fi feature of your smart device to automatically search surrounding
hotspots.
3. Select "PIXPRO-SL25_XXXX", and input the eight-digit number password
[12345678]. (The camera's SSID and password are located on the back side of
the battery cover.)
Table of contents
