Speco Intensifier K HTINT70K User manual

INSTRUCTION
MANUAL
IQWHQVLÀHU.SHULHV
4QFDP5FDIOPMPHJFTJTDPOTUBOUMZEFWFMPQJOHQSPEVDUJNQSPWFNFOUT
8FSFTFSWFUIFSJHIUUPNPEJGZQSPEVDUEFTJHOBOETQFDJGJDBUJPOTXJUIPVUOPUJDFBOEXJUIPVUJODVSSJOHBOZPCMJHBUJPO 3FW
HTINT70K
(Bullet Camera)
HTINT60K
(Turret Camera)
HTINT59K
(Dome Camera)
HTINT40K
(Miniature Camera)

Contents
1
Ł
Contents......................................................1
Ł
Precautions.................................................2, 3
Ł
Safety Instructions ......................................4
Ł
Package Contents.......................................5
Ł
Camera Installation.....................................6-12
Ł
Lens Adjustment .........................................13-16
Ł
6SHFL¿FDWLRQV..............................................17-20
Ł
Camera Dimension.....................................21-22
Ł
Features......................................................23
Ł
OSD Menu Details......................................24-46
Ł
Trouble Shooting.........................................47

2
Precautions
Do not install the camera in
extreme temperature conditions. Do not touch the front lens of the camera.
Never keep the camera pointed
directly at strong light. Do not expose the camera to radioactivity.
Do not install the camera under
unstable lighting conditions.
Do not drop the camera or subject
it to physical shocks.
Only use the camera under conditions
where temperatures are between
-10°C and +50°C. Be especially careful to
provide ventilation when operating under
high temperatures.
This is one of the most important parts of
the camera. Be careful not to leave
fingerprints on the lens cover.
It can cause malfunctions to occur. If exposed to radioactivity the CCD
will fail.
Severe lighting change or flicker can
cause the camera to work improperly.
Housing damage can compromise
weatherproof ratings.
NOTE
* If the camera is exposed to spotlight or object reflecting strong light,
smear or blooming may occur.
* please check that the power satisfies the normal specification before
connecting the camera.

3

4
Safety Instructions
1SFDBVUJPOTGPSVTF
1MFBTFIBOEMFUIJTDBNFSBDBSFGVMMZ
Ł7KLVFDPHUDVKRXOGEHLQVWDOOHGE\TXDOL¿HGSHUVRQQHORQO\
ŁThere are no user serviceable parts inside
ŁDo not disassemble this camera other than to make initial adjustments
ŁUse a UL approved regulated 24 volt AC or 12 volt DC power supply
Ł
8VHDSSURSULDWHORZYROWDJHSRZHUFDEOHWRSUHYHQW¿UHRUHOHFWULFDOVKRFN
Ł
Please insure that your installation area can support the weight of the camera
ŁDo not use a strong or abrasive detergent when cleaning the camera
ŁDo not install near cooling or heating device

5
Package Contents
Please make sure that the following items are included in the Package:
1) HTINT70K
q1 8ideo Test Connector, 2ower ,ack
q1 (ocus #djustment
q1 Bracket Base
q1 9rench
q5et 5crew
4 Tapping 5crews 4x5
4 Hexagon 5ocket 5crews M5x10
) HTINT60K
q1 8ideo Test Connector, 2ower ,ack
q9renches
q5et 5crew
Tapping 5crews 4x5
3) HTINT59K
q1 8ideo Test Connector, 2ower ,ack
q1 Chameleon CoXer
q1 9rench
q5et 5crew
3 Tapping 5crews 3.5x0
4) HTINT40K
q1 8ideo Test Connector, 2ower ,ack
q5et 5crew
Tapping 5crews M3x10
Machine 5crews Mx3

6
CAMERA INSTALLATION
jvuulj{Gwv~lyGjhislG
XUG~oluG|zpunGXYG}vs{zGkjGOGG\WWGhPG
YUG~oluG|zpunGY[G}vs{zGhjGO[WG}GhP
ZUGjvuulj{G}pklvGjhislG
T jvuulj{GiujGjhislG{vG{olGiujGqhjrUG
kjGXY}GwGz
wGpGaylk
j GaGORP
ishjraOTP
ylkORP
wGz
hjGY[}

7
CAMERA INSTALLATION
Compatibility
1) HTINT70K
) HTINT60K
CVCJBB INTJBS INTCM
CVCJBD
ȥ
Adaptor plate(60PLATE) with rubber

8
CAMERA INSTALLATION
Compatibility
3) HTINT59K
CVCJBD
ȥ
Adaptor plate(59PLATE) with rubber

CAMERA INSTALLATION
9
C#7TI1N The installation instructions in this manual are for use by Sualified serXice
personnel only. To reduce the risk of electric shock, do not perform any serXicing other
than that contained in the operating instructions unless you are qualified to do so.
3AXIS BRACKET
SCREW TS T1, 4X25, TH, SUS, 4EA
SCREW M5X10, HEXAGON SOCKET, SUS, BK, 4EA
WALL
1. HTINT70K

CAMERA INSTALLATION
10
2. HTINT60K
BALL DOME BASE
BALL DOME BODY
BALL DOME
SCREW TS T1, 4X25, TH, SUS, 3EA

CAMERA INSTALLATION
11
3. HTINT59K
VANDAL DOME BASE
VANDAL DOME BODY
BODY OUTER COVER SPECO
SCREW TS T1, 3.5X20, PH, SUS, 3EA

12
1. HTINT70K
LENS ADJUSTMENT
Focus adjustment
Open the cap
Lock screw
Zoom adjustment

13
2. HTINT60K
LENS ADJUSTMENT
Focus adjustment
Lock screw
Zoom adjustment

14
3. HTINT59K
LENS ADJUSTMENT
Focus adjustment
Zoom adjustment
Open the cap

15
Image Sensor
Resolution
Effective Pixels
Total Pixels
Scanning System
S/N Ratio
Frame rate
Video Output
Minimum Illumination
LENS
Electronic Shutter Speed
OSD
BLC
HSBLC
WDR (Wide Dynamic Range)
Digital WDR
Day&Night
White Balance
Smart-IR
Sense-Up
Motion Detection
Motion Tracking (Quick Zoom)
OSD output for Anti Shifting
OSD output for Anti Blocking
3D DNR
Defog
Brightness
AGC
Privacy Masking
Mirror / V-FLIP
Sharpness
LensShading Compensation (LSC)
RS-485(Protocol)
View Angle
CVBS OUTPUT
Communication
Language
Power Supply
Operating Temperature
Lens
Dimension
1/3" 1.3MP SONY Sensor
1000TV Lines
1305(H) X 1049(V), 1.37M Pixels
1312(H) X 1069(V), 1.40M Pixels
Progressive Scan
More than 50dB
MAX 50P/60P
CVBS : 1.0Vp-p/75 Ohm
0Lux(Intensify x64)
DC/MANUAL
AUTO / Manual(1/60Sec ~ 1/60000Sec) / FLICKER
Built-in
O
O
ON(LOW,MIDDLE,HIGH) / OFF
ON(LOW/MIDDLE/HIGH) / OFF
Color / BW / EXTERN / Auto
AATW / AWB / AWC -> SET / MANUAL
0~20(Level Adjustable), Default : 0
x2 ~ x64, Default : x16
ON / OFF (Programmable 4 Zones)
ON/OFF
ON/OFF
ON/OFF
OFF/LOW/MIDDLE/HIGH
ON(AUTO/MANUAL) / OFF
0~20 (Level Adjustable), Default : 10
0~20 (Level Adjustable), Default : 15
ON / OFF (Programmable 16 Zones)
ON/OFF
0~10 (Level Adjustable), Default : 7
ON/OFF
Available
WIDE 4:3 / Normal / WIDE 16:9
NTSC / PAL selectable
Coaxial Control
English
DC12V/AC24V Dual Voltage Operation
-4ºF ~ +140ºF(Humidity : 20%RH ~ 95%RH)
Storage Temperature -4ºF ~ +140ºF(Humidity : 20%RH ~ 95%RH)
DC Auto Iris Varifocal Lens(2.8mm-12mm)
3.94"(W) * 3.94"(H) * 8.27"(D)
Power Consumption DC 12V 590mA / AC 24V 350mA
Weight 3.09 Ibs
HTINT70K
64
SPECIFICATIONS
+7,17.
ʄ
Intensifier K Series
DC #uto Iris 8arifocal .ens .1mm

16
Image Sensor
Resolution
E ective Pixels
Total Pixels
Scanning System
S/N Ratio
Frame rat e
Video Output
Minimum Illuminatio n
LENS
Electronic Shutter Spee d
OSD
BLC
HSBLC
WDR (Wide Dynamic Range )
Digital WD R
Day&Night
White Balanc e
Smart-I R
Sense-Up
Motion Detection
Motion Tracking (Quick Zoom)
OSD output for Anti Shifting
OSD output for Anti Blocking
3D DN R
Defo g
Brightness
AGC
Priv acy Masking
Mirror / V-FLI P
Sharpness
LensShading Compensation (LSC)
RS-485(Protocol)
View Angle
CVBS OUTPU T
Communication
Language
Power Suppl y
Operating Temperature
Lens
Dimension
1/3" 1.3MP SONY Sensor
1000TV Line s
1305(H) X 1049(V) , 1.37M Pixel s
1312(H) X 1069(V) , 1.40M Pixel s
Progressive Sca n
More than 50dB
MAX 50P/60P
CVBS : 1.0Vp-p/75 Oh m
0Lux(Intensify x64)
DC/MAN UAL
AUTO / Manual(1/60Sec ~ 1/60000Sec) / FLICKE R
Built-i n
O
O
ON(LOW ,MIDDLE,HIGH) / OFF
ON(LOW/MIDDLE/HIGH) / OFF
Color / BW / EXTERN / Auto
ATW / AWB / AWC - > SET / MAN UAL
0~20(Level Adjustable), Default : 0
x2 ~ x64, Default : x16
ON / OFF (Programmable 4 Zones)
ON/OFF
ON/OFF
ON/OFF
OFF/LOW/MIDDLE/HIGH
ON(A UTO/MANU AL) / OFF
0~20 (Level Adjustable), Default : 10
0~20 (Level Adjustable), Default : 15
ON / OFF (Programmable 16 Zones)
ON/OFF
0~10 (Level Adjustable), Default : 7
ON/OFF
Available
WIDE 4:3 / Normal / WIDE 16: 9
NTSC / P AL selectabl e
Coaxial Control
English
DC12V/A C24V Dual Voltage Operatio n
-4ºF ~ +140ºF(Humidity : 20%RH ~ 95%RH )
Storage Temperature -4ºF ~ +140ºF(Humidity : 20%RH ~ 95%RH )
DC Auto Iris Varifocal Lens(2.8mm-12mm)
4.65"(Dia) * 3.80"(H)
Power Consumption
DC 12V 570mA/AC 24V 350m A
Weight 1.99 Ibs
HTINT60K
64
SPECIFICATIONS
+7,17.
ʄ
Intensifier K Series
DC #uto Iris 8arifocal .ens .1mm

17
Image Sensor
Resolution
Effective Pixels
Total Pixels
Scanning System
S/N Ratio
Frame rate
Video Output
Minimum Illumination
LENS
Electronic Shutter Speed
OSD
BLC
HSBLC
WDR (Wide Dynamic Range)
Digital WDR
Day&Night
White Balance
Smart-IR
Sense-Up
Motion Detection
Motion Tracking (Quick Zoom)
OSD output for Anti Shifting
OSD output for Anti Blocking
3D DNR
Defog
Brightness
AGC
Privacy Masking
Mirror / V-FLIP
Sharpness
LensShading Compensation (LSC)
RS-485(Protocol)
View Angle
CVBS OUTPUT
Communication
Language
Power Supply
Operating Temperature
Lens
Dimension
1/3" 1.3MP SONY Sensor
1000TV Lines
1305(H) X 1049(V), 1.37M Pixels
1312(H) X 1069(V), 1.40M Pixels
Progressive Scan
More than 50dB
MAX 50P/60P
CVBS : 1.0Vp-p/75 Ohm
0Lux(Intensify x64)
DC/MANUAL
AUTO / Manual(1/60Sec ~ 1/60000Sec) / FLICKER
Built-in
O
O
ON(LOW,MIDDLE,HIGH) / OFF
ON(LOW/MIDDLE/HIGH) / OFF
Color / BW / EXTERN / Auto
ATW / AWB / AWC -> SET / MANUAL
0~20(Level Adjustable), Default : 0
x2 ~ x64, Default : x16
ON / OFF (Programmable 4 Zones)
ON/OFF
ON/OFF
ON/OFF
OFF/LOW/MIDDLE/HIGH
ON(AUTO/MANUAL) / OFF
0~20 (Level Adjustable), Default : 10
0~20 (Level Adjustable), Default : 15
ON / OFF (Programmable 16 Zones)
ON/OFF
0~10 (Level Adjustable), Default : 7
ON/OFF
Available
WIDE 4:3 / Normal / WIDE 16:9
NTSC / PAL selectable
Coaxial Control
English
DC12V/AC24V Dual Voltage Operation
Power Consumption IR LED ON : DC 12V 750mA/AC 24V 165mA, IR LED OFF : DC 12V 400mA/AC 24V 95mA
-4ºF ~ +140ºF(Humidity : 20%RH ~ 95%RH)
Storage Temperature -4ºF ~ +140ºF(Humidity : 20%RH ~ 95%RH)
DC Auto Iris Varifocal Lens(2.8mm-12mm)
5.31"(W) * 3.74"(H) * 11.57”(D)
Weight 3.96 Ibs
HTINT59K
64
SPECIFICATIONS
+7,17.
ʄ
Intensifier K Series
DC #uto Iris 8arifocal .ens .1mm

18
Image Sensor
Resolution
Effective Pixels
Total Pixels
Scanning System
S/N Ratio
Frame rate
Video Output
Minimum Illumination
LENS
Electronic Shutter Speed
OSD
BLC
HSBLC
WDR (Wide Dynamic Range)
Digital WDR
Day&Night
White Balance
Smart-IR
Sense-Up
Motion Detection
Motion Tracking (Quick Zoom)
OSD output for Anti Shifting
OSD output for Anti Blocking
3D DNR
Defog
Brightness
AGC
Privacy Masking
Mirror / V-FLIP
Sharpness
LensShading Compensation (LSC)
View Angle
CVBS OUTPUT
Communication
Power Supply
Lens
Dimension
1/3" 1.3MP SONY Sensor
1000TV Lines
1305(H) X 1049(V), 1.37M Pixels
1312(H) X 1069(V), 1.40M Pixels
Progressive Scan
More than 50dB
MAX 50P/60P
CVBS : 1.0Vp-p/75 Ohm
0.00001Lux
DC/MANUAL
AUTO / Manual(1/60Sec ~ 1/60000Sec) / FLICKER
Built-in
O
O
ON(LOW,MIDDLE,HIGH) / OFF
ON(LOW/MIDDLE/HIGH) / OFF
Color / BW / EXTERN / Auto
ATW / AWB / AWC -> SET / MANUAL
0~20(Level Adjustable), Default : 0
x2 ~ x64, Default : x16
ON / OFF (Programmable 4 Zones)
ON/OFF
ON/OFF
ON/OFF
OFF/LOW/MIDDLE/HIGH
ON(AUTO/MANUAL) / OFF
0~20 (Level Adjustable), Default : 10
0~20 (Level Adjustable), Default : 15
ON / OFF (Programmable 16 Zones)
ON/OFF
0~10 (Level Adjustable), Default : 7
ON/OFF
WIDE 4:3 / Normal / WIDE 16:9
NTSC / PAL selectable
Coaxial Control
DC12V
Power Consumption 120mA
3.6mm Fixed Board Lens
1.34"(W) * 1.34"(H) * 0.65”(D)
Weight 0.66 Ibs
HTINT40K
SPECIFICATIONS
+7,17.
ʄ
Intensifier K Series
3.6mm (ixed Board .ens

19
CAMERA DIMENSION
1) HTINT70K
3.94” dia
3.38”
8.27”
4.80”
2.95”
3.01” 3.46”
) HTINT60K
4.65” dia
3.80”
2.66”
3.01”
