Bosch Tassimo Suny TAS 37 Series User manual

suny
1
TAS31xx
TAS32xx
TAS37xx
GB/CH
en Instruction manual
de Gebrauchsanleitung
fr Mode d’emploi
it Istruzioni per l’uso
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 1C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 1 22.06.2021 08:58:1222.06.2021 08:58:12

a
b
h
1English
6Deutsch
13 Français
20 Italiano
en Safety instructions
de Sicherheitshinweise
fr Consignes de sécurité
it Avvertenze di sicurezza
en At a glance
de Auf einen Blick
fr Présentation
it Panoramica
en Troubleshooting
de Hilfe bei Problemen
fr Aide en cas de problèmes
it Soluzione di guasti
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 2C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 2 22.06.2021 08:58:1222.06.2021 08:58:12

a
b
c
d
b
a
e/f
b
a
c
d
c
b
ab
a
5
4 3 2
6
1
b
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 3C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 3 22.06.2021 08:58:1322.06.2021 08:58:13

T
U
en Risk of electric shock!
de Stromschlaggefahr!
fr Risque de choc électrique !
it Pericolo di scossa elettrica!
en Risk of burns!
de Verbrennungsgefahr!
fr Risque de brûlure !
it Pericolo di ustioni!
V
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 4C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 4 22.06.2021 08:58:1322.06.2021 08:58:13

1
en
Safety instructions
a
For optimum results,  ll the
tank only with cool, fresh,
non-carbonated water each
day.
Do not use chemically softened
water. Never leave the
appliance unattended while it
is in operation!
Saving energy
You should switch o󹈭 your
TASSIMO appliance after every
use in order to save energy.
WRisk of electric shock!
■Operate and connect
the appliance only
in accordance with
theinstructions given on the
nameplate.
■The appliance may only
be connected to a power
supply with alternating
current via a correctly
installed socket with
earthing. Ensure that the
protective conductor system
of the domestic supply has
been correctly installed.
■Before cleaning, switch
o󹈭 the appliance using
the On / O󹈭 switch and
disconnect from the mains.
■Only use your TASSIMO
appliance if the power cable
and appliance show no signs
of damage.
■Disconnect the appliance
from the mains as soon as a
fault is detected.
Intended use
Check the appliance after
unpacking it. Do not connect
the appliance if it has been
damaged in transit.
This appliance is intended for
domestic use only.
Only use the appliance indoors
at room temperature and up to
2000 m above sea level.
Important safety information
Please read parts 1 and 2 of
these manuals carefully before
using the product and keep
them for future reference.
Passthemon to all users.
This appliance may be used
by children aged 8 years and
older and by persons with
reduced physical, sensory or
mental capabilities or who lack
experience and / or knowledge
if they are supervised or have
been given instruction in the
safe use of the appliance and
have understood the dangers
involved. Children may not play
with the appliance.
Cleaning and user maintenance
shall not be made by children
unless they are older than
8years and supervised.
Keep children under 8 years of
age away from the appliance
and connecting cable and
do not allow them to use the
appliance.
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 1C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 1 22.06.2021 08:58:1422.06.2021 08:58:14

2
en
Safety instructions
a
■Any repairs, such
as replacing a damaged
power cable, may only be
carried out by our Customer
Services team in order to
avoid potential danger.
■Never immerse the
appliance or power cable in
water.
■Avoid spillage on the
connector.
■Please note the special
information on cleaning in
the instructions.
WRisk of burns!
■Never attempt to open
the brewing unit during
operation. Pleasenote that
any escaping liquids will
be very hot. TheTDISC,
the piercing unit and the
beverage outlet may be
very hot immediately after
brewing. Allow to cool  rst.
■Do not use TDISCs that are
damaged.
■Only use each TDISC once.
■After the use the heating
element surfaces can be
subjected to residual heat.
■Freshly prepared beverages
are very hot. Leave to cool a
little if necessary.
WRisk of fi re!
■The appliance gets hot.
■Never operate the appliance
in a cupboard.
WRisk of injury!
■A misuse of the appliance
can potentially lead to injury.
■Under no circumstances you
should drink the descaling
liquid.
■The T DISC piercing unit
has sharp cutting edges. Be
careful of your  ngers when
inserting the T DISC or
cleaning it.
WRisk of su󹈭 ocation!
■Do not allow children to play
with packaging material.
■Store small parts safely
as they can be easily
swallowed.
WCaution!
■Cleaning surfaces which
come into contact with
foodstu󹈭 s! Please note
the special information on
cleaning in the illustrated
instructions.
WWarning – Hazard due to
magnetism!
The appliance contains
permanent magnets. They may
a󹈭 ect electronic implants, e.g.
pacemakers or insulin pumps.
■Persons with electronic
implants must stand at
least 10cm away from the
appliance.
■The minimum distance
of 10cm must also be
observed for the water tank
when removed.
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 2C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 2 22.06.2021 08:58:1422.06.2021 08:58:14

3
en
At a glance
b
Before reading on, please unfold the illustrations page at the start of the booklet.
1 On / O󹈭 switch
2 Start / Stop button with
display elements
a Status LED S
b Fill water tank R
c Descale Q
3 Brewing unit
a Lid
b TDISC support
c TDISC piercing unit
d TDISC reading window
e Beverage outlet
f Splash guard
Disposal
g
4 Removable water tank
a max mark
b “Descaling” Qmark
c Float
d Handle
5 Storage compartment
a Yellow Service TDISC
b Brief cleaning / descaling
instructions
6 Cup stand
(removable and height adjustable)
a Drip grate
b Drip tray
Dispose of packaging in an environmen-
tally-friendly manner. This appliance
islabelled in accordance with European
Directive 2012/19/EU concerning used
electrical and electronic appliances
(waste electrical and electronic
equipment – WEEE). The guideline
determines the framework for the
returnand recycling of used appliances
as applicable throughout the EU.
Please ask your specialist retailer about
current disposal facilities.
Info
i
Bosch is the manufacturer of the
TASSIMO machine. Therefore, it cannot
provide any delivery guarantee for the
TASSIMO T DISCs.
TASSIMO TDISCs are available from
specialist retailers.
Or visit www.tassimo.com to discover the
large variety of beverages available and to
order your discs online.
Accessories
j
Accessories Order number
Webshop
Descalingtabs TCZ6004 / 00311909
TCZ6008 / 00312249
www.tassimo.com
www.bosch-home.com
Yellow
Service TDISC
00576836
www.bosch-home.com
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 3C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 3 22.06.2021 08:58:1422.06.2021 08:58:14

4
en
Troubleshooting
h
The following table contains solutions to problems or faults which may occur during
operation of the appliance and that can be easily rectied at home. If you are not satis-
ed with the solutions provided here, please contact our Customer Service department.
Further customer service information can also be found online:
www.tassimo.com
www.bosch-home.com
Problem Cause Solution
The appliance is not
working and none of the
display elements (LEDs)
are lighting.
The appliance has no
power supply.
Check to see whether the appliance is
connected to the mains.
The appliance is not
switched on.
Make sure the appliance has been switched
on.
The brewing starts,
however there is no
beverage dispensed.
The water tank is not
inserted correctly.
Check that the water tank is correctly inserted.
The water tank was
removed during the
brewing stage or there is
air in the system.
Start the cleaning process with the yellow
Service TDISC. Please refer here to the
section First Time Use, Steps 2 – 13.
The float in the water
tank is stuck.
Clean the water tank and free the float.
The brewing will not
start.
No TDISC inserted. Check that a TDISC has been inserted.
The appliance does not
recognise the TDISC bar
code.
Clean the TDISC reading window with a soft,
damp cloth.
Smooth out the foil of the TDISC with your
finger so that the bar code can be read.
Use a new TDISC.
If the problem persists, contact the TASSIMO
careline.
The brewing unit is not
closed properly.
Clean the brewing unit with a soft, damp cloth,
paying particular attention to the lid area.
The appliance was
not switched on when
inserting the TDISC.
Switch on the appliance before inserting the
TDISC
The brewing unit cannot
be closed.
The piercing unit and/
or the TDISC support
have not been correctly
inserted.
Press the piercing unit into its holder using
both thumbs and check the position of the
TDISC support.
The TDISC has not been
correctly inserted.
Replace the damaged TDISC with a new one.
Place the TDISC with the printed side facing
downwards so that the tab is resting in the
intended slot.
The brewing unit is not
closed properly.
Clean the brewing unit with a soft, damp cloth,
paying particular attention to the lid area.
Press the lid down until it audibly clicks into
place.
The brewing unit cannot
be opened.
The brewing unit is still
locked.
Wait until the Status LED Shas stopped
blinking before attempting to open the
brewing unit.
If the brewing unit stays locked, contact the
TASSIMO careline.
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 4C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 4 22.06.2021 08:58:1422.06.2021 08:58:14

5
en
Problem Cause Solution
Fill water tank R
lightsup.
There is not enough
water in the water tank.
Fill the tank with cold, fresh water as far as the
max mark. Reinsert the water tank.
Fill water tankRlights
up even though there
is enough water in the
water tank.
The float in the water
tank is stuck.
Clean the water tank and free the float.
The water tank is not
inserted correctly.
Check that the water tank has been correctly
inserted.
Fill water tank Rand
Descale Qare flashing
simultaneously and it is
not possible to prepare
drinks.
There is a fault on the
machine.
Turn the machine off using the On / Off switch,
wait approximately 5 minutes and turn the
machine back on. If Rand Qare still flashing,
please contact the TASSIMO careline.
Descale Qlights up or
starts flashing.
The appliance needs to
be descaled.
Descale the appliance. Please refer here to the
section Descaling. Do not use descaling agent
with phosphoric acid.
Descale Qlights up
or starts flashing even
though decalcified water
has been used.
Even decalcified water
contains low amounts of
calcium carbonate.
Descale the appliance. Please refer here to the
section Descaling. Do not use descaling agent
with phosphoric acid.
The quality of the crema
has deteriorated.
The beverage outlet is
sticky or dirty.
Clean the beverage outlet. Please refer here to
the section Cleaning.
Clean the brewing unit with the yellow Service
TDISC. Please refer here to the section
Cleaning.
Build-up of limescale in
the appliance.
Descale the appliance. Please refer here to the
section Descaling. Do not use descaling agent
with phosphoric acid.
Water is dripping from
the brewing unit.
The TDISC is damaged
or leaky.
The TDISC has not been
pierced correctly.
Do not use TDISCs that are damaged.
Only use each TDISC once.
Wait until the brewing stage has come to
an end and the appliance has cooled down.
Remove the TDISC and clean the brewing unit.
Please refer here to the section Cleaning.
The piercing unit has not
been inserted correctly.
Press the piercing unit into its holder using
both thumbs (until an audible click is heard).
On the surface below
the cup stand there is
water.
This is condensation. Condensation may appear and is not caused
by any fault with the appliance. Wipe the water
away with a cloth.
The yellow Service
TDISC is damaged or
lost.
The yellow Service TDISC can be requested
from Bosch Customer Services (item no.
00576836, contact information included at the
end of these instructions).
The beverage quantity
does not meet your
requirements.
The TDISC bar
code provides the
recommended volume
for every beverage
selected. This volume
can also be adapted to
personal requirements.
Reduced quantity:
During the brewing process, press the
Start / Stop button to interrupt this stage.
Increased quantity:
Press and hold the Start / Stop button until the
required beverage quantity has been reached.
Build-up of limescale
in the appliance could
cause reduced quantity.
Descale the appliance. Please refer here to the
section Descaling. Do not use descaling agent
with phosphoric acid.
Troubleshooting
h
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 5C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 5 22.06.2021 08:58:1422.06.2021 08:58:14

6
de
Sicherheitshinweise
a
Kinder unter 8Jahren sind vom
Gerät und der Anschlussleitung
fernzuhalten und dürfen das
Gerät nicht bedienen.
Füllen Sie täglich ausschließlich
frisches, kaltes Wasser
(keinMineral wasser mit Koh-
lensäure) in den Wassertank.
Verwenden Sie kein chemisch
entkalktes Wasser.
Das Gerät während des
Betriebs stets beaufsichtigen.
Energie sparen
Sie sollten Ihr TASSIMO Gerät
aus Energiespargründen nach
jedem Gebrauch ausschalten.
WStromschlaggefahr!
■Betreiben und schließen
Sie das Gerät nur gemäß
den Angaben auf dem
Typenschild an.
■Das Gerät darf nur über eine
vorschriftsmäßig installierte
Steckdose mit Erdung an ein
Stromnetz mit Wechselstrom
angeschlossen werden.
Stellen Sie sicher, dass
das Schutzleitersystem der
elektrischen Hausinstallation
vorschriftsmäßig installiert
ist.
■Schalten Sie vor der
Reinigung das Gerät mit
dem Ein / Aus Schalter
aus und ziehen Sie den
Netzstecker.
Bestimmungsgemäßer
Gebrauch
Das Gerät nach dem Aus-
packen prüfen. Bei einem
Transportschaden nicht
anschließen.
Dieses Gerät ist nur für den
privaten Haushalt und das
häusliche Umfeld bestimmt.
Das Gerät nur in Innenräumen
bei Raumtemperatur und bis
zu 2000m über Meereshöhe
verwenden.
Wichtige Sicherheitshinweise
Lesen Sie die Gebrauchs-
anleitungen Teil1 und 2
sorgfältig durch, handeln
danach und bewahren die
Anleitungen auf. Geben Sie sie
an alle Benutzer weiter.
Dieses Gerät kann von Kindern
ab 8 Jahren und darüber und
von Personen mit reduzierten
physischen, sensorischen oder
mentalen Fähigkeiten oder
Mangel an Erfahrung und / oder
Wissen benutzt werden, wenn
sie beaufsichtigt oder bezüg-
lich des sicheren Gebrauchs
des Gerätes unterwiesen
wurden und die daraus resul-
tierenden Gefahren verstanden
haben. Kinder dürfen nicht mit
dem Gerät spielen. Reinigung
und Benutzer-Wartung dürfen
nicht durch Kinder vorgenom-
men werden, es sei denn, sie
sind 8 Jahre oder älter und
werden beaufsichtigt.
C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 6C8_TAS31-32-37_TEXT_GBCH_8001224674.indb 6 22.06.2021 08:58:1522.06.2021 08:58:15
