ANGLE GRINDER 1853-5
24.10.2005
22:24:44
Pa
g
e 1 of 5
10/24/2005htt
p
://le11288.le.de.bosch.com/sid/
p
rintdirect.as
p
?ID
_
PRODUCT=0601852B61&ID
_
VE...

Item Quantity Order No. Designation Price
group Page
1 1 1 605 108 240 MOTOR HOUSING \ BLUE 28 1
2 1 1 604 220 385 FIELD \ 100-120V 38 1
5 1 1 604 460 133 MAINS CONNECTION CABLE \ USA/CDN 2,15m 2 x 2,08mm SJ
14/2 1
6 1 1 600 703 023 GROMMET \ Ø10,5-Ø11x100 MM 12 1
7 1 1 601 302 018 FASTENING CLAMP 11 1
9 1 1 601 118 F38 MANUFACTURER'S NAMEPLATE 15 1
23 21 605 500 206 LOCKING COVER \ BLUE 16 1
24 11 605 132 141 HANDLE \ BLUE 22 1
25 11 603 523 117 GRINDING SPINDLE \ 5/8" 30 1
26 11 606 333 271 CROWN GEAR \ Z=49 44 1
27 11 606 333 252 BEVEL GEAR \ Z=9 40 1
28 11 600 210 033 O-RING \ 80x1,8 MM 11 1
29 11 600 210 045 O-RING \ 8x1 MM 11 1
30 11 600 591 029 AIR DISTRIBUTOR 13 1
31 11 600 591 028 AIR-DEFLECTOR RING 13 1
32 11 600 290 019 RETAINING RING 11 1
33 11 600 290 013 RADIAL-LIP-TYPE OIL SEAL \ RED 13 1
34 11 600 190 020 SHIM \ 0,15 MM 11 1
34 11 600 190 021 SHIM \ 0,30 MM 11 1
34 11 600 190 022 SHIM \ 0,10 MM 11 1
34 11 600 190 037 SHIM \ 0,20 MM 10 1
34 11 600 190 038 SHIM \ 0,25 MM 10 1
34 11 600 190 039 SHIM \ 0,35 MM 10 1
34 11 600 190 040 SHIM \ 0,40 MM 10 1
35 11 600 205 034 FELT WASHER 11 1
37 11 600 290 050 SEAL RING \ RED 14 1
38 11 600 206 020 RUBBER RING \ 7 MM \ WIDE 11 1
39 11 600 206 030 RUBBER RING 11 1
45 11 603 300 019 HEXAGON NUT \ M10, SW14 11 1
51 11 600 200 031 FRICTION BEARING \ Ø14 MM 11 1
53 11 605 190 068 SOCKET HOUSING 11 1
59 11 600 101 655 PLAIN WASHER 11 1
60 41 603 435 023 THREAD-FORMING TAP. SCREW \ TT M5x18 MM 11 1
61 62 912 401 038 SELF-TAPPING SCREW \ DIN 7981-4,8x38-C-Z-ST 10 1
63 21 603 410 014 SLOTTED PAN-HEAD SCREW \ M4x10 MM 11 1
64 41 603 435 042 SELF-CUTTING SCREW 11 1
65 22 912 401 020 SELF-TAPPING SCREW \ DIN 7981-3,9x19-C-Z-ST 1
66 12 910 211 019 SELF-TAPPING SCREW \ DIN 7971-ST3,9x16-F 10 1
68 11 601 006 011 SEALING PLATE 11 1
75 11 600 290 057 DAMPING ELEMENT 29 1
76 41 603 414 016 COLLAR SCREW \ TORX-PLUS-20-IP 11 1
78 11 900 210 111 O-RING \ 12x3 MM 13 1
79 11 600 171 001 LOCKING WASHER 11 1
131 11 601 118
G66 REFERENCE PLATE 15 1
650 11 602 025 030 AUXILIARY HANDLE \ M14, Ø37x115 MM \ BLACK 27 2
800 11 607 000 380 PARTS SET 26 2
803 11 604 011 178 ARMATURE \ 100-120V 45 1
804 11 607 000 704 ON-OFF SWITCH 36 1
