Bosch Compress 5800iAW 12 E | OR-S | T User manual

6721871228 (2023/06) UK
Operating Instructions
Air to water heat pump
Compress 5800iAW 12 E | OR-S | T
0010039138-002
Heat pump with indoor unit

Table of contents
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
2
Table of contents
1 Explanation of symbols and safety instructions . . . . . . . . . . . 3
1.1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . 3
1.2.1 Application area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Protection zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1.1 Protection zone, ground-placed heat pump by wall . . . . . 4
2.1.2 Protection zone, ground-placed heat pump free
standing or on a flat roof . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1.3 Protection zone, ground-placed heat pump in a
corner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2 Data plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 Heat pump (outdoor unit) . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3.1 Range for heat pump without booster heater. . . . . . . . . 4
2.3.2 Generic overview of the refrigerant circuit . . . . . . . . . . . 5
2.4 Indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.5 Hints on energy saving. . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.6 Control unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.6.1 Overview of control elements and symbols . . . . . . . . . . 6
3 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 Shutting-down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 Main menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1 Heating settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.2 DHW settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.3 Solar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.4 Energy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.5 Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.1 Indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
5.1.1 Check system pressure . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.1.2 Particle filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.1.3 Overheating protection . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.1.4 Moisture in cooling mode. . . . . . . . . . . . . . . . . . . . . . . . 13
5.1.5 Safety valves. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.2 Heat pump (outdoor unit) . . . . . . . . . . . . . . . . . . . . . . . 14
5.2.1 Housing (casing) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.2.2 Evaporator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.2.3 Snow and ice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.3 Faults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6 Environmental protection and disposal . . . . . . . . . . . . . . . . . 14
7 Data Protection Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8 Open Source Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8.1 List of used Open Source Components . . . . . . . . . . . . 15
8.2 Appendix - License Text . . . . . . . . . . . . . . . . . . . . . . . . . 16
8.2.1 Apache License 2.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8.2.2 BSD 3-Clause New or Revised License . . . . . . . . . . . . . 17
8.2.3 License for STM32CubeMX (STMicroelectronics) . . . . 17
8.2.4 MIT License. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9 Display of consumption values in relation to the
funding guidelines for federal funding for efficient
buildings - individual measures (BEG EM) . . . . . . . . . . . . . . . 18
10 Technical terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
11 Overview Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Explanation of symbols and safety instructions
3
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
1 Explanation of symbols and safety instructions
1.1 Explanation of symbols
Warnings
In warnings, signal words at the beginning of a warning are used to
indicate the type and seriousness of the ensuing risk if measures for
minimizing danger are not taken.
The following signal words are defined and can be used in this document:
DANGER
DANGER indicates that severe or life-threatening personal injury will
occur.
WARNING
WARNING indicates that severe to life-threatening personal injury may
occur.
CAUTION
CAUTION indicates that minor to medium personal injury may occur.
NOTICE
NOTICE indicates that material damage may occur.
Important information
The info symbol indicates important information where there is no risk to
people or property.
Additional symbols
Table 1
1.2 General safety instructions
1.2.1 Application area
The heat pump may only be used in sealed heating systems according to
EN 12828.
Other uses are not appropriate. Any damage that results from such use is
excluded from liability.
The heat pump must undergo maintenance according to EN1717 4.6.
HSafety of electrical devices for domestic use and similar
purposes
The following requirements apply in accordance with EN 60335-1 in
order to prevent hazards from occurring when using electrical
appliances:
“This appliance can be used by children of 8 years and older, as well as
by people with reduced physical, sensory or mental capabilities or
lacking in experience and knowledge, if they are supervised and have
been given instruction in the safe use of the appliance and understand
the resulting dangers. Children shall not play with the appliance.
Cleaning and user maintenance must not be performed by children
without supervision.”
“If the power cable is damaged, it must be replaced by the manufacturer,
its customer service department or a similarly qualified person, so that
risks are avoided.”
HDanger of fire or explosion of flammable gases
The product contains the flammable refrigerant R290. If a leak occurs,
the refrigerant may form a combustible gas due to mixing with air. There
is a risk of fire and explosion.
A protection zone is defined around the product; see the "Protection
zone" chapter.
▶ Make sure that no sources of ignition are present near the protection
zone, especially open fires, surfaces hotter than 370 °C, spray or
other gases that could ignite.
HInspection and maintenance
If there is a lack of cleaning, inspection or maintenance, or if these are
carried out incorrectly, this may result in material damage and/or
personal injury, including possible risk to life.
▶ Have work carried out only by an approved contractor.
▶ Do not take off the heat pump cover.
▶ Do not modify the heat pump or other parts of the heating system.
HRoom air
The air in the installation room must be free of combustible or chemically
aggressive substances.
▶ Do not use or store combustible or explosive materials (paper,
propellants, thinners, paints, etc.) within the vicinity of the
appliance.
▶ Do not use or store corrosive substances (solvents, adhesives,
chlorinated cleaning agents, etc.) within the vicinity of the appliance.
HDamage caused by frost
The solar system can freeze if it is switched off:
▶ Observe the notices regarding frost protection.
▶ Due to the additional functions, e.g. DHW heating or pump anti-
seizure protection, the system should always be left on.
▶ Correct any faults immediately.
HRisk of scalding at the DHW draw-off points
▶ If DHW temperatures above 60 °C are set or if thermal disinfection is
activated, a mixer must be installed. If in doubt, ask your installer.
2 Product description
Heat pump AW OR is included with the unit Compress 5800i 12 E in a
series of heating pumps that extract energy from the outdoor air to
provide water-borne heat and hot water. By turning the process over and
taking up heat from the water and placing it in the outdoor air, the plant
can produce cooling if necessary. However, this requires that the heating
system is intended for cooling operation.
The heating system is controlled by a control unit located in the inside
unit. The control unit controls and monitors the system with the help of
various settings for heating, cooling, hot water and other operations. The
monitoring function closes e.g. of the outdoor unit in case of any
malfunctions so that no vital parts are damaged.
2.1 Protection zone
The product contains the refrigerant R290 that has a density greater
than air. If a leak occurs, the refrigerant could accumulate near the
ground. The refrigerant must therefore be prevented from collecting in
niches, drains, gaps, other sinks, hollows or depressions in the building.
No building openings such as light shafts, hatches, valves, open down
pipes, cellar entrances, windows, doors, roof vents and roof drainage
systems, pump shafts, inlets in sewers, waste water shafts, etc. are
permitted within the defined protection zone around the product. The
protection zone must not overlap general areas or adjacent plots.
Symbol Meaning
▶ a step in an action sequence
a reference to a related part in the document
• a list entry
– a list entry (second level)

Product description
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
4
No sources of ignition such as contactors, lamps or electrical switches
are permitted within the protection zone. The defined protection zones
are also applicable for installations on pitched roofs, with the addition
that no openings to the building and no sources of ignition are allowed
below the product.
No structural changes are allowed in the protection zone that violates the
rules mentioned above for the protection zone.
2.1.1 Protection zone, ground-placed heat pump by wall
Fig. 1 Protection zone ground-placed
[A] 1000 mm
[B] 1000 mm
2.1.2 Protection zone, ground-placed heat pump free standing or
on a flat roof
Fig. 2 Protection zone ground-placed on plot or roof
[A] 1000 mm
[B] 1000 mm
[F] Front
2.1.3 Protection zone, ground-placed heat pump in a corner
Fig. 3 Protection zone ground-placed in a corner
[A] 1000 mm
[B] 2000 mm
2.2 Data plate
• AW OR: The data plate is located on the rear side of the heat pump.
• Compress 5800i 12 M: The data plate is located inside of the indoor
unit. For the exact location (the installation instructions of the
appliance).
The data plate contains information on output, item number, serial
number and date of manufacture.
2.3 Heat pump (outdoor unit)
The heat pump is inverter operated, which means that it will
automatically change the compressor speed to deliver the exact amount
of energy required at the moment. The fan is also RPM controlled and will
change its speed as needed. This provides the lowest possible energy
consumption.
The speed changes have an effect on the sound emissions, as higher
speed results in higher sound emission.
Defrosting
Ice might form on the evaporator during lower outside temperatures. In
case there is enough ice to inhibit the air flow through the evaporator, an
automatic defrosting will start. As soon as the ice is gone, the heat pump
returns to its normal operation.
If the outside temperature is above +5 °C the defrosting will be
performed alongside continued heat production, however if the
temperature is lower, the defrosting is done by ways of a 4-way valve
turning the heat medium direction in the circuit so that the hot gas from
the compressor melts away the ice. The duration of the defrost cycle
depends on the actual outdoor temperature and the amount of frost on
the evaporator.
2.3.1 Range for heat pump without booster heater
In heating mode the heat pump switches off at approx. – 23 °C or +45 °C
outdoor temperature. The indoor unit or an external heat source then
takes over the heating and domestic hot water production. The heat
pump restarts if the outdoor temperature exceeds roughly – 17 °C or
falls below +42 °C.
In cooling mode, the heat pump switches off at roughly +45 °C and
restarts at roughly +42 °C.
A A
B
0010037106-006
A
A
0010037107-005
B
F
A
0010037110-005
B

Product description
5
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
Fig. 4 Heat pump in heating mode without booster heater
[1] Flow temperature (T0)
[2] Outdoor temperature (T1)
Fig. 5 Heat pump in cooling mode
[1] Flow temperature (T0)
[2] Outdoor temperature (T1)
2.3.2 Generic overview of the refrigerant circuit
Fig. 6 Functional principle of the refrigerant circuit in the heat pump
[1] Evaporator
[2] Compressor
[3] Condenser
[4] Expansion valve
2.4 Indoor unit
The task of the indoor unit is to distribute the heat from the heat pump to
the heating system and the hot water cylinder. The circulation pump in
the indoor unit module is RPM controlled, and will automatically
decrease in speed when demand is low. This decreases energy
consumption. When the heating demand is higher during cold outdoor
temperatures, an additional heat source - a booster - may be required.
This booster heater is integrated, an its on/off is controlled by the user
interface in the indoor unit. Please note that when the heat pump is
running, the booster heater will only provide the heating output that the
heat pump cannot produce itself. When the heat pump is able to provide
all the heating needed, the booster is automatically turned off.
Compress 5800i 12 E
When heat pump AW OR is connected to indoor unit Compress 5800i 12
E, an external domestic hot water cylinder is required if the purpose of
the heat pump is also to produce domestic hot water (DHW). In this case,
switching between heating and DHW is managed by an internal 3-way
valve. The integrated booster in the indoor unit will turn on if needed.
35
45
55
60
-30
T1[°C]
T0[°C]
25
15
10
-20 0-10 10 20 30 40
1
2
65
70
75
50
0010038451-003
15
20
25
30
T1[°C]
T0[°C]
10
5
2015 25 30 35 40
1
2
45
7
0010041081-002
+27 °C
75 %
+35 °C+2 °C –2 °C
0 °C 88 °C
–4,5 °C 50 °C
25 % 100 %
12
4
3

Product description
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
6
Fig. 7 Heat pump AW OR, indoor unit Compress 5800i 12 E with immersion heater and external domestic hot water cylinder
2.5 Hints on energy saving
• Use the normal heating mode, thus the heating system will use the
least energy. Set the desired room temperature according to your
personal comfort needs.
• Open the thermostatic vents fully in all rooms. Increase the
temperature setting on the control only when the desired room
temperature has not been reached for some time. Close the
thermostatic valve in a specific room, only if that room is warmer then
the others.
• If there is a room controller installed, this can be used to set the
optimal room temperature. Avoid influence of external heating (i.e
sunlight or wood stove). Otherwise unwanted fluctuations in the
room temperature may occur.
• Avoid placing big objects e.g. a sofa in front of the radiators
(minimum 50 cm distance). This will block the circulation of the
heated air in the room.
• Do not set a too low temperature for cooling. Cooling will also
consume energy.
Vent the room correctly
Open the windows fully for a short period instead of leaving them ajar.
Leaving the windows ajar will let the heated air out of the room constantly
without increasing the air quality. Close the thermostatic valves or lower
the heating setting on the room controller while the room is vented.
2.6 Control unit
If a room controller is installed, the thermostatic valves in the reference
room (the room in which the remote control is installed) must be fully
open!
Depending on the software version of the user interface, the texts shown
in the display may differ from the texts in these instructions.
The adjustment ranges, default settings and functional scope may differ
from the information in these instructions, depending on the system
installed at the site.
• If special system components and modules are installed,
corresponding settings are available and necessary.
2.6.1 Overview of control elements and symbols
This control panel has a touch screen. Use your finger to scroll between
menus and click on specific items to select them.
In each installation only menus of the installed modules or components
are shown. The menu items shown may vary between different countries
and markets.
In the manual the displays are shown from left to right. The display shown
as the start screen in the heat pump depends on which settings have
been selected and which accessories are installed.

Product description
7
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
Fig. 8 Control Panel
[1] Menu key: Displays the menus where general settings for the
system can be selected.
[2] System overview: Provides a graphical overview of the current
status of the heat pump. The submenu More… shows a complete
status list for the entire system.
[3] Status lamp: Normally green. Changes color to red or yellow if
there is an error in the system.
[4] Status: Shows the status of the system. A green tick shows that
no alarms are active in the heat pump system. A warning triangle
shows that one more alarms are active. Click on the warning
triangle for more information.
Outside temperature: Shows current outside temperature.
[5] Heating circuit 1: Shows measured temperature and direct
access to menu to change temperature, heating circuit 1.
[6] Scrolling arrow: Click this to move between menus, or swipe left
or right with your finger on the display.
[7] Scroll bar: Shows which set of menus is currently visible.
Fig. 9
[1] Hot water: Direct access to change DHW mode.
[2] Ventilation: Direct access to menu to change ventilation settings.
Fig. 10 Control Panel
[1] Present: Direct access to settings for presence/absence. By
changing to absence, the room temperature is lowered and the
domestic hot water is set to ECO+.
[2] Solar: Direct access to status of solar thermal system.
[3] Holiday: Direct access to settings for holiday mode.
[4] Energy: Displays sub menus for Energy monitoring.
Fig. 11 Control Panel
[1] Cleaning: By clicking on this, the display locks for 15 seconds so
that it can be cleaned without making any involuntary settings.
If the display is off, the lighting only lights up if it is touched once. The
description of the settings assumes that the display is lit. if no menus are
activated, the display will turn off automatically (after about 2 minutes
with the default setting).
Certain functions are only shown in the display when the function is
activated or accessory is installed.
The system overview shows the status of the heat pump and
temperatures in the system and surroundings.
0010035046-005
6
5
2
1
3
4
7
2
1
0010044163-001
2
1
4
3
0010042067-002
1
0010042068-001

Operation
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
8
Fig. 12 System overview
[1] Key to return to the main menu
[2] Display of date and time
[3] Status display of Wi-Fi active, radio transmission active (for
wireless sensor) and internet connection active
[4] Display of outdoor air temperature
[5] Display of temperatures to and from the outdoor unit
[6] Help menu
[7] Display of flow temperature
[8] Display of return temperature
[9] Display of DHW temperature
[10] More…, for additional settings
More…
Table 2 More settings
3 Operation
WARNING
Material damage from frost!
The heating or auxiliary heater may be irreparably damaged by frost.
▶ Do not start the heat pump if there is a possibility of the heating or
auxiliary heater being frozen.
8
7
6
9
4
3
2
1
0010044162-001
10
5
Menu item Description
Settings ▶ Alternating operation. Select On to activate DHW
alternating operation. Select Off to deactivate
DHW alternating operation.
▶ Time prog., add. heater.
– Select On to activate time program. Select
Off to deactivate time program.
– Edit. Setting a time program for the booster
heater.
– Reset. To reset, press Yes. To return without
resetting, press No.
– Time prog. min. outdoor temp.. Select the
temperaturelimitto automaticallydisablethe
booster heater program.
▶ PV system
– Incr. the desired temp.. The energy available
in the PV system is used for heating, if the
system is in heating mode.
Set how much the room temperature may be
increased.
– Greater hot water covenience. The energy
available in the PV system is used for DHW.
[Yes] | [No]
If enabled the DHW is heated to the
temperature set for DHW operating mode
[Comfort]. No DHW heating is done if the
holiday program is active.
– Red. the desired temp.. The energy available
in the PV system is used for cooling, if the
system is in cooling mode.
– Cooling only with PV energy. Cooling mode is
activated only if energy is available in the PV
system.
[Yes] | [No]
No cooling is done if the holiday program is
active.
▶ Smart grid
– Selectable rise. Set how much the room
temperature may be increased.
– Greater hot water covenience [Yes] | [No]
If enabled the DHW is heated to the
temperature set for DHW operating mode
[Comfort]. No heating is done if the holiday
program is active.
▶ Restore installer settings. To return to saved
installer settings, select Yes; to exit without
making any changes, select No.
Heat pump
status
▶ Shows the heat pump's operating status.
Statistics ▶ Shows the statistics for the heat pump
operation.

Main menu
9
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
An overview of the structure of the main menu and the position of the
individual menu items can be found at the end of this document.
The info menu is useful to get instant information of the status of the heat
pump.
Each of the following descriptions takes the standard display as its
starting point.
3.1 Shutting-down
The unit is normally switched on. The system is only switched off for
maintenance purposes, for example.
Standby means that the system is completely switched off and no safety
functions, such as frost protection, are active.
▶ To temporarily switch off the system:
– Select the option > Menu in the start menu
– Select Expert view > On for more menu options.
– Select Standby mode in the list
–PressYes
▶ To switch on the system:
– Press on the display.
– Select Yes.
▶ To switch off the system permanently: interrupt the power supply to
the whole system and all BUS participants.
After a prolonged power failure or extended period of idleness, the date
and time must be reset. All other settings are retained permanently.
4 Main menu
Depending on the heating appliance and how the user interface is used,
not all menu items will be available for selection.
4.1 Heating settings
Menu > Heating circuit 1
Table 3 Heat settings for heating circuit 1
If there are other heating circuits installed, repeat the settings above for
each heating circuit.
CAUTION
Risk of damage to the system!
▶ Do not switch over to summer mode if there is a risk of frost.
If cooling function is enabled, the heating menu changes as in the table
below.
Menu > Heating circuit 1
Menu item Description
Set operating
modeforHeating
circuit 1
▶ Select Off to switch off the heating circuit. Select
Auto for automatic control of the heating circuit
according to the time program. Select Manual to
set continuous operation of the heating circuit.
▶ Set the desired room temperature in this menu
by scrolling left or right on the scale. Save the
new setting with Confirm,
-or-
go back without making any changes with
Cancel.
Click on More… for additional settings.
Season switch
HC1
In the summer, the heating mode can be switched
off for the selected heating circuit. The DHW mode is
not affected by this setting.
▶ Select Auto for automatic switchover between
summer and winter mode.
▶ Select Heating for continuous heating mode.
▶ Select Cooling for continuous cooling mode.
Heating off from Set the temperature at which the heat pump must
change from summer to winter mode by scrolling up
or down the scale. Save the new setting with
Confirm,
-or-
go back without making any changes with Cancel.
Display time
program HC1
Select Yes to activate
-or-
No to deactivate.
Desired room
temp.
[5...21...30] °C. Set the desired room temperature.
Time program If a time program has been activated, this menu is
shown.
▶ Edit. Set schedule for time control.
▶ Reset. Select Yes to reset
-or-
No to return without resetting.
▶ Temperature settings. Heating. Set desired
normal temperature. Setback. Set how much the
temperature should be reduced by in night
reduction mode.
Rename heating
circuit
Enter a new name for the heating circuit using the
keyboard shown in the display. Save the new setting
with Confirm,
-or-
go back without making any changes with the cross
(X) in the top right corner.
Menu item Description
Set operating
mode for
Heating circuit
1
▶ Select Off to switch off the heating circuit. Select
Auto for automatic control of the heating circuit
according to the time program. Select Manual to
set continuous operation of the heating circuit.
▶ Set the desired room temperature in this menu
by scrolling left or right on the scale. Save the
new setting with Confirm,
-or-
go back without making any changes with
Cancel.
Click on More… for additional settings.
Season switch
HC1
In the summer, the heating mode can be switched
off for the selected heating circuit. The DHW mode is
not affected by this setting.
▶ Select Auto for automatic switchover between
summer and winter mode.
▶ Select Heating for continuous heating mode.
▶ Select Cooling for continuous cooling mode.
Menu item Description

Main menu
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
10
Table 4 Heat settings for heating circuit 1
If there are other heating circuits installed, repeat the settings above for
each heating circuit.
4.2 DHW settings
WARNING
Danger to health from legionella!
Legionella can form in domestic hot water at DHW temperatures that are
too low.
▶ Activate thermal disinfection.
▶ Observe the statutory regulations on drinking water.
WARNING
Risk of scalding!
If automatic thermal disinfection has been activated to avoid legionella,
the DHW is heated once to 65 °C (e.g. every Tuesday night at 02:00).
▶ Only carry out thermal disinfection outside normal hours of use.
▶ Make sure that a thermal mixer is installed. If in doubt, ask your
installer.
Menu > Hot water
Table 5 DHW settings
Heating •Heating off from Set the outdoor temperature
at which the heat pump must change from
summer to winter mode by scrolling up or down
the scale.
•Display time program HC1
Select Yes to activate
-or-
No to deactivate.
•Heat. mode HC1
•Desired room temp. Set the desired room
temperature.
•Time program.
Cooling •Cooling on from Set the outdoor temperature at
which the heat pump must change to cooling
mode by scrolling up or down the scale.
•Desired room temp. cooling Set the desired
room temperature.
•Cooling mode HC1.
Renameheating
circuit
Enter a new name for the heating circuit using the
keyboard shown in the display. Save the new setting
with Confirm,
-or-
go back without making any changes with the cross
(X) in the top right corner.
Menu item Description
Menu item Description
Set operating
mode for Hot
water
▶ Select Off to switch off DHW production.
Select Auto for automatic time control of the
DHW production.
Select Manual to set continuous operation of
DHW production.
▶ Set the desired operating mode for DHW
production in this menu by scrolling left or right
on the scale.
Eco+ provides the best operating economy,
Comfort provides the best DHW comfort.
Save the new setting with Confirm,
-or-
go back without making any changes with
Cancel.
Extra hot water [1...2...48] hours. Set the desired time for how long
extra DHW mode should be on. Confirm extra DHW
with Start extra hot water. It is possible to cancel
extra DHW production while it is activated by
pressing Stop extra hot water.
Click on More… for additional settings.
Time program ▶ Select Edit to schedule DHW production.
▶ Reset. Select Yes to reset
-or-
No to return without resetting.
Thermal
disinfection
▶ Start. Start thermal disinfection immediately.
▶ Stop. Stop thermal disinfection immediately.
▶ Auto. Select On to start automatic time control of
thermal disinfection. Select Off to switch off
automatic disinfection.
▶ Daily/weekday. Set which day thermal
disinfection should be activated, or select Daily.
▶ Time of Day. Set what time of day thermal
disinfection should be activated.
Hot water
circulation pump
▶ Operation mode. Select Off to switch off DHW
circulation. Select On for permanent operation
of DHW circulation. Select Hot water set
temperaturetocontrolDHWcirculation basedon
the set DHW temperature. Select Auto for
operation according to time program.
▶ Start frequency. Select Permanent for
permanent operation of DHW circulation. Select
Interval to set an interval during which DHW
circulation is activated. An interval is a pump run
of 3 minutes. Value [1...6] refers to the number
of starts per hour. Value [7] means that the
pump runs continuously.
▶Time program. Select Edit to schedule DHW
production. Reset.
Select Yes to reset
-or-
No to return without resetting.
Activate time
program
Select Yes to activate
-or-
No to deactivate.
Red.HWtemp on
alarm
Select Yes to activate, then the hot water
temperature will be set to 35 °C for further fault
detection in the event of a compressor alarm.
-or-
No to deactivate.
Measured
temperature
Shows current DHW temperature.

Main menu
11
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
Menu > Holiday
Table 6 Holiday settings
CAUTION
Risk of system damage!
▶ Before a prolonged period of absence, only change the settings
under Holiday.
▶ After a long absence, check the operating pressure of the heating
system.
4.3 Solar
Information about the solar thermal system is shown in the information
menu. No changes can be made in this menu.
Table 7 Information menu that shows the status and energy production
of the solar thermal system
4.4 Energy
The energy statistics of the system are indicated in this menu. Only the
information on functions and accessory components actually installed in
the heat pump and in the system are displayed.
Table 8 “Energy staistics” menu
Menu item Description
Holiday ▶ From. Set the start date/time for absence: the
holiday program starts at the set date/time.
Select Confirm to confirm or Cancel to return
without making changes.
▶ To:. Set the end date/time for absence: the
holiday program ends at the set date/time.
Select Confirm to confirm or Cancel to return
without making changes.
Click on Advanced settings for additional settings.
Apply settings to Select which functions (heating circuits, DHW
productionandventilation) thatwillbe controlledby
the holiday setting.
Heating Select how DHW production will be controlled by the
holiday setting.
▶ Off. To switch off heat production for the set
time.
▶ On. To change to set temperature for the set
time.
Desired room
temp.
[10...17...30] °C. Set the desired room
temperature for the period that the holiday function
is activated.
Select Confirm to confirm
-or-
Cancel to return without making changes.
Hot water Select which DHW setting should be active during
the holiday setting.
▶ Off. To switch off DHW production for the set
time.
▶ Eco+. To change DHW production to Eco+ for the
set time.
▶ Eco. To change DHW production to Eco for the
set time.
▶ Comfort. To change DHW production to Comfort
for the set time.
Ventilation Select how ventilation will be controlled by the
holiday setting.
▶ Off. To switch off ventilation for the set time.
▶ Level. [1...4]. To set the ventilation level for the
set time.
▶ Demand. To set the demand-controlled
ventilation for the set time.
Menu item Description
Solar ▶ Shows the solar thermal system configuration.
Click on Advanced settings for additional settings.
Solar sensor
overview
▶ Shows the system sensors
Solar yield
overview
▶ Shows statistics on energy produced
Meu item Description
Energy Display of the system energy statistics. Overview of
the total energy generated, specified by energy
source, e.g. proportion of ambient energy,
proportion of the heat pump (electricity energy for
compressor operation) and proportion of auxiliary
heater.
• Select Total to display the energy statistics of the
system since being commissioned.
• To display the statistics for a specific year, select
the respective year. Display the statistics since
commissioning.
Select More… to display more energy statistics.
Energy
consump.
Display of the statistics for energy consumption.
Select Total or a specific year.
• Total
•Heating
•Cooling
• Hot water
• Ventilation
ProducedEnergy
Total
Display of the statistics for energy generation.
Select Total or a specific year.
• Total
•Heating
•Cooling
• Hot water
• Ventilation
Efficiency Display of the statistics for effectiveness. Select
Total or a specific year.
• Total
•Heating
•Cooling
• Hot water
• Ventilation
Reset Resetting the yearly energy statistics. Select Yes to
reset. The values since commissioning are not
deleted.
-or-
Select No to go back without resetting.
Menu item Description

Maintenance
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
12
4.5 Settings
Menu > Press menu button in the Start menu at the top on the left to call
up the "General settings" menu.
Table 9 General Settings
Standby means that the system is completely switched off and no safety
functions, such as frost protection, are active.
5 Maintenance
DANGER
Risk of electric shock.
Grave personal injuries may occur.
▶ Disconnect the power supply before carrying out maintenance work.
Using the wrong cleaning product may damage the units!
▶ Do not use acid or chlorine based products or products that contain
abrasives.
5.1 Indoor unit
Carry out the following inspection and maintenance activities a couple of
times a year:
▶ System pressure
▶ particle filter
▶ Magnetitefilter
▶ Humidity in cooling mode
▶ Pressure-relief valves
Meu item Description
Language Set the language of the menu texts shown in the
display.
Time of Day Set the current time. This setting is used as the basis
for the holiday program, thermal disinfection and
weekday, for example.
Date format Set the required date format and time. This setting is
used as the basis for the holiday program, thermal
disinfection and weekday, for example.
Date Set the current date. This setting is used as the basis
for the holiday program, thermal disinfection and
weekday, for example.
Auto. time
switchover
Activate or deactivate the automatic changeover
between summer and winter time. If [Yes] is set, the
time setting automatically changes (from 02:00 to
03:00 on the last Sunday in March and from 03:00
to 02:00 on the last Sunday in October).
Time correction
factor
Option for correcting the time if the time deviates in
the control panel.
Suppress
warning sound
As soon as an alarm occurs, a warning signal sounds.
The signal output can be deactivated for any length
of time.
• [Operation mode]
– [On]:
The buzzer is always active.
– [Off]:
The buzzer is never active.
– [Auto]:
The buzzer is normally active, but switched of
during the set interval.
• [Start Time]:
Set the start time for switching off the summer.
• [End time]:
Set the end time for switching off the summer.
Brightness Change the display brightness (to make it easier to
read).
Display off after Set the time delay (following the last activity) until
the display is shut down.
Installer contact
data
In this menu the installer contact data are displayed
(if entered).
Internet In this menu the data for the internet connection are
displayed. The QR code can be scanned with the
phone app to make the connection with the internet
gateway.
• Internet connection
• WLAN network
• IP address
• Server connection
• Internet module software version
• MAC address
• Login data
• Establish connection
– Pairing status
– Activ. Hotsp.
– Activate WPS
• Terminate connection
• Reset Internet password
Standby mode The heat pump is normally switched on. The system
is only switched off in order to carry out
maintenance or similar tasks.
▶ To temporarily switch off the display and the
system:
– Select [Yes]
▶ To switch on the display and the system:
– Press on the display.
– Select [Yes].
Activate keylock Select [On] to activate the child-lock.
Meu item Description

Maintenance
13
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
Fig. 13 Indoor unit Compress 5800i 12 E
[1] particle filter
[2] Pressure gauge
5.1.1 Check system pressure
▶ Check the pressure on the pressure gauge. The pressure is also
shown in the system overview on the display (Chapter 2.6.1).
▶ If the pressure is lower than 0.6 bar, slowly increase the pressure in
the heating system by adding water through the filling valve to a
maximum of 2 bar.
▶ Contact your installer or reseller if you are insecure how to perform
the filling.
5.1.2 Particle filter
WARNING
Strong magnet!
Can be harmful to pacemaker wearers.
▶ Do not clean the filter or check the magnetite indicator if you are a
pacemaker wearer.
The filter prevents particles and contamination from entering the heat
pump. Over time, the filter may become blocked and must be cleaned.
The system does not need to be emptied to clean the filter. The filter is
integrated into the shut-off valve.
Cleaning the strainer
▶ Close the valve (1).
▶ Unscrew the cap (manually) (2).
▶ Take out the strainer and clean it with running water over it or by
pressure cleaning.
▶ Check attached debris on the cap’s magnet (3) and clean it.
▶ Reinstall the strainer (4). For proper assembly, make sure that the
guide bumps fit into the recesses in the valve.
▶ Screw the cap back on (hand tight).
▶ Open the valve (5).
Fig. 14 Cleaning the strainer
Check and clean the magnetite filter
Check and clean the magnetite filter 1-2 times a year, but directly after
installation and commissioning the filter should be checked and cleaned
more frequently. See the instruction that is supplied with the filter for
correct procedure.
5.1.3 Overheating protection
Overheating protection is only available in indoor units with integrated
booster heater. The overheating protection has to be manually reset if it
is triggered.
To reset the overheating protection on Compress 5800i 12 E:
▶ Contact the installer or dealer.
5.1.4 Moisture in cooling mode
NOTICE
Insufficient condensate insulation
Moist near the components of the heating system.
▶ Shut of the heating system and contact retailer/installer if moist or
condensate is found near any of the heating system components.
5.1.5 Safety valves
Water is expelled from the safety valve during heat-up. Never close the
safety valves.
▶ Check the safety valves function.
2
1
0010039496-002
1.
2.
12
3
2.
1.
5
4
0010033735-001

Environmental protection and disposal
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
14
▶ The safety valves should only let water out if the maximum pressure is
exceeded. Contact the installer if water is coming from the safety
valves below the maximum allowed pressure.
5.2 Heat pump (outdoor unit)
The following inspection and maintenance steps are carried out several
times per year in order that the heat pump's maximum output will be
maintained:
▶ Housing (casing)
▶ Cleaning of the evaporator
▶ Snow and ice
5.2.1 Housing (casing)
Dust and other dirt particles concentrate in the heat pump's outdoor unit
over time.
▶ Remove dirt and leaves from the heat pump with a brush.
▶ If required, clean the outside with a damp cloth.
▶ Spot repair cracks and damage on the casing with anti-corrosive
paint.
▶ Standard car wax can be applied to protect the paint.
5.2.2 Evaporator
Any layers of dust or dirt, for example, deposited on the surface of the
evaporator must be removed.
CAUTION
The aluminium fins are thin and sensitive.
They can be damaged easily due to careless handling.
▶ Never use hard objects.
▶ Never rub the fins directly with a cloth.
▶ Wear protective gloves.
▶ Never use water pressure that is too high.
Damage to system due to use of unsuitable cleaning agents!
▶ Do not use acidic or alkaline cleaning agents or cleaning agents
containing chlorine or abrasive products.
▶ Do not use strong alkaline cleaning agents, e.g. sodium hydroxide.
Cleaning of the evaporator:
▶ Spray a cleaning agent on the evaporator fins on the back of the heat
pump.
▶ Rinse off coatings and detergent with water.
In some regions, the cleaning agent must not be flushed into gravel beds.
If the condensate tube discharges into a gravel bed:
▶ Remove the flexible condensate tube from the drain pipe prior to
cleaning.
▶ Collect the cleaning agent liquid in a suitable container.
▶ Reconnect the condensate tube after cleaning.
5.2.3 Snow and ice
In certain geographical regions or during periods of heavy snow, snow
can get stuck on the back and the roof of the heat pump. Make sure to
clear the snow to prevent icing-up.
▶ Carefully brush the snow off the fins.
▶ Clear the snow off the roof.
▶ Hot water can be used to rinse off the ice.
Moisture can form under the heat pump due to condensate not falling
into the condensation catch pan. This is normal and no special action is
required.
5.3 Faults
Faults can be of different kind and severity, indicated by the colour of the
fault icon and the text associated with it. If present, the four digit number
in brackets (xxxx) after the text is the fault code.
Table 10 Symbols in the display
If a fault persists:
▶ Confirm the fault by tapping the popup on the display.
▶ As long as the fault icon is displayed, there are still active faults. Tap
the icon to show the fault list.
▶ Call an authorised contractor or customer service and give them the
fault information displayed.
6 Environmental protection and disposal
Environmental protection is one of the fundamental company policies of
the Bosch Group.
We regard quality of products, economy and environmental protection
as equal objectives. Environmental protection laws and regulations are
strictly adhered to.
To protect the environment, we use the best possible technology and
materials taking economic aspects into account.
Packaging
Where packaging is concerned, we participate in country-specific
recycling processes that ensure optimum recycling.
Allofour packagingmaterials are environmentallycompatible andcanbe
recycled.
Used appliances
Used appliances contain valuable materials that can be recycled.
Thevariousassemblies canbeeasily dismantled.Synthetic materialsare
marked accordingly. Assemblies can therefore be sorted by composition
and passed on for recycling or disposal.
Old electrical and electronic appliances
This symbol means that the product must not be disposed
of with other waste, and instead must be taken to the waste
collection points for treatment, collection, recycling and
disposal.
The symbol is valid in countries where waste electrical and
electronic equipment regulations apply, e.g. "European Directive 2012/
19/EC on old electronic and electrical appliances". These regulations
define the framework for the return and recycling of old electronic
appliances that apply in each country.
As electronic devices may contain hazardous substances, it needs to be
recycled responsibly in order to minimize any potential harm to the
environment and human health. Furthermore, recycling of electronic
scrap helps preserve natural resources.
Symbol Explanation
Green symbol: A green tick shows that no alarms are
active in the heat pump system.
Red symbol: Locking or blocking fault.
Some part of the system is defective witch prevents
the system from running properly. A service action is
required.
Yellow symbol: Fault or Maintenance fault.
Some part of the system is not functioning properly
and may need attention. The system will continue to
run.

Data Protection Notice
15
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
For additional information on the environmentally compatible disposal
of old electrical and electronic appliances, please contact the relevant
local authorities, your household waste disposal service or the retailer
where you purchased the product.
You can find more information here:
www.weee.bosch-thermotechnology.com/
Disposal of refrigerant
The heat pump contains the refrigerant R290.
Only qualified installers or service personnel should dispose of the
refrigerant.
▶ Follow general safety instructions.
7 Data Protection Notice
We, Bosch Thermotechnology Ltd., Cotswold Way,
Warndon, Worcester WR4 9SW, United Kingdom
process product and installation information,
technical and connection data, communication data,
product registration and client history data to provide
product functionality (art. 6 (1) sentence 1 (b) GDPR
/ UK GDPR), to fulfil our duty of product surveillance and for product
safety and security reasons (art. 6 (1) sentence 1 (f) GDPR / UK GDPR),
to safeguard our rights in connection with warranty and product
registration questions (art. 6 (1) sentence 1 (f) GDPR / UK GDPR) and to
analyze the distribution of our products and to provide individualized
information and offers related to the product (art. 6 (1) sentence 1 (f)
GDPR / UK GDPR). To provide services such as sales and marketing
services, contract management, payment handling, programming, data
hosting and hotline services we can commission and transfer data to
external service providers and/or Bosch affiliated enterprises. In some
cases, but only if appropriate data protection is ensured, personal data
might be transferred to recipients located outside of the European
Economic Area and the United Kingdom. Further information are
provided on request. You can contact our Data Protection Officer under:
Data Protection Officer, Information Security and Privacy (C/ISP),
Robert Bosch GmbH, Postfach 30 02 20, 70442 Stuttgart, GERMANY.
You have the right to object, on grounds relating to your particular
situation or where personal data are processed for direct marketing
purposes, at any time to processing of your personal data which is based
on art. 6 (1) sentence 1 (f) GDPR / UK GDPR. To exercise your rights,
please contact us via privacy[email protected] To find further
information, please follow the QR-Code.
8 Open Source Software
The following text is in English for legal reasons.
8.1 List of used Open Source Components
This document contains a list of open source software (OSS)
components used within the product under the terms of the respective
licenses. The source code corresponding to the open source
components is also provided along with the product wherever mandated
by the respective OSS license.
In case of certain OSS licenses, for example LGPL, the license may
require a right to reverse engineering with respect to proprietary code,
for a limited purpose. This is applicable to the extent of the software
component that is in direct interaction with said OSS component. This
shall not apply for other components of the software
Name of OSS
Component
Version of OSS
Component
Name and Version of
License
(License text can be found in
Appendix below)
More Information
mbed TLS v2.7.0 Apache License 2.0 Copyright © 2006-2015, ARM Limited, All Rights Reserved
Copyright © 2006-2018, Arm Limited (or its affiliates), All Rights Reserved
Copyright © 2006-2016, ARM Limited, All Rights Reserved
Copyright © 2015-2016, ARM Limited, All Rights Reserved
Copyright © 2016, ARM Limited, All Rights Reserved
Copyright © 2016, ARM Limited, All Rights Reserved
Copyright © 2014-2016, ARM Limited, All Rights Reserved
Copyright © 2012-2016, ARM Limited, All Rights Reserved
Copyright © 2006-2017, ARM Limited, All Rights Reserved
Copyright © 2017, ARM Limited, All Rights Reserved
Copyright © 2015-2018, Arm Limited (or its affiliates), All Rights Reserved
Copyright © 2014-2017, ARM Limited, All Rights Reserved
Copyright © 2013-2016, ARM Limited, All Rights Reserved
Copyright © 2009-2016, ARM Limited, All Rights Reserved
Copyright © 2006-2018, Arm Limited (or its affiliates), All Rights Reserved
Copyright © 2009-2017, ARM Limited, All Rights Reserved
Copyright © 2009-2018, ARM Limited, All Rights Reserved
Copyright © 2017-2018, ARM Limited, All Rights Reserved
QR Code generator
library
Unspecified MIT License Copyright © Project Nayuki
STM32 cube HAL
library
5.2.0 BSD 3-Clause "New" or
"Revised" License
COPYRIGHT 2010 STMicroelectronics
COPYRIGHT 2011 STMicroelectronics
STM32 cube HAL
library
(STM32-USBD)
5.2.0 License for STM32CubeMX
(STMicroelectronics)
Copyright © 2017 STMicroelectronics International N.V.

Open Source Software
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
16
Table 11 OSS Components
8.2 Appendix - License Text
8.2.1 Apache License 2.0
Apache License Version 2.0, January 2004
http://www.apache.org/licenses/
TERMS AND CONDITIONS FOR USE, REPRODUCTION, AND
DISTRIBUTION
1. Definitions.
"License" shall mean the terms and conditions for use, reproduction, and
distribution as defined by Sections 1 through 9 of this document.
"Licensor" shall mean the copyright owner or entity authorized by the
copyright owner that is granting the License.
"Legal Entity" shall mean the union of the acting entity and all other
entities that control, are controlled by, or are under common control with
that entity. For the purposes of this definition, "control" means (i) the
power, direct or indirect, to cause the direction or management of such
entity, whether by contract or otherwise, or (ii) ownership of fifty
percent (50%) or more of the outstanding shares, or (iii) beneficial
ownership of such entity.
"You" (or "Your") shall mean an individual or Legal Entity exercising
permissions granted by this License.
"Source" form shall mean the preferred form for making modifications,
including but not limited to software source code, documentation
source, and configuration files.
"Object" form shall mean any form resulting from mechanical
transformation or translation of a Source form, including but not limited
to compiled object code, generated documentation, and conversions to
other media types.
"Work" shall mean the work of authorship, whether in Source or Object
form, made available under the License, as indicated by a copyright
notice that is included in or attached to the work (an example is provided
in the Appendix below).
"Derivative Works" shall mean any work, whether in Source or Object
form, that is based on (or derived from) the Work and for which the
editorial revisions, annotations, elaborations, or other modifications
represent, as a whole, an original work of authorship. For the purposes
of this License, Derivative Works shall not include works that remain
separable from, or merely link (or bind by name) to the interfaces of, the
Work and Derivative Works thereof.
"Contribution" shall mean any work of authorship, including the original
version of the Work and any modifications or additions to that Work or
Derivative Works thereof, that is intentionally submitted to Licensor for
inclusion in the Work by the copyright owner or by an individual or Legal
Entity authorized to submit on behalf of the copyright owner. For the
purposes of this definition, "submitted" means any form of electronic,
verbal, or written communication sent to the Licensor or its
representatives, including but not limited to communication on
electronic mailing lists, source code control systems, and issue tracking
systems that are managed by, or on behalf of, the Licensor for the
purpose of discussing and improving the Work, but excluding
communication that is conspicuously marked or otherwise designated in
writing by the copyright owner as "Not a Contribution."
"Contributor" shall mean Licensor and any individual or Legal Entity on
behalf of whom a Contribution has been received by Licensor and
subsequently incorporated within the Work.
2. Grant of Copyright License.
Subject to the terms and conditions of this License, each Contributor
hereby grants to You a perpetual, worldwide, non-exclusive, no-charge,
royalty-free, irrevocable copyright license to reproduce, prepare
Derivative Works of, publicly display, publicly perform, sublicense, and
distribute the Work and such Derivative Works in Source or Object form.
3. Grant of Patent License.
Subject to the terms and conditions of this License, each Contributor
hereby grants to You a perpetual, worldwide, non-exclusive, no-charge,
royalty-free, irrevocable (except as stated in this section) patent license
to make, have made, use, offer to sell, sell, import, and otherwise
transfer the Work, where such license applies only to those patent claims
licensable by such Contributor that are necessarily infringed by their
Contribution(s) alone or by combination of their Contribution(s) with
the Work to which such Contribution(s) was submitted. If You institute
patent litigation against any entity (including a cross-claim or
counterclaim in a lawsuit) alleging that the Work or a Contribution
incorporated within the Work constitutes direct or contributory patent
infringement, then any patent licenses granted to You under this License
for that Work shall terminate as of the date such litigation is filed.
CMSIS Core 5.4.0_cm4 Apache License 2.0
BSD 3-Clause "New" or
"Revised" License
Copyright © 2009-2017, ARM Limited, All Rights Reserved
Copyright © 2009-2018, ARM Limited, All Rights Reserved
Copyright © 2017-2018, ARM Limited, All Rights Reserved
Copyright © 2017-2018, ARM Limited, IAR Systems
CMSIS Device F4 2.6.8 Apache License 2.0
BSD 3-Clause "New" or
"Revised" License
COPYRIGHT © 2021 STMicroelectronics
COPYRIGHT © 2016 STMicroelectronics
COPYRIGHT © 2017 STMicroelectronics
COPYRIGHT © 2020 STMicroelectronics
COPYRIGHT © 2018 STMicroelectronics
COPYRIGHT © 2019 STMicroelectronics
HAL Driver F4
Modified
1.8.0 BSD 3-Clause "New" or
"Revised" License
© Robert Bosch GmbH
COPYRIGHT © 2021 STMicroelectronics
COPYRIGHT © 2016 STMicroelectronics
COPYRIGHT © 2017 STMicroelectronics
COPYRIGHT © 2020 STMicroelectronics
COPYRIGHT © 2018 STMicroelectronics
COPYRIGHT © 2019 STMicroelectronics
COPYRIGHT © 2016-2019 STMicroelectronics
STM32 cubeF4
(HAL)
v1.26.1 BSD 3-Clause "New" or
"Revised" License
COPYRIGHT 2018 STMicroelectronics
COPYRIGHT 2016-2017 STMicroelectronics
Name of OSS
Component
Version of OSS
Component
Name and Version of
License
(License text can be found in
Appendix below)
More Information

Open Source Software
17
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
4. Redistribution.
You may reproduce and distribute copies of the Work or Derivative
Works thereof in any medium, with or without modifications, and in
Source or Object form, provided that You meet the following conditions:
1. You must give any other recipients of the Work or Derivative Works a
copy of this License; and
2. You must cause any modified files to carry prominent notices stating
that You changed the files; and
3. You must retain, in the Source form of any Derivative Works that You
distribute, all copyright, patent, trademark, and attribution notices from
the Source form of the Work, excluding those notices that do not pertain
to any part of the Derivative Works; and
4. If the Work includes a "NOTICE" text file as part of its distribution, then
any Derivative Works that You distribute must include a readable copy of
the attribution notices contained within such NOTICE file, excluding
those notices that do not pertain to any part of the Derivative Works, in
at least one of the following places: within a NOTICE text file distributed
as part of the Derivative Works; within the Source form or
documentation, if provided along with the Derivative Works; or, within a
display generated by the Derivative Works, if and wherever such third-
party notices normally appear. The contents of the NOTICE file are for
informational purposes only and do not modify the License. You may add
Your own attribution notices within Derivative Works that You distribute,
alongside or as an addendum to the NOTICE text from the Work,
provided that such additional attribution notices cannot be construed as
modifying the License.
You may add Your own copyright statement to Your modifications and
may provide additional or different license terms and conditions for use,
reproduction, or distribution of Your modifications, or for any such
Derivative Works as a whole, provided Your use, reproduction, and
distribution of the Work otherwise complies with the conditions stated in
this License.
5. Submission of Contributions.
Unless You explicitly state otherwise, any Contribution intentionally
submitted for inclusion in the Work by You to the Licensor shall be under
the terms and conditions of this License, without any additional terms or
conditions. Notwithstanding the above, nothing herein shall supersede
or modify the terms of any separate license agreement you may have
executed with Licensor regarding such Contributions.
6. Trademarks.
This License does not grant permission to use the trade names,
trademarks, service marks, or product names of the Licensor, except as
required for reasonable and customary use in describing the origin of the
Work and reproducing the content of the NOTICE file.
7. Disclaimer of Warranty.
Unless required by applicable law or agreed to in writing, Licensor
provides the Work (and each Contributor provides its Contributions) on
an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY
KIND, either express or implied, including, without limitation, any
warranties or conditions of TITLE, NON-INFRINGEMENT,
MERCHANTABILITY, or FITNESS FOR A PARTICULAR PURPOSE. You are
solely responsible for determining the appropriateness of using or
redistributing the Work and assume any risks associated with Your
exercise of permissions under this License.
8. Limitation of Liability.
In no event and under no legal theory, whether in tort (including
negligence), contract, or otherwise, unless required by applicable law
(such as deliberate and grossly negligent acts) or agreed to in writing,
shall any Contributor be liable to You for damages, including any direct,
indirect, special, incidental, or consequential damages of any character
arising as a result of this License or out of the use or inability to use the
Work (including but not limited to damages for loss of goodwill, work
stoppage, computer failure or malfunction, or any and all other
commercial damages or losses), even if such Contributor has been
advised of the possibility of such damages.
9. Accepting Warranty or Additional Liability.
While redistributing the Work or Derivative Works thereof, You may
choose to offer, and charge a fee for, acceptance of support, warranty,
indemnity, or other liability obligations and/or rights consistent with this
License. However, in accepting such obligations, You may act only on
Your own behalf and on Your sole responsibility, not on behalf of any
other Contributor, and only if You agree to indemnify, defend, and hold
each Contributor harmless for any liability incurred by, or claims
asserted against, such Contributor by reason of your accepting any such
warranty or additional liability.
8.2.2 BSD 3-Clause New or Revised License
Redistribution and use in source and binary forms, with or without
modification, are permitted provided that the following conditions are
met:
• Redistributions of source code must retain the above copyright
notice, this list of conditions and the following disclaimer.
• Redistributions in binary form must reproduce the above copyright
notice, this list of conditions and the following disclaimer in the
documentation and/or other materials provided with the
distribution.
• Neither the name of the copyright holder nor the names of its
contributors may be used to endorse or promote products derived
from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND
CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR
CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING,
BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR
SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT
(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT
OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
8.2.3 License for STM32CubeMX (STMicroelectronics)
Redistribution and use in source and binary forms, with or without
modification, are permitted, provided that the following conditions are
met:
1. Redistribution of source code must retain the above copyright notice,
this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright
notice, this list of conditions and the following disclaimer in the
documentation and/or other materials provided with the distribution.
3. Neither the name of STMicroelectronics nor the names of other
contributors to this software may be used to endorse or promote
products derived from this software without specific written permission.
4. This software, including modifications and/or derivative works of this
software, must execute solely and exclusively on microcontroller or
microprocessor devices manufactured by or for STMicroelectronics.
5. Redistribution and use of this software other than as permitted under
this license is void and will automatically terminate your rights under this
license.
THIS SOFTWARE IS PROVIDED BY STMICROELECTRONICS AND
CONTRIBUTORS "AS IS" AND ANY EXPRESS, IMPLIED OR STATUTORY
WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NON-INFRINGEMENT OF THIRD PARTY INTELLECTUAL
PROPERTY RIGHTS ARE DISCLAIMED TO THE FULLEST EXTENT

Display of consumption values in relation to the funding guidelines for federal funding for efficient buildings - individual meas-
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
18
PERMITTED BY LAW. IN NO EVENT SHALL STMICROELECTRONICS OR
CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING,
BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR
SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT
(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT
OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
8.2.4 MIT License
Permission is hereby granted, free of charge, to any person obtaining a
copy of this software and associated documentation files (the
"Software"), to deal in the Software without restriction, including
without limitation the rights to use, copy, modify, merge, publish,
distribute, sublicense, and/or sell copies of the Software, and to permit
persons to whom the Software is furnished to do so, subject to the
following conditions:
The above copyright notice and this permission notice shall be included
in all copies or substantial portions of the Software.
THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY
KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM,
DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF
CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN
CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS
IN THE SOFTWARE.
9 Display of consumption values in relation to the
funding guidelines for federal funding for
efficient buildings - individual measures (BEG
EM)
The displayed energy consumption, heat quantities and device
efficiency (hereinafter "consumption values") are calculated from
device-specific data and measured values. The consumption values
displayed are only an estimate (interpolation).
In real operation, many different factors influence energy consumption.
The specific consumption values are among others influenced by:
• Installation / execution of the heating system,
• user behaviour,
• seasonal environmental conditions,
• components used.
The consumption values displayed relate exclusively to the heating
appliance. Consumption values of other components of the entire
heating system (complete heating system with all its associated
components), such as i.e. external heating circulation pumps or valves
are not taken into account. The deviations between the displayed and the
actual consumption values can therefore be considerable in real
operation.
The representation of the consumption values enables the operator to
make a relative comparison of the energy consumption over time. In
addition, excess or reduced consumption can also be determined. A use
for binding billing purposes is not possible.
10 Technical terms
Heat pump (outdoor unit)
The central heat source. Installed in the open air. Alternative
designation: outdoor unit. Contains the cooling circuit. Heated or cooled
water is channeled from the outdoor unit to the heat pump module
(indoor unit).
Indoor unit
Installed in the building and distributes the heat from the outdoor unit to
the heating system or the DHW cylinder. Contains the control unit and
the pump in the heat transfer medium line for the outdoor unit.
Heating installation
Designation for the entire installation, comprising the heat pump, heat
pump module, DHW cylinder, heating system and accessories.
Heating system
Comprises the heat source, container, radiators, underfloor heating
system or fan convectors or a combination of these elements if the
heating system is made up of several heating circuits.
Heat. circ.
The part of the heating system that distributes the heat throughout the
various rooms. Consists of pipework, pump and radiators, heating hoses
of the underfloor heating system or fan convectors. Only one of the
specified alternatives is possible within a circuit. However, if for example
the heating system is equipped with two circuits, radiators can be
installed in one and an underfloor heating system installed in the other.
Heating circuits can be configured with and without mixers.
Heating water/domestic hot water
If domestic hot water is connected to the system, a distinction is made
between heating water and domestic hot water. The heating water is
channeled to the radiators and the underfloor heating system. Shower
and water taps are supplied with domestic hot water.
If a DHW cylinder is present in the system, the control unit switches
between heating and DHW mode so that maximum comfort is achieved.
The DHW or heating mode can be prioritised by selecting an option on
the control unit.
Heating circuit without mixer
In a heating circuit without mixer the temperature in the circuit is
controlled purely by the energy from the heat source.
Heating circuit with mixer
In a heating circuit with mixer, the mixer mixes return water from the
circuit with water from the heat pump. This allows heating circuits with
mixer to be operated at a lower temperature than the other heating
system, e.g. so that underfloor heating systems that operate at lower
temperatures can be separated from radiators that require higher
temperatures.
Mixer
The mixer is a valve that steadily mixes colder return water with hot water
from the heat source in order to achieve a specific temperature. The
mixer can be situated in a heating circuit or in the heat pump module for
the external auxiliary heater.
3-way valve
The 3-way valve distributes thermal energy to the heating circuits or the
DHW cylinder. It has two defined settings so that heating and DHW
heating cannot occur at the same time. This is also the most effective
operating mode, as the DHW is always heated to a specific temperature,
while the heating water temperature is continuously adjusted to the
outdoor air temperature in each case.
External auxiliary heater (extra)
The external auxiliary heater is a separate heat source which is
connected via pipework to the indoor unit. The heat produced in the
auxiliary heater is controlled via a mixer. It is therefore also referred to as
an auxiliary heater with mixer. The control unit controls the activation
and deactivation of the auxiliary heater according to the existing heat
energy demand. Heat sources are electric, oil-fired or floor standing gas
boilers.

Overview Menu
19
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
Heat transfer medium circuit
The part of the heating system that transports the heat from the outdoor
unit to the indoor unit.
Cooling circuit
The main part of the outdoor unit that obtains energy from the outdoor
air and transfers this as heat to the heat transfer medium circuit.
Consists of evaporator, compressor, condenser and expansion valve.
The refrigerant circulates in the cooling circuit.
Evaporator
Heat exchanger between air and refrigerant. The energy from the air that
is drawn in through the evaporator causes the refrigerant to boil and turn
to gas as a result.
Compressor
Moves the refrigerant through the cooling circuit from the evaporator to
the condenser. Increases the pressure of the gaseous refrigerant. The
temperature also increases as the pressure increases.
Condenser
Heat exchanger between refrigerant in the cooling circuit and water in
the heat transfer medium circuit. During the heat transfer, the
temperature of the refrigerant falls as it changes into the liquid
aggregation state.
Expansion valve
Reduces the pressure of the refrigerant after it is discharged from the
condenser. The refrigerant is then channeled back to the evaporator
where the process starts again.
Inverter
Located in the outdoor unit and enables the speed of the compressor to
be controlled based on the heat energy demand in each case.
Setback phase
A period during the time-controlled operation involving the setback
operating mode.
Time-controlled operation
The heating system is heated in accordance with the time program and
switching between the operating modes occurs automatically.
Operating phase
The heating operating phases are: heating and setback. They are
depicted by the symbols and .
The operating phases for DHW heating are: Comfort, Eco and Eco+. A
temperature can be set for each operating phase (except for Off).
Frost protection
Depending on the type of frost protection selected, the outdoor unit is
switched on if the outside temperature or room temperature falls below
a certain critical threshold. Frost protection prevents the heating system
from freezing up.
Desired room temperature
The room temperature to be achieved by the heating system. It can be set
individually.
Default settings
Values saved permanently on the control unit, which are available at all
times and can be reset as necessary.
Heating phase
A period during the time-controlled operation involving the heating
operating mode.
Parental lock
Settings in the standard display and in the menu can only be changed if
the parental lock (key block) is switched off.
Mixer/mixing valve
Assembly that automatically ensures that DHW can be drawn from the
draw-off points at a temperature no higher than the temperature set on
the mixing valve.
Normal Operation
In normal mode, automatic mode (the heating system time program) is
not active and the home is steadily heated at the temperature set for
normal mode.
Reference room
The room in your home where the remote control is installed is the
reference room. The room temperature in this room acts as the control
variable for the assigned heating circuit (which can include several
rooms or the entire house if only one circuit is present).
Switching time
A particular time when the heating temperature, for example, is
increased or reduced. A switching time is a component of a time
program.
Temperature during an operating phase
A temperature that is assigned to an operating phase. The temperature
is adjustable. Refer to the explanations about the operating mode.
Flow temperature
The temperature that the heating water in the heating circuit retains from
the heat source through to the radiators or the underfloor heating system
in the room.
Hot water cylinder
A DHW cylinder stores large volumes of heated potable water. Sufficient
hot water is available at the draw-off points (e.g. water taps) as a result.
Time program for heating
This time program ensures automatic switchover between the operating
phases at defined switching times.
11 Overview Menu
This chapter contains an overview of all menu options. Only the menus of
the installed modules and components in each system installation are
shown.
Main screen
– Menu
– Language
– Time of Day
– Date format
– Date
– Auto. time switchover
– Time correction factor
– Suppress warning sound
– Brightness
– Display off after
– Installer contact data
– Internet
– Standby mode
– Key block is activated.
– Deactivate demo mode
System
– Settings
– Alternating operation
– Time prog., add. heater
– PV system

Overview Menu
Compress 5800iAW 12 E | OR-S | T – 6721871228 (2023/06)
20
– Smart grid
– Heat pump status
– Statistics
Heating circuit 1
–Season switch HC1
– Auto
– Heating
– Cooling
–Heating off from
–Cooling on from
–Display time program HC1
–Heat. mode HC1
–Off
–Manual
–Auto
– Desired room temp. heating
–Time program
– Heating curve HC1
–Cooling mode HC1
–Desired room temp. cooling
–Heating
–Heating off from
–Display time program HC1
–Heat. mode HC1
– Desired room temp. heating
–Cooling
–Cooling mode HC1
–Desired room temp. cooling
–Cooling on from
–Rename heating circuit
Hot water
– Operation mode
–Off
– Manual - Eco+
– Manual - Eco
– Manual - Comfort
–Auto
–Time program
– Thermal disinfection
– Start now
– Stop now
– Auto
– Daily/weekday
– Time of Day
– Hot water circulation pump
– Operation mode
–Off
–On
– Hot water set temperature
– Auto
– Start frequency
–Time program
– Activate time program
– Red. HW temp on alarm
– Measured temperature
– Overview of sensor values
Ventilation
– Settings
–Time program
– Requested air humidity level
– Requested air quality level
– Activate manual bypass
– Op. mode aux. heater
– Set temp. auxiliary. htr
– Filter timer
– Confirm filter change
– Info
– Ventilation temperature overview
– Outdoor air temperature
– Supply air temperature
– Extract air temperature
– Exhaust air temperature
– Supply air temp. aux. heater
– Ambient air humidity
– Ambient air quality
– Exhaust air humidity
– Exhaust air quality
– Humidity remote control XXX
– Bypass damper
– Time to filter exchange
– Energy consump.
Solar
– Solar sensor overview
– Solar yield overview
Holiday
–From
–To
–Advanced settings
–Apply settings to
–Heating circuit 1
–Hotwater
– Ventilation
–Heating
–Off
– On - set temperature
–Desired room temp.
–Hotwater
–Off
–Eco
– Eco+
– Comfort
– Thermal disinfection
– Ventilation
–Off
– Level 1
– Level 2
– Level 3
– Level 4
– Demand
– Rename holiday period
Display cleaning mode
