Bosch NDN-50022-A3 User manual

1 2 3 4 5
6 7 8 9 10
6 x 30
T10
x4
4.5 x 40
x4
Desiccant
Mounted
x4
IR version
microSD card
Menu
Reset
Desiccant
Ø 6 ~ 7 mm
sealant
Ø6 mm
x4
x4
Ø6 mm
56
32
x4
4.5 x 40
7 mm
(0.3 in)
12 VDC
SELV
Class 2
24-28 AWG
RJ45
Ethernet (PoE)
Default: DHCP on
(no DHCP: 192.168.0.1)
This equipment is only to be connected to PoE networks
without routing to outside plant
8 mm
(0.3 in)
CVBS
BNC
SMB
connector
AUDIO ALARM
OUT OUT OUTGND GND GNDIN IN
24-28 AWG
NBN-MCSMB
(optional)
not included
Pan
350°
Tilt
130°
Twist
330°
T10
Do not position light
sensor below edge of
cover (IR only).
x2
Menu
On
180°
Default
Focus
Zoom OK
Zoom (0-6)
Focus & Zoom OK
- autofocus
- autofocus
>2s
>2s
>2s
<2s
<2s
<2s
<2s
<2s
<2s
<2s
Analog format
<2s
Output OK
CVBS
x4

1 2 3 4
en en en en
FLEXIDOME IP outdoor 5000
NDN-50022-A3 | NDI-50022-A3
NDN-50051-A3 | NDI-50051-A3
Quick Installation Guide
Bosch Security Systems B.V.
Torenallee 49
5617 BA Eindhoven
The Netherlands
www.boschsecurity.com
© Bosch Security Systems B.V., 2015
F.01U.304.149
IPHelper Lens Wizard
Configuration >> Camera >> Installer Menu
Zoom & Focus View & Configure
Bosch Video
Client
Video Security
Client
Configuration
Manager
Safety
Safety precautions
!
Caution!
1
1.1
Installation should only be performed by qualified
service personnel in accordance with the National
Electrical Code (NEC 800 CEC Section 60) or
applicable local codes.
The Low Voltage power supply unit must comply
with EN/UL 60950. The power supply must be a
SELV-LPS unit or a SELV - Class 2 unit (Safety
Extra Low Voltage - Limited Power Source).
After connections are made ensure that the
watertight compartment is tightly closed and
cables and conduits are properly sealed to
prevent ingress of water.
1.2 Important safety instructions
Read, follow, and retain for future reference all of the
following safety instructions. Follow all warnings on the
unit and in the operating instructions before operating the
unit.
1. Clean only with a dry cloth. Do not use liquid cleaners
or aerosol cleaners.
2. Do not install unit near any heat sources such as
radiators, heaters, stoves, or other equipment
(including amplifiers) that produce heat.
3. Never spill liquid of any kind on the unit.
4. Take precautions to protect the unit from power and
lightning surges.
5. Adjust only those controls specified in the operating
instructions.
6. Operate the unit only from the type of power source
indicated on the label.
7. Unless qualified, do not attempt to service a damaged
unit yourself. Refer all servicing to qualified service
personnel.
8. Install in accordance with the manufacturer's
instructions in accordance with applicable local codes.
9. Use only attachments/accessories specified by the
manufacturer.
FCC & ICES Information
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
- reorient or relocate the receiving antenna;
- increase the separation between the equipment and
receiver;
- connect the equipment into an outlet on a circuit
different from that to which the receiver is connected;
- consult the dealer or an experienced radio/TV technician
for help.
Intentional or unintentional modifications, not expressly
approved by the party responsible for compliance, shall
not be made. Any such modifications could void the user's
authority to operate the equipment. If necessary, the user
should consult the dealer or an experienced
radio/television technician for corrective action.
More information
For more information please contact the nearest Bosch Security
Systems location or visit:
http://www.boschsecurity.com/catalog_overview.htm
Disposal - Your Bosch product was developed
and manufactured with high-quality material and
components that can be recycled and reused.
This symbol means that electronic and electrical
appliances, which have reached the end of their
working life, must be collected and disposed of
separately from household waste material.
Separate collecting systems are usually in place
for disused electronic and electrical products.
Please dispose of these units at an environmen-
tally compatible recycling facility, per European
Directive 2012/19/EU.
