Bosch LTC 2600 Series User manual

Also Used by Video Controller
LTC 2600 Series Multiplexer Quick Reference Guide
System4

Installation Instructions
These features are available on System4 Series only.
Keyboard: (LTC 2601/00 and LTC 2602/00 models only). Connect a remote keyboard with Pan/Tilt/Zoom for control and programming.
Console: Connect a host computer for CCL command inputs, or a Bosch LTC 2650 Graphical User Interface, or a printer.
SDA: Five biphase outputs for a Bosch AutoDome®or Receiver/Driver.
Connect cameras (up to 16)
to camera BNC inputs.
Follow steps 1-8 for quick installation
If looping is required,
connect camera out to
second source (second BNC).
Connect a monitor to
MON A output for
multiscreen display
and tape playback.
Connect a monitor to
MON B output if needed.
NOTE: For System4 Triplex Series
only, MON B can display a quad
or a multiscreen picture when
operating in live or playback mode.
For playback, connect the
Output of the VCR to VCR
IN on the multiplexer.
For recording, connect the
Input of the VCR to the
VCR OUT on the multiplexer.
Synchronize the Mux with the VCR by
connecting pin 21 (VEXT INPUT 1)
to VCR Clock Out on your recorder.
Connect pin 25 to VCR ground.
For 6-Channel LTC 2622, refer to the
Instruction Manual
Apply power to the unit. The Console, SDA, KB, SVHS,
and Fonts are available with
System4 Series only. Refer to the
Instruction Manual for details.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
61234587
Pin 25 Pin 21
7543
1
2
8
6

Operating Instructions
Display Modes Available For LTC 2600 Series Multiplexers
Full Screen Display: Shows one camera, full screen on one monitor.
Press FULL SCREEN on the front panel, then press the appropriate
camera number.
Quad Screen Display: Divides the screen into four viewing areas.
Press QUAD once to enable the feature. Press QUAD repeatedly
to toggle through the viewing configurations (three times for the
9-Channel model; four times for the 16-Channel model; eight times
for System4 models). Press ALT , then SEQ to sequence through
all quad screens.
Multiscreen Display: Enabling this feature shows one of five
multiscreen configurations: 4x4 (16 cameos), 12+1, 8+2, 3x3, and
4+3. Press MULTI repeatedly to toggle through the selections.
Cameo Mode: When in MULTI or QUAD mode, the screen
area where a camera is displayed is called a cameo. Note that the
numbered front panel keys can refer to either cameras or cameos.
Press CAMEO to toggle the operation of these keys to the cameo
function (the CAMEO LED is illuminated when the multiplexer is in
cameo mode). Press CAMEO again to revert to the camera function.
Assign a Camera to the Cameo
1) In MULTI or QUAD display mode, press the desired camera key, and then press
CAMEO. The cameo selected will display a flashing camera title. Select the desired
camera, and the cameo will display the selected camera.
Press CAMEO to store and/or exit.
2) Press ALT and SELECT (the ALT LED will flash). Cameo #1 will be selected
and will show a flashing camera title. Press the desired camera key. Cameo #1 will
display the selected camera, and cameo #2 is automatically selected. Repeat this
procedure for the remaining cameras.
Press ALT to exit at any time.
Recording Live Pictures
Press the green ALT key, and then press RECORD. This
key combination toggles the record mode on and off.
For System4 LTC 2672 or LTC 2682 Series:To activate
both VCR outputs, press ALT , then 2, then RECORD.
Playback
To playback the recorded pictures, press the green ALT
key, and then press PLAY.
For Simplex models, Record mode must be turned OFF.
Advanced Functions
Zoom: Enables the active camera display (a cameo in MULTI
or QUAD display) to be digitally enlarged by a factor of 2:1.
Zoom will be displayed on the monitor screen. Use the arrow
keys for closer inspection of any part of the selected image.
Freeze: Holds the selected camera picture on either full screen
or cameo. Press FREEZE again to release the image from this
function. Changing the display screen mode releases the freeze
mode from all cameos.
Alarms and Actions Acknowledge:
When an alarm or action condition occurs, the action alarm
camera picture displays full screen on Monitor B, and the
ALM or ACT LED flashes. ALARM/ACTION will also
flash on Monitor A. Clearing an Alarm/Action by pressing
ACT or ALM will stop any recording associated with that
function. The method of clearing alarms or action conditions
depends on the model of your multiplexer.
Refer to the Instruction Manual for advanced operation
features.
REC
PLAY

Access the menu screens by pressing
ALT (Green)followed by
MENU . The menus (as
shown above) will be displayed
on Monitor A.
The Main Menu (shown above)
displays two setup options: Quick
Setup and Advanced Setup. In most
cases, the Quick Setup provides all
programming necessary for system
operation.
To choose the option,
press SELECT .
The Quick Setup program includes
Time/Date, AutoSet, and VCR
Setup. For further information, consult
the built-in HELP feature by pressing
ALT.
Select Time/Date. Enter the time
format (12 or 24 hours), time, date
format (dd/mm/yyyy;yyyy/mm/dd),
and date information as requested. Use
the direction (arrow) keys to move the
cursor and scroll through menu
settings. Press SELECT to choose the
settings, and save your selections.
When finished programming all
time/date settings, use ZOOM to
return to the Quick Setup menu.
Select Autoset and choose
AUTOSET ALL BELOW to
automatically set the record list,
sequence, and video loss list (according
to the number of camera inputs
detected by the multiplexer). Selecting
any of the other menu options, will set
only the selected option.
When Autoset is finished, a message is
displayed for three seconds. The
camera inputs detected in the setup
process are also displayed, as shown in
the above sample screen.
Press ZOOM to return to the Quick
Setup menu.
NOTE: The LTC 2600 Series
Multiplexers are configured to record
and playback from a wide variety of
VCRs.
Decide how to synchronize the
multiplexer and the VCR. The options
are (a) Connect and enable the VEXT
output from the VCR (no further
VCR programming is required), or (b)
if VEXT is not available, specify the
VCR model and the time-lapse mode.
To program the multiplexer for the VCR
in use, select the RECORD SETUP
menu. From the SELECT VCR
menu, press SELECT. Scroll to the
appropriate VCR model and press
SELECT.
Press ZOOM to exit. Choose the
TIME LAPSE menu and select the
recording speed. Press ZOOM five
times to exit the programming menu.
The unit is now ready for operation.
Programming Instructions
MAIN MENU
SETUP 1
>QUICK SETUP
ADVANCED SETUP
Choose: SELECT More:V
Exit:ZOOM
QUICK SETUP
SETUP 1
>TIME/DATE
AUTOSET
VCR SETUP
Choose: SELECT More:V
Exit:ZOOM
TIME/DATE
>TIME FORMAT 12
TIME 12:00:00
DATE FORMAT MM/DD/YYYY
DATE 01/01/1998
Choose: SELECT More:V
Exit:ZOOM
AUTOSET
SETUP 1
>AUTOSET ALL BELOW
RECORD LIST
SEQUENCES
VIDEO LOSS LIST
Choose: SELECT More:V
Exit:ZOOM
AUTOSET
SETUP 1
01 02 03 04 05 06 -- --
-- -- -- -- -- -- -- -- -- --
The above cameras were
included in selected input lists
HIT ANY KEY TO COMPLETE
VCR SETUP
SETUP 1
>RECORD SETUP *VCR OUT*
PLAYBACK FORMAT
RECORD LOCK
Choose: SELECT More:V
Exit:ZOOM
RECORD SETUP
*VCR OUT* SETUP 1
VEXT INPUT OFF
SELECT VCR PHILIPS 3991HD
TIME LAPSE 6HD
Choose: SELECT More:V
Exit:ZOOM
NOTE: To perform an Advanced Setup for customized system configurations, refer to the instruction manual.
For further information within the menu,
consult the built-in HELP feature by pressing ALT
To exit from any menu, press ZOOM to return to the previous screen.

LTC 2601, LTC 2602 ALLPLEX Quick Reference Card Keyboard Commands
Numeric Display
The numeric display is a three-digit display that shows the number of the multiplexer that the keyboard is currently controlling. When in the VCR control mode the display shows VCR.
Status Display
The status display indicators are located on both sides of the numeric display at the top of the keyboard. On the right side of the numeric display, there are three status display indicators:
Camera , Cameo , Pound . On the left side of the numeric display, there are six status display indicators: VCR , Monitor B , Sequence,Allplex , Record , and Playback .
PLAY
RECAPXSEQ
VCR
#
Status Display Functions
Camera LED lit Full Screen selection
Cameo LED lit Quad or Multi screen selection
Record LED lit Recording mode enabled
Play LED lit Playback mode enabled
MonB LED lit Mon B is enabled
Sequencing LED lit Sequencing mode enabled
VCR LED lit VCR test mode enabled
VCR
SEQ
PLAY
REC
Full Quad Multi Cameo Zoom
Freeze Action Clear Alarm Clear Select Menu
Icon Key
BOSCH

View Format and Camera Select
SELECT . . . . . . . . . . . . . . . . . Press Keys
FULL SCREEN . . . . . . . . . . . .Press FULL and then the camera #
QUAD . . . . . . . . . . . . . . . . . . Press QUAD and then press the key
repeatedly to toggle through the different quad
pages: Quad 2, 3. etc.
MULTISCREEN: . . . . . . . . . . . Press MULTI and press the key
repeatedly to toggle through the different
viewing configurations
Multiplexer Command
RECORD (ENCODE) . . . . . . . Press ALT then REC
PLAYBACK (DECODE) . . . . . . Press ALT the PLAY
MON B . . . . . . . . . . . . . . . . . Press ALT then MON B
SEQUENCE . . . . . . . . . . . . . . . Press ALT then SEQ
VCR TEST MODE . . . . . . . . . Press ALT then SEQ
ACTION ACKNOWLEDGE . . . Press ACTION CLEAR
ALARM ACKNOWLEDGE . . . . Press ALARM CLEAR
ZOOM PICTURE . . . . . . . . . . Press ZOOM to enlarge the picture
FREEZE . . . . . . . . . . . . . . . . . Press FREEZE to freeze the picture
MENU SELECTION . . . . . . . . . Press ALT and then MENU
MENU SCROLL . . . . . . . . . . . >, <, ^, and v
ALLPLEX SELECTION . . . . . Allplex + SELECT simultaneously, then #,
then SELECT to select the new Allplex
number. The system accepts only valid Allplex
numbers 1 through 30.
P/T/Z FUNCTIONS . . . . . . . NOTE: Refer to Bosch R/D or AutoDome
Instruction Manual for Auxiliary function
SAVE PRE-POSITION . . . . . . . . Press SET ,# (1-99) then SELECT
RECALL PRE-POSITION . . . . . Press SHOT ,#(1-99), then SELECT
AUXILIARY ON/OFF . . . . . . . Press AUX + AUX ,then #, then
SELECT
VCR CONTROL . . . . . . . . . Note: Only with Bosch RS-232 VCRs
VCR MODE SELECTION . . . . PressVCR + SELECT
simultaneously. LED will display VCR
RECORD . . . . . . . . . . . . . . . . REC
PLAYBACK . . . . . . . . . . . . . . . PLAY
STOP . . . . . . . . . . . . . . . . . . . ZOOM
PAUSE . . . . . . . . . . . . . . . . . FREEZE
FAST FORWARD . . . . . . . . . . CAMEO
FAST REWIND . . . . . . . . . . . . FULL
PLAY
REC
VCR
AUXAUX
SHOT
SET
ALT
VCR
ALT
SEQ
ALT
ALT
PLAY
ALT
REC
ALT
