1. ATM/POS bridge
The ATM/POS bridge connects a Point-of-Sale (POS) or an Automatic Teller Machine
(ATM) to a Bosch digital video recorder so that transactional data from these units can
be stored and displayed with associated video recordings.
1.1 Package contents
Check the package for following items:
•ATM/POSbridge
• External DC power supply
• Mounting kit
• 2 connection cables and 1 console cable (with two 9-pole SubD connectors)
• Installation manual (this manual)
1.2 Supported protocols
The ATM/POS bridge is designed to operate with many different terminals. If you have
any questions regarding the suitability of the firmware for your terminal or any other
enquiries, contact your Bosch representative.
1.3 Mounting
Using the screws provided, attach the two mounting brackets to the sides of the bridge.
Secure the brackets to a solid fixture.

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 4
English
1.4 Applications
The following illustration shows an example of how a bridge is used in a network of digital
video recoders and POS terminals.
The following illustration shows an example of how a bridge is used in a network of digital
video recoders and ATM terminals.

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 5
English
1.5 Connections
Using the supplied cables, connect the bridge as follows:
1. Connect the supplied DC power adapter unit to the DC power input connector of
the bridge.
2. Connect the RJ45 connector of the bridge via a straight Ethernet CAT5 network
cable to a network switch or hub that supports 10BaseT. Alternatively, the bridge can
be connected directly to the digital video recorder via a cross-over cable.
3. To configure the bridge, use an RS232 cable to connect the COM3 (console) port to
the serial port of a PC. If you use the RS232 console cable supplied with the bridge,
ensure that the bridge is powered before connecting the cable.
Ethernet RJ45 connector DC Power input connector
COM 3 (console) RS232 connector
COM 2 RS232 connector COM 1 RS232 connectorCOM 4 RS485 connector
Activity indicator

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 6
English
4. Connect your terminal to COM port 1, 2, 3 or 4 of the bridge using the supplied
cable. Choose the COM 4 port on the bridge if your connection protocol is RS485.
Normally, you would use the supplied splitter cable to make this connection. For
example, you remove the existing cable that connects your terminal to the
printer. Use the supplied splitter cable to connect the terminal to the printer.
The third connector of the splitter cable then connects to the supplied
connection cable which connects to the bridge.
To select the communication parameters for the ports and the network parameters, use a
PC to start a configuration session as described below. The activity LED lights when the
bridge is active.
Note
To download firmware to the bridge you must use the supplied RS232 cable connected
to the COM3 (console) port. In this situation the cable must be connected to the bridge
before it is powered.
POS terminal
Printer Digital
Video
Recorder
Ethernet
cross-over
cable
ATM/POS
bridge
Supplied splitter
cable
Supplied
connection cable

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 7
English
2. Configuration
The ATM/POS bridge is configured via a PC HyperTerminal session. The PC is
connected via a COM serial port to the COM 3 (console) port of the bridge. Start a
HyperTerminal session on the PC to get access to the configuration menu of the bridge.
2.1 How to set up a HyperTerminal session
1. Start the PC HyperTerminal program in Windows (normally available under
Start_Programs_Accessories_Communications).
2. Enter a name for the HyperTerminal session and click OK.
3. For the connection, select the COM port number of the PC.
4. Fill in the following values for the COM port properties and click OK:

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 8
English
5. If the bridge is switched on, a welcome message is shown on the screen. This
message prompts you to press the F1 key (a function key on your keyboard).
6. Press the F1 key; the screen displays the System Options Menu.
7. To configure the bridge, navigate through the menus using the numeric keys on your
keyboard to select menu items.
2.2 Configuration menus
2.2.1 System options menu
The system options menu has 6 items:
1. Network Setup
2. Communication Channels
3. Terminal Setup
4. Simulation mode
5. Recording Language
6. Service Menu
Network Setup
The Network Setup submenu enables you to configure network settings and enter a
bridge name:
The MAC Address of the bridge is shown but cannot be changed.
1BridgeName BRIDGE-01
2 I P - A d d r e s s 19 2 .16 8 .10 . 2
3 Subnet Mask 255.255.255.0
4 Default Gateway 0.0.0.0
5 Recorder TCP Port 4200 (default)
6 Service TCP Port 4201 (default)

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 9
English
Communication Channels
In the Communication Channels submenu you can select one of the four COM ports to
configure. The submenu that appears depends on the setting of the Comport Mode. Enter
the parameters that are required for your terminal.
Terminal Setup
In the Terminal Setup submenu you can select one of the four connected terminals to
configure. Enter a terminal name and select the type of device connected to your
terminal. Contact your local sale representative if your device is not listed in the menu
for selection. Our firmware is continously extended with new options.
Simulation Mode
The Simulation Mode is used to test the connection between the bridge and the digital
recorder. If this mode is selected, sample data is sent from the bridge to the digital
recorder.
1ComportMode Asynchronous
3 Baudrate 9600
4 Databits 8 bits
5Parity None
6 Stop bits 1bit
7FlowControl Off
1Name TERMINAL-01
2 Device Epson TM-T88III (example)
3 Comm Channel Com 1 - RS232
4 Address 0

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 10
English
Recording Language
Select the same language that is set on the connected digital recorder. This ensures that
characters are displayed correctly. The configuration menu language continues to be
English.
Service Menu
The Service Menu is used to restore the bridge to factory defaults, to reset the bridge, or
to do diagnostics.

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 11
English
3. Connectors
The four COM connectors are all 9-pin SubD-type male connectors.
The following table lists the signals and pin numbers for the four ports.
Pin COM 1
RS 232
COM 2
RS 232
COM 3
(console)
RS 232
COM 4
RS 485
1
2RxRxRxD2+
3TxTxTxD2-
4
5 GND GND GND GND
6
7RxC RxC
8TxC TxC
9INIT
5
1
69

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 12
English
4. Troubleshooting
If you are unable to capture transaction data, perform the following steps:
1. Recheck your cables.
2. Check your TCP/IP network connection with the ATM/POS bridge. Check your
gateway and subnet mask settings, they must match the digital recorder settings.
3. If the recorder has established communication with your bridge and you still cannot
capture the transaction data, use the simulation mode of the bridge in the System
Options Menu. The bridge will send sample transactions to the recorder in this
mode.
4. Check the COM ports settings in your bridge. If the transaction data is being
recorded, but shows the wrong characters, check the COM port settings. The
language setting must be the same as the recorder language setting.
5. If your recorder requires an ATM/POS software license (for example, the Divar 2
digital versatile recorder), please check if this license is enabled in the System
Settings - Licenses submenu of the Divar.

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 13
English
5. Technical specifications
Electrical
Power supply: External DC power supply (supplied)
Input: 100-240 VAC; 150mA, 50/60Hz
Output: 12 VDC; 450mA
Connector: DC jack, positive center pin; 10-30 VDC; 2W
Mechanical
Dimensions: 152 x 110 x 35 mm / 5.98 x 4.33 x 1.38 inch
Weight: Approx. 0.6 kg / 1.3 lbs
Mounting kit: Supplied
Interface
Ethernet: RJ45 shielded, 10 BaseT
Com 1 port: 9-pin SUBD male connector; RS232 synchronous or
asynchronous signals according to EIA/TIA-232-F
Com 2 port: 9-pin SUBD male connector; RS232 synchronous or
asynchronous signals according to EIA/TIA-232-F
Com 3 (console) port: 9-pin SUBD male connector; RS232 asynchronous signals
according to EIA/TIA-232-F
Com 4 port: 9-pin SUBD male connector; RS485 asynchronous
Environmental
Temperature: Operating: +0°C to +45°C (+32°F to +113°F)
Storage: -25°C to +70°C (-13°F to +158°F)
Relative humidity: Operating: < 80% non-condensing
Storage: < 90% non-condensing

Bosch Security Systems
ATM / P OS br idg e | Installation Manual EN | 14
English
Electromagnetic Compatibility
EMC requirements: USA: FCC Part 15, Class B
EU: EMC directive 89/336/EEC
Immunity: EN50130-4
Emission: EN55022 Class B
Harmonics: EN61000-3-2
Voltage fluctuations: EN61000-3-3
Safety: USA: UL60950
EU: EN60950
Canada: CAN/CSA - C22.2 - 60950-00
