[en] Instruction manual Free standing cooker
Free standing cooker
HKA00.02.U, HKA00.020W, HKA050022W

en
3
Table of contents
[en]I ns t r uc t i on manual Fr ee st andi ng cooker
8Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(Important safety information . . . . . . . . . . . . . . . 4
Halogen lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
]Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6
Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Damage to the oven. . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Damage to the plinth drawer . . . . . . . . . . . . . . . . . . . . 7
7Environmental protection . . . . . . . . . . . . . . . . . . 7
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Saving energy with the hob . . . . . . . . . . . . . . . . . . . . . 8
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 8
5Installation and connection. . . . . . . . . . . . . . . . . 9
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Adjacent units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Wall fixing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Door lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Measures to be noted during transport . . . . . . . . . . . . 9
*Getting to know your appliance . . . . . . . . . . . . 10
General information . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cooking area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cooking compartment . . . . . . . . . . . . . . . . . . . . . . . . 12
_Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . 12
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 12
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 13
KBefore using for the first time. . . . . . . . . . . . . . 14
Cleaning the cooking compartment and accessories 14
1Setting the cooking time . . . . . . . . . . . . . . . . . 14
Setting procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Table of cooking times. . . . . . . . . . . . . . . . . . . . . . . . 14
1Operating the appliance . . . . . . . . . . . . . . . . . . 16
Switching the appliance on and off . . . . . . . . . . . . . . 16
Setting the type of heating and temperature . . . . . . . 16
AChildproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 16
Activating and deactivating . . . . . . . . . . . . . . . . . . . . 16
DCleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cleaning agents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Keeping the appliance clean . . . . . . . . . . . . . . . . . . . 19
pRails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Detaching and refitting the rails . . . . . . . . . . . . . . . . . 19
qAppliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Detaching and attaching the oven door . . . . . . . . . . .20
Removing and installing the door panels . . . . . . . . . .21
Additional door safety. . . . . . . . . . . . . . . . . . . . . . . . .21
3Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 22
Rectifying faults yourself . . . . . . . . . . . . . . . . . . . . . . .22
Replacing the bulb in the top of the cooking
compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
4Customer service . . . . . . . . . . . . . . . . . . . . . . . . 23
E number and FD number . . . . . . . . . . . . . . . . . . . . .23
JTested for you in our cooking studio. . . . . . . . 23
General information . . . . . . . . . . . . . . . . . . . . . . . . . .23
Cakes and pastries. . . . . . . . . . . . . . . . . . . . . . . . . . .24
Bakes and gratins . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Poultry, meat and fish . . . . . . . . . . . . . . . . . . . . . . . . .27
Vegetables and side dishes . . . . . . . . . . . . . . . . . . . .30
Yoghurt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . .30
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Prove dough . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Test dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com

en Intended use
4
8Intended use
Intended use Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
The images shown in these instructions are for
guidance only.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for private domestic
use and the household environment only. The
appliance must only be used for the
preparation of food and beverages. The
cooking process must be supervised. A short
cooking process must be supervised without
interruption. Only use the appliance in
enclosed spaces.
This appliance is intended for use up to a
maximum height of 4000 metres above sea
level.
This appliance is not designed for operation
with an external timer or by remote control.
Do not use inappropriate child safety shields
or hob guards. These can cause accidents.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~"Accessories" on page 12
(Important safety
information
Impor t ant saf et y informat i on :Warning – Risk of fire!
■Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
Risk of fire!
■Hot oil and fat can ignite very quickly. Never
leave hot fat or oil unattended. Never use
water to put out burning oil or fat. Switch off
the hotplate. Extinguish flames carefully
using a lid, fire blanket or something similar.
Risk of fire!
■The hotplates become very hot. Never
place combustible items on the hob. Never
place objects on the hob.
Risk of fire!
■The appliance becomes very hot, and
flammable materials can easily catch fire.
Do not store or use any flammable objects
(e.g. aerosol cans, cleaning agents) under
or in the vicinity of the oven. Do not store
any flammable objects inside or on top of
the oven.
Risk of fire!
■The surfaces of the plinth drawer may
become very hot. Only store oven
accessories in the drawer. Flammable and
combustible objects must not be stored in
the plinth drawer.
:Warning – Risk of burns!
■The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!

Important safety information en
5
■Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.
Risk of burns!
■The hotplates and surrounding area
(particularly the hob surround, if fitted)
become very hot. Never touch the hot
surfaces. Keep children at a safe distance.
Risk of burns!
■During operation, the surfaces of the
appliance become hot. Do not touch the
surfaces when they are hot. Keep children
away from the appliance.
Risk of burns!
■The hotplate heats up but the display does
not work. Switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of burns!
■The appliance becomes hot during
operation. Allow the appliance to cool down
before cleaning.
:Warning – Risk of scalding!
■The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
■Water in a hot cooking compartment may
create hot steam. Never pour water into the
cooking compartment when the cooking
compartment is hot.
:Warning – Risk of injury!
■Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■Saucepans may suddenly jump due to
liquid between the pan base and the
hotplate. Always keep the hotplate and
saucepan bases dry.
Risk of injury!
■If the appliance is placed on a base and is
not secured, it may slide off the base. The
appliance must be fixed to the base.
Risk of injury!
■The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
Risk of injury!
■If you leave the appliance door open,
people may bump into it, resulting in injury.
The appliance door must be kept closed
both while the appliance is in operation and
when it has finished.
:Warning – Risk of tipping!
Warning: In order to prevent tipping of the
appliance, this stabilizing means must be
installed. Refer to the instructions for
installation.
:Warning – Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out by one of our
trained after-sales engineers. If the
appliance is faulty, unplug the mains plug or
switch off the fuse in the fuse box. Contact
the after-sales service.
Risk of electric shock and serious injury!
■The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
Risk of electric shock!
■Cracks or fractures in the glass ceramic
may cause electric shocks. Switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
Halogen lamp
:Warning – Risk of burns!
The bulbs in the cooking compartment
become very hot. There is still a risk of burning
your skin for some time after they have been
switched off. Do not touch the glass cover.
Avoid contact with your skin when cleaning.

en Causes of damage
6
:Warning – Risk of electric shock!
When replacing the cooking compartment
bulb, the bulb socket contacts are live. Before
replacing the bulb, unplug the appliance from
the mains or switch off the circuit breaker in
the fuse box.
]Causes of damage
Ca u s e s of damage Hob
Caution!
■Rough pot and pan bases scratch the ceramic.
■Avoid boiling pots dry. This may cause damage.
■Never place hot pots or pans on the control panel,
the display area or the surround. This may cause
damage.
■Damage can occur if hard or pointed objects fall on
the hob.
■Aluminium foil and plastic containers melt on hot
hotplates. Oven protective foil is not suitable for your
hob.
Overview
The following table provides an overview of the most
frequent kinds of damage:
Damage to the oven
Caution!
■Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
■Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean. Never
operate the appliance if the seal is damaged or
missing. ~"Cleaning" on page 17
■Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
Damage Cause Action
Stains Food spills Remove spills immediately with a glass scraper.
Unsuitable cleaning agents Only use cleaning agents which are suitable for ceramic
Scratches Salt, sugar and sand Do not use the hob as a work surface or storage space.
Rough pot and pan bases scratch the
ceramic.
Check your cookware.
Discolouration Unsuitable cleaning agents Only use cleaning agents which are suitable for ceramic
Pan abrasion (e.g. aluminium) Lift the pots and pans when moving them.
Blisters Sugar, food with a high sugar content Remove spills immediately with a glass scraper.

Environmental protection en
7
■Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
■Grilling: do not insert the baking tray or universal pan
higher than level 3 when grilling. The high heat
distorts it and the enamel may be damaged when it
is removed. At level 4 and 5, only grill directly on the
wire rack.
Damage to the plinth drawer
Caution!
Do not place hot objects in the plinth drawer. It could be
damaged.
7Environmental protection
En v i r o n ment al pr ot ect i on Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■Leave frozen food to defrost before placing it in the
cooking compartment.
■Use baking tins that are dark-coloured, painted black
or have an enamel coating. These absorb the heat
particularly well.
■Remove any unnecessary accessories from the
cooking compartment.

en Environmental protection
8
■Open the appliance door as infrequently as possible
when the appliance is in use.
■It is best to bake several cakes one after the other.
The cooking compartment stays warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Saving energy with the hob
■Use pots and pans with thick, even bases. Uneven
bases increase energy consumption.
■The diameter of pan bases should be the same size
as the hotplate. In particular, small saucepans on the
hotplate cause energy losses. Note that cookware
manufacturers often indicate the upper diameter of
the saucepan. This is usually bigger than the
diameter of the base of the pan.
■Use a small saucepan for small quantities. A larger,
less full saucepan requires a lot of energy.
■Always place suitable lids on saucepans. When
cooking without a lid, four times the energy is
required.
■Cook with only a little water. This will save energy.
Vitamins and minerals in vegetables are preserved.
■Switch to a lower heat setting in good time.
■Use the residual heat. For longer cooking times, you
can switch the hotplate off 5-10 minutes before the
end of the cooking time.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.

Installation and connection en
9
5Installation and connection
Instal l ati on and c onnect i on Do not install the appliance behind a decorative door
or the door of a kitchen unit, as this may cause the
appliance to overheat.
Electrical connection
Only licensed specialists may connect the appliance.It
is important that you comply with the requirements of
your electricity supplier.
Any damage arising from the appliance being
connected incorrectly will invalidate the warranty.
Caution!
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
:Warning – Danger of death!
There is a risk of electric shock if you touch live
components.
■Always make sure your hands are dry when you
touch or hold the mains plug.
■Only pull out the mains cable by taking hold of the
plug and removing the plug; never pull it out by the
mains cable itself, as this could damage it.
■Never unplug the mains plug when the appliance is
in operation.
Please note the following information and ensure that:
Notes
■The mains plug fits the socket.
■The cable cross section is adequate.
■The earthing system is properly installed.
■The mains cable is only replaced by a qualified
electrician (if this is necessary).Spare mains cables
can be ordered from our after-sales service.
■No power strips/multi-way connectors or extension
cables are used.
■If using a residual current device, only use one that
bears the mark z.
The presence of this mark is the only way to be sure
that it fulfils all the applicable regulations.
■The mains plug can be accessed at all times.
■The mains cable is not kinked, crushed, modified or
severed.
■The mains cable does not come into contact with
heat sources.
For the installer
■An all-pole isolating switch with a contact gap of at
least 3 mm must be present in the installation circuit.
This is not necessary if the appliance is connected
by a plug that is accessible to the user.
■Electrical safety: The cooker corresponds to safety
class I and may only be used in conjunction with a
safety earth terminal.
■A type H 05 VV-F or equally rated lead must be used
to connect the appliance.
Adjacent units
Any adjacent units must not be made of flammable
materials. The fronts of any adjacent units must be heat-
resistant up to at least 90 °C.
Wall fixing
To prevent the cooker from tipping over, you must fix it
to the wall using the enclosed bracket. Please observe
the installation instructions for fixing the oven to the
wall.
Door lock
To prevent children reaching into the oven when it is
hot, the oven door is equipped with a lock. It is located
at the top of the oven door.
Opening the oven door
Press the lock upwards (picture A).
Removing the door lock
If the door safety lock is no longer needed or if it is
soiled:
1. Opening the oven door
2. Unscrew the screw and remove the door lock
(picture B).
3. Close the oven door.
Measures to be noted during transport
Secure all mobile parts in and on the appliance using
an adhesive tape that can be removed without leaving
any traces. Push all accessories (e.g. baking tray) into
the corresponding slots with cardboard at the edges, in
order to avoid damaging the appliance. Place
cardboard or similar between the front and rear side to
prevent knocks against the inside of the glass door.
Secure the door and, if available, the top cover to the
appliance sides using adhesive tape.

en Getting to know your appliance
10
Keep the original appliance packaging. Only transport
the appliance in the original packaging. Observe the
transport arrows on the packaging.
If the original packaging is no longer available
pack the appliance in protective packaging to
guarantee sufficient protection against any transport
damage.
Transport the appliance in an upright position. Do not
hold the appliance by the door handle or the
connections on the rear, as these could be damaged.
Do not place any heavy objects on the appliance.
*Getting to know your
appliance
Get t i ng to know your appl i anc e In this section, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
General information
The design depends on the respective appliance
model. Cooking area
Here is an overview of the control panel. The design
depends on the respective appliance model.
Residual heat indicator
The hob has a residual heat indicator for each hotplate.
It shows which hotplates are still hot. Even if the hob is
switched off, the display remains lit until the hotplate
has cooled down sufficiently.
You can save energy by using the residual heat to keep
a small dish warm, for example.
Explanations
1 Hob**
2Control panel**
3* Cooling fan
4 Oven door**
5* Plinth drawer**
* Optional (available for some appliances)
** Details may vary depending on the appliance
model.






Explanations
1 Hotplate 18 cm
2 Hotplate 14.5 cm
3 Hotplate 14.5 cm
4 Hotplate 21 cm
5 Residual heat indicator





Getting to know your appliance en
11
Control panel
Details may vary depending on the appliance model.
Types of heating and functions
Use the function selector to set the types of heating and
other functions.
To make sure you always use the right type of heating
to cook your food, we have explained the differences
and applications below.
--------
Other functions
Your new oven has yet more functions; see below for a
brief description of these.
--------
Temperature
Use the temperature selector to set the temperature in
the cooking compartment. You can also use it to select
the settings for other functions.
For temperature settings above 250 °C, the appliance
reduces the temperature to approx. 240 °C after
approx. 10 minutes. If your appliance has the top/
bottom heating or bottom heating types, this reduction
does not take place.
--------
Temperature display
When the appliance is heating, the indicator lamp
above the temperature selector is lit. It goes out during
pauses in the heating.
When you are preheating the appliance, the optimal
time to place your food in the cooking compartment is
when the indicator lamp first goes out.
Note: Due to thermal inertia, the temperature displayed
may be slightly different to the actual temperature inside
the oven.
Hotplate controls
You can use the four hotplate controls to control the
heat output provided by each hotplate.
Type of heating Use
%Top/bottom heating For traditional baking and roasting on one level. Especially suitable for cakes with moist
toppings.
Heat is emitted evenly from above and below.
This type of heating is used to measure the energy consumption in the conventional
mode.
8Gentle top/bottom heating For gently cooking selected types of food.
Heat is emitted from above and below.
This type of heating is used to measure the energy consumption in the conventional
mode.
$Bottom heating For cooking in a bain marie and for baking food for extra time.
Heat is emitted from below.
*Centre-area grill This heating function is suitable for grilling small amounts of steak, sausages, fish and
bread.
The centre part of the grill heating element becomes hot.
(Grill, large area For grilling flat items, such as steaks or sausages, for making toast, and for browning
food.
The whole area below the grill element becomes hot.
Function Use
^Interior lighting Switches on the interior lighting; all other functions remain off.
Makes it easier to clean the cooking compartment, for example.
DChildproof lock Switch off the power supply for the oven and hob functions on the control panel.
After activation, the appliance cannot be switched on.
Position Meaning
Ú"Off" position The appliance is not heating.
50-275 Temperature
range
The temperature that can be set in the
cooking compartment in °C.
1, 2, 3
or
I, II, III
Grill settings The configurable settings for the grill,
large area (and small area *
(depending on the appliance model).
Setting 1 = low
Setting 2 = medium
Setting 3 = high
Setting Meaning
ýOff position The hotplate is switched off.
1-9 Heat settings 1 = lowest output
9 = highest output

en Accessories
12
When you switch on a hotplate, the indicator lamp lights
up.
Cooking compartment
Various functions in the cooking compartment make
your appliance easier to use. For example, the cooking
compartment is well lit and a cooling fan prevents the
appliance from overheating.
Opening the appliance door
If you open the appliance door when the appliance is in
operation, the appliance will continue to operate as
before.
Interior lighting
With most heating functions and other functions, the
interior lighting in the cooking compartment will remain
lit while the oven is in operation. When the function
selector is turned to bring operation to an end, the
lighting will go out.
By turning the function selector to the interior lighting
setting, you can switch on the lighting without heating
the oven. This makes it easier to clean your appliance,
for example.
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
quickly after operation, the cooling fan continues to run
for a certain period afterwards.
_Accessories
Ac c e s s o r i e s Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Accessories included
Your appliance is equipped with the following
accessories:
--------
Only use genuine accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
Note: The accessories may become deformed when
they become hot. This does not affect their function.
Once they cool down again, they regain their original
shape.
Inserting accessories
The cooking compartment has five shelf positions. The
shelf positions are counted from the bottom up.
In some appliances, the highest shelf position is
marked on the cooking compartment by the grill
symbol.
Always insert accessories between the two guide rods
for the shelf position.
Accessories can be pulled out approximately halfway
without tipping.
Wire rack
For ovenware, cake tins and ovenproof
dishes.
For roasts, grilled items and frozen
meals.
Universal pan
For moist cakes, pastries, frozen meals
and large roasts.
It can be used to catch dripping fat when
you are grilling directly on the wire rack.
Baking tray
For tray bakes and small baked prod-
ucts.






Accessories en
13
When sliding accessories into the cooking
compartment, ensure that the kink in the side rail is at
the back. Only then will they lock in place.
Notes
■Hold the baking tray securely at the sides with both
hands and slide it into the shelf supports, keeping it
parallel. Do not move the baking tray from side to
side as you slide it in, otherwise it will not go in easily
and the enamelled surfaces may be damaged.
■Make sure that you always insert the accessories
into the cooking compartment the right way round.
■Always insert the accessories fully into the cooking
compartment so that they do not touch the appliance
door.
■Take any accessories that you will not be using out
of the cooking compartment.
Optional accessories
You can buy optional accessories from our after-sales
service, from specialist retailers or online. You will find a
comprehensive range of products for your appliance in
our brochures and online.
Their availability and whether it is possible to order
them online varies from country to country. See your
sales brochures for more details.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, always quote the exact
product number (E no.) of your appliance.
~"Customer service" on page 23
--------
Optional accessories
Wire rack
For cookware, cake tins and ovenproof dishes, and for roasts and
grilled food.
Baking tray
For tray bakes and small baked items.
Universal pan
For moist cakes, baked items, frozen food and large roasts.
It can be used to catch dripping fat when you are grilling directly on
the wire rack.
Wire insert
For meat, poultry and fish.
For inserting into the universal pan to catch dripping fat and meat
juices.
Professional pan
For preparing large quantities of food. Also ideal for moussaka, for
example.
Lid for the professional pan
The lid turns the professional pan into a professional roasting dish.
Pizza tray
For pizzas and large round cakes.
Grill tray
Use for grilling in place of the wire rack or as a splatter guard. Use in
the universal pan only.
Baking stone
For home-made bread, bread rolls and pizzas that you wish to have a
crispy base.
The baking stone must be preheated to the recommended tempera-
ture.
Glass roasting dish
For stews and bakes.
Glass pan
For bakes, vegetable dishes and baked items.
Pull-out system, one level
Fitting pull-out rails at position 2 will allow you to pull accessories out
further without them tipping.
Pull-out system, two levels
Fitting pull-out rails at positions 2 and 3 will allow you to pull accesso-
ries out further without them tipping.
Pull-out system, three levels
Fitting pull-out rails at positions 1, 2 and 3 will allow you to pull acces-
sories out further without them tipping.

en Before using for the first time
14
KBefore using for the first
time
Be f o r e usi ng for the fi rst ti me Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Cleaning the cooking compartment and
accessories
Before using the appliance to prepare food for the first
time, you must clean the cooking compartment and
accessories.
Cleaning the cooking compartment
To remove the new-appliance smell, heat up the
cooking compartment when empty and with the oven
door closed.
Make sure that the cooking compartment does not
contain any leftover packaging, such as polystyrene
pellets. Before heating the appliance, wipe the smooth
surfaces in the cooking compartment with a soft, wet
cloth. Keep the kitchen ventilated while the appliance is
heating.
Make the settings indicated. You can find out how to set
the type of heating and the temperature in the next
section. ~"Operating the appliance" on page 16
Switch off the appliance after the cooking time
indicated.
After the cooking compartment has cooled down, clean
the smooth surfaces with soapy water and a dish cloth.
Cleaning the accessories
Clean the accessories thoroughly using soapy water
and a dish cloth or soft brush.
1Setting the cooking time
Se t t i n g the c ooki ng ti me This chapter explains how to set a hotplate. The table
shows heat settings and cooking times for various
meals.
Setting procedure
Adjust the heat setting of the individual hotplates using
the hotplate controls.
Position 0 = off
Position 1 = lowest heat setting
Position 9 = highest heat setting
When you switch on a hotplate, the indicator lamp lights
up.
Table of cooking times
The following table provides some examples.
Cooking times and heat settings may vary depending
on the type of food, its weight and quality. Deviations
are therefore possible.
Settings
Heating function Top/bottom heating %
Temperature maximum
Duration One hour
Ongoing cooking
setting
Ongoing cooking
time in minutes
Melting
Chocolate, cooking chocolate, gelatine
Butter
1
1-2
-
-
Heating and keeping warm
Stew (e.g. lentil stew)
Milk**
1-2
1-2
-
-
Poaching, simmering
Dumplings
Fish
White sauces, e.g. béchamel sauce
4*
3*
1
20-30 mins
10-15 mins
3-6 mins
* Continue cooking without a lid
** Without lid

Setting the cooking time en
15
Boiling, steaming, stewing
Rice (with double the quantity of water)
Unpeeled boiled potatoes
Boiled potatoes
Pasta, noodles
Stew, soups
Vegetables
Vegetables, frozen
Cooking in a pressure cooker
3
3-4
3-4
5*
3-4
3-4
3-4
3-4
15-30 mins
25-30 mins
15-25 mins
6-10 mins
15-60 mins
10-20 mins
10-20 mins
-
Braising
Roulades
Pot roasts
Goulash
3-4
3-4
3-4
50-60 mins
60-100 mins
50-60 mins
Frying**
Escalope, plain or breaded
Escalope, frozen
Steak (3 cm thick)
Fish and fish fillet, plain
Fish and fish fillet, breaded
Fish and fish fillet, breaded and frozen, e.g. fish fingers
Stir fry, frozen
Pancakes
6-7
6-7
7-8
4-5
4-5
6-7
6-7
5-6
6-10 mins
8-12 mins
8-12 mins
8-20 mins
8-20 mins
8-12 mins
6-10 mins
continuous
Ongoing cooking
setting
Ongoing cooking
time in minutes
* Continue cooking without a lid
** Without lid

en Operating the appliance
16
1Operating the appliance
Oper at i ng the appl i ance You have already learnt about the controls and how
they work. Now we will explain how to apply settings on
your appliance.
Switching the appliance on and off
Use the function selector to switch the appliance on or
off. Turning the function selector to any position other
than the "Off" position switches on the appliance. To
switch off the appliance, always turn the function
selector to the "Off" position.
Setting the type of heating and temperature
It is very easy to apply the settings you require to your
appliance using the function and temperature selector.
To find out which heating function is best for which type
of food, refer to the beginning of the instruction manual.
Example in the picture: Top/bottom heating %at
190 °C.
1. Use the function selector to set the heating function.
2. Use the temperature selector to set the temperature
or grill setting.
The appliance starts to heat up after a few seconds.
Once the food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Changing
The heating function and temperature can be changed
at any time using the relevant selector.
AChildproof lock
Ch i l d p r o o f lock Your appliance is equipped with a childproof lock so
that children cannot switch it on accidentally or change
any settings.
Note: If the childproof lock is activated during
operation, the power supply to the appliance is
interrupted. The appliance is blocked. For the initial use
of the appliance, the blockage must be eliminated.
Activating and deactivating
To activate the childproof lock, turn the function selector
to the Dposition.
The power supply to the oven and hob is interrupted.
The appliance is blocked.
To deactivate, press the function selector and turn it to
the off position. The blockage is eliminated.

&

Cleaning en
17
DCleaning
Cl eani ng With good care and cleaning, your appliance will retain
its appearance and remain fully functioning for a long
time to come. We will explain here how you should
correctly care for and clean your appliance.
Cleaning agents
Damage to the various different surfaces caused by
using the wrong cleaning agent can be avoided by
observing the following instructions.
When cleaning the hob do not use
■undiluted washing-up liquid or dishwasher detergent,
■scouring pads,
■abrasive cleaning agents such as oven cleaner or
stain remover,
■high-pressure cleaners or steam jets.
■Do not clean individual parts in the dishwasher.
When cleaning the oven do not use
■sharp or abrasive cleaning agents,
■cleaning agent with a high alcohol content,
■scouring pads,
■high-pressure cleaners or steam jets.
■Do not clean individual parts in the dishwasher.
Wash new sponges thoroughly before first use.
:Warning – Risk of burns!
The appliance becomes very hot. Never touch the
interior surfaces of the cooking compartment or the
heating elements. Always allow the appliance to cool
down. Keep children at a safe distance.
Zone Cleaning agent
Stainless steel sur-
faces*
(depending on appli-
ance model)
Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth. On stainless steel surfaces, always wipe
parallel to the natural grain. Otherwise, you
may scratch the surface. Remove patches and
splashes of limescale, grease, starch and albu-
min (e.g. egg white) immediately. Corrosion
can form under such patches and splashes.
Special care products suitable for hot stainless
steel surfaces are available from our after-
sales service and from specialist retailers.
Apply a thin layer of care product with a soft
cloth.
Enamel, painted, plas-
tic and screen-printed
surfaces*
(depending on appli-
ance model)
Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth. Do not use glass cleaner or glass scrap-
ers for cleaning.
Control panel Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth. Do not use glass cleaner or glass scrap-
ers for cleaning.
* Optional (available for some appliances, depending on the appliance
model)
Upper glass cover*
(depending on appli-
ance model)
Glass cleaner:
Clean with a soft cloth.
You can remove the upper glass cover for
cleaning. To find out how to do this, please
refer to the section Upper glass cover.
Rotary knobs
Do not remove.
Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth.
Hob surround Hot soapy water:
Do not clean with a glass scraper, lemon juice
or vinegar.
Gas hob and pan sup-
ports*
(depending on appli-
ance model)
Hot soapy water.
Use very little water. Water must not be
allowed to enter the appliance through the
base of the burners.
Clean off boiled-over liquids and spilt food
immediately.
You can remove the pan supports.
Cast iron pan supports*:
Do not clean in the dishwasher.
Gas burners*
(depending on appli-
ance model)
Remove the burner head and cap and clean
with hot soapy water.
Do not clean in the dishwasher.
The gas outlet openings must remain unob-
structed at all times.
Ignition plugs: Small, soft brush.
The gas burners only work properly when the
ignition plugs are dry. Dry all parts thoroughly.
Ensure that they are refitted correctly.
The burner caps are coated in black enamel.
The colour may change over time. This does
not impair their performance.
Electric hotplate*
(depending on appli-
ance model)
Abrasive materials or sponges:
Briefly heat up the hotplate afterwards, so that
it dries. Hotplates can rust over time if they
remain wet. Apply care product to finish.
Clean off boiled-over liquids and spilt food
immediately.
Hotplate ring*
(depending on appli-
ance model)
Remove yellow to blue iridescent discoloura-
tion from the hotplate ring with a steel care
product.
Do not use any abrasive materials that may
scratch surfaces.
Ceramic hob*
(depending on appli-
ance model)
Care: Protective/care products for ceramics
Cleaning: Cleaning agents suitable for ceram-
ics.
Follow the cleaning instructions on the packag-
ing.
:Glass scraper for stubborn dirt:
Remove the protective cover and clean using
the blade only. Caution: The blade is very
sharp. Risk of injury.
Cover the blade again after cleaning. Replace
damaged blades immediately.
Zone Cleaning agent
* Optional (available for some appliances, depending on the appliance
model)

en Cleaning
18
Notes
■Slight differences in colour on the front of the
appliance are caused by the use of different
materials, such as glass, plastic and metal.
■Shadows on the door panels, which look like
streaks, are caused by reflections made by the
interior lighting.
■Enamel is baked on at very high temperatures.This
can cause some slight colour variation. This is
normal and does not affect operation.
The edges of thin trays cannot be completely
enamelled. As a result, these edges can be rough.
This does not impair the anti-corrosion protection.
Glass hob*
(depending on appli-
ance model)
Care: Protective/care products for glass
Cleaning: Cleaning agents for glass.
Follow the cleaning instructions on the packag-
ing.
:Glass scraper for stubborn dirt:
Remove the protective cover and clean using
the blade only. Caution: The blade is very
sharp. Risk of injury.
Cover the blade again after cleaning. Replace
damaged blades immediately.
Glass panel Glass cleaner:
Clean with a soft cloth.
Do not use the glass scraper.
The door can be removed to facilitate cleaning.
To find out how to do this, please refer to the
section Removing and refitting the
oven door.
Childproof lock*
(depending on appli-
ance model)
Hot soapy water:
Clean with a dish cloth.
If a childproof lock has been fitted to the oven
door, it must be removed before cleaning.
If it is very dirty, the childproof lock will not
work properly.
Seal
Do not remove.
Hot soapy water:
Clean with a dish cloth. Do not scour.
Cooking zone Hot soapy water or a vinegar solution:
Clean with a dish cloth.
For stubborn dirt, use a stainless steel scour-
ing pad or oven cleaner.
Only use when the cooking compartment is
cold.
:Please use the self-cleaning function to
clean self-cleaning surfaces. To find out how to
do this, please refer to the section Self-
cleaning.
Caution! Never use oven cleaner on self-clean-
ing surfaces.
Glass cover for the
oven light
Hot soapy water:
Clean with a dish cloth.
Shelf Hot soapy water:
Clean with a dish cloth or a brush.
You can remove the shelves for cleaning. To
find out how to do this, please refer to the sec-
tion Removing and refitting shelves.
Telescoping extension rails*
(depending on appliance model)
Hot soapy water:
Clean with a dish cloth or a brush.
Do not remove the lubricant from the extension
rails. It is best to clean them when they are
pushed in. Do not soak, clean in the dish-
washer, or clean in the oven as part of the self-
cleaning programme. This may damage the
shelves and they may no longer work properly
as a result.
Zone Cleaning agent
* Optional (available for some appliances, depending on the appliance
model)
Accessories Hot soapy water:
Soak and then clean with a dish cloth or a
brush.
Aluminium baking tray*:
(depending on appliance model)
Dry with a soft cloth.
Do not clean in the dishwasher.
Never use oven cleaner.
To prevent scratches, never touch the metal
surfaces with a knife or a similar sharp object.
Harsh cleaning products, scratchy sponges
and rough cleaning cloths are not suitable.
Otherwise, you may scratch the surface.
Rotary spit*
(depending on appliance model)
Hot soapy water:
Clean with a dish cloth or a brush. Do not clean
in the dishwasher.
Meat thermometer*
(depending on appliance model)
Hot soapy water:
Clean with a dish cloth or a brush. Do not clean
in the dishwasher.
Plinth drawer*
(depending on appli-
ance model)
Hot soapy water:
Clean with a dish cloth.
Zone Cleaning agent
* Optional (available for some appliances, depending on the appliance
model)

Rails en
19
Keeping the appliance clean
Always keep the appliance clean and remove dirt
immediately so that stubborn deposits of dirt do not
build up.
:Warning – Risk of fire!
Loose food remnants, fat and meat juices may catch
fire. Before using the appliance, remove the worst of the
food remnants from the cooking compartment, heating
elements and accessories.
Tips
■Clean the cooking compartment after each use. This
will ensure that dirt cannot be baked on.
■Always remove flecks of limescale, grease, starch
and albumin (e.g. egg white) immediately.
■Use the universal pan for baking very moist cakes.
■Use suitable ovenware for roasting, e.g. a roasting
dish.
pRails
Ra i l s With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
shelves and clean them.
Detaching and refitting the rails
The rails can be removed for cleaning. The oven must
have cooled down.
Unhooking the rails
1. Hold the shelf frames from underneath and pull
slightly forward. Pull the extension pins at the bottom
of the rails out of the mounting holes (Fig. A).
2. Then fold the rails upwards and carefully remove
them (Fig. B).
Clean the rails with washing-up liquid and a sponge. For
stubborn deposits of dirt, use a brush.
Installing the frames
1. Insert the two hooks carefully into the upper holes.
(Figure A-B)
:Warning
Incorrect assembly!
Never move the frame before the two hooks are fully
anchored in the upper holes. The enamel could be
damaged and may break (figure C).
%
$
% $
&

en Appliance door
20
2. the two hooks must be inserted fully into the upper
holes. Now move the frame slowly and carefully
downwards and insert in the lower holes (figure D).
3. Insert both frames into the side walls of the oven
(figure E).
If the rails are fitted correctly, the distance between the
two upper shelf positions is greater.
qAppliance door
Ap p l i a n c e door With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
appliance door and clean it.
Detaching and attaching the oven door
For cleaning purposes and to remove the door panels,
you can detach the oven door.
The oven door hinges each have a locking lever. When
the locking levers are closed (figure A), the oven door
is secured in place. It cannot be detached. When the
locking levers are open in order to detach the oven
door (Fig. B), the hinges are locked. They cannot snap
shut.
:Warning – Risk of injury!
Whenever the hinges are not locked, they snap shut
with great force. Ensure that the locking levers are
always fully closed or, when detaching the oven door,
fully open.
Detaching the door
1. Open the oven door fully.
2. Fold up the two locking levers on the left and right
(figure A).
3. Close the oven door as far as the limit stop. With
both hands, grip the door on the left and right-hand
sides. Close the door a little further and pull it out
(figure B).
(
'
%$
%$
