CHOP SAW
Model 0601471039
INDUSTRIAL
April 1998 3814
S-B Power Tool Company Chicago IL 60646-5999
6
5
W
G
B
Z
51
15
14
60
33
35
61
52
28
32
45 55 14 53
38
Z
79
80
45
44
101
47
66 54
101
150
46
78
98
66
9
127
29 7
31
82 48 31
63
4
36
30
132
GWR
BW
43
73
75
41
75
71
39
71
77
40 37 154
59
50 123 56
106
65
47
49 74
73
58
76
120
57
42
112
103
130
652
126
152
67
72
W
G
R
62
16 810
51 2
21
69
68
64
70
30
8
99
3
84
83
13
17
11
19
8169 23
85
801
811
82
11
20
114

2 2 610 355 302 Field 115V 22
3 2 610 355 301 Armature w/Fan115V AW
4 2 610 355 335 Switch 15
5 2 610 355 306 Cord 11
6 2 610 355 307 Strain Relief 11
7 2 610 355 342 Clamp 89
8 2 610 994 082 Nameplate "3814" 9
9 2 610 994 083 Label "Bosch" 9
11 2 610 355 310 Cable 10
13 2 610 010 824 Ball Bearing 60
14 2 610 023 268 Ball Bearing {2} 61
15 2 610 355 311 Baffle 24
16 2 610 355 297 Brush Holder 25
17 2 610 355 309 Washer 65
19 2 610 355 349 Baffle 24
20 2 610 994 505 Gear Housing 72
21 2 610 355 298 Brush Cap {2} 25
23 2 610 355 303 Screw {2} 89
28 2 610 355 343 Key 66
29 2 610 355 341 Screw {2} 89
30 2 610 355 337 Screw & Washer {9} 89
31 2 610 356 706 Nut {11} 89
32 2 610 355 323 Output Spindle 52
33 2 610 355 322 Gear 33
35 2 610 355 313 Needle Bearing 56
36 2 610 355 338 Screw 89
37 2 610 352 729 Sleeve 82
38 2 610 355 317 Gear Housing Cover 70
39 2 610 355 267 Screw 89
40 2 610 355 270 Screw 89
41 2 610 355 268 Screw 89
42 2 610 355 286 Knob 63
43 2 610 358 055 Bolt {3} 89
44 2 610 355 345 Bushing 82
45 2 610 355 344 Bushing {2} 82
46 2 610 355 347 Bumper {2} 9
47 2 610 355 284 Retaining Ring {2} 89
48 2 610 355 340 Hook 9
49 2 610 355 279 Chain 9
50 2 610 994 516 Base Assembly 88
51 2 610 355 314 Plug {2} 9
52 2 610 355 348 Roll Pin 66
53 2 610 355 321 Washer 65
54 2 610 355 331 Screw {2} 89
55 2 610 355 320 Retaining Ring 89
56 2 610 994 510 Pin 9
57 2 610 328 702 Push Nut 89
58 2 610 355 280 Roll Pin 66
59 2 610 355 265 Shaft 54
Service Notes:
60 2 610 355 315 Spindle Lock Pin 81
61 2 610 355 316 Spring 27
62 2 610 355 295 Screw 89
63 2 610 355 336 Screw {2} 89
64 2 610 357 149 Screw 89
65 2 610 355 259 Screw {4} 89
66 2 610 355 330 Washer {4} 65
67 2 610 355 278 Screw {2} 89
68 2 610 355 293 Screw {2} 89
69 2 610 355 304 Washer {4} 65
70 2 610 355 269 Washer 65
71 2 610 355 264 Washer {5} 65
72 2 610 355 263 Screw {2} 89
73 2 610 355 271 Washer {3} 65
74 2 610 355 277 Screw {2} 89
75 2 610 355 272 Nut {2} 89
76 2 610 355 290 Retaining Ring 89
77 2 610 355 274 Washer {2} 65
78 2 610 355 332 Nut {2} 89
79 2 610 355 325 Lock Washer {4} 65
80 2 610 355 324 Screw {4} 89
81 2 610 355 570 Washer {2} 65
82 2 610 345 391 Washer {2} 65
83 2 610 355 318 Washer 65
84 2 610 355 319 Washer 65
85 2 610 355 299 Grommet 9
98 2 610 355 329 Lower Guard 92
99 2 610 994 522 Cover Plate 70
101 2 610 910 022 Flange {2} 65
103 2 610 355 266 Spring 27
106 2 610 994 515 Lock 9
112 2 610 355 289 Crank Screw 9
114 2 610 994 511 Fence 9
120 2 610 995 518 Support Bracket 62
123 2 610 994 509 Clamp Plate 80
126 2 610 355 275 Plate 9
127 2 610 994 086 Label "Warning" 9
130 2 610 355 258 Post {4} 9
132 2 610 355 328 Upper Guard 92
+ 145 2 610 994 085 Label "Depth" 9
+ 146 2 610 994 084 Label "Warning" 9
150 2 610 910 023 Bolt 89
152 2 610 994 512 Side Cover 92
154 2 610 994 513 Support Bracket 62
652 2 610 355 260 Wrench 9
801 2 610 994 504 Motor Housing Assembly 71
w/pos. 16, 62, 85
810 2 610 995 539 Brush Set 26
811 2 610 995 517 Handle Assembly 74
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
F/CPos. Part Number Description {Qty} F/CPos. Part Number Description {Qty}
3814 CHOP SAW
