Bosch 601474039 User manual

1 2 610 967 440 Motor Housing 71
2 2 610 911 475 Field 120V 22
3 2 610 911 476 Armature w/Fan 120V AW
4 2 610 910 020 Switch On/Off 120V 15
4/10 2 610 358 901 Screw {6} 89
5 2 610 911 463 Cord 120V 16/2 11
6 2 610 911 464 Strain Relief 11
7 2 610 910 756 Cord Clamp 89
8 2 610 911 450 Washer {2} 65
9 2 610 994 137 Nameplate "3912" 9
12 2 610 911 485 Rubber Bearing Sleeve 82
13 2 610 042 699 Ball Bearing 60
14 2 610 017 349 Ball Bearing 61
15 2 610 911 486 Wire Protector 92
16 2 610 911 488 Brush Holder {2} 25
17 2 610 910 773 Cable 10
18 2 610 910 780 Cable 10
19 2 610 911 477 Baffle 24
20 2 610 911 474 Gear Housing 72
21 2 610 911 487 Brush Cap {2} 25
22 2 610 911 479 Bearing Flange 38
23 2 610 911 452 Screw {2} 89
25 2 610 910 785 Screw & Washer {2} 89
26 2 610 910 754 Spring 9
27 2 610 967 448 Button 9
28 2 610 910 046 Washer 65
29 2 615 296 765 Screw & Washer {3} 89
30 2 610 910 827 Switch Lever 63
31 2 610 355 337 Screw & Washer {2} 89
32 2 610 911 458 Screw {4} 89
33 2 610 911 482 Gear Assembly 32
34 2 610 910 789 Ball Bearing 51
35 2 610 910 787 Ball Bearing 56
36 2 610 990 525 Guard Linkage 62
37 2 610 910 849 Spacer 82
38 2 610 910 821 Cover 70
39 2 610 355 269 Washer {2} 65
40 2 610 908 270 Washer 65
43 2 610 992 376 Spring 27
44 2 610 967 444 Pivot Bracket 62
45 2 610 967 445 Carry Handle 74
46 2 610 910 761 Plug {2} 9
47 2 610 358 172 Nut 89
48 2 610 990 504 Cord Clamp 89
49 2 610 355 338 Screw {4} 89
50 2 610 967 447 Base 88
51 2 610 910 757 Detent Pin 81
52 2 610 910 768 Bushing 82
53 2 610 910 765 Spring 27
54 2 610 910 838 Lock Lever 64
55 2 615 297 329 Washer 65
56 2 610 910 848 Nut 89
57 2 610 910 837 Retaining Plate 65
58 2 610 910 769 Knob 63
59 2 610 910 842 Shaft 54
60 2 610 911 484 Spindle Lock Pin 81
61 2 610 910 770 Spring 80
62 2 610 910 781 Screw {6} 89
63 2 610 328 605 Set Screw {2} 89
64 2 610 910 796 Roll Pin 66
65 2 610 910 750 Pad 88
66 2 610 911 465 Washer {2} 65
67 2 610 910 788 O-Ring 78
68 2 610 910 783 Nut 89
69 2 615 297 323 Screw 89
71 2 610 910 790 Screw 89
72 2 610 910 791 Nut 89
73 2 610 911 451 Screw & Washer 89
74 2 610 911 460 Screw {2} 89
75 2 610 910 786 Set Screw 89
76 2 610 910 751 Spacer 82
77 2 610 910 760 Nut 89
78 2 610 910 797 Screw 89
79 2 610 905 940 Nut 89
80 2 610 356 707 Screw & Washer {2} 89
81 2 610 910 784 Screw {3} 89
82 2 610 911 455 Lock Washer{2} 65
83 2 610 910 779 Washer 65
84 2 610 910 792 Washer 65
86 2 610 911 466 Screw & Washer {3} 89
87 2 610 355 304 Washer {2} 65
88 2 610 910 762 Screw 89
89 2 610 910 766 Nut 89
90 2 610 355 264 Washer 65
91 2 610 910 752 Coil Spring 27
93 2 610 992 377 Bolt 89
94 2 610 910 778 Bolt 89
95 2 610 967 437 Lock Bolt 86
96 2 610 910 758 Spring 27
97 2 610 328 600 Nut {2} 89
98 2 610 990 523 Lower Guard 92
99 2 610 911 461 Screw & Washer {4} 89
100 2 610 990 503 Washer {3} 65
101 2 610 910 846 Inner Blade Washer 65
12" MITER SAW
Model 0601474039
Open for Tool Illustration
3912
F/CPos. Part Number Description {Qty} F/CPos. Part Number Description {Qty}
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
INDUSTRIAL
July 1998

65 69
T
V
UVU
56 76
151 37
78
36 98
86
29 148 8
38
91
117
152
59
73
66
150
99
102 101
63
104
103 48149
132
66
T
Z
S
53
88
54
89
55
90
72 84
109
46
44
71
52
79
58 95
67
51
96
653
650
R
W
G
A
BC
Y
A
C
X
43
27
15
4/10
4
133
30
652
18
17
110
4/10
32
74
45
49
110
29
7142
26
6
5
654
128
129
153
162
164
161
163
160
159
Yellow
Black
Gray
Blue
White
(Power Cord)
White
Red
(Power Cord)

R
Y
B
G
21
W
810
143
31
16
21 810
25 9
1
2
19
12
13
23
82
87
X
3
14
61 60
64 20
33
140
34
28
81100 22
35
Z
116 114
137
138
123
S
118 107
57
80
62
94
39
119144
97
68
75
105
47
83
136
40 111
113
115
106
139
77
119
119 120
145
146
112
121
122
93
50
141
126
86
130
842
125
124
127
131
137
137
147
156191157
154
155
158

+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
S-B Power Tool Company Chicago IL 60646-5999
Service Notes:
102 2 610 910 847 Outer Blade Washer 65
103 2 610 910 755 Coil Spring 27
104 2 610 910 753 Sleeve {2} 82
105 2 610 990 527 Table Insert 87
106 2 610 910 833 Plate 65
107 2 610 910 835 Bevel Pointer 9
109 2 610 910 839 Shaft 54
110 2 610 992 384 Handle Assembly 74
111 2 610 967 449 Table 9
112 2 610 910 822 Knob 63
113 2 610 910 831 Miter Pointer 9
114 2 610 967 427 Fence 9
115 2 610 910 834 Tension Plate 9
116 2 610 967 429 Fence Attachment 9
117 2 610 910 820 Dust Collector 9
118 2 610 358 055 Bolt {2} 89
119 2 610 309 996 Washer {3} 65
120 2 610 910 775 Lever Assembly 64
121 2 610 910 830 Glide Plate {3} 65
122 2 610 911 658 Label "No Hands" {2} 9
123 2 610 967 431 Extension Bracket 62
124 2 610 911 470 Rubber Bushing 80
125 2 610 355 777 Hex Wrench 6mm 9
126 2 610 910 844 RetainingPlate 65
127 2 610 994 139 Label LH "Warning" 9
128 2 610 990 522 Washer 65
129 2 610 990 518 Roller 56
130 2 610 910 764 Rubber Foot {4} 9
131 2 610 994 138 Label RH "Warning" 9
132 2 610 967 435 Upper Guard 92
133 2 610 911 459 Screw 89
136 2 610 910 777 Screw 89
137 2 610 910 793 Screw & Washer {3} 89
138 2 610 356 733 Screw & Washer {2} 89
139 2 610 911 469 Screw & Washer {2} 89
140 2 610 355 320 Retaining Ring 89
141 2 610 910 794 Nut {2} 89
142 2 610 320 345 Screw 89
143 2 610 911 456 Set Screw {2} 89
144 2 610 910 782 Screw 89
145 2 610 910 774 Nut 89
146 2 610 910 776 Screw 89
147 2 610 910 795 Screw {4} 89
148 2 610 910 799 Screw 89
149 2 610 355 293 Screw 89
150 2 610 911 467 Blade Bolt 85
151 2 610 994 140 Label "Warning" 9
152 2 610 910 826 Deflector 92
153 2 610 990 521 Retaining Ring 89
154 2 610 967 433 Clamping Plate 80
155 2 610 358 439 Spring Washer 65
156 2 610 967 438 Retaining Ring 89
157 2 610 967 439 Nut 89
158 2 610 992 372 Bolt 89
159 2 610 027 372 Washer 65
160 2 610 992 366 Retaining Ring 89
161 2 610 992 365 Button 9
162 2 610 992 364 Linkage 9
163 2 610 355 300 Screw 89
164 2 610 992 369 Push Nut 89
191 2 610 967 432 Lever 64
650 2 610 911 939 Dust Bag 9
654 2 610 910 845 Dust Elbow 9
652 2 610 910 828 Wrench 9
653 2 610 992 368 Clamp Assembly 80
810 2 610 993 231 Brush Set 120V 26
842 2 610 910 767 Knob {2} 63
F/CPos. Part Number Description {Qty} F/CPos. Part Number Description {Qty}
