Bosch CS10 User manual

Page 1
0 601 672 039
UN-HD PORT. CIRCULAR SAW CS10
24.10.2005
22:07:23
Pa
g
e 1 of 4
10/24/2005htt
p
://le11288.le.de.bosch.com/sid/
p
rintdirect.as
p
?ID
_
PRODUCT=0601672039&ID
_
VE...

Item Quantity Order No. Designation Price group Page
1 1 2 610 917 049 MOTOR HOUSING \ BLUE 20 1
2 1 2 610 350 741 FIELD \ 110V 31 1
4 1 2 610 919 466 ON-OFF SWITCH 19 1
5 1 2 610 920 507 MAINS CONNECTION CABLE 22 1
6 1 2 610 005 970 GROMMET 16 1
7 1 2 610 993 191 CABLE CLIP 10 1
8 1 2 610 918 141 NAMEPLATE 12 1
9 1 2 610 918 142 LABEL 12 1
13 12 610 017 348 DEEP-GROOVE BALL BEARING 19 1
14 12 610 350 311 DEEP-GROOVE BALL BEARING 24 1
19 22 610 326 578 SCREW 14 1
22 12 610 917 052 HOUSING COVER \ BLACK 12 1
23 12 610 917 050 BAFFLE 11 1
24 12 610 917 061 HANDLE 24 1
25 12 610 924 143 AUXILIARY HANDLE \ BLACK 13 1
26 12 610 917 826 GEAR HOUSING 31 1
28 12 610 326 023 BUSHING 12 1
29 12 610 038 934 CONNECTING CABLE 13 1
30 12 610 038 935 CABLE 13 1
31 22 610 918 148 CABLE 11 1
32 12 610 917 064 LOCKING LEVER 12 1
33 12 610 918 150 SPRING 10 1
37 12 610 923 352 PIVOTING BLADE GUARD 25 1
38 12 610 917 405 LEVER 10 1
39 12 610 929 391 SPRING 1
40 12 610 921 144 RETAINING RING 10 1
41 12 610 919 164 INNER RING 13 1
42 12 610 355 550 FLANGE 15 1
43 12 610 346 554 HEXAGON SCREW 14 1
44 12 610 918 151 RUBBER BUSHING 10 1
45 12 610 917 400 SCREW 10 1
46 32 610 904 165 LOCK NUT 10 1
47 12 610 917 059 BASE 35 1
48 12 610 917 189 BRACKET 17 1
49 12 610 923 551 BRACKET 13 1
50 22 610 917 399 SCREW 10 1
51 22 610 917 048 WASHER 10 1
53 12 610 919 165 WASHER 10 1
55 12 610 917 206 NUT 10 1
56 12 610 917 191 ROD 10 1
57 22 610 924 368 LEVER 10 1
59 72 610 341 364 SELF-TAPPING SCREW 12 1
60 32 610 341 365 SCREW 12 1
61 12 610 920 385 SCREW 10 1
62 12 610 346 204 SCREW 17 1
63 32 610 968 438 HEADLESS SCREW 11 1
64 12 610 328 924 SCREW 14 1
65 12 610 020 639 NEEDLE BUSHING 13 1
66 22 610 352 806 PIN 10 1
68 12 610 918 985 TUBE 10 1
69 12 610 911 889 SCREW 11 1
Pa
g
e 2 of 4
10/24/2005htt
p
://le11288.le.de.bosch.com/sid/
p
rintdirect.as
p
?ID
_
PRODUCT=0601672039&ID
_
VE...

71 22 610 919 166 SPRING 10 1
72 22 610 918 145 COVER 10 1
73 12 610 919 467 SPRING 10 1
74 12 610 919 327 SLEEVE 10 1
75 12 610 919 562 LABEL 12 1
86 12 610 920 799 SLEEVE 10 1
88 12 610 351 293 WASHER 10 1
89 12 610 921 770 SPRING 10 1
650 12 610 916 002 SCREWDRIVER 12 1
803 12 610 920 045 ARMATURE \ 110V 39 1
810 12 610 920 046 CARBON-BRUSH SET 18 1
827 12 610 920 047 UPPER HOUSING 33 1
834 12 610 920 048 GEAR UNIT 30 1
