FlexiDome and Dinion cameras |1
Reveal every detail with
FlexiDome 2X and Dinion 2X

2 |FlexiDome and Dinion cameras
Reveal more details in your surveillance
images with FlexiDome and Dinion cameras
When clarity counts, rely on Bosch cameras to provide the best level of detail to match your application and
budget. We understand high performance CCTV surveillance and our products consistently incorporate
the latest advances to satisfy your needs.
Whatever your surveillance application demands, there’s an ideal solution in our award-winning FlexiDome
and Dinion families of analog cameras. This comprehensive range includes our advanced Dinion 2X models
together with the high-performance DinionXF and professional-standard Dinion cameras. You have a
choice of color or monochrome options, as well as complete FlexiDome cameras incorporating the same
unparalleled technology.
Just as video capture mixes red, green and blue to make white
light, you can mix Dinion fixed cameras and FlexiDome dome
cameras to cover every area of your facility – indoors and
outdoors – and reveal every detail.
DinionDinion 2X
DinionXF

FlexiDome and Dinion cameras |3
Even in the harshest lighting conditions, the flagships
of our camera lines – the FlexiDome 2X and Dinion 2X
– give you the highest level of image quality. We have
engineered these cameras to perform flawlessly in
natural and artificial light so you always get the best
results. Strong backlighting, high-contrast or low-light
scenes – the 2X cameras handle it all with ease and
expose details not visible to the naked eye.
FlexiDome 2X and Dinion 2X
The clearest images, day or night
The next generation of image quality
Dinion 2X and FlexiDome 2X are the newest generation
of Bosch's industry-leading image capture solutions.
Each builds upon the achievements of the Dinion and
FlexiDome families which redefined the standards for
image quality, first with 10-bit, then 15-bit image
processing.
Now the 2X generation with 20-bit technology raises the
bar even higher and delivers on the promise of revealing
every detail – even in difficult settings and low light.
FlexiDome Series
1 Bit 3 Bit 10 Bit
Dinion
FlexiDome
15 Bit
DinionXF
FlexiDomeXF
20 Bit
Dinion 2X
FlexiDome 2X
Image processing
Bosch's innovative 2X Digital Signal Processing chip
combines dual sensor exposure and wide dynamic range
performance to deliver the world's first 20-bit image
processing for outstanding results in every setting.

4 |FlexiDome and Dinion cameras
Are you looking for a dome camera that produces the
highest quality surveillance images? The FlexiDome 2X
Day/Night is the solution for you. It combines the
precise performance of our advanced 2X 20-bit
processing and wide dynamic range sensor with a
rugged, stylish dome.
FlexiDome 2X
Tough-as-nails domes with 20-bit processing
Tough enough for almost any application
From arctic temperatures to blazing sun or heavy rain, the
FlexiDome 2X handles it all, easily coping with rough
treatment in tough locations.
Clear imaging in difficult lighting conditions
Strong backlighting or high contrast scenes are no
problem, thanks to the camera’s wide dynamic range.
Low light situations are handled easily, ensuring high-
quality image capture day or night.
Capture nighttime scenes with
amazing detail with FlexiDome's
infrared illumination sensitiviy
Stands up to attack with
impact-resistant bubble
Privacy masking can hide
sensitive scene content
Compensates for backlighting
with Smart BLC
Completely sealed against water,
dust and other contaminants
VDN-498 FlexiDome 2X camera u

FlexiDome and Dinion cameras |5
Enhanced low-light performance
Capture what the human eye cannot see with
Bosch’s 2X DSP technology, wide dynamic range and
20-bit digital image processing
More detail in harsh lighting conditions
Data from the highest light and lowest light image
sources is analyzed pixel by pixel and combined to
produce the most detailed picture possible
Guaranteed performance around the clock
Get clear imaging 24/7 with 2X image processing that
dynamically adapts to scene changes and infrared
illumination that boosts nighttime performance
Stands up to the elements
Resist damage from wind, rain and flying debris plus
attempts at tampering or breaking the housing
Complete package convenience
Get an attractive, rugged dome, advanced 2X
camera and choice of optimized, high-speed lens
in one package
The field-proven endurance of
FlexiDome is ideal for:
Foyers and lobbies
Warehouses and loading docks
Prisons and correctional facilities
Airport baggage and storage areas
Stadiums

6 |FlexiDome and Dinion cameras
Capture fast-moving objects
with default shutter
Excellent 15-bit image quality
Patented design for viewing
along a ceiling or surface
Better contrast with AutoBlack
FlexiDomeXF
Perfect performance indoors and out
FlexiDomeXF offers a subtle profile, the ruggedness of a
dome and the performance of the renouned DinionXF
camera. This compact, integrated dome solution is
available in a range of models tough enough for almost
any environment, yet attractive enough to be mounted
in any location.
Sharp images, whatever the lighting
Capture movement accurately without blurring and
maintain full image sensitivity in low-light conditions
using default shutter
Clearer detail where it matters most in the image
Adjust for deep shadows with programmable backlight
compensation
FlexiDomeXF stands strong in harsher conditions and
resists wind, rain, flying debris and tampering in:
Stairwells and staircases
High-security storage such as bank vaults
Indoor parking structures
Hotels, bars and nightclubs
Hospitals and medical centers
FlexiDomeXT+ combines award-winning Dinion imaging
quality and outstanding reliability in a tough-as-nails dome.
Or choose our FlexiDomeVF model as the ideal indoor
alternative.
FlexiDomeXT+ and FlexiDomeVF
Subtle surveillance virtually anywhere
More precise recognition
Achieve superior image quality with
540 TVL resolution
Expertly handle low light
Enhanced sensitivity with NightSense delivers more
details in darkened settings
FlexiDomeXT+ and FlexiDomeVF
offer worry-free imaging for:
Museums and art galleries
General surveillance in shopping centers and malls
Offices
Hallways and corridors
Schools, colleges and universities
VDC-485 FlexiDomeXF camera u
VDC-455 FlexiDomeXT+ camera u

FlexiDome and Dinion cameras |7
Selecting
the right FlexiDome
Applications FlexiDome 2X FlexiDomeXF FlexiDomeXT+ and
FlexiDomeVF
Elevators and entranceways
Backlighting makes areas of interest dark and obscures details.
Neutralize shadows with Smart backlight compensation (BLC).

Pedestrian and vehicle traffic
Get the sharpest images where personal safety is at stake
by combining wide dynamic range with color sensitivity.

Warehouse
Critical details hide in shadows, making them difficult to see.
Use Bosch cameras with XF-Dynamic to improve image capture
and eliminate viewing problems.

Reception lobby
High bursts of activity demand detailed, sharp pictures of the
entire scene. Use Bosch cameras with 540 TVL resolution.

Other cameras
Human eyeHigh quality FlexiDome 2X camera image

8 |FlexiDome and Dinion cameras
The flagship of the Dinion range, the 20-bit Dinion 2X
Day/Night camera gives you a powerful solution capable
of handling the most demanding lighting situations, 24
hours a day.
Everything about the Dinion 2X is designed to expose
every possible detail in a scene:
Smart compensation for backlighting
Analyzes the image pixel by pixel for the best result
every time
Brings every detail into focus in both the dark and
light parts of a scene with Bosch’s 2X Dynamic
image processing
Produces clear images regardless of glare or shadows
using Day/Night infrared contrast with unequaled IR
sensitivity
Dinion 2X delivers optimal 20-bit
imaging in natural and artificial light
Exposing details in the most extreme lighting
For every scene, the Dinion 2X generates two images to
produce the clearest picture: one long exposure resolves
details in the scene’s darkest areas, while one short
exposure captures the brightest areas. The digital signal
processor then mixes pixels from each image to produce
the most detailed picture possible.
Images are enhanced pixel by
pixel to reveal all the details
Smart BLC handles
backlighting with ease
Privacy masking to hide
sensitive scene content
Day/Night operation
with switching IR filter
LTC 0498 Dinion 2X camera

High quality Dinion 2X camera image Other camera

FlexiDome and Dinion cameras |9
Enhanced low-light performance
Capture what the human eye can’t detect with
Bosch’s 2X DSP technology, wide dynamic range and
20-bit image processing
More detail in harsh lighting conditions
Reveal details for comprehensive, around-the-clock
surveillance and enhance the entire scene with Auto-
Black to boost the sharpness of each pixel
A smart solution to handle backlighting
Automatically compensate for backlighting
with Smart BLC
Dinion 2X outperforms other cameras in:
Outdoor perimeters
Traffic monitoring
Outdoor parking lots
Ports
Freight terminals
Border control

10 |FlexiDome and Dinion cameras
DinionXF is the natural choice for high-performance
professional surveillance systems. Its many image
enhancement features ensure great performance and
reliability straight from the box.
DinionXF cameras are ideal surveillance partners
indoors or outdoors:
City surveillance and public areas
Public transportation
Commercial and government buildings
General warehouse surveillance
DinionXF
High performance camera
Vivid video images
Capture more true-to-life images with the DinionXF's
15-bit processing power
Optimum image quality in any lighting
Harsh light, low light or backlight – DinionXF
conquers them all while delivering excellent results
Default shutter to capture
fast moving objects
SensUp for improved
sensitivity
XF Dynamic to reveal
details in dark areas
In locations well-illuminated by natural or artificial
lighting, Bosch’s 10-bit Dinion cameras are the right
solution. A professional-standard CCTV camera that
delivers crisp, clear pictures, Dinion gives you
consistent, high-quality performance on which you
can stake your surveillance.
Dinion camera
The professional performer
The picture stays bright in fading light
Automatically switch from color to monochrome to
preserve image quality using NightSense, which
recognizes fading natural light
Details stay clear even when visibility is low
Enhance picture contrast and counteract fog, glare,
mist and smoke with AutoBlack
Typical Dinion application areas:
Office spaces
Service counters such as bank teller windows
Gasoline stations and convenience stores
Self-storage units
NightSense extends
operational sensitivity
AutoBlack to
improve contrast
540 TVL resolution
LTC 0485 DinionXF camera u
LTC 0455 Dinion camera

FlexiDome and Dinion cameras |11
XF Dynamic to reveal
details in dark areas
Putting your Dinion
cameras to work
Applications Dinion 2X DinionXF Dinion
Warehouse entrance/exit
Bring out the details with our high-sensitivity solutions. 
Perimeter fences
Cameras must produce consistently clear images at
night and in dark, shadowy environments. Our Day/Night
feature is the right choice.

City surveillance
Good-quality images in artificial lighting are critical to
security staff and police.

Offices and service counters
Affordable, effective surveillance for well-lit areas calls
for Dinion performance and features.

Other cameras
Human eyeHigh quality Dinion 2X camera image
Ready to start revealing all the details in your surveillance scenes?
Speak with your Bosch representative today or call 866-CCTV-REP.

Bosch Security Systems
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, NY 14450 USA
Phone: [phone]
Fax: [phone]
For more information please visit
www.boschsecurity.us
© Bosch Security Systems, Inc. 2009
Modifications reserved
Printed in United States | 8/09
F01U002342
A Tradition of Quality and Innovation
For over 100 years, the Bosch name
has stood for quality and reliability.
Bosch is the global supplier of choice
for innovative technology, backed by
the highest standards for service
and support.
Bosch Security Systems proudly
offers a wide range of security, safety,
communications and sound solutions
that are relied upon every day in
applications around the world, from
government facilities and public venues
to businesses, schools and homes.
