Bosch MIC IP fusion 9000i User manual

MIC IP fusion 9000i
MIC‑9502‑Z30BQS│MIC‑9502‑Z30WQS│MIC‑9502‑Z30GQS│MIC‑
9502‑Z30BVS│MIC‑9502‑Z30WVS│MIC‑9502‑Z30GVS│MIC‑9502‑Z
30BVF│MIC‑9502‑Z30WVF│MIC‑9502‑Z30GVF│MIC‑9502‑Z30DVF
│MIC‑9502‑Z30BVF9│MIC‑9502‑Z30WVF9│MIC‑9502‑Z30BVS9│
MIC‑9502‑Z30WVS9
en Installation Manual

MIC IP fusion 9000i Table of contents | en 3
Bosch Security Systems Installation Manual 2022-09 | 1.6 | F.01U.334.820
Table of contents
1Safety 4
1.1 About this Manual 4
1.2 Legal Information 4
1.3 Safety Precautions 5
1.4 Important Safety Instructions 6
1.5 Important Notices 7
1.6 Use latest software 10
1.7 Customer Support and Service 10
2Introduction 11
2.1 Additional Products Required 11
2.2 Additional Tools 11
2.3 Establishing the connection 11
2.4 Password protection in camera 12
3Product Description 13
4Installation Overview 14
5Mounting 16
5.1 Mounting Location and Orientation Options 16
5.2 Mounting Options 18
5.3 Mounting Bracket Options 20
5.4 Considerations for Mounting the Camera in Inverted Orientation 23
6Installing the camera outdoors 26
7(Optional) Configuration Programming in the Shipping Box 30
8(Optional) Configuration Programming on a Temporary Table-top Stand 31
9Installing a MIC Camera on a Hinged DCA 32
10 (Optional) Installing a Sunshield 36
11 Connection 38
11.1 About Camera Power and Control 38
11.2 Power Source Options 38
11.3 Ethernet Connections 39
11.4 Camera Connections 40
11.5 Connect the Camera to the Network 40
11.6 Installing the camera outdoors 42
12 Typical System Configurations 43
13 Troubleshooting 44
14 Maintenance 47
14.1 Replacing a wiper assembly 48
15 Decommissioning 56
15.1 Transfer 56
15.2 Disposal 56
16 Technical data 57
17 Support services and Bosch Academy 58

4en | Safety MIC IP fusion 9000i
2022-09 | 1.6 | F.01U.334.820 Installation Manual Bosch Security Systems
1 Safety
1.1 About this Manual
This manual has been compiled with great care and the information it contains has been
thoroughly verified. The text was complete and correct at the time of printing. Because of the
ongoing development of products, the content of the manual may change without notice.
Bosch Security Systems accepts no liability for damage resulting directly or indirectly from
faults, incompleteness, or discrepancies between the manual and the product described.
1.2 Legal Information
Copyright
This manual is the intellectual property of Bosch Security Systems, and is protected by
copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.

MIC IP fusion 9000i Safety | en 5
Bosch Security Systems Installation Manual 2022-09 | 1.6 | F.01U.334.820
1.3 Safety Precautions
In this manual, the following symbols and notations are used to draw attention to special
situations:
Danger!
High risk: This symbol indicates an imminently hazardous situation such as “Dangerous
Voltage” inside the product. If not avoided, this will result in an electrical shock, serious
bodily injury, or death.
!
Warning!
Medium risk: Indicates a potentially hazardous situation. If not avoided, this may result in
minor or moderate injury.
!
Caution!
Low risk: Indicates a potentially hazardous situation. If not avoided, this may result in
property damage or risk of damage to the unit.
i
Notice!
This symbol indicates information or a company policy that relates directly or indirectly to the
safety of personnel or protection of property.

6en | Safety MIC IP fusion 9000i
2022-09 | 1.6 | F.01U.334.820 Installation Manual Bosch Security Systems
1.4 Important Safety Instructions
When transporting, take extra care to protect the wiper and the camera window(s).
!
Caution!
Installation must be made by qualified personnel and conform to ANSI/NFPA 70 (the National
Electrical Code® (NEC)), Canadian Electrical Code, Part I (also called CE Code or CSA C22.1),
and all applicable local codes. Bosch Security Systems accepts no liability for any damages or
losses caused by incorrect or improper installation.
!
Warning!
INSTALL EXTERNAL INTERCONNECTING CABLES IN ACCORDANCE TO NEC, ANSI/NFPA70
(FOR US APPLICATION) AND CANADIAN ELECTRICAL CODE, PART I, CSA C22.1 (FOR CAN
APPLICATION) AND IN ACCORDANCE TO LOCAL COUNTRY CODES FOR ALL OTHER
COUNTRIES. BRANCH CIRCUIT PROTECTION INCORPORATING A 20 A, 2-POLE LISTED
CIRCUIT BREAKER OR BRANCH RATED FUSES ARE REQUIRED AS PART OF THE BUILDING
INSTALLATION. A READILY ACCESSIBLE 2-POLE DISCONNECT DEVICE WITH A CONTACT
SEPARATION OF AT LEAST 3 mm MUST BE INCORPORATED.
!
Warning!
ROUTING OF EXTERNAL WIRING MUST BE DONE THROUGH A PERMANENTLY EARTHED
METAL CONDUIT.
i
Notice!
Outdoor installation
For details about the proper configuration for installing your camera outdoors with surge and
lightning protection, refer to Best Practices for Outdoor Installation.
– Ensure that the unit case is properly earthed. If the product is at risk of being struck by
lightning, ensure that earth bonding connections are made correctly to the mounting of
the base of the unit.
i
Notice!
Bosch recommends the use of surge/lightning suppression devices (sourced locally) to
protect network and power cables and the camera installation site. Refer to NFPA 780, Class
1 & 2, UL96A, or the equivalent code appropriate for your country/region, and to local
building codes. Refer also to the installation instructions of each device (midspan, camera,
and surge suppression device installed where the cable enters the building).
i
Notice!
Ancillary power (UPS) required
To meet the Mains Supply Voltage Dips and Short Interruptions requirements per EN 50130-4
Alarm Standard, ancillary equipment (for example, an Uninterruptible Power Supply (UPS)) is
necessary. The UPS must have a Transfer time between 2-6 ms and Backup Runtime of
greater than 5 seconds for the power level as specified on the product data sheet.
!
Warning!
THE CAMERA MUST BE MOUNTED DIRECTLY AND PERMANENTLY TO A NON-COMBUSTIBLE
SURFACE.

MIC IP fusion 9000i Safety | en 7
Bosch Security Systems Installation Manual 2022-09 | 1.6 | F.01U.334.820
– Make sure that the installation conditions comply with the specified stresses of vibration
and shock as mentioned in the datasheet.
– Use common-sense safety precautions, especially in situations where there could be risk
of injury if any part of the assembly becomes detached and falls. Bosch recommends
using the hinged DCA, which allows installers to “hang” the MIC camera temporarily on
the DCA to make electrical connections, before bolting the camera to the DCA.
i
Notice!
To maintain the Type 6P rating when the camera is mounted to a MIC-DCA, installers must
make sure that the user-supplied cable glands or conduit connections have Type 6P ratings.
!
Warning!
Do not manually back drive the camera
The motor/gear head combinations used in the MIC cameras were designed to provide
smooth pan/tilt movement of the camera during powered operation. The gear heads were not
specifically designed to be manually “back-driven” under any circumstance.
Although it might be possible to do so on unpowered units, there is no guarantee that “back-
driving” will be possible on every unit. Some units may even enter a “locked-up” mechanical
state.
If the camera becomes “locked-up,” simply apply power to the camera. The pan/tilt functions
of the camera should now operate properly.
!
Warning!
Moving parts!
Moving parts may result in risk of injury, therefore, the device should be mounted so that it is
accessible only to the technician/installer.
i
Notice!
Risk of injury or damage
To prevent injury to your hands or damage to the wiper, do not touch the wiper with your
hands, especially when the wiper is moving.
– Do not open the camera unit. Doing so will invalidate the warranty.
– Do not point the camera at the sun. Bosch Security Systems will not be liable for any
damage to cameras that have been pointed directly at the sun.
1.5 Important Notices
i
Notice!
This device is intended for use in public areas only.
U.S. federal law strictly prohibits surreptitious recording of oral communications.
Accessories - Do not place this unit on an unstable stand, tripod, bracket, or
mount. The unit may fall, causing serious injury and/or serious damage to
the unit. Use only with mounting solutions specified by the manufacturer.
When a cart is used, use caution and care when moving the cart/unit
combination to avoid injury from tip-over. Quick stops, excessive force, or
uneven surfaces may cause the cart/unit combination to overturn. Mount the
unit per the installation instructions.

8en | Safety MIC IP fusion 9000i
2022-09 | 1.6 | F.01U.334.820 Installation Manual Bosch Security Systems
Adjustment of controls - Adjust only those controls specified in the operating instructions.
Improper adjustment of other controls may cause damage to the unit.
All-pole power switch - Incorporate an all-pole power switch, with a contact separation of at
least 3 mm, into the electrical installation of the building. If the camera requires service, use
this all-pole switch as the main disconnect device for switching off the voltage to the unit.
Camera signal - Protect the cable with a primary protector if the camera signal is beyond 140
feet, in accordance with NEC800 (CEC Section 60).
Environmental statement - Bosch has a strong commitment towards the environment. This
device has been designed to respect the environment as much as possible.
Electrostatic-sensitive device - Use proper ESD safety precautions when handling the camera
to avoid electrostatic discharge.
Fuse rating - For security protection of the device, the branch circuit protection must be
secured with a maximum fuse rating of 16A. This must be in accordance with NEC800 (CEC
Section 60).
Grounding:
- Connect outdoor equipment to the unit's inputs only after this unit has had its ground
terminal connected properly to a ground source.
- Disconnect the unit's input connectors from outdoor equipment before disconnecting the
grounding terminal.
- Follow proper safety precautions such as grounding for any outdoor device connected to this
unit.
U.S.A. models only - Section 810 of the National Electrical Code, ANSI/NFPA No.70, provides
information regarding proper grounding of the mount and supporting structure, size of
grounding conductors, location of discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
Refer to the section ”Best Practices for Outdoor Installation” of the manual for more
information on outdoor installations.
Heat sources - Do not install unit near any heat sources such as radiators, heaters, or other
equipment (including amplifiers) that produce heat.
Moving - Before moving the unit, disconnect both the 24 VAC connection and the Ethernet
cable connection (if using PoE).
Outdoor signals - The installation for outdoor signals, especially regarding clearance from
power and lightning conductors and transient protection, must be in accordance with NEC725
and NEC800 (CEC Rule 16-224 and CEC Section 60).
Refer to the ”Best Practices for Outdoor Installation” section of the manual for more
information on outdoor installations.
Permanently connected equipment - Incorporate a readily accessible disconnect device in the
building installation wiring.
Power lines - Do not locate the camera near overhead power lines, power circuits, or
electrical lights, nor where it may contact such power lines, circuits, or lights.
Servicing - Do not attempt to service this device yourself. Refer all servicing to qualified
service personnel.
This device has no user-serviceable internal parts.
FCC information
i
Notice!
This is a class A product. In a domestic environment this product may cause radio
interference, in which case the user may be required to take adequate measures.

MIC IP fusion 9000i Safety | en 9
Bosch Security Systems Installation Manual 2022-09 | 1.6 | F.01U.334.820
FCC suppliers Declaration of Conformity
MIC IP fusion 9000i High-definition PTZ camera with thermal and
visual imagers
Responsible party
Bosch Security Systems, Inc.
130 Perinton Parkway
14450 Fairport, NY, USA
www.boschsecurity.us
UL Disclaimer
Underwriter Laboratories Inc. ("UL") has not tested the performance or reliability of the
security or signaling aspects of this product. UL has only tested fire, shock and/or casualty
hazards as outlined in Standard(s) for Safety for Information Technology Equipment,
UL62368-1. UL Certification does not cover the performance or reliability of the security or
signaling aspects of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR CERTIFICATIONS WHATSOEVER
REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING-RELATED
FUNCTIONS OF THIS PRODUCT.

10 en | Safety MIC IP fusion 9000i
2022-09 | 1.6 | F.01U.334.820 Installation Manual Bosch Security Systems
1.6 Use latest software
Before operating the device for the first time, make sure that you install the latest applicable
release of your software version. For consistent functionality, compatibility, performance, and
security, regularly update the software throughout the operational life of the device. Follow
the instructions in the product documentation regarding software updates.
The following links provide more information:
– General information: https://www.boschsecurity.com/xc/en/support/product-security/
– Security advisories, that is a list of identified vulnerabilities and proposed solutions:
https://www.boschsecurity.com/xc/en/support/product-security/security-advisories.html
Bosch assumes no liability whatsoever for any damage caused by operating its products with
outdated software components.
i
Notice!
Bosch strongly recommends upgrading to the latest firmware for the best possible
functionality, compatibility, performance and security.
Check http://downloadstore.boschsecurity.com/ regularly to see if there is a new firmware
version available.
1.7 Customer Support and Service
If this unit needs service, contact the nearest Bosch Security Systems Service Center for
authorization to return and shipping instructions.
USA and Canada
Telephone: [phone], option 5
Fax: [phone]
Email: [email protected]
Customer Service
Telephone: [phone], option 3
Fax: [phone]
Email: [email protected]
Technical Support
Telephone: [phone], option 4
Fax: [phone]
Email: [email protected]
Europe, Middle East, Africa, and Asia Pacific Regions
Contact your local distributor or Bosch sales office. Use this link: https://
www.boschsecurity.com/xc/en/where-to-buy/
More Information
For more information, please contact the nearest Bosch Security Systems location or visit
www.boschsecurity.com.

MIC IP fusion 9000i Introduction | en 11
Bosch Security Systems Installation Manual 2022-09 | 1.6 | F.01U.334.820
2 Introduction
– This equipment should be unpacked and handled with care. Check the exterior of the
packaging for visible damage. If an item appears to have been damaged in shipment,
notify the shipper immediately.
– Verify that all the parts listed in the Parts List below are included. If any items are
missing, notify your Sales or Customer Service Representative from Bosch Security
Systems.
– Do not use this product if any component appears to be damaged. Please contact Bosch
Security Systems in the event of damaged goods.
– The original packing carton (if undamaged) is the safest container in which to transport
the unit and must be used if returning the unit for service. Save it for possible future use.
!
Caution!
Take extra care lifting or moving MIC cameras because of their weight.
The MIC packaging is designed:
– to allow installers to configure the camera inside the shipping box.
– to provide a temporary table-top or desk-top stand.
2.1 Additional Products Required
Quantity Component
100 m
maximum
Ethernet cable (Cat5e or better)
* Power cable (24 VAC)
* Alarm wiring as needed
* Audio wiring as needed
1 Full SD card. Recommended: industrial SD cards from Western Digital
(sold separately by Bosch)
* Refer to the chapter Preparing Wiring in the installation manual.
2.2 Additional Tools
1 Phillips-head screwdriver to secure the ground lug of the camera
1 Adjustable wrench or socket set to secure the base of the camera to mounting accessories
2.3 Establishing the connection
The unit must have a valid IP address and a compatible subnet mask to operate on your
network. By default, DHCP is pre-set at the factory to On and so your DHCP server assigns an
IP address. With no DHCP server the default address is 192.168.0.1
The Project Assistant app or Configuration Manager (version 7.50 or higher) can be used to
find the IP address. Download the software from https://downloadstore.boschsecurity.com:
1. Start the web browser.
2. Enter the IP address of the device as the URL.
3. During the initial installation, confirm any security questions that show.

12 en | Introduction MIC IP fusion 9000i
2022-09 | 1.6 | F.01U.334.820 Installation Manual Bosch Security Systems
If a RADIUS server is used for network access control (802.1x authentication), you must
configure the device before the device can communicate with the network.
To configure the device, connect it directly to a computer using a network cable and then set
the service-level password.
Note:
If you cannot connect, the unit may have reached its maximum number of connections.
Depending on the device and network configuration, each unit can have up to 50 web browser
connections, or up to 100 connections via BoschVideoClient or BVMS.
2.4 Password protection in camera
The device is password-protected. The first time that any user accesses the device, the device
will prompt the user to set a password at the service level.
The camera requires a strong password. Follow the prompts in the dialog box, which specifies
what is required. The system measures the strength of the password that you enter.
Make sure the password obeys these conditions:
– 8 to 19 characters in length
– Upper and lower case letters
– Minimum of 1 digit
– Minimum of 1 special character
These special characters are not allowed: '@', '&', '<', '>', ':', '+'
When you use Configuration Manager to access your device for the first time, you must set the
initial password of the device in Configuration Manager. The Users section (General > Unit
Access > Users) displays the message, "Before you can use this device you have to secure it
with an initial password."
Note: After you set the initial password, a "lock" icon appears next to the device name in the
Devices list in Configuration Manager.
You can also launch the device webpage directly. In the device webpage, an initial password
page appears, displaying input fields and a password strength gauge.
Enter the user name (“service”) and a password in the appropriate fields. Refer to the section
User Management for more information.
After a service-level password is set for the device, the device displays a dialog box that
prompts users to enter the user name (“service”) and the service-level password every time
that they access the device.
1. Fill in the fields User name and Password.
2. Click OK. If the password is correct, the desired page appears.
Note: New releases of software may require you to set a new and stronger password.

MIC IP fusion 9000i Product Description | en 13
Bosch Security Systems Installation Manual 2022-09 | 1.6 | F.01U.334.820
3 Product Description
– Make sure that the installation conditions comply with the specified stresses of vibration
and shock as mentioned in the datasheet.
The MIC IP fusion 9000i camera is a day/night, IP PTZ camera with dual optical/thermal
imagers. Ruggedized and weatherproof, the camera offers a reliable, robust, and high-quality
surveillance solution for extreme security applications.
A long-life silicone wiper blade mounted on a spring-loaded arm is standard on all MIC
cameras.
The following table identifies the optional accessories for MIC cameras. Refer to the
datasheets of each accessory for details. Some accessories may not be available in all regions.
Accessories Description Accessories Description
MIC-DCA-H
- MIC-DCA-HB
- MIC-DCA-HW
- MIC-DCA-HG
- MIC-DCA-HBA
- MIC-DCA-HWA
- MIC-DCA-HGA
Hinged Deep Conduit Adapter in
Black
White
Grey
Black with M25 to ¾” adapter
White with M25 to ¾” adapter
Grey with M25 to ¾” adapter
MIC-SCA
- MIC-SCA-BD
- MIC-SCA-WD
- MIC-SCA-MG
Shallow Conduit Adapter in
Black
White
Grey
MIC-CMB
- MIC-CMB-BD
- MIC-CMB-WD
- MIC-CMB-MG
Corner Mount Bracket in
Black
White
Grey
MIC-SPR
- MIC-SPR-BD
- MIC-SPR-WD
- MIC-SPR-MG
Spreader Plate in
Black
White
Grey
MIC-WMB
- MIC-WMB-BD
- MIC-WMB-WD
- MIC-WMB-MG
Wall Mount Bracket in
Black
White
Grey
MIC-PMB Pole Mount Bracket (stainless
steel only)
NPD-9501A 95 W midspan MIC-WKT-IR Washer Kit
VG4-A-PSU1
VG4-A-PSU2
24 VAC (96 VA) power supply MIC-ALM-WAS-24 Alarm and washer interface
accessory unit
MIC-9K-IP67-5PK Connector kit MIC-9K-SNSHLD-W Sunshield (white)
MVS-FCOM-PRCL Serial protocol license for IP
cameras

14 en | Installation Overview MIC IP fusion 9000i
2022-09 | 1.6 | F.01U.334.820 Installation Manual Bosch Security Systems
4 Installation Overview
i
Notice!
To maintain the Type 6P rating when the camera is mounted to a MIC-DCA, installers must
make sure that the user-supplied cable glands or conduit connections have Type 6P ratings.

MIC IP fusion 9000i Installation Overview | en 15
Bosch Security Systems Installation Manual 2022-09 | 1.6 | F.01U.334.820
Depending on your installation requirements, you may need to complete the following steps:
Pre-configuration (Optional)
Refer to (Optional) Configuration Programming in the Shipping
Box, page 30 .
Mounting options
Refer to Mounting Bracket Options, page 20 .
Camera connections (including power/communication)
Refer to Connection, page 38 .
Optional accessories
Refer to (Optional) Installing a Sunshield, page 36 .
Camera settings
Refer to Configuration.

16 en | Mounting MIC IP fusion 9000i
2022-09 | 1.6 | F.01U.334.820 Installation Manual Bosch Security Systems
5 Mounting
5.1 Mounting Location and Orientation Options
MIC cameras are designed for easy installation in various locations such as directly onto
buildings and poles suitable to support CCTV equipment.
Select a secure installation location and mounting orientation for the device. Ideally, this is a
location where the device cannot be interfered with either intentionally or accidentally.
Select a location where the MIC camera will not touch materials such as steel straps or cables.
You can install the camera:
– onto a MIC-DCA or a MIC wall mount (MIC-WMB) with a MIC shallow conduit adapter
(MIC-SCA). (Never install the wall mount only.)
or
– directly to a mounting surface using the supplied base gasket and the appropriate
connector kit (sold separately):
– MIC-9K-IP67-5PK (IP67 Connector kit for MIC IP fusion 9000i, MIC IP ultra 7100i, and
MIC IP starlight 7100i cameras)
To have an installation rated IP67, you must use the appropriate IP67 Connector Kit from
Bosch.
Confirm that no residual water or moisture is in the bottom of camera. Ground the camera as
described in the chapter “Installing a MIC Camera on a Hinged DCA.”
The most common type of mounting location is the top of a pole suitable to support CCTV
equipment and that provides a robust mounting platform to minimize camera motion and
typically has a large base cabinet for mounting ancillary equipment such as power supplies.
Other locations for mounting the camera include the top of a building, the side (wall) of a
building, the corner of a building, and under the eave of a building.
The camera can also be mounted on the side of a lamp post, pole, or similar column using the
Pole Mount Bracket (MIC-PMB). Be aware that lamp posts can often be subject to movement
and are not suitable platforms in all conditions or for all applications.
i
Notice!
Outdoor installation
For details about the proper configuration for installing your camera outdoors with surge and
lightning protection, refer to Best Practices for Outdoor Installation.
Ensure that the location has the appropriate clearance from power and lightning conductors,
in accordance with NEC725 and NEC800 (CEC Rule 16-224 and CEC Section 60).
Do not install the device near:
– Any heat sources
– Any overhead power lines, power circuits, or electrical lights, or where the device may
contact power lines, circuits, or lights
Isolate shielded CAT5e or CAT6 cable from any high voltage power lines in a separate
grounded, metal conduit. Refer to the datasheet for test conditions for allowable transients /
voltage fluctuations.
i
Notice!
Heat sources may obscure the thermal image
Heat sources in the direct FOV of the thermal camera or which can reflect from thermally
reflective sources might obscure the thermal image.

MIC IP fusion 9000i Mounting | en 17
Bosch Security Systems Installation Manual 2022-09 | 1.6 | F.01U.334.820
Mounting surface recommendations for MIC mounting accessories
The mounting surface should be capable of supporting the combined weight of the MIC
camera + MIC Illuminator + MIC mounting accessory (DCA, wall mount, corner bracket, etc.).
All expected conditions of load, vibration and temperature should be considered when
planning an installation. The material should accommodate a minimum pull-out strength of 275
kg (600 lb).
The mounting accessory should be secured to one of the following surfaces:
– Concrete (solid / cast)
– Concrete masonry unit (concrete block)
– Brick (all types)
– Metal (steel / aluminum, minimum 3 mm (0.125 in.) thick)
In all situations, Bosch recommends referencing any applicable building codes or professional
structural engineering guidelines for a secure installation.
4Ensure that the selected mounting surface is capable of supporting the combined weight
of the camera and mounting hardware (sold separately) under all expected conditions of
load, vibration, wind, and temperature.
!
Caution!
Risk of lightning strikes
If the camera is installed in a highly exposed location where lightning strikes may occur, then
Bosch recommends installing a separate lightning conductor within 0.5 m (1.6 ft) of the
camera and at least 1.5 m (4.9 ft) higher than the camera. A good earth bonding connection
to the camera housing itself will provide protection against damage from secondary strikes.
The camera housing itself is constructed to cope with secondary strikes. If the correct
lightning protection is applied, then no damage to the internal electronics or camera should
result.
Installation in a damp environment (for example, near a coastline)
The fasteners shipped with the camera are designed to resist corrosion. Always use Bosch-
supplied screws and other fasteners when installing the camera.
The camera head has factory-installed plastic screws that prevent corrosion in the screw holes
when no MIC sunshield accessory is attached. Do not remove these screws until you install a
sunshield accessory. For complete details, refer to the installation instructions for the
sunshield accessory.
Before installation, inspect the metal parts of the camera for paint that is chipped or
otherwise damaged. If you notice any paint damage, touch up the damage with paint or
sealants available locally.
Avoid installation practices that may allow the camera’s metal mountings to contact materials
such as stainless steel. Such contact can result in galvanic corrosion and degrade the
cosmetic appearance of the camera. These cosmetic damages caused by improper installation
are not covered by warranty as they do not affect the functionality of the camera.

18 en | Mounting MIC IP fusion 9000i
2022-09 | 1.6 | F.01U.334.820 Installation Manual Bosch Security Systems
5.2 Mounting Options
See the figures that follow for illustrations of the correct and the incorrect mounting
orientations of MIC cameras.
MIC cameras are designed to be mounted upright (straight up) or inverted (straight down).
See the figures below for illustrations of the correct and the incorrect mounting orientations
of MIC cameras.
Correct mounting orientation Canted and horizontal mounting orientations not allowed!

MIC IP fusion 9000i Mounting | en 19
Bosch Security Systems Installation Manual 2022-09 | 1.6 | F.01U.334.820
The figures below illustrate the tilt range of the camera in upright orientation and in inverted
orientation.
56°56°
90° 90°
56° 56°
56°
56°
Tilt range of MIC IP fusion 9000i camera

20 en | Mounting MIC IP fusion 9000i
2022-09 | 1.6 | F.01U.334.820 Installation Manual Bosch Security Systems
5.3 Mounting Bracket Options
Bosch sells a complete series of mounting brackets that support multiple mounting
configurations.
Always use only Bosch-supplied mounts, which are designed for safe installation of your MIC
camera.
Refer to the MIC Series Mounting Brackets Installation Guide for complete installation
instructions.
Mounting hardware recommendations for MIC mounting accessories
Fasteners are not supplied with the MIC mounting accessories for attachment to the mounting
surface. The type of fastener necessary is dependent on the mounting surface.
Fasteners can include wedge anchors, sleeve anchors, single expansion anchors, double
expansion anchors, machine screws or ‘Thru-Bolting’ with a nut.
Fasteners are to be of a structural grade (ISO Class 10.9, SAE Grade 8) and zinc plated for
moderate corrosion resistance. When installed in marine or similarly corrosive environments,
stainless hardware (A2-800, A4-800) is recommended.
Fasteners are to be a minimum diameter of 8 mm (0.3125 in.).
All bolts must extend through the mounting surface and be secured with a flat washer, lock
washer and nut. All studs must be anchored to concrete or welded to a steel backing plate.
In all situations, Bosch recommends referencing any applicable building codes or professional
structural engineering guidelines for a secure installation.
Deep Conduit Adapter
The hinged DCA is well-suited to installations on top of a pole.
MIC-SPR-BD,
-WD, -MG
MIC-SCA-BD,
-WD, -MG MIC-WMB-BD,
-WD, -MG
Figure5.1: Typical Wall mount configuration
Note: Always install an SCA when you install a wall mount for any installation configuration.
Route cables through the bottom of the SCA (to prevent water from running into the side or
top of the SCA along the cables).
