Purpose
This document describes how to set up and demonstrate Bosch Dinion 2X and FlexiDome 2X
analog cameras. It includes:
 Demonstration scenario
 Equipment requirements
 Conguration instructions
 Recommendations on how to best demonstrate the camera’s strengths
How to demo Dinion 2X and FlexiDome 2X
analog cameras

CCTV | How to Demo FlexiDomeDN IP Cameras en
Bosch Security Systems
CCTV | How to Demo Dinion 2X and FlexiDome 2X analog cameras en
Bosch Security Systems
Key messages
The clearest images, day or night
Bosch Dinion 2X and FlexiDome 2X cameras bring the
highest level of image quality to surveillance applications.
Dinion 2X and FlexiDome 2X cameras are built on our
innovative Dinion 2X Digital Signal Processor (DSP)
technology. The Dinion 2X DSP works in combination
with a wide dynamic range (WDR) CCD sensor to deliver
the world’s rst 20-bit image processing for the CCTV
market. Both our Dinion 2X and FlexiDome 2X solutions
take advantage of this technology to provide excellent
low light and WDR performance.
Remote control
Save time, effort and costs. Dinion 2X and FlexiDome 2X
cameras can be congured and controlled remotely via
the coax video cable. The unique Bilinx bi-directional
communication system makes it possible to check status,
change settings and even update rmware remotely.
Installed in an instant!
Dinion 2X cameras can be installed with the minimum
of fuss. Pre-congured in the factory, they are easy to
install ‘out of the box’. Just attach a lens, mount, plug
in, and they are operating immediately. FlexiDome 2X
offers the extra convenience of a complete, aesthetic
system complete with lens.
Reliability
Just as with all Bosch products, Dinion 2X and
FlexiDome 2X cameras are rigorously tested to ensure
they deliver reliable performance. Bosch cameras deliver
the best value and exceptional quality; they give the best
return on investment, saving customers money in the
long term.
Equipment
The equipment for the demo is provided in a product
suitcase, which contains:
 Two cameras
- Dinion xed-body LTC 0498/51 with LTC 3664/40
75-50 mm IR LTC 3674/20
- FlexiDome 2X VDN-498V09-10
 Tripod / stand
 Autoblack chart
 Colorful toy (little demo duck)
 Bilinx tool – VP-USB
 BNC to connect to monitor
 Welder’s glass
 USB stick / CD / DVD with video footage, pictures
and documentation
We recommend you use either a UML-202-90 monitor or
the 10.4” LED monitor. CRT monitors are also
acceptable.
Bosch Security SystemsBosch Security Systems

CCTV | How to Demo FlexiDomeDN IP Camerasen
Bosch Security Systems
CCTV | How to Demo Dinion 2X and FlexiDome 2X analog camerasen
Bosch Security Systems
Bosch Security SystemsBosch Security SystemsBosch Security Systems
Preset mode Description
24-hour Default installation mode provides stable pictures over a 24-hour period.
Settings optimized for out-of-the-box installation
Trafc Capture high-speed objects using default shutter in variable lighting conditions
Low light Provides extra enhancement, such as AGC and SensUp, to make usable pictures in low
light conditions
Smart BLC Settings optimized to capture details in high contrast and extremely bright-dark conditions
Low noise Enhancements set to reduce picture noise – useful for conditional refresh DVR / IP
storage systems because less noise means less storage required
Analog systems Use if camera connected to purely analog system (e.g. matrix switcher with VCR) or to a CRT
monitor. Useful for evaluating / demonstrating camera when directly connected to CRT monitor
Key message: see more clearly in harsh
lighting conditions and reveal more detail in
bright and shady areas of the same scene
The superior performance of Bosch cameras due to image
processing is shown in the examples on the accompanying
USB stick / CD / DVD.
What to demo How to demo Key points
20-bit image processing
15-bit image processing
Highly sensitive CCD
PowerPoint of bars Delivers superior WDR (Wide Dynamic Range).
Handles difcult lighting conditions with ease
Dual exposure High contrast scene
Long and short exposures combined by powerful
DSP – selects best from both, resulting in single
image that reveals details throughout entire scene
NB. 20-bit image processing is 32 times more powerful than 15-bit, which in turn is 32 times more powerful than
typical 10-bit cameras.
Demo 1: Image processing

CCTV | How to Demo FlexiDomeDN IP Cameras en
Bosch Security Systems
CCTV | How to Demo Dinion 2X and FlexiDome 2X analog cameras en
Bosch Security Systems
Ease of installation is shown more clearly by demonstrating
the xed-body camera, so we recommend you use the
Dinion unless your customer expressly asks for the
FlexiDome. In both cases the features to be demonstrated
are the same.
What to demo How to demo Key points
Backfocus adjustment
Press and hold the Menu button to see the
Install menu. Choose Lens wizard and
select ‘set back focus’. Unlock back focus
ring and adjust
Ensures optimal focus in all lighting conditions.
Only needs to be performed once at installation.
Easy-to-use adjustment ring requires no
special tools. No neutral density lter needed
Removable
connectors Show the removable connectors Unique to Bosch cameras – zoom lens, camera, housing. No ddling with cables
6 Modes to
choose from
Exit the Install menu. Press and release the
Menu button to see Main menu. Select
‘Mode’ and click through to show each
mode. Go back to main menu to show some
individual settings
6 preset modes (see table below) make it
easy to match performance to your
application. You can select a mode and adjust
the settings to your exact needs
Instant view update Make a change to any setting that produces
a noticeable effect
Any change can be seen instantly.
Many cameras require you to exit menu rst
before the result of any changes can be seen
Test Pattern
Generator
In the Install menu, select the Test signals
menu. Show some of the Test patterns
Test signals provide a simple way to check
connection. Independent of the image quality
Notch lter In the Install menu, select Connections
To prevent cross color effects or artifacts in
the video. This can occur when scenes
include closely spaced vertical lines such as
window bars, drapes / blinds and some
pavement patterns
Linelock options In the Install menu, select the
Synchronization menu
Important to ensure frame rates can be
achieved. Some DVR / IP encoders need all
cameras to be linelocked together to achieve
full recording frame rates
Isolated mounting* Take xed-body camera out of box. Connect
stand via the isolated mounting Mounting helps prevent ground loops
* If you use the FlexiDome camera to give the demonstration, you can simply place it on the table. You will need to
remove the cover to access the camera controls.
Demo 2: Ease of installation
Key message: ease of installation / set-up
Use the steps below to guide you through the
installation demo. Video clips covering many stages of
the ‘Ease of installation’ demo can be found on the
accompanying USB stick / CD / DVD.

CCTV | How to Demo FlexiDomeDN IP Camerasen
Bosch Security Systems
CCTV | How to Demo Dinion 2X and FlexiDome 2X analog camerasen
Bosch Security Systems
Key message: handy remote conguration
with extras
Use the steps below to guide you through the Bilinx demo.
Video clips covering several stages of this demo can be
found on the accompanying USB stick / CD / DVD.
What to demo How to demo Key points
Bilinx – remote settings
Connect camera to PC with Bilinx
connector. Connect loop through with
monitor. Open Bilinx application on PC
Easy to congure camera remotely.
Bilinx has additional conguration options not
supported on the camera itself
Cable compensation Select Connection, Cable comp.
Choose automatic
Cable compensation allows you to double the
length of cable between the camera and the
monitor (up to 1 km depending on cable type)
Save camera settings Save settings Settings can be saved and then uploaded to
other cameras
Firmware updates Show Firmware update option in menu New rmware can be uploaded to all cameras
in the eld
Demo 4: Bilinx – remote conguration
Key message: overall superior performance
of Bosch cameras
Video clips and photos for the ‘Real comparisons’ demo can
be found on the accompanying USB stick / CD / DVD.
What to demo How to demo Key points
Real comparisons with
competitors
Show video clips and photos. Point out our
strengths versus competition. See the 2X
powerpoint presentation.
Overall performance
SmartBLC
Demo 3: Real comparisons

CCTV | How to Demo FlexiDomeDN IP Cameras en
Bosch Security Systems
CCTV | How to Demo Dinion 2X and FlexiDome 2X analog cameras en
Bosch Security Systems
Key message: up to four easily congurable
privacy zones
This demo is easy to show the customer with the camera on
a table. Follow the steps below to guide you through the
Privacy zones demo. Video clips illustrating this feature can
be found on the accompanying USB stick / CD / DVD.
Demo 7: Privacy zones
Key message: reveal extra details
The Autoblack test chart included in the demo suitcase is
specially designed to help you illustrate the benets of our
Dinion Autoblack feature.
What to demo How to demo Key points
Autoblack
Use test chart of crowd. In the Main
menu, choose Enhance. Switch off and
switch on Autoblack feature
Picks out details that cannot normally be seen.
Even helps to penetrate mist and fog.
Demo 6: Autoblack
Key message: automatic image
compensation in backlit scenes
Use the demo duck toy to demonstrate the benets of
Smart BLC. You can also nd video clips illustrating this
feature on the accompanying USB stick / CD / DVD.
What to demo How to demo Key points
Smart BLC
Hold the demo duck in front of a bright
light (e.g. overhead light). Move the duck
to different areas of the camera view
Don’t have to set BLC area, camera adjusts
automatically
Smart BLC Show video clips
Demo 5: Smart BLC

CCTV | How to Demo FlexiDomeDN IP Camerasen
Bosch Security Systems
CCTV | How to Demo Dinion 2X and FlexiDome 2X analog camerasen
Bosch Security Systems
Key message: high sensitivity means fast
image capture
Use the camera for this demo. You can also nd video clips
illustrating this feature on the accompanying USB stick / CD
/ DVD.
What to demo How to demo Key points
Automatic shutter with
2X-DYN technology Default setting CCD much more sensitive in low light than
CMOS, allowing faster shutter speed with AI lens
Default shutter with
XF-DYN
(Main menu, mode 2, select shutter)
Show video clips Better than progressive scan analog cameras
Shutter speed with
AI lens Show video clips
Demo 9: Shutter speed with auto iris lens
What to demo How to demo Key points
Privacy zones
In the Install menu, choose Privacy masking,
then Pattern. Activate one of the four masks
and adjust it onscreen
Can set up to 4 mask areas.
Easy to adjust size and position
Privacy zones Show video clips
What to demo How to demo Key points
Reliability Show Halt chamber pictures Test till it breaks. Reduces maintenance costs
Impact resistance Show Impact test video of FlexiDome.
Tap the FlexiDome bubble with a pen Tough, yet stylish
Production quality Show video of production line Every camera made to the same high
standard. 3 year warranty
Demo 8: Reliability
Key message: dependable performance and
less maintenance
Build quality of the cameras is obvious – let your customer hold
the camera(s). Various materials referred to in the steps below
can be found on the accompanying USB stick / CD / DVD.

CCTV | How to Demo FlexiDomeDN IP Cameras en
Bosch Security Systems
Bosch Security Systems
For more information please visit
www.boschsecurity.com
or send an e-mail to
emea.securitysyst[email protected]
All rights reserved
Printed in the Netherlands
VS-EH-en-58_F01U520698_01
