Bosch NWD-455V03-20P User manual

FlexiDome IP
NWD-455VO3-10P | NWD-455V04-10P | PNWD-455V03-20P |
NWD-455V04-20P
en Operating Instructions

FlexiDome IP | en 3
Bosch Security Systems Operating Instructions V 1.0 | 2006.12
Table of Contents
1 Introduction 15
1.1 Type number overview 16
1.2 Unpacking 16
1.3 System requirements 17
1.4 Overview of functions 17
1.4.1 Wide dynamic range 18
1.4.2 Power-over-Ethernet 18
1.4.3 Receiver 18
1.4.4 Video encoding 18
1.4.5 Tri Streaming 18
1.4.6 Recording 18
1.4.7 Multicast 19
1.4.8 Encryption 19
1.4.9 Configuration 19
1.4.10 Tampering recognition and motion detectors 19
1.4.11 Snapshots 19
1.4.12 Backup 19
1.4.13 Intelligent Video Motion Detection 20
2 Disassembly 21
3 Mounting the unit 22
3.1 Attach the mounting plate 23
3.2 Make the connections 23
3.2.1 Power connection 24
3.2.2 Network (and PoE) connection 24
3.3 Mount the camera 24
4Cameraset-up 25
4.1 Camera positioning 25
4.2 Focal length and focus 26
4.3 Basic settings 26
4.3.1 Install menu 27

4en | FlexiDome IP
V 1.0 | 2006.12 Operating Instructions Bosch Security Systems
4.3.2 Defaults 28
4.4 Closing the unit 28
5Networkconnection 29
5.1 System requirements 29
5.2 Establishing the connection 29
5.3 Secured network 31
6 Operation via the browser 32
6.1 Livepage 32
6.1.1 Processor load 32
6.1.2 Image selection 33
6.1.3 System log / Event log 33
6.1.4 Saving snapshots 33
6.1.5 Recording video sequences 33
6.1.6 Running recording program 34
6.2 Recordings page 35
6.2.1 Selecting recordings 35
6.2.2 Controlling playback 36
7 Configuration via the browser 39
7.1 Settings 39
7.2 General Settings 41
7.2.1 Camera identification 41
7.2.2 Password protection 41
7.2.3 Language selection 43
7.2.4 Date and time 43
7.2.5 Time server 43
7.3 Display Settings 45
7.3.1 Display stamping 45
7.4 Encoder Settings 46
7.4.1 Selecting an encoder profile 46
7.4.2 Changing profiles 48
7.4.3 JPEG posting 51
7.5 Camera settings 52
7.5.1 ALC 53

FlexiDome IP | en 5
Bosch Security Systems Operating Instructions V 1.0 | 2006.12
7.5.2 Enhance 54
7.5.3 Color 55
7.5.4 Installer options 56
7.6 Recording 56
7.6.1 Type 57
7.6.2 Storage information 57
7.7 iSCSI settings 58
7.7.1 iSCSI IP address 58
7.7.2 iSCSI LUN map 59
7.7.3 Target IP address 59
7.7.4 Target node 59
7.7.5 Target LUN 59
7.7.6 Target password 59
7.7.7 Initiator name 60
7.7.8 Initiator extension 60
7.7.9 Decoupling the drive used 60
7.7.10 Storage information 60
7.8 Partitioning 61
7.8.1 Creating a partition 61
7.8.2 Partition status 63
7.8.3 Editing a partition 63
7.8.4 Deleting partitions 66
7.9 Recording profile 66
7.10 Recording scheduler 69
7.10.1 Activating recording 70
7.10.2 Recording status 71
7.11 Alarm Settings 71
7.11.1 Alarm connections 71
7.12 VCA 74
7.12.1 Analysis 74
7.12.2 Analysis type 75
7.12.3 Motion detector 75
7.12.4 Sensitivity 75
7.12.5 Tamper detection 77
7.13 Alarm e-mail 79
7.13.1 Send alarm e-mail 79
7.13.2 Mail server IP address 79

6en | FlexiDome IP
V 1.0 | 2006.12 Operating Instructions Bosch Security Systems
7.13.3 Layout 79
7.13.4 Destination address 80
7.13.5 Sender name 80
7.13.6 Send e-mail for testing 80
7.14 Service Settings 81
7.14.1 Network 81
7.14.2 Multicasting 84
7.14.3 Encryption 86
7.14.4 Version information 87
7.14.5 Livepage configuration 88
7.14.6 Licenses 90
7.14.7 Maintenance 91
7.15 Function test 93
8 Connections between video servers 94
8.0.1 Installation 94
8.0.2 Establishing the connection 94
8.0.3 Connect on alarm 94
8.0.4 Connecting with a Web browser 95
8.0.5 Closing the connection 95
9 Operation with decoder software 96
10 Maintenance 97
10.1 Testing the network connection 97
10.2 Repairs 97
10.2.1 Transfer and disposal 97
11 Troubleshooting 98
12 Specifications 100
12.1 Dimensions (mm/inch) 102
12.2 Accessories 102
12.2.1 Power transformers 102

FlexiDome IP | en 7
Bosch Security Systems Operating Instructions V 1.0 | 2006.12
13 Glossary 103

8en | FlexiDome IP
V 1.0 | 2006.12 Operating Instructions Bosch Security Systems
Important safety instructions
Read, follow, and retain all of the following safety instructions.
Heed all warnings on the unit and in the operating instructions
before operating the unit.
1. Cleaning - Unplug the unit from the outlet before cleaning.
Follow any instructions provided with the unit. Generally,
using a dry cloth for cleaning is sufficient, but a moist fluff-
free cloth or leather shammy may also be used. Do not use
liquid cleaners or aerosol cleaners.
2. Heat Sources - Do not install the unit near any heat sources
such as radiators, heaters, stoves, or other equipment
(including amplifiers) that produce heat.
3. Water - Do not use this unit near water, for example near a
bathtub, washbowl, sink, laundry basket, in a damp or wet
basement, near a swimming pool, in an unprotected out-
door installation, or in any area classified as a wet location.
To reduce the risk of fire or electrical shock, do not expose
this unit to rain or moisture.
4. Object and liquid entry - Never push objects of any kind
into this unit through openings as they may touch danger-
ous voltage points or short-out parts that could result in a
fire or electrical shock. Never spill liquid of any kind on the
unit. Do not place objects filled with liquids, such as vases
or cups, on the unit.
5. Controls adjustment - Adjust only those controls specified
in the operating instructions. Improper adjustment of
other controls may cause damage to the unit. Use of con-
trols or adjustments, or performance of procedures other
than those specified, may result in hazardous radiation
exposure.
6. Overloading - Do not overload outlets and extension cords.
This can cause fire or electrical shock.
7. Power cord and plug protection - Protect the plug and
power cord from foot traffic, being pinched by items
placed upon or against them at electrical outlets, and its
exit from the unit. For units intended to operate with

FlexiDome IP | en 9
Bosch Security Systems Operating Instructions V 1.0 | 2006.12
230 VAC, 50 Hz, the input and output power cord must
comply with the latest versions of IEC Publication 227 or
IEC Publication 245. For outdoor use the power cord must
comply to NEC400-4 (CEC Rule 4-010) and marked with
OUTDOOR, W, or W-A.
8. Power sources - Operate the unit only from the type of
power source indicated on the label. Before proceeding,
be sure to disconnect the power from the cable to be
installed into the unit.
– For battery powered units, refer to the operating
instructions.
– For external power supplied units, use only the rec-
ommended or approved power supplies.
–Forlimitedpowersourceunits, this power source
must comply with EN60950. Substitutions may dam-
age the unit or cause fire or shock.
– For 24 VAC units, voltage applied to the unit's power
input should not exceed 28 VAC. User-supplied wiring
must comply with local electrical codes (Class 2
power levels). Do not ground the supply at the termi-
nals or at the unit's power supply terminals.
– If unsure of the type of power supply to use, contact
your dealer or local power company.
9. Servicing - Do not attempt to service this unit yourself.
Opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.
10. Damage requiring service - Unplug the unit from the main
AC power source and refer servicing to qualified service
personnel when any damage to the equipment has
occurred, such as:
– the power supply cord or plug is damaged;
– exposure to moisture, water, and/or inclement
weather (rain, snow, etc.);
– liquid has been spilled in or on the equipment;
– an object has fallen into the unit;
– unit has been dropped or the unit cabinet is damaged;

10 en | FlexiDome IP
V 1.0 | 2006.12 Operating Instructions Bosch Security Systems
– unit exhibits a distinct change in performance;
– unit does not operate normally when the user cor-
rectly follows the operating instructions.
11. Replacement parts - Be sure the service technician uses
replacement parts specified by the manufacturer, or that
have the same characteristics as the original parts. Unau-
thorized substitutions may cause fire, electrical shock, or
other hazards.
12. Safety check - Safety checks should be performed upon
completion of service or repairs to the unit to ensure
proper operating condition.
13. Installation - Install in accordance with the manufacturer's
instructions and in accordance with applicable local codes.
14. Attachments, changes, or modifications - Only use attach-
ments/accessories specified by the manufacturer. Any
change or modification of the equipment, not expressly
approved by Bosch, could void the warranty or, in the case
of an authorization agreement, authority to operate the
equipment.

FlexiDome IP | en 11
Bosch Security Systems Operating Instructions V 1.0 | 2006.12
DANGER! High risk:
This symbol indicates an imminently hazardous situation such
as "Dangerous Voltage" inside the product.
If not avoided, this will result in an electrical shock, serious
bodily injury, or death.
!
WARNING! Medium risk:
Indicates a potentially hazardous situation.
If not avoided, this could result in serious bodily injury or death.
!
CAUTION!
Indicates a potentially hazardous situation.
If not avoided, this may result in minor or moderate injury.
Alerts the user to important instructions accompanying the
unit.
i
NOTICE!
This symbol indicates information or a company policy that
relates directly or indirectly to the safety of personnel or
protection of property.

12 en | FlexiDome IP
V 1.0 | 2006.12 Operating Instructions Bosch Security Systems
Video loss
Video loss is inherent to digital video recording; therefore,
Bosch Security Systems cannot be held liable for any damage
that results from missing video information. To minimize the
risk of lost digital information, Bosch Security Systems recom-
mends multiple, redundant recording systems, and a procedure
to back up all analog and digital information.
!
CAUTION!
– Camera Grounding - For mounting the camera in poten-
tially damp environments, ensure to ground the system
using the ground connection of the power supply connec-
tor (see section: Connecting external power supply).
– U.S.A. models only - Section 810 of the National Electrical
Code, ANSI/NFPA No.70, provides information regarding
proper grounding of the mount and supporting structure,
grounding of the coax to a discharge unit, size of grounding
conductors, location of discharge unit, connection to
grounding electrodes, and requirements for the grounding
electrode.
– Permanently connected equipment - Incorporate a readily
accessible disconnect device in the building installation
wiring.
– PoE - Never supply power via the Ethernet connection
(PoE) when power is already supplied via the power con-
nector.
– Pole power switch - Incorporate an all-pole power switch,
with a contact separation of at least 3 mm in each pole,
into the electrical installation of the building.
– Power lines - Do not locate the camera near overhead
power lines, power circuits, or electrical lights, nor where
it may contact such power lines, circuits, or lights.

FlexiDome IP | en 13
Bosch Security Systems Operating Instructions V 1.0 | 2006.12
FCC & ICES Information
(U.S.A. and Canadian Models Only)
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable pro-
tection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio fre-
quency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one
or more of the following measures:
– reorient or relocate the receiving antenna;
– increase the separation between the equipment and
receiver;
– connect the equipment into an outlet on a circuit dif-
ferent from that to which the receiver is connected;
– consult the dealer or an experienced radio/TV techni-
cian for help.
Disclaimer
Underwriter Laboratories Inc. ("UL") has not tested the perfor-
mance or reliability of the security or signaling aspects of this
product. UL has only tested fire, shock and/or casualty hazards
as outlined in UL's Standard(s) for Safety for Information Tech-
nology Equipment, UL 60950-1. UL Certification does not cover
the performance or reliability of the security or signaling
aspects of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR CERTIFI-
CATIONS WHATSOEVER REGARDING THE PERFORMANCE OR
RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNC-
TIONS OF THIS PRODUCT.

14 en | FlexiDome IP
V 1.0 | 2006.12 Operating Instructions Bosch Security Systems
Environmental statement - Bosch has a strong commitment
towards the environment. This unit has been designed to
respect the environment as much as possible.
For additional information, please contact the Bosch Security
Systems location nearest you or visit our web site at
www.boschsecuritysystems.com
Disposal
Your Bosch product was developed and manufactured with
high-quality material and components that can be recycled and
reused. This symbol means that electronic and electrical appli-
ances, which have reached the end of their working life, must
be collected and disposed of separately from household waste
material. Separate collecting systems are usually in place for
disused electronic and electrical products.
Please dispose of these units at an environmentally compatible
recycling facility, per European Directive 2002/96/EC.

FlexiDome IP Introduction | en 15
Bosch Security Systems Operating Instructions V 1.0 | 2006.12
1 Introduction
The FlexiDome IP camera is a small, discreet, high-security sur-
veillance dome containing a high-performance 1/3-inch CCD
color camera with integral varifocal lens. The integrated unit is
mounted to a wall or ceiling. The sturdy construction and high
impact resistant polycarbon dome protect the camera module
from damage.
The smart camera incorporates advanced digital signal process-
ing for outstanding picture performance. The integrated camera
unit operates as a network video server and transmits video and
control signals over data networks such as Ethernet LANs and
the Internet.
The FlexiDome IP camera is easy to install and ready to use, and
offers the best solution for demanding scene conditions. Fea-
tures include:
– Impact-resistant dome
– Tamper-resistant housing
– Intelligent Video Motion Detection (iso enhanced)
– Video and data transmission over IP data networks
– Tri Streaming function for simultaneous encoding with
three individually definable profiles
– Multicast function for simultaneous picture transmission to
multiple receivers
– Video encoding using international MPEG-4 standard
– Integrated Ethernet interface (10/100 Base-T)
– Configuration and remote control of all built-in functions
via TCP/IP and secure HTTPS
– Password protection to prevent unauthorized connection
or configuration changes
– Event-driven, automatic connection
– Convenient maintenance via uploads
– Flexible control and data channel encryption
– Authentication according to the 802.1x standard
–NightSense
TM extends the camera’s low-light performance.

16 en | Introduction FlexiDome IP
V 1.0 | 2006.12 Operating Instructions Bosch Security Systems
1.1 Type number overview
Table 1.1 FlexiDome IP type numbers
1.2 Unpacking
Unpack carefully and handle the equipment with care. The
packaging contains:
– Integrated FlexiDome IP camera unit
– Mounting hardware kit
– Special screwdriver bit for tamper-resistant screws
– Lens adjustment cap
–CDROM
–Manual
– System requirements
– Configuration Manager
–MPEGActiveXcontrol
–DirextXcontrol
– Microsoft Internet Explorer
–SunJVM
– Player and archive player
– Adobe Acrobat Reader
Type number NWD-455V03-10P NWD-455V04-10P NWD-455V03-20P NWD-495V04-20P
Lens Varifocal
2.6 to 6 mm
F1.4
Varifocal
3.7 to 12 mm
F1.6
Varifocal
2.6 to 6 mm
F1.4
Varifocal
3.7 to 12 mm
F1.6
Standard PAL NTSC
Supply volt-
age
24 VAC, 50 Hz or +12 VDC
(use class 2 power supply) or
PoE (IEEE 802.3af)
24 VAC, 60 Hz or +12 VDC
(use class 2 power supply) or
PoE (IEEE 802.3af)
i
NOTICE!
If equipment appears to have been damaged during shipment,
repack it in the original packaging and notify the shipping agent
or supplier.

FlexiDome IP Introduction | en 17
Bosch Security Systems Operating Instructions V 1.0 | 2006.12
1.3 System requirements
– Computer with Windows 2000/XP operating system, net-
work access and Microsoft Internet Explorer web browser
version 6.0 or later
or
– Computer with Windows 2000/XP operating system, net-
work access and reception software, for example VIDOS,
BMVS or DIBOS 8.0
or
– MPEG-4 compatible hardware decoder from
Bosch Security Systems (such as VIP XD) as a receiver and
a connected video monitor
The minimum PC requirements are:
– Operating platform: a PC running Windows 2000 or Win-
dows XP with IE6.0
– Processor:1.8 GHz Pentium IV
– RAM memory: 256 MB
– Video system: 128 MB video memory, 1024x768 display
with 24-bit color
– Network interface: 100-BaseT
–DirectX:9.0b
1.4 Overview of functions
The integrated camera unit incorporates a network video
server. Its primary function is to encode video and control data
for transmission over an IP network. With its MPEG-4 encoding
it is bandwidth efficient for both network and recording. The
use of existing networks means that integration with CCTV sys-
tems or local networks can be achieved quickly and easily.
i
NOTICE! Make sure the graphics card is set to 16-bit or 32-bit
color depth and that Sun JVM is installed on your PC. To play
back live video images, an appropriate MPEG ActiveX must be
installed on the computer. If necessary, install the required
software and controls from the product CD provided. If you
need further assistance, contact your PC system administrator.

18 en | Introduction FlexiDome IP
V 1.0 | 2006.12 Operating Instructions Bosch Security Systems
Video images from a single camera can be simultaneously
received on several receivers.
1.4.1 Wide dynamic range
The digital signal is automatically processed to optimally cap-
ture the detail in both the high and low light areas of the scene
simultaneously, maximizing the information visible in the pic-
ture.
1.4.2 Power-over-Ethernet
Power for the camera can be supplied via a Power-over-Ether-
net (IEEE 802.3af) compliant network cable connection. With
this configuration, only a single cable connection is required to
view, power and control the camera.
1.4.3 Receiver
MPEG-4 compatible hardware decoders (for example VIP XD)
can be used as a receiver. Computers with decoding software
such as VIDOS or computers with the Microsoft Internet
Explorer web browser installed can also be used as receivers.
1.4.4 Video encoding
The camera uses the MPEG-4 compression standard. Thanks to
efficient encoding, the data rate remains low even with high
image quality and can also be adapted to local conditions
within wide limits.
1.4.5 Tri Streaming
Tri Streaming allows the incoming data stream to be encoded
simultaneously according to three different, individually cus-
tomized profiles. This creates two MPEG4 streams per camera
that can serve different purposes, for example, one for local
recording and one optimized for transmission over the LAN, and
an additional JPEG stream for use with a PDA.
1.4.6 Recording
The camera can be used with an iSCSI server connected via the
network to store long-term recordings.

FlexiDome IP Introduction | en 19
Bosch Security Systems Operating Instructions V 1.0 | 2006.12
1.4.7 Multicast
In suitably configured networks, the multicast function enables
simultaneous, real time transmission to multiple receivers. The
prerequisite for this is that the UDP and IGMP V2 protocols are
implemented on the network.
1.4.8 Encryption
The data transmissions and the authentication channel can be
encrypted to prevent unauthorized access. Web browser con-
nections can be protected using HTTPS.
1.4.9 Configuration
The camera can be configured using a browser on the local net-
work (Intranet) or from the Internet. Similarly, firmware
updates and rapid loading of device configurations are also pos-
sible. Configuration settings can be stored as files on a com-
puter and copied from one camera to another.
1.4.10 Tampering recognition and motion detectors
The camera offers a wide range of configuration options for
alarm signaling in the event of tampering with the camera. An
algorithm for detecting movement in the video image is also
part of the scope of delivery and can optionally be extended to
include special video analysis algorithms.
1.4.11 Snapshots
Individual video frames (snapshots) can be called up as JPEG
images, stored on the hard drive or displayed in a separate
browser window.
1.4.12 Backup
The browser application Livepage has an icon for saving the
video images provided by the unit as a file on your computer's
hard drive. Clicking this icon stores the video sequences and
they can be replayed with the Player from
Bosch Security Systems included with the package.

20 en | Introduction FlexiDome IP
V 1.0 | 2006.12 Operating Instructions Bosch Security Systems
1.4.13 Intelligent Video Motion Detection
The intelligent video motion detection (iVMD) system of the
camera uses advanced analysis algorithms with comprehensive
functions for the detection of motion.
