English | 11
Bosch Power Tools 1 609 92A 3TD | (21.9.17)
English
Safety Notes
Readallsafety warningsand all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious
injury.
Save these instructions.
This vacuum cleaner is not intend-
ed for use by children and persons
with reduced physical, sensory or
mentalcapabilities,orlackofexpe-
rience and knowledge. Otherwise,
there is a danger of operating errors
and injuries.
Supervise children. This will ensure
that children do not play with the vac-
uum cleaner.
Do not vacuum materials that are harm-
fultoone’shealth,e. g.dust frombeech
or oak wood, masonry dust, asbestos. These materials are
considered carcinogenic.
Inform yourself about the valid regulations/laws for your
countryconcerning the handling of materials that are haz-
ardous to one’s health.
Use the vacuum cleaner only after hav-
ing received sufficient information on
its usage. A thorough introduction reduces operating errors
and injuries.
The vacuum cleaner is suitable only for
vacuuming dry materials. The penetra-
tion of liquids increases the risk of an electric shock.
The vacuum cleaner may only be
used and stored indoors. The pene-
tration of rain or moisture into the vacuum cleaner lid increas-
es the risk of anelectric shock.
Do not vacuum hot or burning dusts,
and in rooms with an explosion hazard.
Dusts can ignite or explode.
Remove the battery before cleaning or performing
maintenance on the vacuum cleaner, making tool ad-
justments,changingaccessoriesorstoringthevacuum
cleaner.This safety measure preventsthe vacuumcleaner
from being started accidentally.
Provide for good ventilation at the working place.
Have the vacuum cleaner repaired only through quali-
fiedspecialists and only using originalspareparts. This
ensures that the safety of your vacuum cleaner is main-
tained.
Before restarting, check the proper condition of the
vacuum hose. When doing this, leave the vacuum hose
mounted to the vacuum cleaner to prevent dust from
coming out. Otherwise, you could possibly inhale dust.
Do not open the battery. Danger of short-circuiting.
Protect the battery against heat, e. g., against
continuous intense sunlight, fire, water, and mois-
ture. Danger of explosion.
When battery pack is not in use, keep it away from oth-
er metal objects like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally oc-
curs, flush with water. If liquid contacts eyes, addition-
ally seek medical help. Liquid ejected from the battery
may cause irritations or burns.
In case of damage and improper use of the battery, va-
pours may be emitted. Ventilate the area and seek
medical help in case of complaints. The vapours can irri-
tate the respiratory system.
Recharge only with the charger specified by the manu-
facturer. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another bat-
tery pack.
Usethe battery onlytogetherwithyourBoschproduct.
This is the only way to protect the battery against danger-
ous overload.
Thebattery can bedamagedbypointedobjectssuchas
nails or screwdrivers or by force applied externally. An
internal short circuit can occur and the battery can burn,
smoke, explode or overheat.
Symbols
The following symbols could have a meaning for the use of your
vacuum cleaner. Please take note of the symbols and their
meaning. The correct interpretation of thesymbols will help
you to use the vacuum cleaner in a better and safer manner.
WARNING
WARNING
WARNING
WARNING
Symbols and their meaning
Read all safety warn-
ings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Opening the emptying flap
Opening to clean the filter
CAUTION
OBJ_BUCH-3129-003.book Page 11 Thursday, September 21, 2017 5:19 PM

12 | English
1 609 92A 3TD| (21.9.17) Bosch Power Tools
Product Description and Specifica-
tions
Intended Use
The vacuum cleaner is intended for vacuuming dry materials
that are not harmful to one’s health.
Use the vacuum cleaner only when you fully understand and
can perform all functions without limitation, or have received
appropriate instructions.
Rotational Airflow
The bagless filter system removes the need to use dust bags.
Dirt is collected on the inside wall of the container.
Product Features
The numbering of the product features refersto the illustra-
tion of the vacuum cleaner on the graphics page.
1Coarse dirt filter
2Release button for dust cup
3On/Off button
4Handle
5Battery pack*
6Motor housing
7Dust cup
8Emptying flap release button
9Emptying flap
10 Extension tube
11 Floor nozzle
12 Battery port
13 Battery unlocking button
14 Crevice nozzle
15 Flexible extension tube
16 Filter grips
17 Filter
18 Rotational Airflow unit with Filter
19 Filter locking tab
20 Wall bracket*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Assembly
Battery Charging
Use only the battery chargers listed on the accessories
page. Only these battery chargers are matched to the lith-
ium-ion battery pack used in your vacuum cleaner.
Note:The battery supplied is partially charged.To ensure full
capacity of the battery, completely charge the battery in the
batterychargerbeforeusing yourpowertoolforthe firsttime.
The battery must be removed from the vacuum cleaner to
charge it.
The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.
The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.
Following the automatic shut-off of the vacuum clean-
er, do not continue to press the On/Off button. The bat-
tery can be damaged.
The battery is equipped with a NTC temperature control
which allows charging only within a temperature range of be-
tween 0 °C and 45 °C. A long battery service life is achieved
in this manner.
A significantly reduced working period after charging indi-
cates that the battery is used and must be replaced.
Observe the notes for disposal.
Battery Insertion/Removal (see figures A1 – A2)
Do not use force to insert the battery. The battery is de-
signed in such a way that it can only be inserted into the
vacuum cleaner when it is in the right position.
– Slide the battery pack 5all the way into the battery port
12.
– To remove the battery 5, press the unlocking button 13 on
the battery and pull it out of the battery bay 12.
Cordless dry vacuum cleaner GAS 18V-1
Article number 3 601 JC6 2..
Container volume (gross) l0.7
Vacuum, max.*kPa 6
Airflow, max.*l/s 10
Weight according to EPTA-
Procedure 01:2014 kg 1.3
Technical Data varies depending on filter used.
*depending on the battery pack being used
** limited performance at temperatures <0 °C
Permitted ambient temperature
– during charging
– during operation** and during
storage
°C
°C
0...+45
–20...+50
Recommended batteries GBA 18V..
GBA 18V... W
Recommended chargers GAL 18...
GAL 18... W
Cordless dry vacuum cleaner GAS 18V-1
Technical Data varies depending on filter used.
*depending on the battery pack being used
** limited performance at temperatures <0 °C
OBJ_BUCH-3129-003.book Page 12 Thursday, September 21, 2017 5:19 PM

English | 13
Bosch Power Tools 1 609 92A 3TD | (21.9.17)
Mounting VAC Accessories (see figure B)
Remove the battery before cleaning or performing
maintenance on the vacuum cleaner, making tool ad-
justments,changingaccessoriesorstoringthevacuum
cleaner.This safety measure preventsthe vacuumcleaner
from being started accidentally.
Thevacuum cleaneraccessoriescan be connecteddirectlyto
the dust cup 7.
The combination possibilities of the various vacuum cleaner
accessories can be viewed in the figure.
– Connect the vacuum cleaner accessories firmly to the con-
nection at the dust cup 7and in to each other.
Operation
Remove the battery before cleaning or performing
maintenance on the vacuum cleaner, making tool ad-
justments,changingaccessoriesorstoringthevacuum
cleaner.This safety measure preventsthe vacuumcleaner
from being started accidentally.
Starting Operation
Make sure that the filters are fitted securely before
vacuuming.
Only use an undamaged filter (no cracks, small holes,
etc.). Replace a damaged filter immediately.
Switching On and Off
To save energy, only switch the vacuum cleaner on when us-
ing it.
–Toswitch on the vacuum cleaner, press the On/Off button
3.
–Toswitchoff the vacuumcleaner,pressthe On/Offbutton
3again.
Maintenance and Service
Maintenance and Cleaning
Remove the battery before cleaning or performing
maintenance on the vacuum cleaner, making tool ad-
justments,changingaccessoriesorstoringthevacuum
cleaner.This safety measure preventsthe vacuumcleaner
from being started accidentally.
For safe and proper working, always keep the vacuum
cleaner and ventilation slots clean.
– Clean the vacuum cleaner housing from time to time using
a moist cloth.
– Clean soiled charger contacts using a dry cloth.
Emptying the Dust Box (see figure C)
Tomaintaintheoptimumperformanceofthe vacuumcleaner,
clean the dust cup 7after each use.
– Hold the vacuum cleaner over a suitable waste bin.
– Press the release button 8to open the emptying flap 9.
–Shakeoutthedustcontainer7.
–Closetheemptyingflap9again (you should hear it click in-
to place).
– Cleanthe coarse dirt filter 1(see “Emptyingthecoarsedirt
filter”, page 13) if required.
Ifnecessary, cleanthefilter (see“CleaningtheFilter”,page
13).
Emptying the coarse dirt filter (see figures D1 – D2)
– Turn the coarse dirt filter 1as far as it will go in the direc-
tion of rotation “ ” and remove it from the dust contain-
er 7.
– Shake out the coarse dirt filter 1and the dust container 7
over a suitable waste bin.
– Place the coarse dirt filter 1in the dust container 7and
turn it as far as it will go in the direction of rotation “ ”.
Cleaning the rotational airflow unit with filter
(see figures E1–E3)
– Hold the vacuum cleaner down slightly so that dust cannot
fall out of the dust container when the vacuum cleaner is
opened.
– Pressrelease button2and removethe dustcup 7from the
motor housing 6.
– Hold onto the filter grips 16 and pull the rotational airflow
unit with filter 18 out of the dust container 7.
– Shake out the the dust container 7and the rotational air-
flow unit 18 over a suitable waste bin.
– Put the rotational airflow unit filter 18 back in the dust con-
tainer 7.
Cleaning the Filter (see figures F1 – F2)
– Push the locking tab19 up and remove the filter 17.
– Gentlytap the filter 17against a solid surface to loosen the
dust.
– Assembly is carried out in reverse order.
– Afterwards,hangthedust cupatthebottominto the motor
housing, apply light pressure untilthe dust cup can be
heard to engage.
Storage
– Optionally, use the wall bracket 20 for the space-saving
storage of the vacuum cleaner and its accessories (see fig-
ure G).
Malfunctions
In the case of insufficient vacuuming performance, check the
following:
– Is the dust cup 7full?
▷ See “Emptying the Dust Box”, page 13.
– Is the coarse dirt filter 1clogged with dust?
▷ See “Cleaning the Filter”, page 13.
– Is the filter 17 clogged with dust?
▷ See “Cleaning the rotational airflow unit with filter”,
page 13.
– Is the capacity of the battery pack too low?
▷ See “Battery Charging”, page 12.
Regularly emptying the dust container 7and cleaning the fil-
ters will ensure optimum suction power.
Ifthe vacuuming performance isnotachievedthereafter,take
the vacuum cleaner to customer service.
OBJ_BUCH-3129-003.book Page 13 Thursday, September 21, 2017 5:19 PM

14 | English
1 609 92A 3TD| (21.9.17) Bosch Power Tools
After-sales Service and Application Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions
concerning our products and their accessories.
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the nameplate of
the product.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: (0344) 7360109
E-Mail: [email protected]
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: (01) 4666700
Fax: (01) 4666888
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch-pt.com.au
www.bosch-pt.co.nz
Republic of South Africa
Customer service
Hotline: (011) 6519600
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: (011) 4939375
Fax: (011) 4930126
E-Mail: [email protected]
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: (031) 7012120
Fax: (031) 7012446
E-Mail: [email protected]m
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: (021) 5512577
Fax: (021) 5513223
E-Mail: [email protected]
Bosch Headquarters
Midrand, Gauteng
Tel.: (011) 6519600
Fax: (011) 6519880
E-Mail: rbsa-hq.pt[email protected]
Transport
The contained lithium-ion batteries are subjectto the Danger-
ous Goods Legislation requirements. The user can transport
the batteries by road without further requirements.
Whenbeing transported bythirdparties(e.g.:air transport or
forwarding agency), special requirements on packaging and
labelling must be observed. For preparation of the item being
shipped, consulting an expert for hazardous material is re-
quired.
Dispatch batteries only when the housing is undamaged.
Tape or mask off open contacts and pack up the battery in
such a manner that it cannot move around in the packaging.
Please also observe possibly more detailed national regula-
tions.
Disposal
Vacuum cleaners, battery packs, accessories and
packaging should be sorted for environmental-friend-
ly recycling.
Do not dispose of vacuum cleaners and battery
packs/batteries into household waste!
Only for EC countries:
According to the European Guideline 2012/19/EU, vacuum
cleaner that are no longer usable, and according to the Euro-
pean Guideline 2006/66/EC, defective or used battery
packs/batteries, must be collected separately and disposed
of in an environmentally correct manner.
Batteries no longer suitable for use can be directly returned
at:
OBJ_BUCH-3129-003.book Page 14 Thursday, September 21, 2017 5:19 PM
Other manuals for GAS 18V-1
3
Table of contents
Other Bosch Vacuum Cleaner manuals

Bosch
Bosch Ingenius ProSilence 59 User manual

Bosch
Bosch BGS7RCL User manual

Bosch
Bosch Relaxx'x BGS50 User manual

Bosch
Bosch GL-50 User manual

Bosch
Bosch BGL3HYG User manual

Bosch
Bosch BGL3 series User manual

Bosch
Bosch BSR1 Series User manual

Bosch
Bosch BGL3 series User manual

Bosch
Bosch BGL35MON12/01 User manual

Bosch
Bosch BSD 3030 User manual

Bosch
Bosch BSG8 series User manual

Bosch
Bosch BSGL3 User manual

Bosch
Bosch GS60 User manual

Bosch
Bosch GAS 55 M AFC Professional User manual

Bosch
Bosch BGB1 Series User manual

Bosch
Bosch BSG62022 User manual

Bosch
Bosch GL-50 User manual

Bosch
Bosch BSGL5 SERIES User manual

Bosch
Bosch 3 User manual

Bosch
Bosch BBH2 Series User manual
