Bosch Washing/Drying Range Configuration guide

Meet the winners
in laundry solution.
Washing/Drying Range

2 Washing Range
Technologies that not only
improve our everyday lives,
but our future too.
Green Technology is the Bosch roadmap for
sustainability, efficiency and transparency,
especially when it comes to using resources and
energy. Our work is constantly guided by this
principle, in all sectors, from environment-friendly
production methods to researching new, energy-
efficient technologies.
Green Technology Signet
This signet identifies products that feature especially
groundbreaking technology and top efficiency, paired with
low consumption rates in energy, water or other natural
resources. All Bosch products are manufactured according
to these ecological criteria.

Washing Range 3
The top water efficiency
rating is Excellent ✓✓✓✓✓✓.
Bosch is 26% better
than Excellent.
Bosch is one of the first manufacturers
to register a washing machine for
participation in the Water Efficiency
Labeling Scheme (WELS) to encourage the
uptake of water efficient appliances.
Most of our washers are awarded Excellent
✓✓✓ which is the best rating under the Water
Efficiency Labeling Scheme (WELS) in
Singapore. In fact Bosch washers are so water
efficient that they are 26% better than the
qualifying rate for the best water efficiency
rating under the WELS in Singapore. The WELS is a voluntary
scheme jointly administered by the Singapore Environment
Council (SEC) and Public Utilities Board (PUB).
The Label provides information on the product and how much
water it uses. The more ticks awarded, the more water efficient
the product is. For example washing a full load of clothes with
a ✓✓✓ rated washing machine can save you more than 80 litres
of water.

4 Washing Range
The top energy efficiency class is A.
Bosch betters it by up to 30%.
Thanks to the new VarioPerfect™ logic system, the
EcoPerfect option can be combined with practically every
programme for energy-efficient washing and perfect results.
Green Technology inside
VarioPerfect™
The new VarioPerfect™ logic system gives customers
the option of quicker laundry or more energy efficient
laundry while delivering perfectly clean laundry every
time.
With a perfect variety of programmes, VarioPerfect™
achieves outstanding cleaning results for all types
of textiles, and for all load sizes. Practically all
programmes can be combined with the VarioPerfect™
EcoPerfect option for more savings and with
SpeedPerfect for faster results.
The EcoPerfect saver option
Select EcoPerfect and save an
amazing amount of electricity.
With a full load, the Logixx 8
VarioPerfect™ and Maxx 7 VarioPerfect™ are more
economical than the qualifying rate for the top energy
efficiency class A* by 30% and 20% respectively. The
EcoPerfect option can be combined with all
programmes except SuperQuick 15 and wool. This
way you can save electricity and still enjoy perfect
washing results in wash efficiency class A.
*energy efficiency rating based on EU standard, EN60456
The VarioPerfect™ Principle
Either option you choose
Ultra Ultra
Fast Economical
Always
Ultra Clean
Laundry

Washing Range 5
Green Technology inside
Fast option SpeedPerfect
Depending on the programme selected,
you can reduce wash time by up to 60%
with SpeedPerfect. For example, when
the SpeedPerfect function is selected washing
5kg of laundry takes only 60 minutes* with no
compromises on washing efficiency. The
SpeedPerfect function can be used in conjunction
with all programmes except SuperQuick 15 and wool.
* in a 40˚C whites/colored wash programme with
SpeedPerfect option.
Washing efficiency class A
All Bosch washers are awarded with an A rating
for washing efficiency. The washing efficiency
classes record the extent to which washing
efficiency standards are satisfied. Washing efficiency
means maximum cleanliness and maximum care. An
A-rating denotes top washing efficiency and 100 %
washing power.
Other perfect features
Wash programmes with prewash
Thanks to VarioPerfect™. The need for a prewash
button is eliminated. Wash programmes have been
perfected to such a degree that laundry always comes
out perfectly clean. However, for people who don’t
wish to do without a prewash, we have provided 2
standard programmes with a prewash and flexible
temperature settings. That way, you can wash all
textiles from cottons to high-tech materials with a
prewash. Incidentally, you can save even more
electricity by leaving out the prewash cycle.
60% faster washing.
100% satisfaction.
SpeedPerfect is the fastest washing option ever.
At the same time, it also washes thoroughly and gently.
Wash
Performance
Class

6 Washing Range
The only drum system with two different
approaches to one goal: perfect
cleanliness.
It deserves a round of applause: the patented VarioSoft™ drum
system has a host of unique features to ensure perfect wash
results, be it delicate or heavily soiled laundry - or even curtains.
VarioSoft™ drum system
The unique patented VarioSoft™ drum system
offering faster, gentler washing is exclusive
to Bosch. The raindrop structure and asymmetrical
paddles have a steep and flat side each. When the
drum is rotated over the steep side, laundry is
washed more intensively under normal programmes
– and over the flat sides, with extra care for delicate
programmes.
Reduces creasing
At 8 kg or 65 litres capacity, the Logixx 8
VarioPerfect™ features one of the largest drum of all
standard-size washing machines. Creasing is minimal
even for larger loads because there is plenty of room
for garments to move freely.
Asymmetrical glass porthole
The unique porthole on the VarioSoft™ drum also
improves washing results. The asymmetrically curved
inner surface of the porthole gently returns articles
to the center of the drum, permanently integrating
them in the wash process.
Ultra
gentle
action for
delicate
wash
Ultra
gentle
action for
delicate
wash
Intensive
action
for stains
removal
Intensive
action
for stains
removal

Washing Range 7
Peak performers need a sound base.
The new Logixx 8 features the latest generation of
brushless motor - the EcoSilence Drive™.
Green Technology inside:
The new EcoSilence Drive™
Developed by Bosch, the revolutionary
brushless motor is quieter, faster, more
energy-efficient, enduring and powerful than all
others before it. Our patented solution, in contrast
to conventional brushless motors, uses a permanent
magnet with the latest drive electronics. This
advanced technology is also used in powerful
machines like wind turbines where maximum power
and minimum energy loss are demanded.
More efficiency
A conventional motor has an efficiency factor of 25%.
The efficiency factor is the ratio of power input to
output. The higher the efficiency factor, the more
effective the appliance. Thanks to advanced
electronics, the new EcoSilence Drive™ with its
sensor-less, and thus more intelligent electronic
control has an efficiency factor of 60%.
More energy-efficient
The new EcoSilence Drive™ uses up to 30% less
energy than the qualifying rate for energy efficiency
Class A.
More time-saving
Thanks to its outstanding efficiency factor, the new
EcoSilence Drive™ also takes less time to achieve
peak performance.
More quietness
In contrast to conventional motors, the new
EcoSilence Drive™ is extremely quiet. Being brushless
eliminates any high-frequency motor brush noise.
The drive is fully encapsulated and amazingly quiet
when running.
More endurance
Very low on wear and tear, the compact motor has a
long life expectancy.
AntiVibration™ Design
The new spiral design of the side walls isn’t
just for aesthetic. The structure increases
stability and reduces vibrations. Optimum sound
insulation dampens noise even further.

8 Washing Range
One for all.
And all in one.
The new Logixx 8 VarioPerfect adds
magic to your home. With it, all your
laundry wishes come true. What
else would you expect from the new
perfection in home laundry?
The 8 highlights of the Logixx 8 VarioPerfect™
NEW
Long life cycle and outstanding
quietness with EcoSilence Drive™
Green Technology inside: the unique
EcoSilence Drive™ is an advanced motor
offering maximum efficiency, economy and
exceptionally quiet operation.
Excellent ✓✓✓ water efficiency rating
under the Water Efficiency Labeling
Scheme in Singapore
✓✓✓ rating enable you to save more than 80
litres of water when washing a full load of
clothes.
NEW
VarioPerfect™
30% more economy than the
qualifying rate for energy efficiency
Class A, thanks to EcoPerfect
Green Technology inside: the lowest ever
electricity rates thanks to EcoPerfect, based
on the VarioPerfect logic system.
NEW
VarioPerfect™
Thanks to SpeedPerfect, your laundry
time can be reduced by 60%.
NEW
Very quiet thanks to AntiVibration™
side walls
Green Technology inside: together with the
EcoSilence Drive™ the structure of the outer
walls ensures exceptionally quiet operation.
Faster, gentler washing with the
patented VarioSoft™ drum and
asymmetrical porthole design
Thanks to a unique droplet structure, your
laundry is washed more intensively or gently as
the occasion demands.
Target and remove 16 of the most
stubborn stains with the automatic
stain-remover function
Red wine, cosmetics etc. don’t stand a chance
when you combine the automatic stain remover
option with your standard programmes.
100% convenience with the self-cleaning
detergent drawer
Practical hygiene assured by thorough,
automatic flushing during each wash cycle.
7.39litres/kg
Clothes Washing Machines
Bosch
WAS32794ME(cotton cold)
07/2009/104324

- 8kg wash load capacity
- Large drum size at 65 litres
- A-30% Energy Efficiency Rating (EU standard)
- VarioPerfect™ logic system ensures
outstanding results for all kinds of textiles and
load sizes
- EcoSilence Drive™ offers maximum efficiency,
economy and exceptionally quiet operaion
- Anti-vibration side panel ensures exceptionally
quiet operation
- VarioSoft™ drum system for better cleaning
results and shorter washing cycles
- Variable 400 to 1600rpm spin speed with
rinse hold
- 14 washing programmes
(incl. Wool and
Delicates)
- Special programmes:
• Super Quick 15 min
• Curtains
• Dark Wash
• Sports Wear
- Reload function
- Anti-Stain Automatic with settings for 16 stains
- 3D Sensor for dosage recommendation and
load detection
- 32cm large porthole for easy loading and
unloading of big items
- Ergonomically favorably positioned door
handle to enable opening of door without
bending down
- Double slide window for improved efficiency
and maximised laundry protection
- Large LCD display with easy to use
TouchControl operation
- 24hrs time delay with remaining time indicator
- Electronic child lock
- Aquastop™ - 100% leakproof system
Consumption Rates
Electricity: 1.03 kWh
Water: 56 litres
Appliance dimensions:
842H x 600W x 590D mm
Voltage: 220V-240V/ 50 Hz/ 10Amp
- 8kg wash load capacity
- Large drum size at 65 litres
- A-30% Energy Efficiency Rating (EU standard)
- VarioPerfect™ logic system ensures
outstanding results for all kinds of textiles and
load sizes
- EcoSilence Drive™ offers maximum efficiency,
economy and exceptionally quiet operation
- Anti-vibration side panel ensures exceptionally
quiet operation
- VarioSoft™ drum system for better cleaning
results and shorter washing cycles
- Variable 400 to 1400rpm spin speed with
rinse hold
- 14 washing programmes (incl. Wool and
Delicates)
- Special programmes:
• Super Quick 15 min
• Mixed load
• Sports Wear
- Reload function
- 32cm large porthole for easy loading and
unloading of big items
- Ergonomically favorably positioned door
handle to enable opening of door without
bending down
- Double slide window for improved efficiency
and maximised laundry protection
- Large LED display for temperature, spin speed
and time delay selection (24hrs) with remaining
time indicator
- 4 function buttons:
• SpeedPerfect
• EcoPerfect
• Easy Iron
• Rinse Plus
- Aquastop™ - 100% leakproof system
Consumption Rates
Electricity: 1.03 kWh
Water: 56 litres
Appliance dimensions:
842H x 600W x 590D mm
Voltage: 220V-240V/ 50 Hz/ 10Amp
- 8kg wash load capacity
- Large drum size at 65 litres
- A-30% Energy Efficiency Rating (EU standard)
- VarioPerfect™ logic system ensures
outstanding results for all kinds of textiles and
load sizes
- EcoSilence Drive™ offers maximum efficiency,
economy and exceptionally quiet operation
- Anti-vibration side panel ensures exceptionally
quiet operation
- VarioSoft™ drum system for better cleaning
results and shorter washing cycles
- Variable 400 to 1200rpm spin speed with
rinse hold
- 14 washing programmes (incl. Wool and
Delicates)
- Special programmes:
• Super Quick 15 min
• Mixed load
• Sports Wear
- Reload function
- 32cm large porthole for easy loading and
unloading of big items
- Ergonomically favorably positioned door
handle to enable opening of door without
bending down
- Double slide window for improved efficiency
and maximised laundry protection
- Large LED display for temperature, spin speed
and time delay selection (24hrs) with remaining
time indicator
- 4 function buttons:
• SpeedPerfect
• EcoPerfect
• Easy Iron
• Rinse Plus
Consumption Rates
Electricity: 1.03 kWh
Water: 56 litres
Appliance dimensions:
842H x 600W x 590D mm
Voltage: 220V-240V/ 50 Hz/ 10Amp
Washing Range 9
WAS32794ME
Logixx 8 VarioPerfect™
Front Load Washer
WAS28444ME
Logixx 8 VarioPerfect™
Front Load Washer
WAS24444ME
Logixx 8 VarioPerfect™
Front Load Washer
7.39 litres/kg
ClothesWashing Machines
Bosch
WAS32794ME(cotton cold)
07/2009/104324
8
kg 8
kg 8 kg

10 Washing Range
The 7 highlights of the Maxx 7 VarioPerfect™
Excellent ✓✓✓ water efficiency rating
under the Water Efficiency Labeling
Scheme in Singapore
✓✓✓ rating enable you to save more than 80
litres of water when washing a full load of
clothes.
NEW
VarioPerfect™
20% more economy than the
qualifying rate for energy efficiency
Class A, thanks to EcoPerfect
Green Technology inside: the lowest ever
electricity rates. Thanks to EcoPerfect, based
on the VarioPerfect™ logic system.
NEW
VarioPerfect™
Thanks to SpeedPerfect, your laundry
time can be reduced by up to 60%.
Quick solution for today's busy
lifestyle
SuperQuick 15 programme enables
you to wash 2kg of lightly soiled garments in
only 15 minutes with a complete wash
programmes.
Special functions cater to your
individual needs
Easy ironing function reduces crease
formation so less ironing time is required
Rinse Plus is ideal for people with
sensitive skin - when selected, an
additional rinse cycle will be
performed to remove any detergent residues.
Control at the touch of a button with the
easy- to-use technology
With TouchControl technology operating the
washer is a breeze.
Advanced laundry care with a whole range
of special programmes
Because every garment is different:
Individual care programmes are available
e.g. for sport-swear, shirts/ blouses etc.
Maxx 7 VarioPerfect™:
100% cleaning power in
speed and economy settings.
The new Maxx 7 VarioPerfect™ allows
you to choose between ultra-fast and
ultra-economical _ while always getting
your laundry ultra-clean.

- 7kg wash load capacity
- A-20% Energy Efficiency Rating (EU standard)
- VarioPerfect™ logic system ensures
outstanding results for all kinds of textiles and
load sizes
- Variable 600 to 1200rpm spin speed with
rinse hold
- 14 washing programmes (incl. Wool and
Delicates)
- Special programme:
• Super Quick 15 min
- Reload function
- Full electronic control for excess foam
detection and imbalance control
- 30cm wide porthole for easy loading /unloading
- 180 degree opening angle
- LED display for 24hrs time delay selection &
remaining time
- 4 function buttons:
• SpeedPerfect
• EcoPerfect
• Easy Iron
• Rinse Plus
- Easy-to-use TouchControl operation
Consumption Rates
Electricity: 1.05 kWh
Water: 47 litres
Appliance dimensions:
847H x 600W x 590D mm
Voltage: 220V-240V/ 50 Hz/ 10Amp
- 7kg wash load capacity
- A-20% Energy Efficiency Rating (EU standard)
- VarioPerfect™ logic system ensures
outstanding results for all kinds of textiles and
load sizes
- Variable 600 to 1000rpm spin speed with
rinse hold
- 14 washing programmes (incl. Wool and
Delicates)
- Special programme:
• Super Quick 15 min
- Reload function
- Full electronic control for excess foam
detection and imbalance control
- 30cm wide porthole for easy loading /unloading
- 180 degree opening angle
- LED display for 24hrs time delay selection &
remaining time
- 4 function buttons:
• SpeedPerfect
• EcoPerfect
• Easy Iron
• Rinse Plus
- Easy-to-use TouchControl operation
Consumption Rates
Electricity: 1.05 kWh
Water: 47 litres
Appliance dimensions:
847H x 600W x 590D mm
Voltage: 220V-240V/ 50 Hz/ 10Amp
- 7kg wash load capacity
- A-20% Energy Efficiency Rating (EU standard)
- VarioPerfect™ logic system ensures
outstanding results for all kinds of textiles and
load sizes
- Variable 600 to 900rpm spin speed with
rinse hold
- 14 washing programmes (incl. Wool and
Delicates)
- Special programme:
• Super Quick 15 min
- Full electronic control for excess foam
detection and imbalance control
- 30cm wide porthole for easy loading /unloading
- 180 degree opening angle
- 4 function buttons:
• SpeedPerfect
• EcoPerfect
• Easy Iron
• Rinse Plus
- Easy-to-use TouchControl operation
Consumption Rates
Electricity: 1.05 kWh
Water: 47 litres
Appliance dimensions:
847H x 600W x 590D mm
Voltage: 220V-240V/ 50 Hz/ 10Amp
Washing Range 11
WAE24360SG
Maxx 7 VarioPerfect™
Front Load Washer
WAE20360SG
Maxx 7 VarioPerfect™
Front Load Washer
WAE18161SG
Maxx 7 VarioPerfect™
Front Load Washer
7
kg
7
kg
7
kg

- 7kg wash load capacity
- Stainless steel drum
- Variable 400 to 1200rpm spin speed with
Rinse Hold
- Fungus and rust proof phosphate and zinc
coated galvanised body
- Full electronic control for:
• Excess foam detection
• Imbalance control
• Optimum spinning
- Easy TouchControl operation
- 11 washing programmes
- Special programmes:
• Express 15 – World’s First
• Skin care
• Sports light
• Mixed load
• Eco
• Dark load
- 8 function buttons:
• Start/Pause
• Intensive
• Pre-wash
• Easy Iron
• Rinse Plus
• Temperature selection
• Time delay – 24 hours
• Spin speed selection
- Large LED display showing selected spin
speed, time, temperature and progress
indicator
- Acoustic programme end indicator
- 30cm wide porthole and 180°opening door
for easy loading and unloading
- Multi-safe anti-flood protection
- Low fascia panel, can be built under kitchen
worktop
Consumption Rates
Electricity: 1.19 kWh
Water: 49 litres
Appliance dimensions:
847H x 600W x 590D mm
Voltage: 230V-240V/ 50 Hz/ 10Amp
- 7kg wash load capacity
- Stainless steel drum
- 800rpm spin speed
- Fungus and rust proof phosphate and zinc
coated galvanised body
- Full electronic control for:
• Excess foam detection
• Imbalance control
• Optimum spinning
- Programme cum temperature selector on one
knob
- 12 washing programmes
- 3 function buttons:
• Start/Pause
• Rinse Plus
• Quick Wash
- LED indicators for Wash, Rinse and Spin
- 30cm wide porthole and 180°opening door
for easy loading and unloading
- Multi-safe anti-flood protection
- Low fascia panel, can be built under kitchen
worktop
Consumption Rates
Electricity: 1.19 kWh
Water: 49 litres
Appliance dimensions:
847H x 600W x 590D mm
Voltage: 230V-240V/ 50 Hz/ 10Amp
- 7kg wash load capacity
- Stainless steel drum
- 600rpm spin speed
- Fungus and rust proof phosphate and zinc
coated galvanised body
- Full electronic control for:
• Excess foam detection
• Imbalance control
• Optimum spinning
- Programme cum temperature selector on one
knob
- 12 washing programmes
- 3 function buttons:
• Start/Pause
• Rinse Plus
• Quick Wash
- LED indicators for Wash, Rinse and Spin
- 30cm wide porthole and 180°opening door
for easy loading and unloading
- Multi-safe anti-flood protection
- Low fascia panel, can be built under kitchen
worktop
Consumption Rates
Electricity: 1.19 kWh
Water: 49 litres
Appliance dimensions:
847H x 600W x 590D mm
Voltage: 230V-240V/ 50 Hz/ 10Amp
12 Washing Range
WAE12060SG
Maxx 7 Classic
Front load washer
WAE24460AU
Maxx 7 Lifestyle
Front Load Washer
WAE16060SG
Maxx 7 Classic
Front Load Washer
7
kg
7
kg
6.64Litres/Kg
ClothesWashing Machines
Bosch
WAE12060SG
07/2008/000025
7
kg

Washing Range 13
- 5.5kg wash load capacity
- A-10% Energy Efficiency Rating (EU standard)
- 600rpm spin speed with rinse hold
- 15 washing programmes (incl. Wool)
- Super Quick 30min
- 30cm wide porthole for easy loading and
unloading
- 140 degree opening angle
- User friendly with programme and temperature
selector on one knob
- 3 function buttons:
• Start
• Rinse Stop
• Rinse Plus
- LED indicators to show washing process status
Consumption Rates
Electricity: 0.93kwh
Water: 44 litres
Appliance dimensions:
850H x 600W x 560D mm
Voltage: 220V-240V/50 Hz/ 10Amp
WAA12166SG
Classixx 5.5
Front Load Washer
5.5
kg
SuperQuick 30
- 5kg wash load capacity
- 2.5kg drying capacity
- Variable 400 to 1200rpm spin speed with
Rinse Hold
- Full electronic control for:
• Excess foam detection
• Imbalance control
• Optimum spinning
- 11 washing programmes
- 2 drying programmes
- Special wash programmes:
• Super Quick 15 – World’s First
• Sensitive
• Sports wash
• Mixed load
• Eco
• Dark wash
- Gentle and Intensive dry programme
- 9 function buttons:
• Start/Pause (Reload option)
• Pre-wash
• Rinse Plus
• Wash Plus
• Reduced Ironing
• Temperature selection
• Time delay – 24 hours
• Spin speed selection
• Drying
- Full LCD display with TouchControl
operation showing selected spin speed
cycles, programme choice, remaining time
and other options
- 30cm wide porthole and 180°opening door
for easy loading and unloading
Consumption Rates for washing
Electricity: 0.95 kWh
Water: 49 litres
Appliance dimensions:
860H X 600W X 560D mm
Voltage: 220V-240V/50 Hz/ 13Amp
WVD 24520GB
Exxcel 5
Front Load Washer/Dryer
5
kg
- 10.5kg wash load capacity
- A-10% Energy Efficiency Rating (EU standard)
- Large drum size with asymmetrical paddle for
better movement and washing efficiency
- Variable 600 to 1200rpm spin speed with
Rinse Hold
- Full electronic control for:
• Excess foam detection
• Imbalance control
• Optimum spinning
- 13 washing programmes
- Special programme:
• Mix
- 6 function buttons:
• Start/Pause
• Pre-wash
• Extra Rinse
• Easy Iron
• Menu
• Select options
- LCD display and push buttons for wash
programme
- 24 hours time delay with remaining time
indicator
- Aquasecure
- 3D Aquaspa scoop, shower and porthole
system for faster soaking
- Quiet brushless ASM motor
- Acoustic sound buzzer volume selector
- Multi-language display choice
- 41cm wide porthole and 180°opening door
for easy loading and unloading
- Ergonomically designed top front panel
- Electronic child lock
Consumption Rates
Electricity: 1.7 kWh
Water: 74 litres
Appliance dimensions:
937H x 687W x 767D mm
Voltage: 220V-240V/50 Hz/ 10Amp
WBB 24751ME
Logixx 10.5
Front Load Washer
10.5
kg

14 Drying Range
Maximise your playtime.
Minimise your energy bill and not your lifestyle.
Bosch dryers - the most energy efficient across all capacities.
In today’s busy lifestyle, it has become more apparent
that clothes dryers are an important part of modern
laundry. It is without question that dryers make
completing the week’s laundry much easier and
hassle free. Having a dryer means that drying is
guaranteed regardless of the weather.
With Bosch clothes dryers, besides not
having to compromise on your lifestyle, you
can also minimize your electrical bill. Bosch
range of clothes dryers have attained either Very
Good✓✓✓ or Excellent ✓✓✓✓rating under the
Mandatory Energy Labeling Scheme (MELS) in
Singapore. In fact, Bosch dryers consume the least
energy per wash across all capacities. These are made
possible as Bosch has invested years of research to
introduce drying technologies that improve the
efficiency of our dryers, making them more
economical to run.
The MELS is an initiative under the Singapore Green
Labelling Scheme. It is supported by National
Environment Agency (NEA) and the Nation Energy
Efficiency Committee (NEEC). The label provides
consumers with factual information on energy
consumption and allows them to make comparison
between different models before deciding on the
purchase.
Green Techology inside
The EcoLogixx 7, underpinned by the innovative
ActiveAir technology, sets groundbreaking standards
in energy efficiency. Bosch has perfected the heat
pump operation, laundry can now be dried using less
energy for greater environment friendliness and care.
In contrast to conventional dryers, Bosch’s ActiveAir
technology operates without conventional heating.
Drying air is heated at low cost with the help of the
heat pump and existing heat is efficiently re-used.
‘Sensor-Care’ Technology
With the ‘Sensor-Care’ technology, you can be
assured that the dryer is on only for the time required
to reach your desired drying rate. ‘Sensor-Care’
constantly monitors the moisture level of the load
and automatically stops the drying cycle once your
desired level of dryness has been achieved. This
means that not only are you able to save on time,
energy and cost, you are also protecting your valuable
clothes against over-drying which damages the fibres
and reduce the lifespan of your garments.

Drying Range 15
The 8 highlights of Bosch dryers:
Energy efficiency
Bosch dryers are awarded Very Good ✓✓✓
or Excellent ✓✓✓✓ rating under the
Mandatory Energy Labeling Scheme in Singapore.
Sensor drying
The built-in sensors monitor moisture levels and
ensure the right temperature throughout the drying
cycle so that your laundry is not over-dried or
damaged.
Advanced drying care with a whole range of
special programmes
Special programmes are incorporated as we believe
these individual care programmes are required to
protect and prolong the lifespan of different
garments. Sportswear programme ensures gentle
drying for sports clothing made of modern textiles
and high-tech temperature sensitive materials. The
Shirts/Blouse programme helps to smooth out your
garments and minimises creasing on your garments.
Wide capacity range
Bosch dryers range from drying capacities of 6 to
8 kg to suit the needs of different households.
Quick option
For people with no time to spare: the ExtraShort 40
special programme dries 2 kg of laundry in lightning
speed. Cupboard dry results can be achieved in just
40 minutes.
Total laundry solution
Bosch dryers and washing machines can be stacked
together with the aid of a stacking kit. These stacking
kits anchor the machines together to ensure stability
and ease of use.
Drum design
The drums of Bosch dryers are designed to give
laundry plenty of room to spread. The laundry does
not lie flat on the fabric-friendly drum interior
surface but is penetrated by a mild current of warm
air from all sides and gently agitated by the
waveform soft paddles.
Drum material
Bosch dryers are equipped with either a stainless
steel drum or a high quality steel drum that is
galvalume coated. Both materials are highly
corrosion resistant and they are valued for their
versatility, aesthetic and long-term performance.
Galvalume coated steel's resistance to corrosion is
at least twice that of galvanized steel, so you can be
assured of the durability of Bosch dryers.

16 Drying Range
Launch into a new dryer age with Bosch, Europe's
leading household appliances brand and its tumble
dryer, EcoLogixx 7 which sets groundbreaking
standards in energy efficiency, laundry care and user
friendliness. Underpinned by innovative ActiveAir
Technology, with which Bosch has perfected heat
pump operation, laundry can now be dried using less
energy for greater environment-friendliness and care.
SelfCleaning Condenser
Maintenance is now a thing of the past. The
EcoLogixx 7 is the world’s first heat pump dryer
with a maintenance-free condenser. Regular cleaning
of the condenser filter has always been an unpleasant
task. Bosch has put an end to all that! During the
drying cycle, the condenser is automatically clean up
to four times _ Bosch has called this innovation the
“SelfCleaning Condenser”.
A lifetime of energy efficiency
During the drying process, approx. 20% of the lint
collects in the heat exchanger. Permanent self
cleaning prevents deposits which impair
performance, leading to extended drying periods
and, in turn increased energy consumption. The
EcoLogixx 7 maintains its ultra-economical energy
efficiency standard throughout its service life and
always offers peak drying performance. Further
unique benefits include high speed drying – 7 kg of
cupboard dry cottons in just 125 minutes and super
silent operation. And, of course, as you would expect,
it is more efficient than all other heat pump dryers.
An extra serving of convenience?
Beside a maintenance-free condenser, the EcoLogixx
7 features 15 drying programmes for all kinds of
textiles, outstanding user-friendliness with operation
via a comfort display, a handy rotary selector and
TouchControl buttons, activated with a single touch.
Drying with cutting-edge
economy and care.
The world's 1st heat pump dryer with
maintenance-free condenser.

Drying Range 17
ActiveSteam technology
ActiveSteam – a technology that not only dries, but
actively reduces wrinkles and makes clothes feel
fresh again. The Logixx 8 Steam meets consumers'
desire for new laundry care solutions that save time
and simplify their lives.
More care, fewer wrinkles
Ironing is one of the most time-consuming household
chores. No wonder consumers are grateful for
whatever help they can get. Bosch understands this
and presents its Logixx 8 Steam, a condensation
dryer with a fully automatic and intelligent steam
feature. All it takes is to select "Steam Dry" and set
the rotary selector to the easy-care or cotton cycle.
The new model's sensor technology measures the
textiles' moisture content and releases just the right
amount of steam to freshen clothes while drying them
with minimum wrinkles. Even totally wrinkled but dry
laundry can be made smooth again. This makes
ironing easier or totally unnecessary and frees up
valuable time that's better spent on something else.
Fresh steam for sensitive garments
The Logixx 8 Steam is particularly useful when it
comes to the care of non-washable garments such
as blazers, blouses or pants made of sensitive fabrics.
The gentle steam dissolves dust and tiny odor-causing
particles from the fibers without stressing them
mechanically. The result is fresh, wrinkle-free clothing
that looks and smells fresh without spending time
and money on dry-cleaning. Even the refreshing cycle
couldn't be made any easier: Simply put the garments
in the drum, select "Business" or "Leisure" under
"Steam Refresh" depending on the garment type, and
start the cycle.
Top features and lots of convenience
With all this sophisticated steam technology, it should
come as no surprise that the Logixx 8 Steam meets
all of today's requirements in terms of functionality
and convenience. Its spacious drum holds up to 8kg
of laundry and is equipped with the SensitiveDrying
system, a stainless steel drum design with especially
soft paddles that are extra easy on fabrics. The clear
LCD display and the large number of programs to
choose from, the drum light, the easy-to-use glass
door and the easy-to-set child-proof lock are signs
of state-of-the-art ergonomics and user convenience.
Steam fights wrinkles.
The new Bosch Logixx 8 Steam for laundry
that's dry, fresh and wrinkle-free.

- 7kg drying capacity
- Full electronic sensor control with 9 drying
programmes, including 2 timed programmes
- Super Quick 40min program
- Low Heat option button
- Galvalume drum material
- Large round door opening
- 160°opening angle
- LED progress indicator
- Easy-empty condensation tank
- Easy-clean fluff filter
- Overheating temperature protection
Consumption Rates
Maximum heat output: 2100W
Current rating: 220V – 240V/ 50Hz/ 10Amp
Appliance dimensions:
842H x 598W x 625D mm
- 7kg drying capacity
- Energy Efficiency Exellent ✓✓✓✓ over lifetime
- Full electronic sensor control with 15 drying
programmes, including 3 timed programmes
- World’s FIRST heat pump dryer with a
maintenance-free condenser
- ActiveAir Technology - soft laundry and
minimum creasing
- Super silent at 63dB noise level
- Low Heat & Reduced Ironing option buttons
- Remaining time display with 24hrs time delay
option
- Stainless steel drum material
- Large round door opening with cover glass and
interior drum light
- 160°opening angle
- Easy-clean fluff filter
Consumption Rates
Maximum heat output: 2100W
Current rating: 220V – 240V/ 50Hz/ 10-16Amp
Appliance dimensions:
842H x 598W x 625D mm
18 Drying Range
WTE84101AU
Maxx 7
Condensation Dryer
7
kg
WTW86560BY
Ecologixx 7
Condensation Dryer
7
kg
- 8kg drying capacity
- Full electronic sensor control with 15 drying
programmes, including 2 steam and 2 refresh
programmes
- ActiveSteam Technology – fully automatic
process of de-wrinkling and refreshing
- AutoDry function – automatic detection of
moisture adjustment for optimal results
- Low Heat & Reduced Ironing option buttons
- Remaining time display with 24hrs time delay
option
- Stainless steel drum material
- Large round door opening with cover glass and
interior drum light
- 160°opening angle
- Easy-empty condensation tank
- Easy-clean fluff filter
Consumption Rates
Maximum heat output: 2500W
Current rating: 220V – 240V/ 50Hz/ 10Amp
Appliance dimensions:
842H x 598W x 625D mm
WTS86514BY
Logixx 8 SteamPerfect
Condensation Dryer
8
kg

Drying Range 19
- 6kg drying capacity
- Full electronic sensor control with 9 drying
programmes, including 4 timed programmes
- Low Heat & Reduced Ironing option buttons
- Galvalume drum material
- Large round door opening
- 150°opening angle
- LED progress indicator
- Easy-empty condensation tank
- Easy-clean fluff filter
- Overheating temperature protection
Consumption Rates
Maximum heat output: 2000W
Current rating: 220V – 240V/ 50Hz/ 13Amp
Appliance dimensions:
842H x 599W x 635D mm
- 7kg drying capacity
- Wide round door with 160°opening angle
- Stainless steel drum
- “Ellipse” drum with Soft Dry paddles for
even and gentle drying
- Full electronic sensor drying system
with easy TouchControl buttons
- 9 drying programmes including
2 timed programmes
- 2 function buttons:
• Start
• Gentle
- DuoTronic
- 6 LED including programme end,
error and filter clean indicator
- Overheating temperature protection
- Optional accessories:
WTZ11310 stacking kit
WTZ11300 stacking kit with drawer
Consumption Rates
Maximum heat output: 2500W
Current rating: 220-240V/ 50Hz/ 10-16Amp
Appliance dimensions:
842H x 598W x 625D mm
- 6 kg drying capacity
- Full electronic sensor control with 9 drying
programmes, including 4 timed programmes
- Easy Iron & Gentle option buttons
- Galvalume drum material
- Large round door opening
- 150°opening angle
- LED progress indicator
- Separate venting hose for exhaust air
- Easy-clean fluff filter
- Overheating temperature protection
- Exhaust air outlets at rear and left hand side
panel
Consumption Rates
Maximum heat output: 2000W
Current rating: 220V – 240V/ 50Hz/ 10Amp
Appliance dimensions:
842H x 599W x 635D mm
WTC84100GB
Maxx 6
Condensation Dryer
WTV74100ME
Maxx 7
Sensor Dryer
WTA74100ZA
Maxx 6
Sensor Dryer
7
kg
6
kg
6
kg

QUALITY SERVICE
Washing/Drying Range
BWD 09-12/01(S). Whilst every care has been taken in the preparation of this publication, Bosch does not warrant the accuracy or completeness of
the information in this publication and Bosch reserves the right to alter specifications without notice. To the extent permitted by law, Bosch excludes
all liability, including negligence, for any loss incurred in reliance on the contents of this publication. © Copyright 2009 by BSH Home Appliances Pte
Ltd. Company registration number: 199608497E. Printed in Singapore.
Bosch is distributed by:
Bosch will not let you down
The most important quality in the household
is reliability. That is why Bosch appliances are
built to be durable and efficient. In the
unlikely event of a malfunction occurring, our
customer service team pledges Bosch quality:
We will not let you down.
Ingenious technology for low cost
repairs
The far-sightedness of our engineers ensures
that all main operating parts are easily
accessible. This means that malfunctions are
pinpointed and solved quickly - thus reducing
repair costs.
Immediate help in your home for
large appliances!
Large appliances such as washing machines
or dishwashers need specialised engineers
who offer on-site diagnosis and repairs.
We are just a phone call away!
Bosch appliances are retailed in major
departmental stores and authorised dealers.
Bosch product range consists of:
Electric Oven
Steamer
Microwave Oven
Coffee Machine
Electric Hob
Gas Hob
Cookerhood
Refrigerator
Wine Cooler
Dishwasher
Washing Machine
Tumble/Condenser Dryer
Iron
Vacuum Cleaner
Bathroom Scale
Kitchen Machine
Hand Blender
Juicer
If you have further queries about the operation
or function of Bosch household appliances,
please contact at:
Singapore
BSH Home Appliances Pte. Ltd.
(Reg. No: 199608497E)
11 Bishan Street 21
Bosch Building #04-01
Singapore 573943
Mainline: (65) 6356 1080
Fax: [phone]
Customer Service Center
37 Jalan Pemimpin
Block A #01-03
Union Industrial Building
Singapore 577177
Hotline: [phone]
Fax: [phone]
Operating Hours: Mon - Fri, 8.30am – 5.30pm
Malaysia
BSH Home Appliances Sdn. Bhd.
(Reg. No: 711053H)
No.8A Jalan 13/6
46200 Petaling Jaya, Selangor
Tel: [phone]
Fax: [phone]
Customer Service
Hotline: [phone]
Fax: [phone]
Operating Hours: Mon – Fri, 8.30am – 5.30pm
www.bosch-home.com
