Bosch WKD28540EU User manual

Washer-dryer
en Installation and operating instructions

2
Contents
Keep all documents in a safe place for future reference, or to pass on to the next owner.
For further information and a selection of our products, visit our website:
www.bosch-home.com
Operating instructions
General safety information ......................................................... 3
Environmental protection/economy tips .................................. 4
Your new washer-dryer ............................................................... 5
Before washing for the first time ................................................ 7
Preparing and sorting the laundry ............................................. 7
Detergents and Care Products................................................... 9
Programmes.................................................................................11
Washing and drying options .................................................13
Washing and drying ..................................................................15
Cleaning and care ......................................................................17
What to do if... ............................................................................19
After-sales service .....................................................................22
Installation instructions
Installation instructions ........................................................23
Appendix
Table of programmes.................................................................28
Consumption rates......................................................................29
Index ..............................................................................................30
Please read the Installation and operating instructions and all the other
information supplied and handle the appliance accordingly.

3
General safety information
Intended use
The washer-dryer is designed for:
– domestic use only.
– machine-washable fabrics in detergent solution and drying these
fabrics.
– operation with cold drinking water and commercially available
detergents and care products that are suitable for use in washing
machines.
This washer-dryer complies with the relevant safety regulations..
Hazard warnings
– Keep packaging and packing materials out of the reach of children.
Risk of suffocation from plastic film and collapsible boxes.
– When an appliance is worn out, unplug it from the mains. Cut through
the mains cable and remove it together with the plug. Destroy the lock
on the door. This will prevent children from getting locked in and
putting their lives in danger.
Do not use the washer-dryer if the laundry:
– has been treated with solvents, oil, wax, fat or dye (e.g. stain remover,
cleaning solvent, hairspray, nail varnish remover).
– has come into contact with hairspray, nail varnish remover, or similar
substances. Risk of fire or explosion!
– contains dust residues, e.g. coal dust or flour Risk of explosion!
–containsfoam/rubber.
Before using for the first
time
– Set up the washer-dryer according to
the installation instructions –> page23.
– Remove the transport safety bolts and keep them in a safe place.
– Do not operate the washer-dryer if it has any visible damage. If you are
in any doubt, please consult our after-sales service or your retailer.
When washing and
drying
– Remove all objects from pockets, particularly sources of ignition
(e.g. lighters, matches, etc.).
– Do not leave children unsupervised near the washer-dryer.
– The washer-dryer must not be used by children or persons who have
not been instructed in its use.
– Keep pets away from the washer-dryer.
– Take care when Draining hot detergent solution.
– The washing machine door can become very hot during operation.
– Condensed water is not drinking water quality and may be
contaminated with fluff.
To protect the washer-
dryer
– Do not climb onto the washer-dryer.
– Do not lean on the open door of the washer-dryer.
– Do not install the washer-dryer in areas that are at risk of frost.
– Do not transport the washer-dryer without the transport safety bolts in
place.

4
Environmental protection/economy
tips
– Separate out the various waste materials of the packaging and take
them to the nearest collection point.
– Always fill the washer-dryer with the maximum load for the relevant
programme.
– Wash normally soiled laundry without a prewash.
–Insteadofic Cottons(Cottons/Coloureds) 90 °C, select the
0Cottons Eco 60 °C programme. This gives comparable results, but
uses less energy.
– Measure the detergent according to the manufacturer's instructions
and in line with the local water hardness.
WEEE
)
This appliance is labelled in accordance with European Directive
2002/96/EC on Waste Electrical and Electronic Equipment - WEEE.
The directive provides an EU-wide framework for the return and recycling
of used appliances.

5
Your new washer-dryer
Description of the
washer-dryer
The washer-dryer can be used
in 3 ways –> page15:
– washing only
– drying only
– successive washing and drying.
The successive wash-dry programme automatically shifts from the wash
cycle to the dry cycle without further intervention.
Drying is achieved using the condensation principle. The condensate that
is produced during drying runs via the Drain hose into the Drain tank.
Caution: the water supply hose and water Drain hose must be correctly
connected during washing and drying –> page26. The tap must be open.
A safety device prevents the door from being opened during operation.
Before opening
Make sure that there is no water in the drum and that the drum is not
moving.
Emergency release
In the event of a power cut, the door can be released mechanically
–> page21.
Door

6
Control panel
Indicator lamp
Indicates the settings that have been
selected for:
– Temperature: Ž
- 90°C.
– Spin speed: $ - 1400 rpm.
– Options/signal.
Display panel
Shows the settings that have been selected (e.g. spin speed,
drying time), the progress of the current programme and the
programme status.
Programme progress
T N'
B ‘
Pre-wash, Main wash, Rinse,
Final spin, Drying.
Drying options
5 Pe e:
Time-controlled drying, Iron-damp,
Cupboard-dry, Extra-dry.
Auxiliary displays
2 % E
l kg
Finished in time, Programme start, Childproof
lock, Fluff-removal cycle, recommended
load.
Indicator lamp Display panel
Washing and drying options –> page13
–Temperature °C: individual adjustment of the washing
temperature.
–Spin speed B:individual adjustment of the spin speed.
–Options button: sets washing options.
–Set: activation/deactivation of the selected
washing options.
–Finished in time 0 :delays the Programme start.
–Drying 5:sets the drying options
Start/Pause A:
starts and stops the washing programme –> page14.
Buttons
Programme selector –> page11
For switching the washer-dryer on and
off and for selecting the programme, can
be turned in both directions. Do not
adjust the programme selector while
washing/drying is in progress.
Programme selector

7
Before washing for the first time
Preparing and sorting the laundry
The washer-dryer was tested before leaving the factory.
To remove any water that may be left over from the test, do not load any
laundry the first time that you run a wash programme.
Make sure that the transport safety bolts on the rear of the washer-
dryer have been removed –> page24.
Do not load any laundry.
Close the door.
Turn on the tap.
Pull out the detergent drawer.
Add ½ a measuring cup of detergent to compartment II –> page9.
Do not use detergents for wool or delicates (these cause foam to be
created).
Close the detergent drawer.
Turn the programme selector to the 60°C programme.
Press the A (Start/Pause) button.
At the end of the programme, turn the programme selector to Off.
Open the door.
Leave the door open to allow the inside of the washer-dryer to dry.
Sorting laundry for
washing
– Wash white laundry separately from coloureds.
– Unhemmed or torn items should not be washed in the washer-dryer, as
they may fray.
– The laundry may be damaged if you do not observe the fabric care
symbols.
Only wash laundry with the following care labels:
Laundry with care symbol Do not wash.
i
i
Sorting laundry
according to the
information on the
care labels
Care label Type of laundry
<; Cottons 90 °C.
:98 Coloureds 60 °C, 40 °C, 30 °C.
BA> Easy-care 60 °C, 40 °C, 30 °C.
uFAE> Hand- and machine-washable silk, 40 °C, 30 °C,
cold.

8
Sorting laundry for
drying
Only dry laundry that is labelled "suitable for tumble-drying" or which
has the following care symbols:
Do not wash the following fabrics in the washer-dryer:
–Donotmachinedrylaundry with the b
care symbol.
– Airtight fabrics (e.g. rubber-coated fabrics).
– Delicate materials (silk, curtains made from synthetic fabrics) -
they may crease.
– Dripping-wet laundry - high energy consumption
– Wool or fabrics containing wool.
Preparing laundry for
washing
Loose foreign bodies (e.g. coins, paper-clips, needles, nails) may damage
the laundry and components of the washer-dryer (e.g. the drum).
Drain the pockets of all items.
Brush any sand out of pockets and collars.
Pretreat any stains.
Close zips, do up cover buttons.
Remove curtain fittings or place curtains in a laundry bag.
Wash the following in a laundry bag/pillowcase:
– Delicates, e.g. tights, curtains,
– Small items, e.g. socks or handkerchiefs,
– Underwired bras (the underwiring may come loose during the
washing process and cause damage).
Turn trousers, knitwear and knitted fabrics, e.g. jerseys,
T-shirts or sweatshirts inside out.
Preparing laundry for
drying
Only dry fabrics that have already been washed, rinsed and spun.
Also spin easy-care fabrics before drying.
Sort the items for washing according to material and desired level of
dryness to ensure even drying.
Loading the
laundry
Before loading the washer-dryer, make sure that there are no foreign
bodies or pets in the drum.
Risk of explosion. items that have been treated with cleaning agents
containing solvents, e.g. stain remover or, must be carefully rinsed out
before they are loaded into the washer-dryer, otherwise there is the risk
of an explosion.
Unfold the laundry and place it loosely in the drum. Load a mixture of
small and large items.
Observe the maximum drum loads,
Programme table –> page28.
Take care not to trap items of laundry between the door and the rubber
seal.
Close the door. You will hear it click shut.
Measure out and add detergent and care products for only a washing
programme or a combined washing and drying programme.
Turn on the tap.
Sorting laundry
according to the
information on the
care labels
Care label Type of laundry
aDry at normal temperature.
`Dry at low temperature (delicate drying).

9
Detergents and Care Products
Detergent drawer
The detergent drawer is divided into three compartments
Compartment I : detergent for pre-wash.
Compartment II : detergent for main wash,
Compartment i :Liquid additives, such as starch or fabric softener.
Additives are automatically dispensed during the final rinse cycle.
– Do not exceed the maximum capacity, otherwise compartment i may
be emptied too early.
– Dilute viscous additives with water to prevent blockages.
Liquid detergent insert: this must be inserted before liquid detergents
are used.
To do this:
Pull out the detergent drawer as far as the stop.
Press on the zone labelled PUSH and take out the detergent drawer.
Pull the insert in compartment II forwards as far as the stop and push
it down.
Insert the detergent drawer.
Descaler can be added to compartments Iand II according to the man-
ufacturer's instructions. Add detergent first, followed by the descaler.
Detergents and care
products
Risk of poisoning
Keep detergents and care products out of the reach of children.
Risk of chemical burns
Take care when opening the detergent drawer. There may still be deter-
gent residues in the drawer.
Select the correct dosage for the detergent according to:
–thesizeoftheload,
– the instructions of the detergent manufacturer,
– how dirty the laundry is,
– the water hardness. You can find out about water hardness in your area
from your local waterworks.
Using the correct dosage reduces the impact on the environment and
gives a good washing result.
Only use pH-neutral wool detergent for woollens programmes.
II
I
i
Descaler
i
i

10
Normally soiled laundry
Set the programme.
Do not select T(Pre-wash) –> page13.
Add all the detergent, according to the manufacturer's instructions, to
compartment II of the detergent drawer.
Heavily soiled laundry
Set the programme.
Select T(Pre-wash) –> page13.
Add 1/4 of the recommended amount of detergent to compartment I
of the detergent drawer and 3/4 of the detergent to compartment II.
Only use liquid detergent for the main wash cycle with no prewash.
To do this:
Add the recommended amount of detergent to a liquid detergent
measuring aid and place it in the drum.
or
After folding down the liquid detergent insert, pour the detergent into
compartment II of the detergent drawer.
The scale on the liquid detergent insert helps to measure the correct
dosage of liquid detergent.
If compartment II is used for washing powder, the
liquid detergent insert must be folded up.
Measuring washing powder
Measuring liquid detergent
i
i

11
Programmes
Programme selector
The programme selector is used to set the washing and drying
programmes.
The time remaining until the end of the programme and the
Beladungsmenge (Load) are shown on the display panel.
Washing programmes*
*depends on the model
ic Cottons (Cottons/Coloureds)
Suitable for hard-wearing fabrics, heat-resistant fabrics made from cotton
or linen.
– Coloureds up to 60 °C.
– Whites 60 °C to 90 °C.
0Cottons Eco
Washing programme for the best possible washing result with minimum
energy and water consumption.
fEasy-Care (Easy-care)
Washing programme for less hard-wearing fabrics made from cotton,
linen, synthetic fibres or blended fabrics. It is advisable to sort the laundry
by colour.
“Delicate/Silk (Delicates/Silk)
Gentle programme for delicate, washable fabrics, e.g. silk, satin,
synthetics or blended fabrics (e.g. curtains). Gentle spinning between the
rinse cycles and reduced final spin speed.
: Wool (Woollens)
Wool becomes matted when subjected to heat, moisture and movement.
The woollens programme takes these qualities into account and finds a
compromise between standing still and movement.
Suitable for hand- or machine-washable fabrics made from wool or a wool
blend.
Super Quick 15’ … (Rapid 15)
Short programme for easy-care, lightly soiled fabrics made from cotton,
linen, synthetics or blends. Suitable for freshening up items or for washing
new items before wearing for the first time. The programme takes
15 minutes.
Mix k(Mix)
For mixed items of laundry made of various hard-wearing and easy-care
fabrics.
SportsWash w(Sport wash)
For washing functional clothing and sports wear made from microfibre
and synthetics. Reduced creasing and additional rinse cycle.
i

12
Washing programmes*
* depends on the model
Sensitive s
For washing fabrics with increased hygiene requirements or those that will
be used by allergy sufferers. The temperature remains constant during the
washing process. More intensive rinsing with increased water level. For
hard-wearing and easy-care fabrics made from cotton or linen.
Night Wash S
Particularly quiet wash programme with a reduced final spin.
Sleep mode. Once the programme has finished, the display goes out, but
can be reactivated by pressing any button.
Drying programmes Intensive Dry 5
Intensive drying for a (robust fabrics), at 90°C.
Gentle Dry ‰
Gentle drying for ` (easy-care fabrics), 60°C.
Special programmes Fluff Clean l(Fluff-removal cycle)
This programme is designed to clean the drying cycle of any fluff
deposits. The time at which the programme needs to be run is
automatically determined by the washer-dryer and is indicated by the
l(Fluff-removal cycle) symbol on the display panel. The lsymbol
(Fluff-removal cycle) remains lit until the programme has been
successfully completed.
To run the Fluff Clean l(Fluff removal cycle), proceed as follows:
Make sure that the drum is completely empty and close the door.
Turn the programme selector to Fluff Clean l(Fluff-removal cycle).
Press the A (Start/Pause) button.
At the end of the programme, the l(Fluff-removal cycle) symbol goes
out on the display panel.
The Fluff Clean l(Fluff-removal cycle) programme can also be run at
any time without prompting by the appliance.
' + BRinse + Spin:
An additional rinse cycle with a final spin. If the laundry is to be removed
dripping wet, set the Spin speed to $(Rinse hold) before Programme
start –> page13.
[ + B Empty + Spin:
Drain the rinsing water following a programme with
$(Rinse hold) –> page13.
Turn the programme selector to [ + B Empty + Spin.
Set the spin speed to $(Rinse hold).
Press the A (Start/Pause) button.
or
Drain and spin at the desired spin speed:
Turn the programme selector to [ + B Empty + Spin.
Press the BSpin button repeatedly until the desired spin speed is set.
Press the A (Start/Pause) button.
i

13
Washing and drying options
Temperature °C button
The temperature can be adjusted individually for each programme.
To adjust it, press the °C (Temperature) button repeatedly until the
required temperature is displayed.
Spin speed button BThe spin speed can be individually adjusted for each programme.
To set the spin speed, press the B(Spin) button repeatedly until the
required spin speed is displayed.
$ (Rinse hold) deactivates the spin function. The laundry remains in the
rinsing water.
The automatic unbalanced load detection system ensures that the laundry
is evenly distributed using several initial spins. If the laundry is extremely
unevenly distributed, the speed of the final spin is reduced or the spin
cycle is not performed for safety reasons.
Option button
Set button
The set programmes can be individually adjusted.
To choose the required option:
Press the Option button repeatedly until the required option is selected
(indicator lamp flashes).
Press the Set button to switch the option on/off (indicator lamp lights
up/does not light up).
If you press and hold the Option ~ button, all the options scroll through.
Options (symbols on the display panel)
T Pre-wash Prewash at 35 °C. Suitable for heavily soiled laundry.
X Intensive Prolonged washing time. Suitable for particularly heavily soiled laundry
with dried-on stains. Cannot be combined with R Flexi Time
QEasy-iron Special spin sequence with subsequent fluffing. Gentle final spin at
reduced speed. Slightly increased residual moisture in the laundry.
Reduces creasing and laundry is easier to iron.
ZWater Plus Increased water level and additional rinse cycle. For regions with very soft
water or for further improving the rinsing result. Any detergent residues
are removed.
RFlexi Time Sets the washing time. normal-medium-short.
CSignal Activates or deactivates the audible signal.
0Finished in button
You can postpone Programme start before it begins. Using the Remaining
time, you can determine when the selected programme is to end. The
remaining time can be set in one-hour increments, up to a maximum of
24 hours. Press the 0(Finished in) button repeatedly until the required
number of hours is displayed.
Then press the A (Start/Pause) button, the programme will start after a
delay according to the set Remaining time. The required time to the end
of the programme is shown on the display panel.
Rinse hold
Unbalanced load detection
system
i

14
Drying button 5
The drying programmes –> page12 can be individually adapted by
selecting the drying options.
– Press the 5 (Drying) button repeatedly until the required drying option
is shown on the display panel.
– To deactivate, press the 5(Drying) button repeatedly until is
shown on the display.
Drying options (symbols on the display panel)
0 Time-controlled
drying
The drying time can be set to between 2:40 and 0:00 by repeatedly pressing the
5(Drying) button.
P Iron-damp The residual moisture in the washing is increased. Enables easier ironing.
eCupboard-dry The laundry is dry and ready to put away.
e:Extra-dry The laundry is dried intensively. Suitable for laundry that is hard to dry.
A Start/Pause button
Press the A (Start/Pause) button to start the selected programme.
The 2(Remaining time) is shown on the display panel.
The %(programme start) symbol is lit.
The programme progress is shown on the display panel:
!- Pre-wash
N- Main wash
'- Rinse
B- Final spin
‘- Drying
To change the programme:
Select a new programme.
Press the A (Start/Pause) button.
The new programme starts.
Press and hold the A (Start/Pause) button while the programme is in
progress until appears on the display panel. and the
Remaining time appear alternately on the display while the programme is
paused.
Press the A (Start/Pause) button to continue with the programme.
Press and hold button A(Start/Pause) until is displayed.
For washing programmes at high temperatures:
– Cooling down laundry: choose ' + B Rinse + Spin.
– Press the A (Start/Pause) button.
For programmes at low temperatures:
– choose [ + B Empty + Spin.
– Select the A (Start/Pause) button.
If you cancel the Drying programme, the laundry may still be very hot.
i
Programme progress
Changing the programme
i
Pausing the programme
Cancelling the programme

15
Washing and drying
Washing only
Turn the programme selector to the desired programme,
e.g. ic Cottons (Cottons/Coloureds) 60°C.
– The display panel alternately shows 2(Remaining time) and the
recommended load in kg. The %symbol flashes.
If necessary, adjust the temperature and the spin speed and select any
options for your individualised programme, –> page13.
–The5(Drying) function must not be activated.
Load the laundry –> page8.
– Observe the maximum load,
Programme table –> page28.
Press the A (Start/Pause) button.
–2(Remaining time) is shown on the display panel.
The %(Programme start) symbol lights up.
– The washing programme starts.
Drying only
Turn the programme selector to the desired drying programme.
– The display panel alternately shows 2(Remaining time) and the
recommended load in kg.
Press the 5(Drying) button to set the drying options
–> page14
– If you do not make a selection, the e(Cupboard-dry) option is set.
Load the laundry –> page8.
– Observe the maximum load,
Programme table –> page28.
Press the A (Start/Pause) button.
–2(Remaining time) is shown on the display panel and the
5(Drying) and % (Programme start) symbols light up.
– The drying programme starts.
Washing and drying
Successive washing and drying.
Set the programme selector to the desired programme,
e.g. ic Cottons (Cottons/Coloureds) 60°C.
–2(Remaining time) and the recommended load in kg are shown
alternately on the display panel. The %symbol flashes.
If necessary, adjust the temperature and the spin speed and select any
options for your individualised programme, –> page13.
Press the 5(Drying) button to set the drying options
–> page14
Load the laundry –> page8.
– Observe the maximum load in kg,
Programme table –> page28.
Press the A (Start/Pause) button.
The drying programme that is carried out is automatically determined by
the washing programme, see the Programme table –> page28.
i
i
i

16
End of the programme
The washing and drying programmes are ended automatically.
appears on the display panel.
Turn the programme selector to Off.
Remove the washing from the drum.
Leave the door open to allow the inside of the washer-dryer to dry out.
Turn off the tap (not necessary on models with Aqua-Stop).
If the spin function was deactivated at the start of the wash cycle,
$ (no final spin = laundry remains in last rinsing water), the washing
programme is automatically stopped after the final rinse. The display
panel shows alternating with .
In order to Drain the rinsing water and, if required, spin the laundry:
Press the B (Spin) button repeatedly until the required spin speed is
set. The water is Drained and the washer-dryer spins the laundry. The
programme is completed when appears in the display field.
The maximum spin speed depends on the selected wash programme.
If you do not wish to spin the laundry:
Press the B (Spin) button (remaining time for Draining is displayed).
The water is Drained, but the washer-dryer does not spin the laundry.
The programme is complete when appears on the display
panel.
Set the programme selector to Off.
Remove the laundry.
Leave the door open to allow the inside of the washer-dryer to dry out.
Turn off the tap (not necessary on models with Aqua-Stop).
Childproof lock
For preventing the washer-dryer functions that you have set from being
changed inadvertently.
Activate/Deactivate: Press the Option and Set buttons at the same time
to activate or deactivate the Childproof lock. When the childproof lock is
activated, Elights up on the display.
Rinse hold
i

17
Cleaning and care
Safety information
Risk of electric shock
You must disconnect the appliance from the mains first. Never clean the
washer-dryer with a water jet.
Risk of explosion.
Never clean the washer-dryer with solvents.
Risk of scalding
Hot washing water must be cooled before Draining.
Housing and control
panel
Wipe with a soft, damp cloth.
Remove detergent and cleaning agent residue immediately.
Do not clean with a jet of water.
Drum
Remove any foreign bodies from the drum and rubber seals.
Descaling the drum:
– Only use a proprietary brand of descaler with corrosion inhibitor for
washing machines for descaling the washer-dryer.
– Observe the manufacturer's instructions regarding use and dosage.
– After descaling and removing rust from the drum,
run the '+ B Rinse + Spin programme several times to remove any
remaining acid.
If any remaining metal objects (e.g. coins, paper clips, needles, nails)
have caused rust spots:
– Use chlorine-free cleaning agents; observe the manufacturer's
instructions. Never use steel wool.
Detergent drawer
If there are detergent or care product residues:
Pull out the detergent drawer as far as the stop.
Press on the blue zone labelled PUSH and take out the detergent
drawer.
Clean the detergent drawer guide.
Remove the blue fabric softener compartment insert.
Clean the detergent drawer and fabric softener compartment insert
under running water.
Insert the fabric softener compartment insert.
Insert the detergent drawer.

18
Drain pump
Take the Drain hose out of the retainer.
Remove the plug from the Drain hose and release the washing water.
– The container for the Drained water may have to be emptied several
times.
– When no more water runs out, replace the plug.
Place the Drain hose into the retainer.
Unscrew the pump cover.
– Clean the pump housing and remove any foreign objects.
– Make sure that the impeller can turn freely.
Replace the pump cover and screw firmly in place.
Place the kick panel in the 4 clip-in slots and secure to the housing
using the lock pins.
Filter in the water
supply hose
If no water runs into the washer-dryer, or only an insufficient amount, you
must first reduce the water pressure in the supply hose:
Turn off the tap ('+ B Rinse + Spin / [+ B Empty + Spin).
Press the A (Start/Pause) button.
Allow the programme to run for approximately 40 seconds.
Set the programme selector to Off.
Unplug the mains plug from the socket.
Unscrew the water supply hose from the tap.
Clean the filter with a small brush.
Reconnect the hose.
Turn on the tap.
Check whether water comes out of the end of the hose.
If water is escaping, check that the filter is correctly seated.
Descaling the
washer-dryer
This should not be necessary if the correct detergent dosage has been
used. If it is necessary, however, proceed according to the descaling
agent manufacturer's instructions. Suitable descalers can be obtained via
our website or from our after-sales service –> page22.
Set the programme selector to Off.
Use a screwdriver to release the lock pins.
Tip the kick panel and pull upwards to remove.
Draining the water
Cleaning the Drain pump

19
What to do if...
Risk of electric shock.
Repairs must only be carried out by customer services or authorised
technicians.
If repairs are needed, or if you cannot rectify a fault yourself with the help
of the following table:
Set the programme selector to Off.
Disconnect the washer-dryer from the power supply.
Turn off the tap.
Call the after-sales service –> page22.
Other fault codes are only for use by the after-sales service. Make a note of the fault code to inform the after-
sales service.
Fault Possible cause Remedial action
Programme does not start. The A (Start/Pause) button has not
been pressed.
Press the A (Start/Pause) button.
A delayed start time has been
selected.
Washer dryer starts on completion of
the delay period.
Change the “finished in time” if
necessary –> page13.
Power cut.
The delayed start time that was
selected has been cleared.
Reselect the delayed start time or start
the programme immediately.
Press the A (Start/Pause) button.
The door is not properly closed. Close the door.
Plug not inserted properly into socket. Insert plug correctly.
The maximum spin speed
cannot be set.
The maximum spin speed depends on
the programme selected.
Change programme as required.
The water is not Drained. Drain hose is twisted. Fit the Drain hose correctly.
Detergent pump is blocked. Clean the Drain pump –> page18.
Detergent residues in the
detergent drawer.
Damp or lumpy detergent. Clean and dry the detergent drawer –
>page17.
Use the measuring aid for liquid
detergent.
Fault code
The door is not properly closed. Close the door.
The water control system has been activated. Disconnect the appliance from
the mains, turn off the tap and advise the after-sales service.
Water is not entering the appliance. See the fault Water is not flowing in.
The water is not Drained. See the fault Water is not Drained.
Maximum or minimum drying load not taken into account. HI/End or LO/End
flash alternately in the display. See information for the Drying result not
satisfactory fault.

20
Water is not flowing in. The mains plug is not correctly
plugged in.
Plug in the mains plug correctly.
The door is not properly closed. Close the door.
The tap is not turned on. Turn on the tap.
The filter in the water supply hose is
blocked.
Clean the filter in the water supply hose
–> page18.
The water supply hose is pinched or
kinked.
Check the water inlet hose.
Intense vibrations during
spinning.
The washer-dryer is not correctly
levelled.
Level the washer-dryer –> page25.
The transport safety bolts have not
been removed.
Remove the transport safety bolts
–> page24.
Washer-dryer fills with
water and continuously
Drains it away.
Drain hose fitted too low. Fit the Drain hose correctly
–> page26.
No water can be seen in the
drum.
Not a fault. During certain programmes the water
level is below the visible range.
Water leaks from the bottom
of the appliance.
Supply hose screw connection is
leaking.
Tighten the screw connection.
Drain hose is leaking. Have the Drain hose replaced by the
after-sales service.
Foam escapes from
detergent drawer.
Too much detergent has been used. Only use detergent which is correct for
textiles, and suitable for use in
automatic washing machines.
Make sure that you use the correct
dosage.
Several attempts to start
spinning.
Not a fault.
The unbalanced load detection system
attempts to redistribute an unbalanced
load by starting to spin several times.
Always wash large and small items
together.
Washing is not spun
properly.
Large items of laundry are not evenly
distributed in the drum. The spin speed
is automatically reduced for safety
reasons.
Always wash large and small items
together.
Washing results not
satisfactory.
Uncleaned areas worse than expected. Select a suitable programme, e.g. a
programme with Pre-wash.
Pretreat stains if necessary.
Too little or incorrect detergent used. Use the correct dosage of a suitable
detergent, in accordance with the
manufacturer's instructions.
Maximum load exceeded. Select the load appropriate for the
programme.
Detergent residues on the
washing.
Some phosphate-free detergents
contain water-insoluble residues which
appear on washing as light specks.
Rinse the laundry again or change to
using liquid detergent. Brush the
laundry after it has dried.
Grey residues on the
washing.
Soiling caused by ointments, grease or
oil.
Wash the laundry using the maximum
detergent dosage and the maximum
permissible temperature – see the
care label.
