BOSS ILLUMINATION RAY II User manual

www.bia.lighting | [email protected]page 1 / 3
PRODUCT MANUAL
COPYRIGHT BIA ©2019 V10.19
Disclaimer: Please read these warranty
and installation instructions carefully
before installing the product.
BIA products are manufactured
and certied in accordance with all
mandatory Australian Standards.
All products must be installed by a
licensed electrician, in accordance
with relevant Australian Standards.
Technical data and information subject
to changes, visit our website for the
most updated version.
WARRANTY STATEMENT This product is covered by a 3 year replacement warranty.
BIA guarantees this product to be free of defects from the date of purchase for the stated period above. If product fails within the warranty period, BIA will x
or replace the product. This excludes any costs associated with the removal or installation of product. This warranty is subject to the terms and conditions stated
on www.bia.lighting. Failure to comply with installation guidelines will automatically void the warranty. Please retain purchase receipt. For more information on
warranty please visit www.bia.lighting/warranty
BIA reserves the right to change specications and other information, modify products and discontinue items without prior notication.
PRODUCT VARIANTS
Power: 10W
15W
20W
25W
30W
40W
CCT : 3000K
4000K
5000K
PRODUCT SPECIFICATIONS
Input Voltage : 100-240VAC
Ambient Temperature : -10 to 45°C
Dimming : No
Weight : 7.7kg – 18.5kg
RAY II
SOLAR STREET LIGHT
Must be installed by
a licensed electrician.
Must be installed
in accordance with
relevant Australian
Standards.
ADDITIONAL INFORMATION
1. This luminaire is not dimmable.
2. Luminaire installation angle is adjustable. Refer instructions
overleaf.
3. Installation must be carried out with care to ensure the surface of
the luminaire is not scratched or damaged. Damaged surfaces will
result in material corrosion when exposed under harsh weather
conditions.
4. Please ensure luminaire cover is sealed.
5. If cleaning maintenance is required, use a clean microfibre cloth,
slightly dampened with a mild dilution of detergent that is PH
neutral, alcohol free and non-abrasive.
PARTS INCLUDED
LED
Luminaire
IP65 IK0864mm

www.bia.lighting | [email protected]page 2 / 3
PRODUCT MANUAL
COPYRIGHT BIA ©2019 V10.19
INSTALLATION INSTRUCTIONS
A ADJUSTING THE ANGLE
1. Loosen the bolt screws and adjust the spigot bracket by sliding it
up or down.
2. Tighten the bolt screws to secure the bracket.
B INSTALLATION
1. Ensure pole of the correct diametre has been installed/supplied.
2. Place luminare over spigot and slide it all the way in.
3. Tighten the screws to rmly secure luminaire.
3
2
1
2

www.bia.lighting | [email protected]page 3 / 3
PRODUCT MANUAL
COPYRIGHT BIA ©2019 V10.19
643mm
893mm
1033mm
1189mm
1283mm
1283mm
82mm82mm82mm82mm82mm82mm 300mm300mm300mm300mm360mm430mm
Ø64mm
Ø64mm
Ø64mm
Ø64mm
Ø64mm
Ø64mm
180mm
180mm
180mm
180mm
180mm
180mm
DIAMENSION DIAGRAM
Weight
RAY II 10 7.7kg
RAY II 15 10.5kg
RAY II 20 12.8kg
RAY II 25 14.5kg
RAY II 30 17.0kg
RAY II 40 18.5kg
