Panel Descriptions
Top Panel
1 2 3 4
5 6
7 8 9 10
11 12
1 Display
Shows the parameters and the values.
2 [RATE] knob
Adjusts the speed at which the eect sound changes.
Each time you press the button, the rate indication
switches.
Frequency #Tempo (BPM)
Example indications
0.01 Hz = “0.01”, 1 Hz = “1.00”, 10 Hz = “10.0”,
tempo: 120 = “120.”, tempo: 1000 = “1.0K.”,
tempo: 10000 = “10K.”
* When the mode is ROTARY, this switches the speaker’s rotation
speed between SLW (slow) and FST (fast).
3 [DEPTH] knob
Adjusts the depth to which the eect sound is
modulated.
* When the mode is ROTARY, this adjusts the amount of preamp
distortion. When the mode is SLICER, this adjusts the balance
between the eect sound and the direct sound.

Panel Descriptions
3
4 [E. LEVEL] knob
Adjusts the volume of the eect sound.
In some modes, this adjusts the balance between eect
sound and direct sound.
5 Mode knob
Selects the eect.
Mode Explanation
CHORUS (CHO)Chorus sound using cutting-edge BOSS
technology.
CE-1 CHORUS (CE1)A chorus sound that models the CE-1.
FLANGER (FLG)Produces a anging eect.
PHASER (PHS)Produces a phase eect.
Mode Explanation
VINTAGE PHASER
(VPH)
Models the MXR PHASE90 produced
during the 1970s.
CLASSIC VIBE (CVB)Models the Uni-Vibe.
VIBRATO (VIB)Vibrato with a unique eect.
TREMOLO (TRM)An eect that cyclically changes the
volume.
ROTARY (ROT)Realistically reproduces the sound of a
rotary speaker.
AUTO WAH (AWH)Cyclically modulates a lter to
automatically create a wah eect.
SLICER (SLI)Cyclically cuts the sound to create a
variety of slice patterns.
OVERTONE (OVT)
Adds new overtones to create
resonance and depth not present in
the original sound.
6 PARAM [1]–[3] knob
Set the parameters. The parameters dier depending on the mode.
Mode PARAM 1 PARAM 2 PARAM 3
CHORUS (CHO)
SWT (SWEETNESS)
Higher values create a more
enveloping sound.
LOC (LOW CUT FREQUENCY)
Adjusts the tonal character of the
low-frequency region.
HIC (HIGH CUT FREQUENCY)
Adjusts the tonal character of the
high-frequency region.
CE-1 CHORUS (CE1)
TYP (TYPE)
CHO:Chorus sound of the CE-1
VIB:Vibrato sound of the CE-1
LO (LOW LEVEL)
Adjusts the tonal character of the
low-frequency region.
HI (HIGH LEVEL)
Adjusts the tonal character of the
high-frequency region.

Panel Descriptions
4
Mode PARAM 1 PARAM 2 PARAM 3
FLANGER (FLG)
RES (RESONANCE)
Adjusts the amount of resonance
(feedback).
MAN (MANUAL)
Adjusts the center frequency at
which the eect is applied.
LOC (LOW CUT FREQUENCY)
Cuts the frequency components
below the specied frequency.
With the FLT (at) setting, the low
cut lter is not applied.
PHASER (PHS)
RES (RESONANCE)
Adjusts the amount of resonance
(feedback).
MAN (MANUAL)
Adjusts the center frequency at
which the eect is applied.
LOC (LOW CUT FREQUENCY)
Cuts the frequency components
below the specied frequency.
With the FLT (at) setting, the low
cut lter is not applied.
VINTAGE PHASER
(VPH)
TYP (TYPE)
THR (THRU): Only phaser sound.
CRH (CRUNCH): Distortion is added.
DRV (DRIVE)
Adjusts the amount of distortion
when CRH (CRUNCH) is selected.
TON (TONE)
Adjusts the tonal character when
CRH (CRUNCH) is selected.
CLASSIC VIBE (CVB)
TYP (TYPE)
THR (THRU): Only phaser sound.
FUZ (FUZZ): Distortion is added.
DRV (DRIVE)
Adjusts the amount of distortion
when FUZ (FUZZ) is selected.
TON (TONE)
Adjusts the tonal character when
FUZ (FUZZ) is selected.
VIBRATO (VIB)
TON (TONE)
Higher values produce more
complex modulation.
D/E (DIRECT/EFFECT BALANCE)
Adjusts the volume of the direct
sound and the eect sound.
TON (TONE)
Adjusts the tonal character.

Panel Descriptions
5
Mode PARAM 1 PARAM 2 PARAM 3
TREMOLO (TRM)
TYP (TYPE)
TRM (TREMOLO): Cyclically modulates
the volume.
PAN (PAN): By alternately changing
the volume of left and right, this
produces the impression that the
sound is moving between the left
and right speakers when heard in
stereo. (If you don't use stereo output, this will
not produce the intended eect.)
WAV (WAVEFORM)
Selects the type of wave.
TON (TONE)
Adjusts the tonal character.
ROTARY (ROT)
SLW (SLOW SPEED)
Adjusts the SLW (slow) rotation
speed.
FST (FAST SPEED)
Adjusts the FST (fast) rotation
speed.
R/H (ROTOR / HORN BALANCE)
Adjusts the balance between the
horn and the rotor.
AUTO WAH (AWH)
RES (RESONANCE)
Adjusts the depth of the wah
eect in the region of the center
frequency.
FRQ (FREQUENCY)
Species the center frequency of
the wah eect.
TYP (FILTER TYPE)
LPF:Low-pass lter. Only the low-
frequency region is passed.
HPF:High-pass lter. Only the
high-frequency region is passed.
BPF:Band-pass lter. Only a
specic frequency region is passed.
SLICER (SLI)
PTN (PATTERN)
Selects the pattern at which the
sound is sliced.
ATK (ATTACK)
Adjusts the attack volume of the
slice pattern.
DTY (DUTY)
Adjusts the length of sound for the
slice pattern.
OVERTONE (OVT)
LWR (LOWER LEVEL)
Adjusts the overtone one octave
below.
UNI (UNISON LEVEL)
Adjusts the volume at which sound
that is slightly pitch-shifted is added
to the direct sound.
UPR (UPPER LEVEL)
Adjusts the overtone one octave
above.

Panel Descriptions
6
7 [TAP DIVISION] button
Species the rate as a note value relative to the BPM.
Preventing accidental operation (panel lock)
By long-pressing the [TAP DIVISION] button, you can
switch between enabling (unlocking) or disabling
(locking) operation of the knobs and buttons.
If you attempt an operation while the unit is locked, the
display indicates “LCK.”
8 TAP DIVISION indicator
Indicates the rate as a note value, relative to quarter-
notes (100%) of the interval at which you press the
pedal.
TAP DIVISION indicator
Explanation
ª ˇ ¸ ˙ TRI
(
Whole note (25%)
( (
Whole-note triplet (38%)
(
Half note (50%)
( (
Half-note triplet (75%)
(
Quarter note (100%)
( (
Quarter-note triplet (150%)
TAP DIVISION indicator
Explanation
ª ˇ ¸ ˙ TRI
(
Eighth note (200%)
( (
Eighth-note triplet (300%)
9 [MEMORY] button
Switches or saves memories (MANUAL, 1–4) (p. 10).
10 MEMORY indicator
Indicates the currently selected memory.
11 [ON/OFF] switch
Turns the eect on/o.

Panel Descriptions
7
12 [MEMORY/TAP] switch
Switches memories (p. 10).
Long-press the [MEMORY/TAP] switch to select tap
mode.
By pressing the switch in time with the tempo of the
song you're performing, you can specify a speed of
modulation that matches the song.
When the mode is ROTARY, this switches the rotation
speed of the speaker.
MEMO
The function of the footswitch can be changed by
“MFC” (MEMORY FUNCTION).

Panel Descriptions
8
Rear Panel (Connecting Your Equipment)
* To prevent malfunction and equipment failure, always turn down the
volume, and turn o all the units before making any connections.
A B C D
A INPUT (A/MONO, B) jacks
Connect your guitar, bass, or eect unit here.
Use the A/MONO and B jacks if connecting an eect
unit that has stereo output. Use only the A/MONO jack
if using this unit in mono.
Turning On/O the Power
The INPUT A/MONO jack also operates as the power
switch. The power turns on when you insert a plug into
the INPUT A/MONO jack.
When powering up
Power-up equipment such as your guitar amp last.
When powering down
Power-down equipment such as your guitar amp rst.
* Before turning the unit on/o, always be sure to turn the volume
down. Even with the volume turned down, you might hear some
sound when switching the unit on/o. However, this is normal
and does not indicate a malfunction.
B OUTPUT (A/MONO, B) jacks
Connect this jack to your amp or monitor speakers.
Use only the OUTPUT A/MONO jack if using this unit in
mono. Even sound that is input in stereo is output in
mono.
The input/output jacks can be used to utilize the insert
loop function (p. 13).
C CTL 1, 2/EXP jack
Using the jack as CTL 1, 2
You can connect a footswitch (sold separately: FS-5U,
FS-6, FS-7) and use it to tap-input the rate or switch
memories (p. 11).

Panel Descriptions
9
Using the jack as EXP
You can connect an expression pedal (sold separately:
EV-30, Roland EV-5, etc.) and use it to control the rate or
the volume of the eect sound (p. 13).
* Use only the specied expression pedal. By connecting any other
expression pedals, you risk causing malfunction and/or damage
to the unit.
D DC IN jack
An AC adaptor (sold separately: PSA-S series) can be
connected to this jack.
* Use only the specied AC adaptor (sold separately: PSA-S series)
and plug it into an AC outlet of the correct voltage.
* If the AC adaptor is connected while power is on, the power
supply is drawn from the AC adaptor.
Side Panel (Connecting Your Equipment)
E F
E MIDI jacks
Use a TRS/MIDI connecting cable (sold separately:
BMIDI-5-35) to connect an external MIDI device. You can
use an external MIDI device to switch the memories of
this unit.
* Do not connect an audio device here. Doing so will cause
malfunctions.
F USB port (for program updates only)
Connect your computer using a commercially available
USB cable that supports USB 2.0.
* Do not use a micro USB cable that is designed only for charging a
device. Charge-only cables cannot transmit data.
* This is used only for program updates.

10
Saving to Memory
Here’s how to save eect settings that you edited.
1. Long-press the [MEMORY] button.
The display indicates “Wrt.”
2. Press the [MEMORY] button to select the save-
destination (MAN, 1–4).
If you decide to cancel, press the [TAP DIVISION]
button.
3. Long-press the [MEMORY] button to conrm
the save-destination.
The memory is saved.
* If you save to MAN, the settings of the panel are applied as the
values for MODE, DEPTH, E.LEVEL, and PARAM 1–3.
Switching Memories
Here’s how to recall a saved memory.
1. Press the [MEMORY] button to select a
memory.
Each time you press the button, you cycle through
the memories in the order of “MAN (manual) 01
02 03 04 0MAN...”
What is “MAN” (manual)?
This unit normally applies the eect according to the
settings that are saved in memory, but if you select MAN
(manual) the eect is applied according to the positions
of the panel knobs. Even in this case, the rate and TAP
DIVISION recall the settings that are written to MAN (this
can be changed).
Saving and Switching Memories

11
Overall Settings (Menu)
Basic Operation
1. Press the [TAP DIVISION] button and
[MEMORY] button simultaneously.
You enter menu mode.
2. Turn the [RATE] knob to select a parameter, and
then press the [RATE] knob.
The value is displayed.
3. Turn the [RATE] knob to edit the value.
4. Press the [RATE] knob.
5. Press the [TAP DIVISION] button and
[MEMORY] button simultaneously.
You exit menu mode.
Assigning functions to external pedals
You can connect footswitches (sold separately: FS-5U, FS-6, FS-7)
to the CTL 1, 2/EXP jack, and use them to tap-input the rate or to
switch memories.
Use the menu items“C1F” or “C2F” to make these settings (p.
12).
FS-5U FS-6, FS-7
CTL 2 CTL 1 CTL 2 CTL 1
CTL 2
CTL 1
CTL 1
FS-5U×2
FS-5U FS-6, FS-7

Overall Settings (Menu)
12
Menu Parameter List
About the
MEMORYMEMORY
mark
5 Can be set and saved for each memory by the“Saving to Memory”(p.
10) operation. If you do not perform this operation, the settings are lost
when you switch memories.
5 Can be set and saved for each memory if the preference (SWP/MEP/C1P/
C2P/EPP) is set to MEM (MEMORY). To save, refer to“Saving to Memory”
(p. 10).
If set to SYS (SYSTEM), the settings common to the unit are used. Function
settings are saved automatically.
Parameter Explanation
tHd
(TEMPO HOLD)
oFF:Operates using the tempo/rate of
the memory.
on:Operates using the tempo/rate of the
previous memory.
Parameter Explanation
SWF
(ON/OFF SWITCH
FUNCTION)
Specify the functions of the [ON/OFF]
switch, [MEMORY/TAP] switch, and
footswitches connected to the CTL 1, 2/
EXP jack.
* The functions that can be assigned dier
depending on the switch.
oFF:No operation.
SW (ON/OFF SWITCH) : Turns the eect on/o.
MoM (MOMENT) : The eect is on only while
you hold down the switch.
MAn (MANUAL) : Selects manual.
M-1 (MEMORY 1) : Selects memory 1.
M-2 (MEMORY 2) : Selects memory 2
M-3 (MEMORY 3) : Selects memory 3.
M-4 (MEMORY 4) : Selects memory 4.
MUP (MEMORY UP) : Increments the memory
number according to the MEMORY
EXTENT setting.
Mdn (MEMORY DOWN) : Decrements the
memory number according to the
MEMORY EXTENT setting.
tAP (TAP TEMPO) : Operates as tap tempo.
MFC
(MEMORY SWITCH
FUNCTION)
C1F
(CTL1 FUNCTION)
C2F
(CTL2 FUNCTION)
MEMORYMEMORY
MEMORYMEMORY
MEMORYMEMORY
MEMORYMEMORY
MEMORYMEMORY

Overall Settings (Menu)
13
Parameter Explanation
EPF
(EXPRESSION FUNCTION)
Species the function of an expression
pedal connected to the CTL 1, 2/EXP jack.
oFF:No operation.
RAT (RATE) : The same operation as the
[RATE] knob.
DPT (DEPTH) : The same operation as the
[DEPTH] knob.
Elv (E.LEVEL) : The same operation as the
[E.LEVEL] knob.
PR1 (PARAM1) : The same operation as the
[PARAM 1] knob.
PR2 (PARAM2) : The same operation as the
[PARAM 2] knob.
PR3 (PARAM3) : The same operation as the
[PARAM 3] knob.
EPN
(EXPRESSION MIN) Species the variable range of the
parameter controlled by EXPRESSION
FUNCTION. The variable range diers
depending on the parameter.
EPM
(EXPRESSION MAX)
Parameter Explanation
ILP
(INSERT LOOP POSITION)
Selects the position at which the external
eect unit is connected.
OFF:The insert loop function is not used.
PRE (PRE) : Connect before the MD-200’s
eect.
Guitar
&
External Eector
&
MD-200
&
AMP
PST (POST) : Connect after the MD-200’s
eect.
Guitar
&
MD-200
&
External Eector
&
AMP
Insert Loop Function
Guitar
AMP
External
Eector
You can connect an external eect unit
between the OUTPUT A/MONO jack and
the INPUT B jack, and use it in conjunction
with the MD-200’s eect.
For some eect types, you can specify
“before or after distortion.”
MEMORYMEMORY
MEMORYMEMORY
MEMORYMEMORY
MEMORYMEMORY

Overall Settings (Menu)
14
Parameter Explanation
INS
(INSERT LOOP SWITCH)
Turns the insert loop function on/o.
OFF, ON
SWP
(ON/OFF SWITCH FUNCTION
PREFERENCE)
MEM (MEM) : The setting in memory is used.
SYS (SYS) : The controller’s function is xed
regardless of memory.
MEP
(MEMORY SWITCH
FUNCTION PREFERENCE)
C1P
(CTL1 FUNCTION
PREFERENCE)
C2P
(CTL2 FUNCTION
PREFERENCE)
EPP
(EXPRESSION FUNCTION
PREFERENCE)
ETF (EXTENT FROM) Specify the memory switching range
(MEMORY EXTENT FROM–TO).
Man (MANUAL), 1–4
ETT (EXTENT TO)
G/B
(GUITAR/BASS MODE)
Species the response of the FLANGER,
PHASER, and AUTO WAH.
GTR (Guitar): Settings suitable for guitar.
BAS (Bass): Settings suitable for bass.
Parameter Explanation
CMD
(CHORUS CONTROL MODE)
Species the function of E.LEVEL when
CHORUS or CE-1 CHORUS are selected as
the mode.
If this is set to ELV (EFFECT LEVEL), the
E.LEVEL knob adjusts the balance between
the direct sound and the eect sound.
If this is set to TTL (TOTAL LEVEL), the
E.LEVEL knob adjusts the combined
volume of the direct sound and the eect
sound. In this case, the direct sound and
eect sound are mixed at a ratio of 1:1.
RCH
(MIDI RECEIVE CHANNEL)
Species the MIDI receive channel.
If this is “oFF,”MIDI messages are not
received.
1–16, oFF
TCH
(MIDI TRANSMIT CHANNEL)
Species the MIDI transmit channel.
If this is “oFF,”MIDI messages are not
transmitted.
If this is RECEIVE, the same setting as the
receive channel is used.
1–16, RCv (RECEIVE), oFF
Pin (PC IN) Species whether program changes are
received (on)or not received (oFF).

Overall Settings (Menu)
15
Parameter Explanation
Pot (PC OUT)
Species whether program changes
are transmitted (on)or not transmitted
(oFF).
Correspondence between memories
and program numbers
Memory Program number
MAN 1
MEMORY 1–4 2–5
CCI (CC IN)
Species whether control changes are
received (on)or not received (oFF).
By receiving CC messages, this unit
lets you use MIDI to control the same
operations as a knob or footswitch.
CCO (CC OUT)
Species whether control changes are
transmitted (on)or not transmitted
(oFF).
Parameter Explanation
RTC (RATE CC)
Specify the controller number
corresponding to each controller.
oFF, 1–31, 64–95
DPC (DEPTH CC)
ELC (E.LEVEL CC)
P1C (PARAM1 CC)
P2C (PARAM2 CC)
P3C (PARAM3 CC)
SWC
(ON/OFF SWITCH CC)
MEC (MEMORY CC)
C1C (CTL1 CC)
C2C (CTL2 CC)
EPC (EXPRESSION CC)
EFC
(EFFECT ON/OFF CC)
SYN (SYNC)
Species the tempo clock to which this
unit will synchronize.
int (INTERNAL): Synchronize to the internal
tempo.
Aut (AUTO): Normally synchronize to
the internal tempo, but if MIDI clock is
being input via the MIDI IN connector,
synchronize the tempo to MIDI clock. If
you’re using the MD-200 as a slave device,
choose the “Aut” setting.

Overall Settings (Menu)
16
Parameter Explanation
RTS
(REALTIME SOURCE)
Species the source of realtime messages
that are output to the MIDI OUT jack.
int (INTERNAL) : Internal realtime messages
are the source.
Mid (MIDI) : Realtime messages from the
MIDI IN jack are the source.
MTH (MIDI THRU)
Species whether MIDI messages received
at the MIDI IN connector are retransmitted
without change from the MIDI OUT
connector (on)or are not retransmitted
(oFF).
P1–Pg
(P1–P9)
P10–Pgg
(P10–P99)
P.00–P.28
(P100–P128)
Specify the memory corresponding to the
received program number. Bank select is
ignored (received regardless).
If this is OFF, the eect turns o.
OFF, M-1, M-2, M-3, M-4

17
Returning to the Factory Settings (Factory Reset)
Here's how to return the MD-200 to its factory-set state.
1. While holding down the [ON/OFF] switch and
[MEMORY/TAP] switch, turn on the power
(insert a plug into the INPUT A/MONO jack).
The display indicates“FCt.”
2. Press the [MEMORY/TAP] switch.
The display indicates“Sur.”
If you decide to cancel, press the [MEMORY] button.
3. Press the [MEMORY/TAP] switch.
The factory reset is executed.
4. When the display indicates“FIn,” turn the
power o and on again.
Installing Batteries
Insert the batteries as shown below, being careful to
orient the batteries correctly.
* Batteries should always be installed or
replaced before connecting any other
devices. This way, you can prevent
malfunction and damage.
* If operating this unit on batteries, please
use alkaline batteries.
* Even if batteries are installed, the unit
will turn o if you connect or disconnect
the power cord from the AC outlet while
the unit is turned on, or if you connect or
disconnect the AC adaptor from the unit.
When this occurs, unsaved data may be
lost. You must turn o the power before
you connect or disconnect the power
cord or AC adaptor.
* When turning the unit over, be careful
so as to protect the buttons and knobs from damage. Also, handle the
unit carefully; do not drop it.
* If you handle batteries improperly, you risk explosion and uid
leakage. Make sure that you carefully observe all of the items related to
batteries that are listed in“USING THE UNIT SAFELY”and “IMPORTANT
NOTES”(leaet “USING THE UNIT SAFELY” ).
* “Lo” will appear on the display if the batteries are low. Replace them
with new ones.
Appendix

Appendix
18
Attaching the Rubber Feet
You can attach the rubber feet (included) if necessary.
Attach them in the locations shown in the illustration.
* Using the unit without rubber feet may damage the oor.
Main Specications
BOSS MD-200: Modulation
Power Supply Alkaline battery (AA, LR6) x 3,
AC adaptor (sold separately)
Current Draw 225 mA
Expected Battery
Life Under
Continuous Use
Alkaline: Approx. 4 Hours
* These gures will vary depending on the actual
conditions of use.
Dimensions
101 (W) x 138 (D) x 63 (H) mm / 4 (W) x 5-7/16 (D) x 2-1/2
(H) inches
101 (W) x 138 (D) x 65 (H) mm / 4 (W) x 5-7/16 (D) x 2-9/16
(H) inches (including rubber foot)
Weight 680 g / 1 lb 8 oz (including batteries)
Accessories
Owner’s Manual
Leaet“USING THE UNIT SAFELY”
Alkaline battery (AA, LR6) x 3
Rubber foot x 4
Options
AC adaptor: PSA-S series
Footswitch: FS-5U
Dual footswitch: FS-6, FS-7
Expression pedal: FV-500H, FV-500L, EV-30, Roland EV-5
MIDI/TRS connecting cable: BMIDI-5-35
* This document explains the specications of the product at the time
that the document was issued. For the latest information, refer to the
Roland website.

19
CAUTION
Keep small items out of the reach of children
To prevent accidental ingestion of the parts
listed below, always keep them out of the reach
of small children.
• Included Parts
Rubber feet (p. 18)
Repairs and Data
• Before sending the unit away for repairs, be sure to
make a backup of the data stored within it; or you
may prefer to write down the needed information.
Although we will do our utmost to preserve the data
stored in your unit when we carry out repairs, in some
cases, such as when the memory section is physically
damaged, restoration of the stored content may be
impossible. Roland assumes no liability concerning the
restoration of any stored content that has been lost.
Additional Precautions
• Any data stored within the unit can be lost as the
result of equipment failure, incorrect operation, etc. To
protect yourself against the irretrievable loss of data,
try to make a habit of creating regular backups of the
data you’ve stored in the unit.
• Roland assumes no liability concerning the restoration
of any stored content that has been lost.
• Do not use connection cables that contain a built-in
resistor.
USING THE UNIT SAFELY/IMPORTANT NOTES

USING THE UNIT SAFELY/IMPORTANT NOTES
20
Intellectual Property Right
• This product includes third party open source software.
Copyright (c) 2009-2017 ARM Limited. All rights reserved.
Licensed under the Apache License, Version 2.0 (the
“License”); You may obtain a copy of the License at
http://www.apache.org/licenses/LICENSE-2.0
• Roland, BOSS are either registered trademarks or
trademarks of Roland Corporation in the United States
and/or other countries.
• Company names and product names appearing in this
document are registered trademarks or trademarks of
their respective owners.
• In this manual, company names and product names
of the respective owners are used because it is the
most practical way of describing the sounds that are
emulated using DSP technology.
