Boston Acoustics GTuned G210PS User manual

GTuned™
High Performance Subwoofer Enclosures
Introducing the newest addition to the Boston Acoustics family, GTuned™high
performance subwoofer enclosures. Every enclosure has been designed to
optimize our subwoofers and deliver no compromise performance—regardless
of listening tastes or budget.
SureSet™Protection:
All G5 and G2 subwoofers feature
SureSet™overdrive protection for the
highest level of reliability.
Optimized Design:
Enclosures designed and tuned by the
engineers that developed the
subwoofers. Each design has been real
world tested in numerous vehicles and
applications.
Integrated Port:
The port used in the PS Series
enclosures maximizes surface area
while adding structural rigidity.
(PS enclosures only)
Stout Cabinet Construction:
Use of true 3⁄4-Inch MDF, all CNC cut
with glued dadoed ends.
Heavy Duty Input Terminals:
The terminal cup is inset into the
enclosure delivering a tight seal and
finished look. Use of nickel plated push
terminals ease wire installation.

Model Enclosure Power Impedance Q-Tune™ Tuning Height Width Top Bottom Weight
Name Type Handling Setting Frequency Depth Depth
G512RS Passive Radiator 450 W RMS 2Ω34Hz @ 1.0 35Hz 13” 14” 12” 15 1⁄2”46 Lbs.
G510RS Passive Radiator 450 W RMS 2Ω34Hz @ 1.0 35Hz 11 1⁄4” 12 1⁄4” 9” 12 1⁄4” 40 Lbs.
G212SD Sealed 600 W RMS 2Ω28Hz @ 0.707 N/A 13” 27 1⁄4”12” 15 1⁄2”59 Lbs.
G210SD Sealed 600 W RMS 2Ω33Hz @ 0.707 N/A 11 1⁄4” 24” 9” 12 1⁄4” 49 Lbs.
G212PS Ported 300 W RMS 2Ω34Hz @ 0.9 32Hz 13” 27 1⁄4” 12” 15 1⁄2” 49 Lbs.
G210PS Ported 300 W RMS 2Ω36Hz @ 0.9 34Hz 13” 20 1⁄4” 12” 15 1⁄2” 42 Lbs.
G212SS Sealed 300 W RMS 2Ω28Hz @ 0.707 N/A 13” 14” 12” 15 1⁄2” 32 Lbs.
G210SS Sealed 300 W RMS 2Ω34Hz @ 1.0 N/A 11 1⁄4”12 1⁄4”9” 12 1⁄4”40 Lbs.
GTuned™Enclosure Specifications:
Boston Acoustics, Inc. 300 Jubilee Drive, Peabody, MA 01960 USA
T: 978.538.5000 F: 978.538.5100 W: bostonacoustics.com
GTuned, SureSet, Q-Tune are trademarks and Boston, Boston Acoustics, and the Boston Acoustics logo are registered trademarks of Boston Acoustics,
Inc. Specifications are subject to change without notice. © 2006 Boston Acoustics, Inc. All rights reserved. Covered by patents issued and/or pending.
G512RS G510RS G212SS G210SS
G210SD
G212SDG212PS G210PS
RS Enclosures SS Enclosures
PS Enclosures SD Enclosures
PS, SD, and SS Subwoofers
G512 GTR12
RS Subwoofers and TunableRadiators™
G210G212G510 GTR10
