MUX-24
User Instructions
Product Description
Delivery Package
Check for transport damage.You should be in possession of the following items:
1 MUX-24
1 Manual
1 Adaptor
Should you discover transport damage after unpacking the equipment, inform the hauler immediately.
Never connect a damaged device. You may also contract your supplier.
MUX-24
DMX Address Setting
DMX is short for Digital Multiplex. This is a universal binary language used as a
form of communication between intelligent fixtures. Each Dip Switch represents a
binary value.
In this mode, DMX address can be set. The dip-switch 10 is ineffective.
12345678910
A DMX value(address) is set by combining the different dipswitches that will add up to the value you wish to achieve,
for example:
Setting DMX address for 201.
Flip switches1,4,7,& 8 to the
"ON" position
Dipswitches# Value
1=1
4=8
7=64
8=128
=201
Setting DMX address for 21.
Flip switches1,3,&5 to the
"ON" position
Dipswitches# Value
1=1
3=4
5=16
=21
Dip Switch 1 address equals 1
Dip Switch 2 address equals 2
Dip Switch 3 address equals 4
Dip Switch 4 address equals 8
Dip Switch 5 address equals 16
Dip Switch 6 address equals 32
Dip Switch 7 address equals 64
Dip Switch 8 address equals 128
Dip Switch 9 address equals 256
1,2,4
3,4
1,3,4
2,3,4
1,2,3,4
1
2
1,2
3
1,3
2,3
1,2,3
4
1,4
2,4
SWITCHES ON SWITCHES ON
START
CH#
START
CH#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
..
..
..
..
..
..
1234 56 78910
511 1,2,3,4,5,6,7,8,9
..
..
-Page1-
Congratulation with your purchase of MUX-24. MUX-24, an analog signal to DMX signal converter, converts
each analog control signal to one DMX control signal. Up to 24 channel analog signal can be accepted by
one MUX-24 and the input analog control voltage is usually 0-10 VDC. The dip switches on the panel are
used to set the DMX address.
ON RS
123456789
10
DMX Start Address
On
1
2
4
8
16
32
64
128
256
Addr
Analog
1
Analog
13
Analog
12
Analog
24
DMX Output
MUX-24 Analog 24 - DMX 512 Convertor
Analog 0-10VDC Input
GND
Data-
Data+
Power
DC input:
12-24V,
300mA Min
1
2
3
4
5
1
1. Analog signal input: 2-pin green terminal.
2. DC input 12-24V, 300mA Min.
3. Power indicator.
4. Dip switches.
5. DMX output: 3-pin green terminal.
Front Panel Layout
P/N: 24-004-0658-00
Rev: 1.1
ON RS
123456789
10
DMX Start Address
On
1
2
4
8
16
32
64
128
256
Addr
Analog
1
Analog
13
Analog
12
Analog
24
DMX Output
MUX-24 Analog24 - DMX 512 Convertor
Analog0-10VDC Input
GND
Data-
Data+
Power
DC input:
12-24V,
300mAMin
Analog 1-24 Analog 25-48
DMX 512 OUT
MUX-24 MUX-24
DM-2512 PRO
48 Ch. Linkup Wiring Diagram
ON RS
123456789
10
DMX Start Address
On
1
2
4
8
16
32
64
128
256
Addr
Analog
1
Analog
13
Analog
12
Analog
24
DMX Output
MUX-24 Analog24 - DMX 512 Convertor
Analog0-10VDC Input
GND
Data-
Data+
Power
DC input:
12-24V,
300mAMin
Technical Specifications
Voltage range
Frequency range
Plug
AC230V
50Hz
BS/VDE
Analog signal 0-10VDC
Connector 2pin Green Terminal
DMX signal Standard DMX 512
Connector
Environment
Working TEMP.
Working humidity 20 ~ 90% RH
Storage TEMP.,humidity
Dimension
Others 195x105x19mm
Net weight 0.25kg
O
C
0~+45
DC output DC12V
Current 500mA
Analog channel 24Ch.
3pin Green Terminal
Analog max channel 48 Channel
-20~+85 ,10~95% RH
O
C
Analog
out
DMX
in
Adapter
AC/DC
Link up
-Page2-
Physical Dimensions
*Please Note: Improvements and specifications in the design of the unit and the manual are subject to change
without any prior written notice.
