DM2 Mk2
Stand-mount loudspeaker system
Product Summary
●The DM2 MK2 is a three-driver loudspeaker system of 47 litres capacity. It is a free-standing
design, for use with B&W purpose-made accessories but will also incorporate well into existing
furniture.
●The DM2 MK2 offers a wide horizontal dispersion and excellent vertical dispersion within a
listening window of approximately 10° in the vertical plane and 40° in the horizontal.
●To take maximum advantage of this of this important design feature, the loudspeaker must be
mounted vertically and located at the correct listening height or angled slightly to project the
window in an upward direction.
●The pedestal stand or angled plinth caters for these two alternatives.
Technical highlights
●The bass driver is housed in a critically vented enclosure and has a crossover point of 400 Hz
where the vent tuning is so designed to extend the low frequency half point to 45Hz.
●The mid band frequencies are handled by a 100mm unit housed in a separate enclosure –
critically damped with long-haired natural wool.
●Frequencies above 3kHz are handled by a 25mm multi-filament weave polyester dome unit,
critically damped with PVA compounds.
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
www.bwspeakers.com
Drive Units
Frequency Response
High-frequency driver: a 25mm multi-
filament weave polyester dome unit,
critically damped with PVA compounds
Mid-range driver: a 100mm unit housed
in a critically vented enclosure
Bass Driver: housed in a critcally vented
enclosure
50Hz – 18kHz ± 3dB, at centre of
listening window
Sensitivity
Power Handling
Dimensions
9 volts into 8 ohms = 85dB at 1m
25W – 200W
Height: 710mm Width: 270mm
Depth: 330mm
