B+B SmartWorx SPECTRE v3 LTE User manual

Cellular router
SPECTRE v3 LTE
USER’S MANUAL

HEADQUARTERS
International Headquarters
B&B Electronics Mfg. Co. Inc.
707 Dayton Road
Ottawa, IL 61350 USA
Phone [phone] – General Fax [phone]
Websites
www.bb-smartworx.com
www.bb-smartsensing.com
suppor[email protected]
European Headquarters
B&B Electronics
Westlink Commercial Park
Oranmore, Co. Galway, Ireland
Phone [phone] – Fax [phone]
Websites
www.bb-europe.com
[email protected]
c
2015 B&B Electronics Mfg. Co. Inc. No part of this publication may be reproduced or transmitted in any
form or by any means, electronic or mechanical, including photography, recording, or any information storage and
retrieval system without written consent. Information in this manual is subject to change without notice, and does
not represent a commitment on the part of B&B Electronics Mfg. Co. Inc.
B&B Electronics Mfg. Co. Inc. shall not be liable for incidental or consequential damages resulting from the
furnishing, performance, or use of this manual.
All brand names used in this manual are the registered trademarks of their respective owners. The use of
trademarks or other designations in this publication is for reference purposes only and does not constitute an
endorsement by the trademark holder.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following 2 conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
i

USED SYMBOLS
Used Symbols
Danger – important notice, which may have an influence on the user’s safety or the function
of the device.
Attention – notice on possible problems, which can arise in specific cases.
Information, notice – information, which contains useful advice or special interest.
GPL License
Source codes under GPL license are available free of charge by sending an email to:
[email protected].
Conel s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Manual Rev. 1 issued in CZ, June 8, 2015
ii

CONTENTS
Contents
1 Safety Instruction 1
2 Product Disposal Instructions 3
3 Router Description 4
3.1 UsageoftheRouter ................................. 5
4 Contents of Package 7
5 Router Design 8
5.1 Routerversions.................................... 8
5.2 Deliveryidentification ................................ 10
5.3 Orderingcodes.................................... 10
5.4 Basic dimensions of router box . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.5 Mechanical dimensions and mounting recommendations . . . . . . . . . . . . . 12
5.6 Removing from the DIN rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.7 Description of the rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.8 Description of the front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.8.1 Statusindication ............................... 15
5.8.2 PowerconnectorPWR............................ 16
5.8.3 Antenna connector ANT, DIV, GPS and WiFi . . . . . . . . . . . . . . . 17
5.8.4 SIMcardreader ............................... 18
5.8.5 MicroSDcardreader............................. 18
5.8.6 Ethernet Port (ETH0 and ETH1) . . . . . . . . . . . . . . . . . . . . . . 19
5.8.7 USBPort ................................... 20
5.8.8 I/OPort .................................... 21
5.8.9 Reset ..................................... 23
5.9 Interfacesdescription ................................ 24
5.9.1 RS232interface ............................... 24
5.9.2 RS232-RS485/422 interface . . . . . . . . . . . . . . . . . . . . . . . . 26
5.9.3 SWITCHinterface .............................. 28
6 First Use 29
6.1 Connecting the router before first use . . . . . . . . . . . . . . . . . . . . . . . 29
6.2 Start.......................................... 30
6.3 Configuration ..................................... 30
6.3.1 Configuration over web browser . . . . . . . . . . . . . . . . . . . . . . . 30
7 Technical Parameters 32
iii

CONTENTS
7.1 Basicparameters................................... 32
7.2 Type tests and environmental conditions . . . . . . . . . . . . . . . . . . . . . . 33
7.3 Technical parameters of module . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.3.1 LTEmoduleforEMEA............................ 34
7.3.2 LTE module for NAM, AT&T operator . . . . . . . . . . . . . . . . . . . . 34
7.3.3 LTE module for Australia . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.3.4 LTE module supports 450 MHz . . . . . . . . . . . . . . . . . . . . . . . 36
7.4 Technical parameters of GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.5 Technical parameters of WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.6 Technical parameters of I/O port . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.7 Other technical parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8 Recommended Literature 39
9 Troubleshooting 40
9.1 FAQ .......................................... 40
10 Customers Support 42
10.1GlobalCustomerSupport .............................. 42
10.2 Customer Support for NAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
iv

LIST OF FIGURES
List of Figures
1 Access to the Internet from LAN . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Backed up access to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 UsingVPNtunnel .................................. 6
4 SerialGateway .................................... 6
5 Contentsofpackage................................. 7
6 Basicversion(plastic) ................................ 8
7 Basic version with WiFi (plastic) . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8 Basicversion(metal)................................. 8
9 Basic version with WiFi (metal) . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
10 VersionSWITCH(plastic) .............................. 9
11 Version SWITCH and WiFi (plastic) . . . . . . . . . . . . . . . . . . . . . . . . . 9
12 VersionRS232(plastic) ............................... 9
13 Version RS232-RS485 (plastic) . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
14 Ver. RS232-RS485 & WiFi (plastic) . . . . . . . . . . . . . . . . . . . . . . . . . 9
15 VersionSWITCH(metal)............................... 9
16 Version SWITCH and WiFi (metal) . . . . . . . . . . . . . . . . . . . . . . . . . 9
17 VersionRS232(metal)................................ 9
18 Version RS232-RS485 (metal) . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
19 Version RS232-RS485 & WiFi (metal) . . . . . . . . . . . . . . . . . . . . . . . 9
20 Labelexample .................................... 10
21 Basic dimensions of router box . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
22 Default position of DIN holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
23 RemovingfromtheDINrail ............................. 13
24 SPECTRE v3 LTE front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
25 Powerconnector ................................... 16
26 Connection of power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
27 Connectingoftheantenna.............................. 17
28 SIMcards....................................... 18
29 SDcard ........................................ 19
30 Ethernetconnector.................................. 19
31 Connection of ethernet cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
32 USBconnector .................................... 20
33 I/Oconnector..................................... 21
34 Binaryinputsconnection............................... 22
35 Binaryoutputconnection .............................. 22
36 Routerreset...................................... 23
37 Version with RS232 interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
38 RS232connector................................... 25
39 Meterconnectiontorouter.............................. 25
40 Version with RS232-RS485/422 interface . . . . . . . . . . . . . . . . . . . . . 26
41 RS232connector................................... 26
v

LIST OF FIGURES
42 RS485/422connector ................................ 27
43 Connectionofjumpers................................ 27
44 VersionwithSWITCHboard............................. 28
45 Routerconnection .................................. 29
46 Entering the IP address of the router . . . . . . . . . . . . . . . . . . . . . . . . 30
47 Entering login information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
48 Routerwebinterface................................. 31
vi

LIST OF TABLES
List of Tables
1 Routerversions.................................... 8
2 Deliveryidentification ................................ 10
3 Orderingcodesoverview .............................. 10
4 TypeoftheLTEmodule ............................... 11
5 Typeofrouterbox .................................. 11
6 Typeofpowersupply................................. 11
7 Examplesofordercode ............................... 11
8 Frontpaneldescription................................ 14
9 Statusindication ................................... 15
10 Connection of power connector . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
11 Technical specifications of microSD card . . . . . . . . . . . . . . . . . . . . . . 18
12 Connection of Ethernet connector . . . . . . . . . . . . . . . . . . . . . . . . . . 19
13 Connection of USB connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
14 ConnectionofI/Oport ................................ 21
15 Characteristicsofinputs............................... 21
16 Description of reset and restart router . . . . . . . . . . . . . . . . . . . . . . . 23
17 Connection of RS232 connector . . . . . . . . . . . . . . . . . . . . . . . . . . 24
18 State indication of RS232 port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
19 Connection of RS232 connector . . . . . . . . . . . . . . . . . . . . . . . . . . 26
20 Connection of RS485 connector . . . . . . . . . . . . . . . . . . . . . . . . . . 26
21 Connection of RS422 connector . . . . . . . . . . . . . . . . . . . . . . . . . . 27
22 State indication of the port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
23 Basicparameters................................... 32
24 Type tests and environmental conditions . . . . . . . . . . . . . . . . . . . . . . 33
25 Technical parameters of module for EMEA . . . . . . . . . . . . . . . . . . . . . 34
26 Technical parameters of module for NAM AT&T . . . . . . . . . . . . . . . . . . 35
27 Technical parameters of module for Australia . . . . . . . . . . . . . . . . . . . 35
28 Technical parameters of LTE module 450 MHz . . . . . . . . . . . . . . . . . . 36
29 Technical parameters of GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
30 Technical parameters of WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
31 Characteristicsofinputs............................... 38
32 Other technical parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
vii

1. SAFETY INSTRUCTION
1. Safety Instruction
Please, observe the following instructions:
•THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I, DIVISION 2, GROUPS A, B,
C, AND D HAZARDOUS LOCATIONS, OR NON-HAZARDOUS LOCATIONS ONLY.
•WARNING – EXPLOSION HAZARD – DO NOT DISCONNECT EQUIPMENT UNLESS
POWER HAS BEEN REMOVED OR THE AREA IS KNOWN TO BE NON-HAZARDOUS.
•WARNING – EXPLOSION HAZARD – SUBSTITUTION OF ANY COMPONENTS MAY
IMPAIR SUITABILITY FOR CLASS I, DIVISION 2.
•CET ÉQUIPEMENT EST CONVENABLE EN CLASSE 1, DIVISION 2, GROUPES A, B,
C, ET D ENDROITS DANGEREUX OU ENDROITS NON DANGEREUX SEULEMENT.
•AVIS – RISQUE D’EXPLOSION – NE DÉCONNECTEZ PAS L’ÉQUIPEMENT, SAUF
SI L’ALIMENTATION A ÉTÉ COUPÉE OU SI L’ENVIRONMEMENT EST CLASSÉ NON
DANGEREUX.
•AVIS – RISQUE D’EXPLOSION - SUBSTITUTION DE TOUTE COMPOSANTE RIS-
QUERAIT LA QUALITÉ POUR CLASSE 1, DIVISION 2.
•The router must be used in compliance with all applicable international and national laws
and in compliance with any special restrictions regulating the utilization of the router in
prescribed applications and environments.
•To prevent possible injury and damage to appliances and to ensure compliance with
all relevant provisions, use only the original accessories. Unauthorized modifications or
the use of unapproved accessories may result in damage to the router and a breach of
applicable regulations. Unauthorized modifications or use of unapproved accessories
may void the warranty.
•The router can not be opened.
•Turn off the router and disconnect it from power supply before handling of the SIM card.
•Caution! The SIM card could be swallowed by small children.
•Input voltage must not exceed 60 V DC max.
•Do not expose the router to extreme ambient conditions. Protect the router against dust,
moisture and high temperature.
•The router should not be used in locations where flammable and explosive materials
are present, including gas stations, chemical plants, or locations in which explosives
are used. We remind the users of the duty to observe the restrictions concerning the
utilization of radio devices at such places.
1

1. SAFETY INSTRUCTION
•Switch off the router when travelling by plane. Utilization of the router in a plane may
endanger the operation of the plane or interfere with the mobile telephone network, and
may be unlawful. Failure to observe these instructions may result in the suspension
or cancellation of telephone services for the respective client, or, it may result in legal
sanctions; it may also result in both eventualities.
•When using the router in the close proximity of personal medical devices, such as cardiac
pacemakers or hearing aids, you must proceed with heightened caution.
•The router may cause interference when in the close proximity of TV sets, radio receivers
or personal computers.
•It is recommended that you should create an appropriate copy or backup of all the im-
portant settings that are stored in the memory of the device.
2

2. PRODUCT DISPOSAL INSTRUCTIONS
2. Product Disposal Instructions
The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive has been
introduced to ensure that electrical/electronic products are recycled using the best available
recovery techniques to minimize the impact on the environment. This product contains high
quality materials and components which can be recycled. At the end of it’s life this product
MUST NOT be mixed with other commercial waste for disposal. Check the terms and condi-
tions of your supplier for disposal information.
3

3. ROUTER DESCRIPTION
3. Router Description
Cellular router SPECTRE v3 LTE is designed for wireless communication in mobile net-
works that make use of LTE, HSPA+, UMTS, EDGE or GPRS technology. Due to the high
speed of data transfer up to 100 Mbit/s (download) and up to 50 Mbit/s (upload) is this router
an ideal solution for wireless connection of traffic and security camera systems, individual
computers, LAN networks, automatic teller machines (ATM) and other self-service terminals.
As a standard, cellular router is equipped with two Ethernet 10/100, one USB 2.0 Host
port, two binary inputs and one output (I/O connector). The device also has two readers for
3 V and 1.8 V SIM cards, which are placed on the rear panel of the router. An integral part
of the router is also a memory card reader. This reader allows SPECTRE v3 LTE to operate
with microSD cards and increase storage space of the router up to 64 GB (32 GB in case of
SDHC cards). The router can be equipped with WiFi module on customer’s request, however
it is not possible to add it to the router at some time in the future. Richer range of interfaces
is available in versions containing one of these ports: SWITCH – three switched Ethernets;
RS232 – serial interface; RS232-RS485/422 – combination of serial interface RS232 and
RS485/422. SPECTRE v3 LTE is supplied either in a plastic or metal casing, based on the
requirements of the customer.
For configuration of the cellular router is available web interface protected by password.
Web interface provides (after logging in) detailed statistics about the router activities, signal
strength, detailed system log etc. This device supports the creation of VPN tunnels using tech-
nologies IPSec, OpenVPN and L2TP for secure communications. There are also supported
functions such as DHCP, NAT, NAT-T, DynDNS, NTP, VRRP, control by SMS, backup primary
connection and many other functions.
Other diagnostic functions ensuring continuous communication include automatic inspec-
tion of PPP connection offering an automatic restart feature – in case of connection losses, or
hardware watchdog which monitors the status of the router. Using a special window (start up
script window) you may insert Linux scripts for various actions. For some applications is crucial
the possibility to create several different configurations for one router. These configurations can
be switched as necessary (for example using SMS, binary input status, etc.). Cellular wireless
routers SPECTRE v3 LTE may automatically upgrade configuration and firmware from server.
This allows mass reconfiguration of many routers in one time.
For further facilitating of workikg with routers can be used any additional software, e.g.
R-SeeNet for permanent traffic monitoring of routers.
Examples of possible applications
•mobile office
•fleet management
•security system
•telematic
•telemetric
•remote monitoring
•vending and dispatcher machines
4

3. ROUTER DESCRIPTION
3.1 Usage of the Router
The router is primarily intended for these four basic situations:
I. Access to the Internet from LAN
Figure 1: Access to the Internet from LAN
II. Backed up access to the Internet (from LAN)
Figure 2: Backed up access to the Internet
5

3. ROUTER DESCRIPTION
III. Secure networks interconnection or using VPN
Figure 3: Using VPN tunnel
IV. Serial Gateway
Figure 4: Serial Gateway
6

4. CONTENTS OF PACKAGE
4. Contents of Package
Basic delivered set of router includes:
•router,
•power supply,
•crossover UTP cable,
•up to three external antennas,
•loose power and I/O connector (+8 pins1),
•4-pins and 5-pins terminal block for RS485 and RS232
(only for version with interface RS232-RS485/422),
•clip for the DIN rail,
•paper start guide.
Figure 5: Contents of package
1These pins are designed for cables with a diameter from 0.2 to 0.8 mm2
7

5. ROUTER DESIGN
5. Router Design
5.1 Router versions
SPECTRE v3 LTE router is supplied in the following versions (see table below). All versions
are available in plastic or metal box according to customer requirements.
Router versions
SIM
BIN
BOUT
USB
SD
ETH
WiFi
232 485
Basic version 2 x 2 x 1 x 1 x 1 x 2 x
Basic version with WiFi 2 x 2 x 1 x 1 x 1 x 2 x 1 x
Version with SWITCH board 2 x 2 x 1 x 1 x 1 x 5 x
Version with SWITCH board & WiFi 2 x 2 x 1 x 1 x 1 x 5 x 1 x
Version with RS232 board 2 x 2 x 1 x 1 x 1 x 2 x 1 x
Version with RS232-RS485/422 board 2 x 2 x 1 x 1 x 1 x 2 x 1 x 1 x
Version with RS232-RS485/422 & WiFi 2 x 2 x 1 x 1 x 1 x 2 x 1 x 1 x 1 x
Table 1: Router versions
Figure 6: Basic version (plastic)
Figure 7: Basic version with WiFi (plastic)
Figure 8: Basic version (metal)
Figure 9: Basic version with WiFi (metal)
8

5. ROUTER DESIGN
Figure 10: Version SWITCH (plastic)
Figure 11: Version SWITCH and WiFi (plastic)
Figure 12: Version RS232 (plastic)
Figure 13: Version RS232-RS485 (plastic)
Figure 14: Ver. RS232-RS485 & WiFi (plastic)
Figure 15: Version SWITCH (metal)
Figure 16: Version SWITCH and WiFi (metal)
Figure 17: Version RS232 (metal)
Figure 18: Version RS232-RS485 (metal)
Figure 19: Version RS232-RS485 & WiFi (metal)
9

5. ROUTER DESIGN
5.2 Delivery identification
Trade name Type name Other
SPECTRE v3 LTE SPECTRE-v3-LTE Router in a plastic or metal box
Table 2: Delivery identification
Figure 20: Label example
5.3 Ordering codes
Ordering codes overview is shown in the table below.
Name Order code Features – interfaces
SPECTRE v3 LTE set SR3xx000yz∗LTE module, 2x ETH, 1x USB, 2x BI, 1x BO, 1x mi-
croSD reader, 2x SIM reader
SPECTRE v3 LTE set SR3xx100yz∗LTE module, 2x ETH, 1x USB, 2x BI, 1x BO, 1x mi-
croSD reader, 2x SIM reader, WiFi
SPECTRE v3 LTE set SR3xx001yz∗LTE module, 5x ETH, 1x USB, 2x BI, 1x BO, 1x mi-
croSD reader, 2x SIM reader
SPECTRE v3 LTE set SR3xx101yz∗LTE module, 5x ETH, 1x USB, 2x BI, 1x BO, 1x mi-
croSD reader, 2x SIM reader, WiFi
SPECTRE v3 LTE set SR3xx002yz∗LTE module, 2x ETH, 1x USB, 2x BI, 1x BO, 1x mi-
croSD reader, 2x SIM reader, RS232
SPECTRE v3 LTE set SR3xx003yz∗LTE module, 2x ETH, 1x USB, 2x BI, 1x BO, 1x mi-
croSD reader, 2x SIM reader, RS232, RS485
SPECTRE v3 LTE set SR3xx103yz∗LTE module, 2x ETH, 1x USB, 2x BI, 1x BO, 1x mi-
croSD reader, 2x SIM reader, WiFi, RS232, RS485
Table 3: Ordering codes overview
∗Replace the letters "xx", "y" and "z" with the values from the tables on the following page.
10

5. ROUTER DESIGN
Letters "xx" – type of the LTE module
Type of the LTE module Number "xx" in code
LTE module for EMEA 03
LTE module for NAM, AT&T operator 04
LTE module for Australia 06
LTE module supports frequency 450 MHz 07
Table 4: Type of the LTE module
Letter "y" – type of the router box
Type of box Number "y" in code
Plastic 1
Metal 2
Table 5: Type of router box
Letter "z" – type of the power supply connector
Type of power supply Number "z" in code
Europe 1
UK & Ireland 2
Australia 3
North America 4
Table 6: Type of power supply
Examples of complete order code:
Order code Features – interfaces Box Power supply
SR30300011 LTE module for EMEA, 2x ETH, 1x USB, 2x BI,
1x BO, 1x microSD reader, 2x SIM reader
plastic Europe
SR30300122 LTE module for EMEA, 5x ETH, 1x USB, 2x BI,
1x BO, 1x microSD reader, 2x SIM reader
metal UK & Ireland
SR30410124 LTE module for NAM AT&T, 5x ETH, 1x USB, 2x
BI, 1x BO, 1x microSD reader, 2x SIM reader, WiFi
metal North America
SR30600213 LTE module for Australia, 2x ETH, 1x USB, 2x BI,
1x BO, 1x microSD reader, 2x SIM reader, RS232
plastic Australia
SR30710021 LTE module supports 450 MHz, 2x ETH, 1x USB,
2x BI, 1x BO, 1x microSD reader, 2x SIM reader,
WiFi
metal Europe
Table 7: Examples of order code
You can use the ordering codes configurator on the www.conel.com web pages.
11

5. ROUTER DESIGN
5.4 Basic dimensions of router box
Figure 21: Basic dimensions of router box
5.5 Mechanical dimensions and mounting recommendations
Mounting recommendations:
•possibility to be put on a work surface,
•DIN rail with clips CPD3 (or CKD2 for metal version) are included.
For the most of applications with a built-in router in a switch board it is possible to recognize
two kinds of environments:
•no public and industry environment of low voltage with high interference,
•public environment of low voltage without high interference.
For both of these environments it is possible to mount router to a switch board, the following
there is no need to have examination immunity or issues in connection with EMC according to
EN 60439-1 ed.2:00 + A1:04.
For compliance of EN 60439-1 ed.2:00 + A1:04 specification it is necessary to observe
next assembly of the router to the switch – board:
•For whip antennas we recommend to observe a distance of 6 cm from cables and metal
surfaces on every side due to the elimination of interference. While using an external
antenna except for the switch-board it is necessary to fit a lightening conductor.
•Before mounting a router on sheet-steel we recommend using a "cable" antenna.
•For every cables we recommend to bind the bunch, we recommend for this use:
–Length of the bunch (combination of power supply and data cables) can be maxi-
mum 1.5 m. If the length of data cables exceeds 1.5 m or in the event of, the cable
leads towards the switch – board. We recommend installing over – voltage protec-
tors (surge suppressors).
12
