1. Introduction
Description
The 9130 is a fully programmable triple Output DC Power Supply delivering 0-30V/0-3A on 2
outputs and 0-5V/0-3A on 1 output. Each output is fully floating and outputs can be adjusted
independently or connected in series or parallel to produce higher voltages or currents. The front
panel keys and the control knob provide a convenient means to adjust the voltage and current of a
selected output; enable or disable parallel or series tracking mode; store and recall operating states
or enable/disable individual outputs. The 9130 is ideally suited for applications in Electronic Test,
Production and Service, where multiple independent DC supplies are required and bench space is
at a premium.
Key Features
3 independent, fully programmable and electrically isolated outputs
Series or parallel operation
Display Voltage and Current for of all 3 channels simultaneously
Over Current (OCP) and Over Temperature (OHT) protection
Very compact foot print ( 2U x 1/2)
Bright and easy to read display (VFD technology)
High resolution, accuracy and stability
Output on/off control
Low ripple and low noise
SCPI compatible command set, communicate via USB or RS232 port
Application Software for front panel emulation and simple test sequence generation
50 memory locations for instrument state storage & recall
Convenient data entry via knob or numerical key pad
Rack mount kit available

6
2. Quick Start
This chapter will help you getting acquainted with the front panel operation of this power supply.
2.1 Front & Rear Panel
Front panel
1
2
3
4
5
6
7
1
VFD display
2
Rotary knob
3
Main power switch
4
Numerical key pad and “Esc” key
5
Function keys
6
Cursor position & Channel Selection keys, “Enter” key
7
Output terminals

7
Rear Panel
1
2
3
4
5
6
1) Terminal block for GND reference and additional negative output terminal
2) AC receptacle
3) Ventilation holes
4) Interface connector for remote control of power supply
5) 110V/220V AC Power selection switch
6) Fuse compartment
2.2 Preliminary Checkout
The following steps will help you verify that the power supply is ready for use.
1．Check the list of supplied items
Verify that you have received the following items with your power supply. If anything is missing, contact your
authorized B+K Precision distributor.
•Power cord
•Instruction manual
•Calibration Report
•Communication cable

8
•Software installation disk
2．Connect the power cord and turn on the power supply
When you turn on the power supply, the front-panel display will light up briefly while the power supply
performs its power-on self-test. All the VFD annunciators will turn on at once. Check for any missing display
segments. In the event that there is no response when you turn on the power supply, refer to section 5 of this
chapter for additional information.
3. System Checkout
At power up, the instrument will automatically perform a self test routine. During this time, the following
should be displayed:
System Test, Please wait!
followed by
0.000V 0.000V 0.000V
<OFF> <OFF> <OFF>
Or:
Note: The first row is the output voltage for channels 1 – 3. The second row will display the on/off state or the
output current of each channel.
In case the self test routine is not successful, you may see one of the following:
If the EEPROM is damaged, the VFD will display the following:
EEPROM Error
If the last operation data which should be stored in the EEPROM was lost you should see
Data Check Error
If the latest data about off-time in EEPROM was lost, the VFD will display
Load Off Time Fail
If the calibration data stored in the EEPROM was lost, the VFD will display
10.000V 11.000V 3.000V
2.000A 3.000A 3.000A

9
CH X Lost Calibration...
Note: “X” denotes the channel for which calibration data was lost.
If the calibration data in the EEPROM is corrupted or the factory calibration values are lost, the VFD will display
the following:
Lost Factory Calibration
Note: You will see a “?” on the VFD, in case of any errors are encountered during the self
test routine.
4．Output Verification
The following procedures verify that the power supply outputs the correct voltage and current levels and properly
responds to entries from the front panel.
•Voltage Output Checkout
The following steps verify basic voltage functions without load.
1) Turn on the power supply.
2) Turn on the outputs using the
On/Off
key
Note: Flashing voltage values indicates that the power supply is in “Set mode, ‘‘Set mode’’ means that
the VFD display shows the set values for voltage and current. In “meter mode” the display will
indicate the actual output voltage and current.
3) Check that the front-panel voltmeter properly responds to number key entries
Enter a different voltage value and wait a few seconds until the meter mode activates. Verify that the
actual output value voltage is identical to the set value. Also verify that the displayed current value is
close to zero.
4) Ensure that the voltage level can be adjusted from zero to the maximum rated value.
5) Verify channels 2 & 3 according to steps 1) – 4)
•Current Output Current
The following steps check basic current functions with a short across the power supply’s output.
6) Turn on the power supply
7) Turn the output off
Press
On/Off
key to ensure that the outputs are off. (bottom row indicates “OFF”)
8) Connect the (+) and (-) output terminals of channel 1 with a short, insulated test lead. Use a wire size
sufficient to handle the maximum current.
9) Set the voltage value with 1V
10) Turn on the output using the
On/Off
key.
11) Adjust the current value

10
Enter a different current value, wait until the instrument is in meter mode, then make sure that the
displayed current value (actual output value) is the same as the set value.
12) Ensure that the current can be adjusted from zero to the maximum rated value.
13) Turn off the power supply and remove the short wire from the output terminals.
14) Verify channels 2 & 3 according to steps 1) – 8)
5．If the Power Supply Does Not Turn On
Use the following steps to help resolve problems you might encounter when turning on the instrument.
1). Verify that there is AC power applied to the power supply.
Verify that the power cord is firmly plugged into the power receptacle on the rear panel of the power supply.
Make sure the power outlet you are using is working properly and verify that the power supply is turned on.
2). Verify the power-line voltage setting.
Make sure the voltage selector switch is set according to the present line voltage (110VAC or 220VAC).
Change the voltage setting if it’s not correct.
3). Verify that the correct power-line fuse is installed.
Model Fuse Description
9130 Fuse 3.15A T250V(220V AC)
Fuse 6.30A T250V(110V AC)
If the fuse is blown replace it according to the table above.
6．To Adjust the Carrying Handle
To adjust the position, grasp the handle on each side and pull outwards, then rotate the handle to the desired
position.
Bench-top viewing positions Carrying position

11
7. To Rack Mount the Instrument
You can mount the power supply in a standard 19-inch rack cabinet using the IT-E151 rack mount kit.
Note: Remove the carrying handle and the two plastic ears before rack-mounting the instrument. To remove
the handle, grasp the handle on the side, pull outwards and rotate it to a special position where the
arrow on the handle and the arrow on the plastic ears are in opposite directions. Now you can pull
the handle outwards. After removing the handle, you can remove the two plastic ears with a screw
driver.

12
3. Specifications
3.1 Specifications
Parameter 9130
Output ratings
Voltage 0~30V×2, 0~5V×1
Current 0~3A×2, 0~3A×1
LVP* 0~31V×2, 0~6V×1
Load Regulation
±(%of output+offset)
Voltage ≤0.01%+3mV
Current ≤0.01%+3mA
Line Regulation
±(%of output+offset)
Voltage ≤0.01%+3mV
Current ≤0.1%+3mA
Programming
Resolution Voltage 1mV
Current 1mA
Readback
Resolution
Voltage 1mV
Current 1mA
Programming accuracy
(12 months)
±(%of output+offset)
Voltage ≤0.03%+10mV
Current ≤0.1%+5mA
Readback accuracy
(25 °C ± 5 °C)
±(%of output+offset)
Voltage ≤0.03%+10mV
Current ≤0.1%+5mA
Ripple & noise Voltage Ripple: ≤1mVrms/3mVp-p
Noise: ≤3mVrms
Transient Response Time
< 500 μs for CH1&2, < 200 μs for CH3
for output to recover to within 75 mV
following a change from 100 mAto 1 A
Temperature coefficient
(0 °C ~ 40 °C)
±(%of output+offset)
Voltage ≤0.03%+10mV
Current ≤0.1%+5mA
Readback Temperature
Coefficient
±(%of output+offset)
Voltage ≤0.03%+10mV
Current ≤0.1%+5mA
Tracking Accuracy
Series Operation Current ≤0.05%+10mA
Tracking Accuracy
Parallel Operation Voltage ≤0.02%+5mV
Current ≤0.1%+20mA
Output Timer Time set 1s~999999s
Resolution
1s
Weight 19.8 lbs, (9 kg)
Dimensions 214.5mm(W) × 88.2mm (H) × 354.6mm (D)

13
8.45in(W) x 3.8in(H) x 13.9in(D)
*) LVP: Limit Voltage Protection. Limits the voltage than can be set either via the front panel or remote control command.
NOTE: Specifications and information are subject to change without notice. Please visit www.bkprecision.com for the most
current product information.
3.2 Supplemental Characteristics
State Storage Memory
50 user-configurable stored states
Recommended Calibration Interval
1 year
AC Input Ratings (selectable via switch on the rear panel)
220AV±10%，47～63Hz
110AV±10%，47～63Hz
Maximum power consumption
Model 9130
Power 750VA
Cooling
Fan cooled
Operating Temperature
0 to 40 °C for max rated output
Storage Temperature
-20 to 70 °C for storage environment.
Environmental Conditions
Designed for indoor use in an installation category II, pollution degree 2 environment. Designed to operate at
maximum relative humidity of 95% and at altitudes of up to 2000 meters.

14
4. Front-panel Operation
So far we have covered the quick start chapter which briefly introduced the front panel operation and how to
check basic voltage and current functionality. This chapter describes in detail how to operate the instrument
manually via the front-panel keys.
4.1 Front-panel Operation Overview
The power supply is shipped from the factory ready for front-panel operation mode. At power-on, the power
supply will automatically enter the front-panel operation mode and the instrument can be controlled via the
font panel keys and knob.
The power supply enters remote mode as soon as a valid remote command is received via the
communication connector in the rear. Switching to remote mode does not impact the supply’s output
parameters. In remote mode, front-panel operation is disabled. If the power supply is in remote mode, and
the [LOCAL] key is not disabled, you can revert to manual mode by pressing the [LOCAL] key .
The power supply is in Meter mode when it is powered on. In this mode, the VFD will display the actual
voltage and current output value. If the user adjusts the knob while in this mode, the power supply will
automatically enter Set mode then revert back to meter mode and display the modified voltage and current
values.
The output of the power supply can be enabled/disabled from the front panel by pressing the
On/Off
key.
The VFD also displays operation states or error information. “ ”means the power supply is in remote
mode. If an error occurred, ”?” will be displayed.
If the power supply is in Set mode, you can modify parameters using the knob. If the power supply is in
menu operation, the knob is used for menu selection. If the power supply is in the regular output mode you
can use the knob to set the voltage value.
If “?” is displayed on the VFD, please consult the submenu “error information” for more details (see chapter
4.4).
●
●

15
4.2 Panel Description
4
1 2
7
5
3
6
Esc
0
●
98
Recall
Menu
Enter
V-setV-set
I-setI-set
Save
On/Off
0
～
9 Use keys 1~3 to control the output state of the 3 channels。Use keys 4~6 to set the
voltage and keys 7~9 to set the current value for each channel.
V-setV-set
Set the voltage value
I-setI-set
Set the current value
Save
Save the current setup of the power supply to internal memory
Recall
Recall the setup from internal memory
Menu
Set general parameters of the power supply
On/Off
Set the output state of the power supply
Up arrow key, select a menu or channel
Down arrow key, select a menu or a channel
4.3 VFD Description and Wiring Diagram
Explanation of annunciators on the display
OFF
The output is off.
The key panel is locked.
The power supply is in remote mode.
？
There is some error or fault with the power supply.
Indicates the channel currently selected

16
4.4 Menu Descriptions
Press
Menu
to indicate operation mode. View the menu on the VFD, and use the keys or the knob to
scroll through the complete menu listed below. Press
Enter
to enter the selected menu function, press
Esc
to return to the previous menu. A ”↑↓” symbol displayed on the left means that you are currently in the middle of
a menu and you can now use the keys to select other menu parameter. If there is only”↑” displayed, you
are at the end of the currently active menu and you can only press the key to select a different parameter.
Accordingly, ”↓” indicated that you can use the key to select another parameter. Symbols …….
enclose the currently selected menu.
Menu
Power Config...
Reset Config System reset
Out State Set “Remember” Output On/Off state before power off
Out Parameter Set “Remember” parameters before power off
Key Sound Set
Knob Function Set Enable/disable knob
Screen Brightness
Baud Rate Set Set baud rate
Communication Parity
System Wait Time determines duration of set mode
Local Address Set communication address
Key Lock Set Set password
Exit
System Set…
Out Series Set Configure for series operation
Out Parallel Set Configure for parallel operation
Max Voltage Set… Set the max. voltage for each channel (LVP)
Set First Channel
Set Second Channel
Set Third Channel
Out Time Set… Set output time for each channel
Set First Channel
Set Second Channel
Set Third Channel
Exit
Power Information…
Power Model Display the power rating

17
Power SN display the serial number
Soft Version Display the firmware version
Cal Information
Error Information
Exit
Exit Menu
4.5 Panel Operation
Channel Operation
When the power supply is in “METER” mode, you can select a channel using the arrow keys .
OUT ON/OFF
Pressing
On/Off
toggles the output state of all 3 channels of the power supply. If the output state is ON,
press it, to turn the output state to OFF. While the output state is OFF, press
On/Off
and the power supply
output will turn ON.
To control channels individually, press one of the number keys
1
,
2
3
corresponding to each channel.
Key
1
controls the output state of the first channel, key
2
controls the output state of the second channel
and key
3
controls the output state of the third channel.
When the power supply is in remote mode, you can set the output state by sending SCPI command（OUTPut:
ON | OFF）The Output state operation doesn’t affect any other parameter.
Note: The
On/Off
key controls the output state of all 3 channels simultaneously.
If you want to control the output state of individual channels, use the number keys 1-3.
Timer Operation
If you have set the output timer and the power supply is in “METER” mode, you can check the remaining time
by pressing
0
. When the timer expires, the power supply will turn off the channel automatically.
Set Voltage
Solution 1: Press
V-setV-set
, enter a numeric value (via key pad) then press
Enter
to confirm.

18
Solution 2: Press
V-setV-set
, then use the arrow keys to move the cursor to the desired position and
adjust the value with the knob. (Make sure the knob function is enabled in the systems menu,,
otherwise use solution 1). Press
Esc
or
Enter
to return to meter mode. (Otherwise the
cursor will remain visible indefinitely or until the system Wait time timer expires).
Solution 3: Press one of the keys 4-6, corresponding to the channel which you want to adjust (Press
4
to
adjust the first channel, press
5
to control the second channel and press
6
to control the
third channel).
For example, to set voltage for the first channel: Press
4
, then enter a numerical value
followed by
Enter
. Alternatively, press to move the cursor adjust the voltage value
using the knob. Press
Esc
o r
Enter
to escape and return to meter mode.
Set Current
Solution 1: Press
I-setI-set
, enter a numeric value then press
Enter
to confirm.
Solution 2: Press
I-setI-set
, the press to move the cursor position and adjust the voltage value using the
knob. (Make sure the knob function is enabled in the systems menu,, otherwise use solution 1).
Press
Esc
or
Enter
to exit.
Solution 3: Press one of the number keys 7 – 9 corresponding to the channel for which you want to set the
current value. (Press key
7
to control the first channel,
8
for the second channel or press
key
9
to control the third channel). For example, if you want to set the current for the first
channel, press key
7
, then enter a numeric value followed by the
Enter
key. Alternatively,
or press to move the cursor and adjust the value with the knob. Press
Esc
or
Enter
to escape and return to meter mode.(Otherwise the cursor will remain visible indefinitely or
until the system Wait time timer expires).
Save and Recall Operation
You can store up to 50 different operating states in memory locations 1 through 50. Each operating state
includes a constant voltage value, constant current value, maximum output voltage value and voltage step
value. Press
Save
followed by a number key to save the current operating state to non volatile memory.

19
Press
Recall
followed by a number 1 – 50 to recall operating state assigned to this location.
You can also use the SCPI command:*SAV、*RCL to save and recall.
Over Temperature Protection
If the internal temperature of the power supply exceeds 80 °C, the instrument will protect itself by
automatically turning power OFF. When this happens you will hear a buzzer and the display will indicate the
following:
Over Temp
4.6 Menu Function
In menu operation, the keys or the knob can be used to select the menu.
Enter
is used to confirm a
selection. The
Esc
key is used to exit the current menu
•Power Config
Reset Config
If you enter this menu and select “YES”, all parameters will be set to their default values.
Out State Set
This parameter sets the Output On/Off state at power up. If you select “Last Set”, the power supply will save
the output state prior to power down and revert to that state at power up. If you select “Off”, the output state is
always “OFF” when the power supply is turned on. The recommend setting is “OFF”.
If Out Parameter Set is set to “Default”, the output state of the power supply after power –up will always be off,
regardless of the settings of this parameter
Out Parameter Set
This parameter determines the state of the power supply after power up. If you select “Last Set”, the
power supply will automatically restore (“remember”) the last output parameters setting prior to power
down. If you select “default”, the default output parameter settings will be active after power up.
Recommend setting is “Last Set”.
Key Sound set
This parameter turns the beep sound for key presses “On” or “Off”.
Knob Function Set
This parameter enables (“On”) or disables (“Off”) the knob.

20
Baud Rate Set
This parameter configures the baud rate for serial communication.Possible values are 4800，9600，19200 or
38400. When operating the power supply in remote mode, make sure that you configure identical baud rate
settings for the power supply and the computer. The default setting is 9600.
Communication Parity
This parameter sets the parity bit for serial communication. Possible values are NONE, ODD and EVEN.
Default setting is NONE.
System Wait Time
This parameter determines how long the power supply will remain in set mode until it automatically reverts
back to meter mode or output mode The minimum is 4 seconds, and the maximum is 9999 seconds. Enter a
numerical value followed by
Enter
or press +
Enter
to set the wait-time. To disable the system
wait time function, set the wait time to 0 seconds. (In this case, the power supply will remain in set mode until
the ESC or ENTER key is pressed). Set mode is active when a cursor is visible. Default setting is 0 seconds.
Note: the wait-time range is 4~9999S, if you set it with 1~3S, the wait-time will be 4S automatically.
Local Address
With this parameter, it is possible to address each instrument. The address range is 0 to 30.
Key Lock Set
A password can be assigned (1 - 4 digits) to lock the function key operation. After setting the password, there
is a sign displayed on the VFD and all the function keys on the front panel will be locked except of the
On/Off
key (if the knob is enabled, keys can also can be used). You must enter the correct password to
unlock the keys. If you don’t want to lock the function keys, please set the password to 0 when entering
the >SET KEYLOCK function.
When the knob function is enabled:
You can press the keys to move the cursor position, then enter a number and press
Enter
to set
the password. Or press to select the cursor position and change the value using the password using the
knob. Press +
Esc
or
Enter
to exit.
When the knob function is disabled:
Press number key+
Enter
to set the password or use the keys.
•System Set
