Braemar TG3 Series Assembly instructions

GAS DUCTED HEATER
TG3 SERIES
Home Owners Guide

Features
D es ign e d a nd m a nu f ac t u r e d in A u s t r a li a t o exac t ing s t a nd a r d s .
1
1. Heat exchanger - 10 year warranty
2. Fully automatic electronic ignition
3. Approved by the Australian Gas
Association
4. Three speed fan
GENERAL
INTRODUCTION
Congratulations on choosing a
Braemar Gas Ducted Heating Unit.
Your Braemar Heater is built from
the highest quality materials and is
engineered to provide many years
of trouble free performance.
Delivery
The customer or installer, upon
delivery of the heater should
ensure that the model number
and gas type is as requested.
A data label on the end of the
heater details both the model
number and gas type. Please
check the heater and report any
freight damage.
Please take a moment to
read these instructions.
TG3
Internal
TG3
External

TURNING THE HEATER ON FOR THE FIRST TIME
2
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
10
15
20
25
30
On
Off
B r ae m a r
Simply follow the steps below
P R OG RA MM AB LE T H E R M OST A T
M ANUA L T H E R M OST A T
MAN
ON
HEAT
HOME
I NCR E A SE
TE
M PE RA T UR E
121
2

TROUBLE SHOOTING
Problem?
HEAT should be ON but the heater is not working.
Check that gas is on to heater
Check that power is on to the heater
Problem?
Heater has gone through a start-up sequence and has not lit.
Turn the Thermostat OFF-ON-OFF-ON with a 5 second
interval between steps.
Set the thermostat temperature to above room temperature.
The heater should now operate.
Problem?
Heater is not operating effectively.
Check that there are enough outlets opened for the fan speed
selected. Is the return air filter blocked ?
We recommend cleaning every fortnight.
Problem?
Not enough Heating.
Is the thermostat located in the correct area according
to the Installation Instructions.
Increase the SET temperature.
Problem?
Heater runs when not programmed - Electronic thermostats.
Check the time AM or PM.
Sleep or away programmed temperature is too high: lower.
3
MAINTENANCE SCHEDULE
Periodic maintenance of the heater will ensure a long and satisfactory
service life with the heater operating at optimum performance.
Maintenance should be performed on a yearly basis by an Authorised
person trained in the service of the Braemar Heaters.
If heater does not operate satisfactorily refer to the trouble shooting
chart below or contact your Braemar Dealer.
If you have difficulty operating your Heater check
the trouble shooting guide before calling for service

IMPORTANT
IMPORTANTIMPORTANT
Record the Serial No. and Model No. of the heater here.
Model No:____________________
Serial No:____________________
Date of Installation:_____/______/______
Installer:_______________________
1. Checked through the trouble shooting guide.
2. Noted the Serial No. & Model No. of the heater.
( if they are not recorded above, the numbers
are located on the side of the heater. )
3. Spoken to your Braemar Dealer / Installer.
FOR SERVICE CALL : 1 300 650 644
SERVICE
Before calling for service have you :

P/No. 622651 /c
Manufacturers and Designers of Technically Advanced Quality Heating and Cooling Products
Seeley International Pty Ltd has a policy of continuous product development and therefore
reserves the right to make changes to these specifications without notice. Whilst every
care has been taken to assure accuracy of the data compiled in the document,
Seeley International Pty Ltd does not assume any liability for errors and/or omissions.
Braemar is a registered trademark of Braemar Industries Pty Ltd.
Seeley International Pty Ltd ACN 23 054 687 035
Albury Manufacturing
77 North Street Albury, NSW 2640
www.seeley.com.au
TECHNICAL SUPPORT CENTRE: 1300 650 399
For technical support regarding
the installation of this product
SALES: 1300 650 141
For all your sales enquiries
SERVICE: 1300 650 644
For all your Braemar warranty and service needs.
