Brant Radiant Heaters LR-LB1 Series User manual

All persons involved with the installation, operation, and maintenance of the lighting system must read
and understand the information in this manual.
LR-LB1 Series Manual
Brant Radiant Heaters Ltd.
Improper installation, adjustment, alteration, service or maintenance can cause property
damage, injury or death. Read and understand the installation, operating and
maintenance instructions thoroughly before installing or servicing this equipment.
WARNING
!
!
INSTALLER: Present this manual to the end user.
Keep these instructions in a clean and dry place for future reference.
Model#: Serial #:
(located on rating label)
LIOLR-LB-Rev.-9/16
LED Bay Lighting Fixtures
Installation, Operation,
and Maintenance
IP65

LR-LB1 Series
2
3
Contents
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
LB1 Series Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.0 Specifications ............................................................ 4
Design ................................................................ 4
3.0 Maintenance, Care, and Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Bracket Mount Installation.................................................. 6
Maintenance Log .........................................................7
4.0 Electrical & Wiring..........................................................8
General Wiring Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Dimming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Hard Wiring Lumen Levels Internally . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.0 Parts Breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.0 Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2
LR-LB1 Series
3
LRA-HSA Kit Contents
1.0 Introduction
The LB1 Series LED Bay light, is designed for illumination of industrial locations. It uses the latest in solid
state lighting (SSL) technology for long life, low maintenance, and high efficiency. The unique optical design
focuses light downward to where it is needed, giving improved efficiency over a conventional HID luminaire.
LB1 Series LED Bay Lighting Fixtures are designed to vastly reduce energy use and maintenance needs,
improve safety, and reduce CO2 emissions.
1.0 Introduction
LB1 Series Kit Contents
Eye Bolt
Qty. 1
Horseshoe Bracket
Qty. 1
Spring Washer
Qty. 1
Flat Washer
Qty. 2
LIOLB: LR-LB1 Series
LED Bay Lighting Manual
Screws
Qty. 4
Nuts
Qty. 2
All persons involved with the installation, operation, and maintenance of the lighting system must read
and understand the information in this manual.
LR-LB1 Series Manual
Brant Radiant Heaters Ltd.
Improper installation, adjustment, alteration, service or maintenance can cause property
damage, injury or death. Read and understand the installation, operating and
maintenance instructions thoroughly before installing or servicing this equipment.
WARNING
!
!
INSTALLER: Present this manual to the end user.
Keep these instructions in a clean and dry place for future reference.
Model#: Serial #:
(located on rating label)
LIOLR-LB-Rev.-2/16
LED Bay Lighting Fixtures
Installation, Operation,
and Maintenance
IP65
To avoid the risk of fire, explosion, or electric shock, this product should be installed,
inspected, and maintained by a qualified electrician only in accordance with all
applicable electrical codes.
To avoid electric shock:
• Be certain electrical power is OFF before and during installation and maintenance.
• Luminaire must be connected to a wiring system with an equipment-grounding
conductor.
• Make sure the supply voltage is the same as the rated luminaire voltage.
• Do not operate in ambient temperatures above those indicated on the luminaire
nameplate.
• No user serviceable parts inside of fixture. Removal of lens will void the warranty.
WARNING
!
!

LR-LB1 Series
4
5
Design
When designing a layout for a particular application, there are several factors that should be taken into
consideration.
The typical mounting height for model LR-LB1 is 8 - 24 ft. from the ground. This mounting height is a
recommendation only. The facility usage purpose, colour scheme, desired brightness levels, and overall
facility size will all factor into the layout of the lighting fixtures.
These LED Lighting Fixtures are NEC Class 1 compliant. Check applicable province, local, and national
codes before designing and installing lighting fixtures.
A common misconception with LED lighting is the belief that they do not generate heat. While it is true
that LED fixtures produce much less heat than other forms of lighting due to the increased efficiency and
lower power consumption, thermal management is still a crucial component of a well-designed LED
fixture. The LR-LB1 fixtures have been designed to not only enclose the LEDs and circuitry, but to act as
a heat sink as well. These fixtures utilize state of the art thermal interface materials to conduct the heat
from the LED module to the housing. The housing has been geometrically designed with a large surface
area for excellent convection of heat away from the housing. As a result, the LR-LB1 series fixture is
warranted for 50,000 hours of use within an ambient temperature of up to 45°C (113°F). For maximum
long-term reliability, this light should be installed in free air.
2.0 Specifications
MODEL DESCRIPTION
Watts
(w)
Colour
(k)
Lumens
(l)
Amps
(A)
Typical
Mount1
Weight
(lbs.)
LR-LB1_6PT-4W LR-LB1 Fixture with 6 ft. Pigtail 18/4 97 5,000 8,600 0.80 8-24 ft. 5
Limited Warranty: 5-Years 1Recommended mounting height allowance will depend on proper building evaluation. Product can dim from 10% to 100%
Operating temperature range: -40°C to +45°C (-40°F to 113°F). CSA/DLC certified for indoor and outdoor applications, IP65 certified, and NEMA 4X certified.
2.0 Specifications • Design • Sample Lighting Layout
Chart 2.1 • LED Bay Lighting Specifications
IP Code Definition and Explanation of IP65 Rating
The IP Code, International Protection Marking, IEC standard 60529, also interpreted as Ingress Protection
Marking, classifies and rates the degree of protection provided against intrusion (body parts such as
hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures.
Solid Particle Protection: The first digit indicates the level of protection that the enclosure provides
against access to hazardous parts (e.g., electrical conductors, moving parts) and the ingress of solid
foreign objects. 6: Totally protected against dust ingress.
Liquid Ingress Protection: The second digit indicates the level of protection that the enclosure provides
against harmful ingress of water. 5: Protected against low pressure jets of water from all directions - limited
ingress

4
LR-LB1 Series
5
2.0 Specifications • Design • Sample Lighting Layout
Figure 2.1 • Sample Lighting Layout - Maintenance Hangar
Description Symbol Avg Max Min Max/Min Avg/Min
Airplane Hangar + 49.6 fc 61.5 fc 29.6 fc 2.1:1 1.7:1
Chart 2.2 • Sample Lighting Layout Statistics
Chart 2.3 • Sample Lighting Layout Schedule
Symbol Label Qty.
Catalog
Number Lamp
Number
Lamps
Lumens
/Lamp Description Wattage Polar Plot
A 39
LR-LB1
(100%
Output)
144 White LEDs.
Lumen Output=
8,599 LMS.
1 8,599
Brant Radiant
Heaters
LED Bay
Luminaire
97.07
Max: 3476cd
90.0’
65.0’
Notes:
- Airplane Repair
Hangar
- 19 ft Ceiling
- Dark Walls
and Floor
- High Light Output
Desired

LR-LB1 Series
6
7
3.0 Maintenance, Care, and Usage
Visual, mechanical, and electrical inspections should be performed on a regular basis. Routine checks at
least once a year are recommended. Frequency of use and environmental conditions may make it necessary
to perform more than one routine check per year. It is recommended to follow the Electrical Preventative
Maintenance Program as described in NFPA 70B: Recommended Practice of Electrical Equipment.
The lens should be cleaned periodically as needed to ensure continued photo-metric performance. Clean
the lens with a damp, non-abrasive, lint-free cloth. If a damp cloth alone is not sufficient, use mild soap or
a liquid cleaner. Do not use an abrasive, strong alkaline or acid cleaner as damage may occur.
Inspect the cooling fins on the luminaire to ensure that they are free of any obstructions or contamination
(i.e. excessive dust build-up). Clean with a non-abrasive cloth if needed.
Electrical connections and wires should be checked for exposed wire and overall circuit integrity.
Bracket Mount Installation
NOTE: Accessory installation sheets supersede these instructions.
1 Sub assemble the eyebolt to the hanging bracket using the two jam nuts and one lock washer
(provided) in a sandwich-like assembly.
2 Use the four screws provided on the main housing to attach the hanging bracket assembly to the
housing.
3 Use a chain or cable (must be able to bare the weight of 50 lbs. or more) and hook into the eyebolt.
Always close “S” hooks if used.
Figure 3.1 • Bracket Mount Dimensions
To avoid personal injury, disconnect power to the light and allow the unit to cool down before
performing maintenance.
CAUTION
!
3.0 Maintenance, Care, and Usage • Bracket Mount Installation
Ø11.0"
6 ft. Pig-tail
18/4 AWG
Rating Plate
516" - 18 Eyebolt
516" - 18 Jam Nut
38" NPT IP65
Cord Grip
HB Hanging Bracket
2.28"
4.78"

6
LR-LB1 Series
7
Maintenance Log
3.0 Maintenance, Care, and Usage • Maintenance Log
Date Maintenance Performed Replacement Parts Required

LR-LB1 Series
8
9
4.0 Electrical and Wiring
General Wiring Steps
The LR-LB1 Series of LED Fixtures is an AC driverless bay light. We have eliminated the ballast component
of the light which, in a conventional LED fixture, transforms the mains voltage to DC and steps the voltage
down to the level required by the LED module. The ballast and LED module in a standard fixture are often
not compatible with the existing building management systems as the ballast has specific power
requirements in order to supply the LED module with the correct DC voltage and amperage. The LR-LB1
Series, on the other hand, is exceptionally versatile due to the advanced circuitry employed in the
construction of the AC driverless LED module. This facilitates straightforward integration of controls such
as daylight harvesting, occupancy sensors, timers, and dimmers. Essentially, from a control aspect, the
LR-LB1 Series behaves similarly to an incandescent light bulb.
When installing the LR-LB1 Series LED Lighting Fixtures, it is important to be aware of, and comply with,
all province, local, and national codes applicable to LED lighting and other Class 1 compliant lighting
fixtures before beginning installation.
If the fixture is to be hard-wired into a junction box, determine the required lumen level by referring to the
Specifications table on page 4 as well as the Wiring Diagrams on page 9. Required wiring will vary
depending on the lumen level to be achieved. This fixture is designed for 120VAC, single phase only.
Dimming
The LR-LB1 Series is capable of dimming from 10% to 100%. The lifespan of the LED is not diminished
when using a control system for dimming. Phase-cut dimmers, particularly forward phase/ leading-edge
are compatible with the LR-LB1 AC driverless technology. Other types of dimmers may or may not be
compatible, depending upon manufacturer and specific application.
Additional Power Saving Options
The LR-LB1 fixture has been designed with a modular LED circuit board which allows the maximum
power consumption to be hardwire limited to 1/3 or 2/3rds the maximum output. There are often areas
of a facility which do not require the full amount of illuminance due to different light requirements for
different tasks, but similarly, it makes economic sense to install the same light fixture throughout the
facility. In addition to being individual controllability, the LR-LB1 can be switched from 1/3, to full power
by a switch on a panel, or through an occupancy sensor. By hardwire limiting the output of the fixture,
many lights can be in a zone of control, operated by a single sensor, and result in varying amounts of
illuminance from the exact same fixture depending on mounting heights, and specific task requirements.
4.0 Electrical and Wiring • General Wiring Steps • Dimming

8
LR-LB1 Series
9
Hard Wiring Lumen Levels Internally
4.0 Electrical and Wiring • Hard Wiring Lumen Levels Internally
L1 R
L1 L1
R R
1/3 Power 3/3 Power2/3 Power
L1 R
L1
L1
R
R
1/3 Power 3/3 Power2/3 Power
L1 R L1
L1
R
R
1/3 Power 3/3 Power2/3 Power
Figure 4.1 • Block Wiring Diagram - 1/3 Power
For a 1/3 Power Phase connection, connect the
green wire to ground, the red wire to the hot
conductor, and the white wire to the neutral
conductor. The black wire should be unused and
capped with a wire nut.
For a 2/3 Power Phase connection, connect the
green wire to ground, the black wire to the hot
conductor, and the white wire to the neutral
conductor. The red wire should be unused and
capped with a wire nut.
Figure 4.2 • Block Wiring Diagram - 2/3 Power
For a 3/3 Power Phase connection, connect the
green wire to ground, both the black and the red
wires to the hot conductor, and the white wire to the
neutral conductor. All wires should be connected
for this setup.
Figure 4.3 • Block Wiring Diagram - 3/3 Power

LR-LB1 Series
10
11
Part No..Description
LRP-1001 LR-B Aluminum Housing LRP-1031 5/16” Flat Waher
LRP-1002 LR-B Aluminum Ring LRP-1032 M4 x 10 mm Pan Head Casting Screw
LRP-1003 LR-B Lens Gasket LRP-1033 5/16” - 8 Nuts, Zinc
LRP-1004 LR-B Graphite Heat Spreader LRP-1034 M3.5 x 6 mm Zinc Philips Pan Head Screw
LRP-1007 LR-B Hanging Braket LRP-1035 5/16” Spring Washer
LRP-1009 LR-B Tempered Glass 8.75” Dia. LRP-1037 5/16” - 18 x 1.0” L - Hex Bolt, Zinc
LRP-1010 3/8” NPT Liquid Tight Cord Grip, (IP65) LRP-1039 LR-B 5/16”- 18 x 2.0” Hanging Eyebolt
LRP-1018 6 ft. 18/4 Pig-tail LRP-1047 Rating Plate
LRP-1020 L.E.D board
1039
1033
1032
1034
1047
1001
1004 1020 1003 1009
1010
1007
1018
1032
1002
1031
1031 1035
1033
Chart 5.1 • Parts List
Figure 5.1 • LR-LB1 Assembly Components
5.0 Parts • Light Components and Parts List
Light Components and Parts List

10
LR-LB1 Series
11
Notes

© 2016 Brant Radiant Heaters Limited
34 Scott Ave. Paris, ON N3L 3R1 Canada
Voice: [phone]
Fax: [phone]
Website: www.brantradiant.comPrinted in Canada
6.0 Limited Warranty
Five-Year Limited Warranty: Brant Radiant Heaters Ltd. (herinafter referred to as the Company) warrants
to the original purchaser or original user that all Brant Radiant Lighting Systems sold by it and all parts thereof
are free from defects in materials or workmanship under normal use and service. The Company’s sole
obligation under this warranty shall be limited to furnishing replacement parts, F.O.B. Paris, Ontario, for 60
months from the date of initial installation of the light, but not to exceed 66 months from the date of shipment
by the Company of the lighting system, for any parts which the Company’s examination shall disclose to its
satisfaction to be defective. Defective parts are to be returned to the company, transportation charges prepaid.
General Conditions: The warranties set out in this certificate are the exclusive remedy of the original owner
or user in lieu of all other warranties written, oral, or implied (including any warranty of merchantability or
fitness for the purpose) and all other obligations or liabilities on the part of the Company, and the Company
neither assumes nor authorizes any person to assume for it any other obligation or liabilities on the part of the
Company, and the Company neither assumes nor authorizes any person to assume for it any other obligation
or liability in connection with the sale, installation, or use of the lighting system or any parts thereof.
The Company will not be responsible for labor charges for the analysis of a defective condition in the lighting
system for the installation of replacement parts. The warranties provided herein will not apply if the lighting
system in the judgement of the Company has been subjected to misuse, excessive dust, improper conversion,
negligence, accident, corrosive atmospheres, excessive thermal shock, excessive vibration, physical damage
to the lighting system, alterations by unauthorized service personnel, operation contrary to the Company’s
instructions, or if the serial number has been altered, defaced, or removed. The Company shall not be liable
for any default or delay in the performance of these warranties caused by contingency beyond its control,
including war, government restriction or restraints, strikes, fire, flood, short or reduce supply of raw materials,
or parts.
The warranties herein shall be null and void if the lighting system is not installed by a competent electrical
contractor and/or if the lighting system is not installed according to, and repaired according to, the Company’s
instructions. Normal product degradation and wear (rust, oxidation, etc.) does not constitute a material defect
and applicable warranty claim.
Written permission is required for the return of any parts or equipment and any such return must be made on
the basis of transportation charges prepaid. Shipment may be refused unless prior written permission is
obtained and good returned prepaid.
This warranty applies only to North America.
