BreezeCOM BreezeACCESS 2.4 User manual

BreezeACCESS 2.4
Base Station Equipment
Installation
Manual
Revision 3
November, 2000
Cat. No. 213125

Front Matter
BS Equipment Installation Manual ii BreezeACCESS 2.4 Series
© 2000 by BreezeCOM Ltd. All rights reserved.
No part of this publication may be reproduced in any material form without the written permission of
the copyright owner.
Trade Names
BreezeACCESS, BreezeNET, BreezeLINK, BreezeVIEW, BreezeMANAGE and WIX are trade
names of BreezeCOM Ltd. Other brand and product names are registered trademarks or trademarks of
their respective companies.
Statement of Conditions
The information contained in this manual is subject to change without notice. BreezeCOM shall not be
liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this manual or equipment supplied with it.
Warranty
In the following warranty text, “the Company” shall mean:
• BreezeCOM Ltd., for products located outside the USA.
• BreezeCOM Inc., for products located in the USA.
This BreezeACCESS product is warranted against defects in material and workmanship for a period
of one year from date of purchase. During this warranty period the Company will, at its option, either
repair or replace products that prove to be defective.
For warranty service or repair, the product must be returned to a service facility designated by the
Company. Authorization to return products must be obtained prior to shipment. The buyer shall pay
all shipping charges to the Company and the Company shall pay shipping charges to return the
product to the buyer.
The Company warrants that the firmware designed by it for use with the unit will execute its
programming instructions when properly installed on the unit. The Company does not warrant that the
operation of the unit or firmware will be uninterrupted or error-free.

Front Matter
BreezeACCESS 2.4 Series iii BS Equipment Installation Manual
Limitations of Warranty
The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance
by the buyer, buyer supplied interfacing, unauthorized modification or misuse, operation outside of
the environmental specifications for the product, or improper site preparation or maintenance. No
other warranty is expressed or implied. The Company specifically disclaims the implied warranties of
merchantability and fitness for any particular purpose.
BreezeCOM shall not be liable to any person for any special or indirect damages, including, but not
limited to, loss of profits or revenues, loss of use or damage to any associated equipment, cost of
capital, cost of substitute products, facilities or services, downtime costs or claims resulting from any
cause whatsoever arising from or in any way connected with the manufacture, sale, handling, service,
repair, maintenance or use of the products. In no event shall the company’s liability exceed the
purchase price denoted on the invoice.
Electronic Emission Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for digital equipment,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his/her own expense.
Information to User
Any changes or modifications of equipment not expressly approved by the manufacturer could void
the user’s authority to operate the equipment.
Safety Considerations
For the following safety considerations, “Instrument” means the BreezeACCESS Base Station
equipment components and cables.

Front Matter
BS Equipment Installation Manual iv BreezeACCESS 2.4 Series
RF Warning
To comply with FCC RF exposure requirements in section 1.1307, a minimum separation distance of
2m (79 inches) is required between the antenna and all persons.
Line Voltage
Before connecting this instrument to the power line, make sure that the voltage of the power source
matches the requirements of the instrument.
Radio
The instrument transmits radio energy during normal operation. To avoid possible harmful exposure
to this energy, do not stand or work for extended periods of time in front of its antenna. The long-term
characteristics or the possible physiological effects of Radio Frequency Electromagnetic fields have
not been yet fully investigated.
Antenna Installation and Grounding
Be sure that the Outdoor unit, the antenna and the supporting structure are properly installed to
eliminate any physical hazard to either people or property. Verify that the antenna mast is grounded so
as to provide protection against voltage surges and static charges. Make sure that the installation of the
outdoor unit, antenna and cables is performed in accordance with all relevant national and local
building and safety codes.

BreezeACCESS 2.4 Series v BS Equipment Installation Manual
Table of Contents
1. INTRODUCTION.....................................................................................................................1
2. BASIC INSTALLATION .........................................................................................................2
2.1 Packing List – Modular Shelf Equipment.............................................................................2
2.1.1 BS-SH Base Station Shelf..............................................................................................2
2.1.2 AU-A/E-BS Access Units (up to six per shelf)..............................................................2
2.1.3 BS-PS Power Supply (one or two per shelf)..................................................................2
2.2 Packing List – Stand-alone AU-A/E-NI Access Unit...........................................................3
2.3 Other Items Required for Installation....................................................................................3
2.4 Guidelines for Selection of Equipment Location..................................................................3
2.5 Installing the Outdoor Radio Unit.........................................................................................6
2.5.1 Mounting the Outdoor Unit ...........................................................................................6
2.5.2 Connecting the Antenna Cable (AU-RE) ......................................................................8
2.5.3 Connecting the Ground and IF Cables...........................................................................8
2.6 Installing the Modular Shelf Indoor Equipment ...................................................................9
2.6.1 BS-SH Slot Assignments...............................................................................................9
2.6.2 The BS-AU..................................................................................................................10
2.6.3 The BS-PS....................................................................................................................12
2.6.4 Shelf and Modules Installation Procedure...................................................................13
2.7 Installing the AU-NI Indoor Unit........................................................................................14
3. CONFIGURING SYSTEM PARAMETERS........................................................................15
3.1 Getting Started with the Local Terminal.............................................................................15
3.2 Configuring Basic Parameters.............................................................................................17
3.3 Reset Unit............................................................................................................................18
4. VERIFYING CORRECT OPERATION..............................................................................19
4.1 Verifying Correct Operation of the AU-A/E-BS ................................................................19

Table of Contents
BS Equipment Installation Manual vi BreezeACCESS 2.4 Series
4.2 Verifying Correct Operation of the AU-A/E-NI.................................................................19
4.3 Verifying Correct Operation of the Outdoor Unit...............................................................20
5. SPECIFICATIONS.................................................................................................................21
5.1 Radio...................................................................................................................................21
5.2 Outdoor Unit to Indoor Unit Communication.....................................................................21
5.3 Configuration and Management..........................................................................................22
5.4 Interfaces.............................................................................................................................22
5.5 Electrical .............................................................................................................................23
5.6 Mechanical..........................................................................................................................23
5.7 Environmental.....................................................................................................................23
5.8 Standards Compliance, General..........................................................................................23
APPENDIX A. USING TELNET
APPENDIX B. BASIC PARAMETERS

Table of Contents
BreezeACCESS 2.4 Series vii BS Equipment Installation Manual
Table of Figures
Figure 2-1. Holes/Grooves/Screw Holes...................................................................................6
Figure 2-2. AU-RE 3" Pole Mounting Installation Using the Special Brackets ......................7
Figure 2-3. AU-RA/AU-RE Radio Unit Bottom Panel..............................................................8
Figure 2-4. Shelf Slot Assignments...........................................................................................9
Figure 2-5. BS-AU Front panel...............................................................................................10
Figure 2-6. BS-PS Front Panel................................................................................................12
Figure 2-7. AU -NI Rear Panel ................................................................................................14
Figure 2-8. AU -NI Front Panel...............................................................................................14
Figure 3-1. Main Menu ...........................................................................................................16
Table of Tables
Table 2-1: IF Cables...................................................................................................................4
Table 2-2: BS-AU LEDs.........................................................................................................11
Table 2-3: BS-PS Power Supply LEDs....................................................................................12
Table 4-1: AU-NI LEDs...........................................................................................................19
Table 4-2: AU-RA/RE LEDs...................................................................................................20
Table 5-3. Hopping Sequences................................................................................................26

Introduction
BreezeACCESS 2.4 Series 1 BS Equipment Installation Manual
1. INTRODUCTION
This manual describes installation guidelines for BreezeACCESS 2.4 base station
equipment, including the stand-alone AU-E/A-NI-2.4 Access Units and the
modular AU-E/A-BS-2.4 Units with the BS-SH rack mounted shelf.
The BreezeACCESS IP Broadband Wireless Local Loop (WLL) system allows
access service providers to provide high-speed IP connectivity services to their
subscribers. To support IP-based services effectively BreezeACCESS systems
employ wireless packet data switching technology.
The BreezeACCESS 2.4 line of products uses Frequency Hopping Spread
Spectrum radios that operate in Time Division Duplex (TDD) mode in the
2.400GHz – 2.500GHz frequency range.
The AU-A/E-NI and the AU-A/E-BS Access Units are comprised of an indoor
unit and an outdoor unit. In the AU-A-NI and AU-A-BS products, the outdoor
unit (AU-RA) contains the radio module and an integral flat antenna. In the
AU-E-NI and AU-E-BS products, the outdoor unit (AU-RE) contains the radio
module and an interface to an external antenna (not included).
The indoor unit of the AU-A/E-NI is a stand-alone unit (AU-NI) that is powered
from the mains via its AU-PS power supply unit. The indoor unit of the AU-A/E-
BS is a module (BS-AU) that is designed for insertion into the BS-SH shelf. The
BS-SH, which is a 3U shelf suitable for installation in 19"racks, can contain up
to six BS-AU active modules and one or two BS-PS power supply modules. The
shelf is powered from a –48VDC power source. Power supply redundancy is
supported through the optional use of a second BS-PS power supply module.
The indoor unit provides the interface to the network. It also contains an IF
(Intermediate Frequency) module and is connected to the outdoor unit via a
50-ohm coaxial IF cable. The IF cable serves for transmission of the 440MHz IF
signal between the indoor and the outdoor units. It also serves for transferring
power (12VDC), management and control signals from the indoor unit to the
outdoor unit.
Note: The information contained in this manual is applicable to
BreezeACCESS 2.4 units with software release 2.5 and up.

Basic Installation
BS Equipment Installation Manual 2 BreezeACCESS 2.4 Series
2. BASIC INSTALLATION
2.1 Packing List – Modular Shelf Equipment
2.1.1 BS-SH Base Station Shelf
• BS-SH shelf (with blank panels)
• Rubber legs for optional desktop installation
Note: Unless ordered otherwise, each BS-SH will be shipped with one BS-PS
power supply installed.
2.1.2 AU-A/E-BS Access Units (up to six per shelf)
• Outdoor unit:
⇒ AU-RA with integral antenna
or
⇒ AU-RE with a connector to an external antenna (not included)
• Pole mounting kit for the outdoor unit (with two brackets, four sets of
screws, nuts and washers)
• BS-AU Network Interface module
• Monitor cable
2.1.3 BS-PS Power Supply (one or two per shelf)
• BS-PS Power Supply module
• Power cable

Basic Installation
BreezeACCESS 2.4 Series 3 BS Equipment Installation Manual
2.2 Packing List – Stand-alone AU-A/E-NI Access Unit
• AU-NI indoor unit
• Outdoor unit:
⇒ AU-RA with integral antenna
or
⇒ AU-RE with a connector to an external antenna (not included)
• AU-PS power supply with a mains power cord
• Pole mounting kit for the Outdoor unit (with two brackets, four sets of
screws, nuts and washers)
• Wall mounting kit for the AU-NI unit
2.3 Other Items Required for Installation
• IF cable (s)* (one for each AU)
• Grounding cable(s) with an appropriate termination (one for each AU)
• Ethernet cable(s) (straight, one for each AU)
• Antenna(s)* and RF cable(s)* (AU-E-NI or AU-E-BS only)
• A portable PC with terminal emulation software
• Installation tools and materials.
Items marked with an asterisk (*) are available as options from BreezeCOM.
2.4 Guidelines for Selection of Equipment Location
Select appropriate locations for the equipment using the following guidelines:
• The outdoor unit can be pole—or wall mounted. Its location should allow
easy access to the unit for installation and testing.
• The AU-RA unit with its integrated antenna, or the external antenna
connected to the AU-RE unit, should be installed where it provides coverage
of all subscriber units in the area it is intended to serve. The higher the AU-
RA or the antenna, the better coverage it can provide.

Basic Installation
BS Equipment Installation Manual 4 BreezeACCESS 2.4 Series
• The AU-RE outdoor unit should be installed as near as possible to its
antenna.
Note: The distance between any two antennas should be greater than 40 cm.
• The outdoor unit is connected to the indoor unit by means of a coaxial IF
cable carrying signals, controls and power. The IF frequency is 440 MHz.
The maximum allowed attenuation of the IF cable is 15dB and its maximum
allowed DC resistance (the sum of the DC resistance of the inner and outer
conductors) is 1.5 ohm. This allows for cable lengths of up to 30m when
using the standard RG 58 cable. If longer cables are required, a cable with
lower attenuation and/or DC resistance should be used.
Table 2-1 provides data regarding several industry-standard cables such as
RG 58 and RG 213. If the spectral environment is polluted with noise in the
440 MHz band, it is recommended to use a higher quality double-shielded
cable such as LMR 240 or LMR 400 (manufactured by Times
Communications).
Table 2-1: IF Cables
Cable Type RG 58 RG 213 LMR 240 LMR 400
Maximum cable
Length (m) 30 100 65 150
• The BS-SH and its modules and the SU-NI are designed for indoor operation,
i.e., inside buildings, a suitable cabinet or a shelter. Air temperature control
might be necessary – the equipment is designed to operate over the
temperature range 0°C to 45°C.

Basic Installation
BreezeACCESS 2.4 Series 5 BS Equipment Installation Manual
Notice:Outdoor units and antennas should be installed ONLY by experienced
installation professionals who are familiar with local building and safety
codes and, wherever applicable, are licensed by the appropriate
government regulatory authorities.
The system complies with EN61000-4-5, level 3, (2kV) standard and is protected
against secondary lightning strikes when its outdoor unit is properly
grounded according to the applicable country-specific industry standards
for protection of structures against lightning. The use of any antenna other than
those certified with this product is forbidden in accordance to FCC rules 15.204.
Failure to do so may void the BreezeACCESS product warranty and may
expose the end user or the service provider to legal and financial liabilities.
BreezeCOM and its resellers or distributors are not liable for injury,
damage or violation of regulations associated with the installation of
outdoor units or antennas.Refer to Appendix C for approved antennas.

Basic Installation
BS Equipment Installation Manual 6 BreezeACCESS 2.4 Series
2.5 Installing the Outdoor Radio Unit
2.5.1 Mounting the Outdoor Unit
The outdoor unit can be secured to the pole using one of the following options:
• Special brackets and open-ended screws (supplied with each unit). There are
two pairs of screw holes on the rear of the unit, allowing use of the brackets
with various pole widths.
• U-bolts - size A (inner installation holes, up to 2" pole).
• U-bolt - size B (outside installation holes, up to 3" pole).
• Metal bands (9/16” wide, minimum 12” long).
Figure 2-1 shows the locations of the U-bolt holes, band grooves and screw holes
on the rear side of the unit.
Figure 2-2 illustrates the method of installing an AU-RE unit on a pole using the
supplied brackets and open-ended screws. The installation of an AU-RA unit
with an integral antenna is very similar to the installation of an SU-RE unit.
Note: Make sure to install the unit with the bottom panel (the panel with the IF
connector) facing downward.
Bracket Screw Holes
Grooves for Insertion of 9/16” Metal Band
Size B U-Bolt Holes (3” Pole)
Size A U-Bolt
Holes (2” Pole)
Figure 2-1. Holes/Grooves/Screw Holes

Basic Installation
BreezeACCESS 2.4 Series 7 BS Equipment Installation Manual
Figure 2-2. AU-RE 3" Pole Mounting Installation Using the
Special Brackets
Note: When inserting the open-ended screws, make sure to insert them with the
grooves pointing outwards; these grooves are intended to allow fastening of
the screws with a screwdriver.

Basic Installation
BS Equipment Installation Manual 8 BreezeACCESS 2.4 Series
2.5.2 Connecting the Antenna Cable (AU-RE)
Connect an RF cable between the ANT connector (located on the top panel of the
unit, marked ANT) and the antenna.
2.5.3 Connecting the Ground and IF Cables
The Ground terminal (marked )and the IF cable connector (marked IF) are
located on the bottom panel of the Outdoor unit, shown in Figure 2-3.
Figure 2-3. AU-RA/AU-RE Radio Unit Bottom Panel
1. Connect one end of the grounding cable to the Ground terminal and connect
the other end to a good ground connection.
2. Connect the coaxial cable to the IF connector. Verify that the length of the IF
cable is sufficient and that it can easily reach the Indoor unit.
Note: Make sure to switch OFF the power of the indoor unit prior to
connecting/disconnecting the IF cable.
Ground
Screw

Basic Installation
BreezeACCESS 2.4 Series 9 BS Equipment Installation Manual
2.6 Installing the Modular Shelf Indoor Equipment
2.6.1 BS-SH Slot Assignments
The Base Station shelf has ten slots, as shown in Figure 2-4
BS-AU
MON
IF
ETH
RESET
OFF
ON
PWR
ALRM WLNK MASTER
BS-AU
MON
IF
ETH
RESET
OFF
ON
PWR
ALRM WLNK MASTER
BS-AU
MON
IF
ETH
RESET
OFF
ON
PWR
ALRM WLNK MASTER
BS-AU
MON
IF
ETH
RESET
OFF
ON
PWR
ALRM WLNK MASTER
BS-AU
MON
IF
ETH
RESET
OFF
ON
PWR
ALRM WLNK MASTER
BS-AU
MON
IF
ETH
RESET
OFF
ON
PWR
ALRM WLNK MASTER
Figure 2-4. Shelf Slot Assignments
The two wide slots on the both sides of the shelf accommodate the BS-PS power
supply modules. The shelf is designed to support power supply redundancy
through the use of two Power Supply modules. If a single power supply is used,
it can be inserted in any of the two available slots.
The remaining eight slots can accommodate up to six active BS-AU modules.
Two extra slots are for future use. Active BS-AU modules can be installed in any
of the 8 slots. Unused slots should be covered by blank panels.
8 Middle slots - BS-AU modules
Extreme slots - Power Supply modules

Basic Installation
BS Equipment Installation Manual 10 BreezeACCESS 2.4 Series
2.6.2 The BS-AU
The BS-AU front panel is shown in Figure 2-5.
BS-AU
MON
IF
ETH
RESET
OFF
ON
PWR
ALRM WLNK
MASTER
Figure 2-5. BS-AU Front panel
The BS-AU provides the following interfaces:
An Ethernet connector (ETH) for connecting the BS-AU to the network. This
connector should be connected to a straight Ethernet cable.
An IF connector for connecting the BS-AU to an outdoor AU-RE or AU-RA
radio unit. The outdoor radio unit provides the air link between the BS-AU and
the remote Subscriber Units.
A MON connector for connecting an ASCII terminal with terminal emulation
software for configuration and maintenance purposes.

Basic Installation
BreezeACCESS 2.4 Series 11 BS Equipment Installation Manual
The BS-AU front panel LEDs are described in Table 2-2.
Table 2-2: BS-AU LEDs
Name Description Functionality
PWR Power supply
12 VDC On – 12 VDC power is supplied to AU-RE Off – 12 VDC power is not supplied to AU-RE
WLNK Wireless link
activity Blinking –Receiving packet from the wireless link Off – No reception of packets from the wireless
link
ALRM ALARM
Indication On – Loss of hopping synchronization (slave units)
MASTER Master
Indication On – The unit is configured as a Master
ETH
connector
embedded
LED
Ethernet
activity On- Receive/Transmit on Ethernet port Off- No Receive/Transmit on Ethernet port
ETH
connector
embedded
LED
ETH Link
Integrity On- Unit is connected to Ethernet segment Off- Unit is not connected to Ethernet segment
The switch on the BS-AU front panel controls the supply of 12 VDC power to
the outdoor unit via the IF cable. The momentary RESET position of this switch
is for resetting the outdoor unit. In the OFF position, power is not supplied to the
outdoor unit, even when the BS-AU unit is still ON.

Basic Installation
BS Equipment Installation Manual 12 BreezeACCESS 2.4 Series
2.6.3 The BS-PS
The BS-PS provides power to all the modules installed in the BS-SH rack. The
BS-PS front panel is shown in Figure 2-6.
BS-PS
OFF
ON
-48V
12V
5V
ON
PWR
Figure 2-6. BS-PS Front Panel
The BS-PS provides a single connector (marked -48V) for connecting the -
48VDC power source to the module. The color codes of the cable wires are:
black -48VDC
red + (Return)
The switch turns the mains power to the power supply ON and OFF.
Table 2-3: BS-PS Power Supply LEDs
Name Description
ON -48 VDC is available and Power Supply is ON
5V The 5V power supply module is OK
12V The 12V power supply module is OK
