Breville Smart Dry Ultimate LAD500 User manual

the Smart Dry Ultimate™Dehumidifier
Instruction Book - LAD500
LAD500_ANZ_IB_C19.indd 1 8/4/19 1:38 pm

2
2 Breville Recommends Safety First
6 Components
7 Control Panel
8 Features
8 Assembly
9 Functions
13 Care, Cleaning & Storage
16 Troubleshooting
Contents
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition, we ask that
you exercise a degree of care
and adhere to the following
precautions.
IMPORTANT
SAFEGUARDS
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
• Carefully read all instructions
before operation and save for
future reference.
• Remove and safely discard
any packaging material and
promotional labels from both
the dehumidifier and the air
filter before using for the first
time.
• To eliminate a choking
hazard for young children,
remove and safely discard
the protective cover fitted
to the power plug of this
dehumidifier.
• When unpacking the
dehumidifier, check to see
you have received all the
items listed in the parts
list before discarding the
packaging.
• The dehumidifier is intended
for household use only
and not for commercial or
industrial use. Do not use
outdoors.
• Always ensure the
dehumidifier is properly
assembled before use.
Follow the instructions
provided in this booklet.
• Do not place the dehumidifier
near the edge of a bench
or table during operation.
Ensure the surface is level,
clean and free of water.
• Do not run the cord under
carpeting or cover the cord
with rugs, runners or the like.
Arrange the cord away from
LAD500_ANZ_IB_C19.indd 2 8/4/19 1:38 pm

3
traffic areas and where it will
not be tripped over.
• Do not route the power cord
under furniture or appliances.
• To protect against electrical
hazards, do not immerse any
part of the dehumidifier in water
or other liquids. Do
not use the dehumidifier in the
immediate surroundings of a
bath, shower or
swimming pool.
• Water in the water tank is
not suitable for drinking.
Do not drink this water, and do
not serve to animals or use to
water the plants. Pour the water
down a drain.
• Always turn off and unplug the
dehumidifier before moving,
removing the water tank,
changing filters, cleaning or
whenever the dehumidifier
is not in use.
• Do not unplug the dehumidifier
by pulling on the cord. Use the
plug to disconnect.
• Never insert fingers, pencils or
any other objects through the
grilles whenever the power plug
is connected, in particular while
the dehumidifier is switched on.
• Do not operate the dehumidifier
with a damaged cord or plug,
or if the dehumidifier has
been dropped or damage
in any manner, return the
dehumidifier to your nearest
Breville service centre for
examination, electrical
or mechanical adjustment
or repair.
• Do not use the dehumidifier
with an external timer,
programmer or any other
device that switches
the dehumidifier on
automatically since a fire risk
may exist if the dehumidifier
is covered or positioned
incorrectly.
• Do not place anything on
top of the dehumidifier when
assembled, when in use and
when stored.
• Never block the air openings,
grilles and outlets, or place on
a soft surface such as a bed or
sofa as this could cause the
unit to tip over, blocking the
air inlet or outlet.
• Do not attempt to repair or
adjust any electrical or
mechanical functions on
this unit. Doing so will
void your warranty. The
inside of the unit contains
no user serviceable parts.
All servicing should be
performed by qualified
personnel only.
• If the dehumidifier ever tips
or falls over when the water
reservoir is full, immediately
unplug the power cord.
LAD500_ANZ_IB_C19.indd 3 8/4/19 1:38 pm

4
Ensure the unit is dried
thoroughly before resuming
operation.
• Keep the dehumidifier and
dust filters clean. Follow
the cleaning instructions
provided in this book.
Dehumidification
Capacity ^
30 Litres/day (30°C 80%)
15 Litres/day (27°C 60%)
Product Dimension 370x250x585mm
Water Capacity 4L
For Room Size Up to 80m²
Noise Level 51dBa
Power
Consumption
510W
Weight 15kg
Refrigerant R134a (165g)
^ Without the air filter
IMPORTANT
SAFEGUARDS
FOR ALL
ELECTRICAL
APPLIANCES
• Fully unwind the power cord
before use.
• Connect only to a 230V or
240V power outlet.
• Do not let the power cord
hang over the edge of a
bench or table, touch hot
surfaces or become knotted.
• To protect against electric
shock, do not immerse the
power cord, power plug or
appliance in water or any
other liquid or allow moisture
to come in contact with the
part, unless it is recommended
in the cleaning instructions.
• The appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
• Children should be supervised
to ensure that they do not play
with the appliance.
• It is recommended to
regularly inspect the
appliance. To avoid a hazard,
do not use the appliance if
power cord, power plug or
appliance becomes damaged
in any way. Return the entire
appliance to the nearest
authorized Breville Service
Centre for examination
and/or repair.
• Any maintenance other than
cleaning should be performed
at an authorised Breville
Service Centre.
• This appliance is for
household use only.
Do not use this appliance
for anything other than its
intended use. Do not use in
LAD500_ANZ_IB_C19.indd 4 8/4/19 1:38 pm

5
moving vehicles or boats.
Do not use outdoors.
Misuse may cause injury.
• The installation of a residual
current device (safety switch)
is recommended to provide
additional safety protection
when using electrical
appliances. It is advisable that
a safety switch with a rated
residual operating current not
exceeding 30mA be installed
in the electrical circuit
supplying the appliance.
• See your electrician for
professional advice.
• During electrical storms,
the appliance should be
disconnected from the power
source at the wall socket
to prevent any electrical
surges that may arise during
the storm and which may
inadvertently cause damage
to the appliance and its
electronic componentry.
• Always turn the appliance to
the off position, switch off at
the power outlet and unplug
at the power outlet when the
appliance is not in use.
• Before cleaning, always turn
the appliance to the off
position, switch off at the
power outlet, unplug at the
power outlet and remove the
power cord, if detachable,
from the appliance and allow
all parts to cool.
• Do not place this appliance
on or near a heat source, such
as hot plate, oven or heaters.
• Position the appliance at a
minimum distance of 20cm
away from walls, curtains and
other heat or steam sensitive
materials and provide
adequate space above and
on all sides for air circulation.
WARNING
To avoid electric shock, do not
connect the plug to the power
outlet when hands are wet.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
LAD500_ANZ_IB_C19.indd 5 8/4/19 1:38 pm

6
Components
A. Control Panel
B. Carry Handle
C. Air Outlet
D. Water Tank Handle
E. Water Tank Cover
F. Water Tank
G. Wheels
H. Housing Body
I. Air Inlet and Filter
J. Continuous Drainage Outlet (with Plug)
K. Pump Drainage Outlet
L. Cord Storage
Not Pictured
Air Filter
Dust Filter
Carbon Filter
Pump Drainage Hose (8m)
Pump Outlet Clip
Pump Suction Hose (20cm)
Pump Suction Joint
Drainage Hose (gravity-assisted)
Power Cord
Water Level Sensor
A
B
C
D
J
I
K
L
H
E
F
G
Front Back
LAD500_ANZ_IB_C19.indd 6 8/4/19 1:38 pm

7
CHILD LOCK
NIGHT
HUMIDITY SETTING MODE
TIMER SPEED
LOW HIGH
PUMP
%
Control Panel
A. Humidity Setting
B. Child Lock
C. Night Mode
D. Timer
E. Pump On/Off
F. Mode
G. Power On/Off
H. Fan Speed
I. Display Screen
C
D
E
G
F
H
I
A
B
Display Screen Icons & Lights
Auto Dehumidification
Continuous Dehumidification
Laundry
Ventilation
Pump
Relative Humidity Level (%)
Empty Me Light
Defrost Light
LAD500_ANZ_IB_C19.indd 7 8/4/19 1:38 pm

8
WHAT IS A DEHUMIDIFIER?
Your Breville dehumidifier is designed to
reduce and maintain the level of humidity in
the air as well as to prevent condensation and
mildew on the ceilings and walls.
HOW DOES A DEHUMIDIFIER WORK?
Your Breville dehumidifier regulates the
relative humidity of your home by drawing
moist, humid air from the surrounding area
and passing it over cooled evaporator coils
causing the moisture to condense into water.
The water is dispensed into the water tank or
drainage hose, while the now non-humid air is
re-warmed and passed back into the room.
WHAT IS RELATIVE HUMIDITY?
Relative humidity is the amount of water
vapour in the air and it is commonly expressed
as a percentage of the maximum amount of
water vapour that the air can hold at a given
temperature. A comfortable %RH level is
commonly considered to be between
40-60%RH.
Assembly
BEFORE FIRST USE
1. Before using your dehumidifier for the
first time, remove and safely discard any
packaging material or promotional labels
attached to your air dehumidifier and air
filter.
2. Check for any missing or damaged parts as
per the components list.
3. Remove the air inlet grille and air filter
as per the Filter Cleaning & Replacement
section of this book. Remove all packaging
material from the air filter. Ensure the
air filter and the air inlet grille are fitted
correctly onto the dehumidifier before
operating.
4. Clean all parts according to the Care,
Cleaning & Storage section in this book.
5. Use the carry handles and wheels to move
the dehumidifier.
6. Position the dehumidifier away from walls,
furniture and other appliances as per the
illustration below.
7. Ensure that all filters, grilles, water tank and
drainage hose (if applicable) are correctly
installed before use.
8. Connect the power plug to a 230V or 240V
outlet and switch the outlet on.
Up: 30cm or more
Right & Left: 20cm
or more
Back & Front:
20cm or more
WARNING
Before first use, remove the packaging from
the air filter stored behind the air inlet grille
in the back of the dehumidifier (See the Care,
Cleaning & Storage section of this book).
Features
LAD500_ANZ_IB_C19.indd 8 8/4/19 1:38 pm

9
Functions
USING YOUR BREVILLE
DEHUMIDIFIER
1. To operate the dehumidifier, press the
POWER button.
2. The icon for the last mode used will
illuminate on the control panel. Another
mode can be selected if desired.
3. If in Auto mode, adjust the humidity level if
desired (see Humidity Setting).
4. The dehumidifier will start to operate within
5 seconds.
5. Press the POWER button again to turn off.
NOTE
The dehumidifier cannot operate if the water
tank is full or is not installed correctly.
TO SELECT ONE OF THE FOUR
OPERATING MODES:
Press the MODE button on the control
panel until the corresponding icon flashes on
the display screen.
AUTO MODE
The dehumidifier will operate to reach, then
maintain, the humidity setting.
CONTINUOUS MODE
The dehumidifier will operate on Low speed
until it is manually turned off.
LAUNDRY MODE
Laundry mode operates at High speed and a
Low humidity setting. This assists with drying
wet clothes faster when hanging indoors. It is
also useful in drying wet carpets or rugs.
The chosen mode will start within 5 seconds
of selection.
VENTILATION MODE
Circulates ambient air without
dehumidification.
NOTE
This dehumidifier produces heat during
operation which may cause room temperatures
to rise by 1°C to 4°C, especially if used in an
enclosed space.
SENSAIR™ LIVE HUMIDITY CONTROL
• Your Breville Smart Dry Ultimate™
Dehumidifier has a built-in sensor to detect
changes in the humidity level in the air.
• The SensAir ™ live humidity indicator light
will change colour according to the relevant
humidity (%).
• The LED screen provides real-time indication
of the relative humidity in the air.
%HUMIDITY LEVEL
When the dehumidifier is turned on, the
current humidity level (%) will show on the
display screen and the % icon will illuminate.
This number will adjust as the dehumidifier
operates.
The Humidity Setting allows you to manually
set the relative humidity level (%RH) between
30% - 80% (in 5% increments), when the unit is
operating in Auto mode only.
1. Press the %HUMIDITY SETTING
button to increase the humidity level in 5%
increments with each press. Stop once the
desired humidity level is displayed.
FAN SPEED
In both Auto and Ventilation modes, the Fan
Speed can be manually selected.
1. Press the FAN SPEED button to select
between Low or High. The light will
illuminate under the selected speed.
NOTE
The fan will only operate on Low speed in
Continuous mode and on High speed in
Laundry mode.
LAD500_ANZ_IB_C19.indd 9 8/4/19 1:38 pm

10
NIGHT MODE
The Night mode will automatically turn off all
lights on the control panel (except the Night
button light) and operate in the last setting.
1. Press the NIGHT button on the control
panel.
2. Within 5 seconds, the lights on the
control panel will turn off, except the
NIGHT button.
3. Press once to view current humidity level.
4. Press the NIGHT button twice to exit
Night mode.
TIMER
The Timer operates in two ways.
• Auto Off, where the timer determines when
to turn the unit OFF, can be set when the
dehumidifier is turned on.
• Delayed Start, where the timer determines
when to turn the unit ON, can be set when
the dehumidifier is turned off.
1. Press the TIMER button.
2. The display screen will flash ‘00’ and the
will illuminate.
3. Press the TIMER button to increase the
time in one-hour increments, up to
24 hours.
4. The time will countdown each hour,
automatically turning the dehumidifier ON
or OFF when it reaches ‘00’.
5. To cancel Auto Off or Delayed Start, press
the POWER button or continue to press
the TIMER button until it reaches '00'.
NOTE
On Delayed Start, dehumidification mode can
be set after the delayed start time has been
entered by following the steps on page 9.
WARNING
As a safety feature, the dehumidifier will
automatically turn off if the water tank is full,
even if the countdown timer has not reached
‘00’. The dehumidifier will not turn on in
Delayed Start if the water tank is full.
CHILD LOCK
When the Child Lock is engaged, the buttons
on the control panel are locked from use.
1. To turn on, press and hold the CHILD
LOCK button until a beep sounds and the
light above the button illuminates.
2. To cancel, repeat step 1 until the light above
the button turns off.
WATER DRAINAGE
During the process of dehumidification, water
is created and needs to be expelled from the
dehumidifier. This dehumidifier offers three
options to drain the water.
REMOVABLE WATER TANK
(with Empty Me warning)
The removable water tank will collect water
until it reaches the water level sensor when the
tank is full. Once full, the EMPTY ME light
on the control panel will illuminate red and the
dehumidifier will cease dehumidification until
the water tank is emptied.
1. Remove the water tank as per the water tank
cleaning instructions in the Care, Cleaning &
Storage section of this book.
NOTE
The dehumidifier will not operate if the tank
is not installed correctly, even if the drainage
hose is in use.
WARNING
Water from the dehumidifier is not suitable for
drinking. Do not drink this water, and do not
serve it to animals or use to water plants.
CONTINUOUS DRAINAGE
(hose drainage using gravity)
The continuous drainage outlet allows water to
drain without having to monitor and empty the
water tank. Ensure the hose (included) is properly
inserted before starting the dehumidifier.
LAD500_ANZ_IB_C19.indd 10 8/4/19 1:38 pm

11
1. Locate the continuous drainage outlet
on the back, right hand side of the
dehumidifier, underneath the air inlet grille.
Remove the plug and insert one end of the
hose over the connection outlet, pushing in
as far as possible.
Pull out the plug
2. As the drainage is dependent on gravity for
the dehumidifier to drain correctly, no part
of the hose should sit higher than the hose
connection outlet.
3. Place the other end of the hose into a
water drain, being careful that it cannot
inadvertently come loose when water starts
to drain.
4. The water will drain from the dehumidifier
directly through the hose.
WARNING
Ensure the hose is secure in both the hose
connection and the drainage outlet and into
the water drain.
NOTE
Ensure the plug is placed back onto the
continuous drainage outlet securely when
continuous drainage is not in use.
PUMP DRAINAGE
Pump drainage allows the dehumidifier
to empty the water tank using the hose to
pump the water out of the tank when full.
This is suitable for homes where there is
a drain available within the vicinity of the
dehumidifier. It is also suitable for homes
that have drainage sources higher than the
dehumidifier, such as a sink drain, as the pump
does not rely on gravity to empty the water
tank. Ensure the hoses (included) are properly
inserted before turning on the dehumidifier.
Note, the pump suction hose can already be
found in the unit, secured in place.
1. Pull the water tank half way out from the
back of the dehumidifier.
2. Ensure that one end of the 20cm pump
suction hose is in the water tank, through
the slot located in the tank lid (see
illustration below) and that it hits the
bottom of the tank.
The pump suction
hose is inserted into
the water.
3. Locate the pump suction joint on the
right hand side between the tank and the
dehumidifier body. Ensure the other end of
the pump suction hose is securely over the
suction joint.
The other end is connected
to the suction joint.
4. Fit the water tank back into the
dehumidifier, ensuring both ends of the
20cm hose piece remain securely in place.
LAD500_ANZ_IB_C19.indd 11 8/4/19 1:38 pm

12
5. Locate and remove the blue pump outlet
clip from the drainage outlet on the
opposite side of the dehumidifier, and set
aside for later use. Insert one end of the
8m pump drainage hose into the pump
drainage outlet, ensuring the hose is pushed
in as far as possible.
Remove the blue
pump outlet clip
NOTE
Keep the blue outlet pump clip in a safe place
for future use if the pump drainage is no
longer required.
NOTE
If the 8m hose is too long, it can be cut to the
desired length.
6. Place the other end of the drainage hose
into a drainage source such as a bathroom
floor drain or laundry sink.
7. Press the PUMP button to start pump
drainage and the PUMP ON light will
illuminate on the control panel. The pump
will enter standby mode and will only drain
once the water tank is full. The pump will
stop draining after 15 minutes. This cycle
will continue each time the tank is full.
NOTE
If at any time the pump needs to be activated
manually during dehumidification, press and
hold the PUMP button for 5 seconds and
the pump will automatically begin and run for
8 minutes, then turn off.
8. If pump drainage is no longer required,
hold the PUMP button down until
the PUMP ON light is off. Ensure the
dehumidifier is switched off and unplug
from the power outlet.
9. Remove the drainage hose from the rear of
the unit.
10. Replace the blue pump outlet clip, placing
it between the ring and base of the
pump outlet.
DEFROST
This dehumidifier is equipped with an
automatic defrost function. The evaporator
may start auto-defrosting if operating in a
room temperature that is less than 23°C.
1. If the DEFROST light turns on,
defrosting has automatically started. The
fan will operate on HIGH during defrost
and dehumidification will stop.
2. Automatic defrost will operate for up to
5 minutes.
WARNING
Do not disconnect the plug or turn
off the unit during defrost operation.
LAD500_ANZ_IB_C19.indd 12 8/4/19 1:38 pm

13
Care, Cleaning
& Storage
WARNING
Before cleaning or maintenance of the
dehumidifier, ensure the power is switched
off at the outlet, and the plug is removed.
CLEANING YOUR DEHUMIDIFIER
1. Keep the unit upright when cleaning.
2. Wipe the dehumidifier housing, control
panel, air inlet and outlet grilles with a soft,
dry cloth.
3. To remove dirt that has built-up heavily, wipe
with a slightly damp cloth only.
WARNING
Do not clean the control panel with a damp
cloth. Do not clean the unit with gasoline,
thinner or liquid detergent to avoid deformation
and fission of the unit. The cloth may contain
chemicals which may change the colour of the
dehumidifier.
NOTE
Using a brush may scratch the dehumidifier.
Do not use any objects that may scratch the unit.
WATER TANK CLEANING
NOTE
The dehumidifier cannot operate if the tank is
full or is not installed correctly. Clean the water
tank once a week if used regularly.
1. Remove the water tank from the front of
the dehumidifier by holding the sides and
pulling outwards.
2. Leaving the water tank cover in place, run
tap water into the tank using the holes in the
cover. Swish the water around the tank then
tip to empty.
3. Wipe the outside of the water tank with a
soft, dry cloth before replacing.
WATER LEVEL SENSOR
The water level sensor is situated in a chamber
found in the corner of the water tank and is held
in place by the water tank cover (see illustration
below). The sensor rises and falls with the level
of the water, and should not be removed as it
will prevent the dehumidifier from operating.
If the sensor inadvertently falls out of the water
tank during cleaning, replace it back into the
sensor chamber, ensuring the magnetic strip
faces inside towards the dehumidifier.
Do Not
Remove
FOR A MORE THOROUGH CLEANING OF
THE WATER TANK:
1. Remove the water tank from the
dehumidifier.
2. Tip any water out of the tank into a sink
or drain.
3. Place the tank on a dry, level surface. Flip
the handle on the water tank cover until the
grooves in the handle match the grooves in
the handle holders. Pull outwards on both
sides of the handle to disengage.
4. Once the handle has been removed, carefully
pull upwards on either side of the tank cover.
Remove the cover.
5. Rinse the inside of the water tank with warm,
soapy water, then rinse well with clean water.
During cleaning, be careful to keep the water
level sensor in place or replace if it comes out
of the tank (see Water Level Sensor).
6. Once clean, fit the cover back onto the
water tank, and replace the handle.
7. Wipe the outside of the water tank with
a soft, dry cloth before replacing into the
dehumidifier.
LAD500_ANZ_IB_C19.indd 13 8/4/19 1:38 pm

14
WARNING
Water in the water tank is not suitable for
drinking. Do not drink this water, and do not
serve to animals or use to water plants.
FILTER CLEANING AND REPLACEMENT
The air inlet grille at the back of the
dehumidifier also acts as the filter holder.
The filter holder includes a mesh pre-filter
to capture dust and pet dander, and a black
carbon filter to help reduce odours and smoke.
WARNING
It is important to keep the filter clean as
a dirty filter may cause a reduction in the
dehumidifier's performance.
NOTE
Clean the filter at least monthly, or more often
if in frequent use.
DUST & CARBON FILTER FREQUENT
CLEANING
1. Remove the air inlet grille from the back of
the unit.
2. With the dust filter and carbon filter still
attached to the air inlet grille, use a hand-
tool on a vacuum cleaner (such as a brush
or upholstery tool) to clean both sides.
Alternatively, lightly tap the grille over a
garbage receptacle to loosen the dust.
3. Replace the air inlet grille onto the
dehumidifier, inserting the bottom of the
grille first, then the top. Ensure the grille
clicks into place correctly before using the
dehumidifier.
DUST & CARBON FILTER HEAVY-
DUTY CLEANING
If dirt and dust has built up, and a simple clean
(as instructed above) does not remove all the
debris, it is recommended that the filters be
separated for cleaning.
1. Remove the air inlet grille from the back of
the unit using the grooves on either side of
the holder and pulling outwards.
2. Separate the dust filter from the grille.
3. The black carbon filter sits between the air
inlet grille and the mesh dust filter as per
the illustration below. Separate this filter
and set aside.
4. Use a hand-tool on a vacuum cleaner (such
as a brush or upholstery tool) to clean the
dust from the filters, or tap the filter lightly
over a garbage receptacle to loosen the dust
from the filter.
5. If the dirt and dust has built up on the mesh
dust filter, hand wash in warm, soapy water,
then rinse well and dry before replacing.
WARNING
Never wet the carbon filter. This filter can be
cleaned by simply tapping over a garbage
receptacle.
6. Re-assemble the carbon filter and dust filter
back on to the air inlet grille.
7. Replace the air inlet grille onto the
dehumidifier, inserting the bottom of the
grille first, then the top. Ensure the grille
clicks into place correctly before using the
dehumidifier.
LAD500_ANZ_IB_C19.indd 14 8/4/19 1:38 pm

15
AIR FILTER CLEANING
The air filter sits within a cavity at the back of
the dehumidifier and is held in place by the air
inlet grille.
NOTE
A dirty filter may reduce the performance of
the dehumidifier. Clean regularly.
1. Remove the air inlet grille to access the air
filter. Use a hand-tool on a vacuum cleaner
(such as a brush or upholstery tool) to clean
both sides of the filter.
Air Filter
Dust Filter
Carbon
Filter
Air Inlet
Grille
2. The air filter should be replaced every
6 months, depending on frequency of use.
AIR FILTER REPLACEMENT
Your Smart Dry Ultimate™ Dehumidifier air
filter should be replaced in the time frames
indicated below.
• The filter life is approximately 6 months if
used 24 hours daily, or 12 months if used
12 hours daily.
• The filter life may vary to this timing,
depending on environmental conditions.
• Remove all packaging from the replacement
filter and place the filter into the unit as
described below.
1. Remove the air inlet grille to access the air
filter.
2. Remove the used air filter, being careful that
any residue or debris that may fall from the
filter does not cause damage.
3. Remove the new air filter from the
packaging material.
4. Place the new filter into the dehumidifier,
then replace the air inlet grille back onto
the dehumidifier to hold in place before
operating.
NOTE
If the filter is not in place or not fitted correctly,
the dehumidifier will not operate effectively
and may cause damage to the dehumidifier.
NOTE
The air filter has no front or back, top or
bottom and can be placed in the dehumidifier
either way.
REPLACEMENT FILTERS
Replacement filters can be purchased from
the Breville website^ or at participating retail
outlets.
See the table below for the replacement
product code to suit this Breville Dehumidifier.
Breville Dehumidifier
Model No.
Filter Replacement
Product Code
LAD500WHT LAD050GRY
^Delivery charges may apply.
Please contact Breville Customer Service
Centre for further support.
Only use the original Breville filter specially
intended for this appliance. Do not use any
other filters.
STORAGE
1. Disconnect the dehumidifier from the
power outlet.
2. Ensure the water tank is empty and cleaned
as per instruction.
3. Clean the dehumidifier as per instructions.
4. Wrap the power cord around the cord
storage on the back of the unit.
5. Store the dehumidifier upright and avoid
standing in direct sunlight if leaving for
long periods.
6. Never store anything on top of the
dehumidifier.
LAD500_ANZ_IB_C19.indd 15 8/4/19 1:38 pm

16
Troubleshooting
TROUBLESHOOTING GUIDE
Before carrying out any of the following service checks, unplug the unit from the power outlet.
PROBLEM POSSIBLE CAUSES WHAT TO DO
Dehumidifier not
working. • Power plug is disconnected.
• The tank is full of water.
• The tank is not in the right
position.
• Plug the power cord into the power socket.
• Empty the water tank.
• Position the water tank correctly in the unit.
Dehumidification has
reduced in power. • The filter is too dirty.
• The air inlet or outlet are
blocked.
• Clean the filter.
• Remove the object that is blocking the air
inlet or outlet.
Loud noises coming
from the dehumidifier. • The dehumidifier is on an
uneven surface. • Position the dehumidifier on a smooth and stable surface.
The dehumidifier
suddenly stops. • The room humidity level may
be outside of the radar of the
dehumidifier.
• The dehumidifier will start again
automatically when it can read the room
humidity level again.
Clothing dries
very slowly. • The room temperature is
too low.
• The wet clothes are not
exposed to the air from the
unit.
• If the room temperature is too low, the
clothing will dry slower than usual.
• Place the wet clothes closer to the unit so
they are exposed to the air flow.
No reduction of
humidity in the room. • The room is too large for the
unit’s scope.
• Doors and windows in the
room are open.
• Move to a smaller room.
• Close any doors or windows in the room.
WARNING
This dehumidifier uses a refrigerant compressor. The noise from the compressor turning off and
on during operation is normal.
LAD500_ANZ_IB_C19.indd 16 8/4/19 1:38 pm

17
TROUBLESHOOTING GUIDE
Possible issues not related to the dehumidifiers performance.
ISSUE REASON
Unit occasionally stops working. • The unit is defrosting. The unit will start again once
defrosting is finished.
Reduction in dehumidification
strength. • Dehumidification reduces in strength when the room
temperature is too low. The unit may stop operating when the
room temperature is too low. The dehumidifier stops operating
when the humidity level in the room drops below the set
humidity level during the Auto Dehumidification mode.
There is a bad smell while on. • The smell may come from the walls, furniture or other
household objects.
Sound is coming from within the
dehumidifier. • Circulation of the refrigerant may cause sound until the
unit is stable.
The buzzer sounds. • This happens when the water tank is full.
ERROR CODES
ERROR CODE POSSIBLE CAUSES WHAT TO DO
E2 is on the display
screen. The humidity sensor is not working. Contact Breville customer service.
E3 is on the display
screen. There is damage to the automatic defrost sensor. Contact Breville customer service.
E6 is on the display
screen. The pump is not working. Contact Breville customer service.
LAD500_ANZ_IB_C19.indd 17 8/4/19 1:38 pm

Notes
LAD500_ANZ_IB_C19.indd 18 8/4/19 1:38 pm

19
Notes
LAD500_ANZ_IB_C19.indd 19 8/4/19 1:38 pm

Australian Customers
Phone: [phone]
Web: www.breville.com
New Zealand Customers
Phone: [phone]
Web: www.breville.com
Breville Customer Service Centre
Breville, the Breville logo, Master Every Moment, Smart Dry Ultimate and SenSair
are trademarks of Breville Pty. Ltd. A.B.N. 98 000 092 928.
Copyright Breville Pty. Ltd. 2019.
Due to continued product improvement, the products illustrated/photographed in this booklet
may vary slightly from the actual product.
LAD500 ANZ C19
LAD500_ANZ_IB_C19.indd 20 8/4/19 1:38 pm
