SMC Networks IDFC60-23 User manual

IDX-OM-U010-D
PRODUCT NAME
Refrigerated Air Dryer
MODEL / Series
IDFC60-23-C,L,R,T,V
IDFC70-23-C,L,R,T,V
IDFC80-23-C,L,R,T,V
IDFC90-23-C,L,R,T,V
Please read this manual prior of using the air dryer.
Keep the manual readily available for reference.

To Customers
Thank you for selecting SMC Refrigerated Air Dryer.
This operation manual must be read and understood thoroughly before using the product. It provides all
essential information pertaining to safety, as well as, maximizing product efficiency in order to extend the
life of the product.
In addition, it is strongly recommended that you follow all the safety guidelines and regulations set forth by
the local government agency for proper installation and usage.
This manual explains about installation and trial operation of the product. These tasks should be
performed only by individuals with the proper training and have a good understanding of the air dryer.
For safety and long life of the product, be sure to read this operation manual (hereinafter referred to as the
“manual”) and clearly understand the contents.
There is no production amends or financial compensation due to dryer’s trouble.
This manual contains confidential information proprietary to SMC.
It must not be reproduced or disclosed to others, or used in any other way, in part or in whole, except as
authorized in writing by SMC.
Note: The contents of this operation manual are subjected to change without prior notice.

IDX-OM-U010
Contents
IDFC60/70/80/90 Series
Contents
Chapter 1 Safety Instructions...........................................................1-1
1.1 Before Using Air Dryer............................................................................................ 1-1
1.1.1 Danger, Warning, and Caution Used in This Manual.......................................................... 1-1
1.2 Hazard Classifications & Position of Hazard warning Labels.............................. 1-2
1.2.1 Hazard of Electricity ............................................................................................................ 1-2
1.2.2 Hazard of Hot Surface......................................................................................................... 1-2
1.2.3 Danger of Compressed Air Circuit....................................................................................... 1-2
1.2.4 Positions of Hazard Warning Labels................................................................................... 1-3
1.2.5 Model no. Label................................................................................................................... 1-4
1.3 Disposal................................................................................................................... 1-5
1.4 Limited warranty and Disclaimer / Compliance Requirements ............................ 1-6
Chapter 2 Parts Name and Functions ..............................................2-1
2.1 Parts Name and Functions ..................................................................................... 2-1
Chapter 3 Transportation/Installation...............................................3-1
3.1 Transportation ......................................................................................................... 3-1
3.2 Installation ............................................................................................................... 3-2
3.2.1 Location............................................................................................................................... 3-2
3.2.2 Anchorage........................................................................................................................... 3-2
3.2.3 Air piping.............................................................................................................................. 3-3
3.2.4 Auto Drain tube ................................................................................................................... 3-4
3.2.5 Electric Wiring ..................................................................................................................... 3-5
3.3 Cautions for Reinstallation..................................................................................... 3-7
Chapter 4 Operation/Shutdown........................................................4-1
4.1 Check points before operation............................................................................... 4-1
4.2 Operation................................................................................................................. 4-1
4.3 Shutdown................................................................................................................. 4-2
4.4 Cautions about restart ............................................................................................ 4-2
4.5 Check points before restart.................................................................................... 4-2
4.6 Precautions for long-term non-operation.............................................................. 4-2
Chapter 5 Maintenance .....................................................................5-1
5.1 Daily Inspection....................................................................................................... 5-1
5.2 Periodical Maintenance........................................................................................... 5-2
5.2.1 Cleaning of dust proof filter ................................................................................................. 5-2
5.2.2 Cleaning of Auto Drain ........................................................................................................ 5-2
Chapter 6 Troubleshooting...............................................................6-1
6.1 Cause and countermeasure of errors.................................................................... 6-1
6.2 How to reset the thermal relay and high pressure switch.................................... 6-4

IDX-OM-U010
Contents
IDFC60/70/80/90 Series
Chapter 7 References ....................................................................... 7-1
7.1 Specifications...........................................................................................................7-1
7.2 Refrigerant with GWP reference .............................................................................7-2
7.3 Dimensions ..............................................................................................................7-3
7.4 Electrical Circuit.......................................................................................................7-4
7.5 Compressed Air and Refrigerant Circuit/Option Principles..................................7-5
Chapter 8 Specification for Option C............................................... 8-1
8.1 Specifications...........................................................................................................8-1
8.2 Precautions for the installation and handling of the product ...............................8-1
Chapter 9 Specification for Option L ............................................... 9-1
9.1 Safety instructions...................................................................................................9-1
9.2 Specifications...........................................................................................................9-1
9.3 Installation of heavy duty auto drain......................................................................9-2
9.4 Maintenance.............................................................................................................9-2
Chapter 10 Specification for Option R............................................. 10-1
10.1 Safety instructions.................................................................................................10-1
10.2 Specifications of GFCI...........................................................................................10-1
10.3 How to connect the power supply........................................................................10-2
Chapter 11 Specification for Option T ..............................................11-1
11.1 Safety instructions.................................................................................................11-1
11.2 Running and error signals.....................................................................................11-1
11.3 Remote operation ..................................................................................................11-2
11.4 How to connect the power supply and signal cable............................................11-3
11.5 Electric circuit........................................................................................................11-4
Chapter 12 Specification for Option V............................................. 12-2
12.1 Safety instructions.................................................................................................12-2
12.2 Specifications.........................................................................................................12-2
12.3 How to perform maintenance................................................................................12-3
Chapter 13 Service Record............................................................... 13-1
13.1 Service Record.......................................................................................................13-1

IDX-OM-U010
Chapter 1 Safety Instructions
IDFC60/70/80/90 Series 1.1 Before Using Air Dryer
1-1
Chapter 1 Safety Instructions
1.1 Before Using Air Dryer
In this chapter, the stated contents are especially about safety.
This Air Dryer is installed downstream of the air compressor to remove moisture. The manufacturer
is not responsible for any misuses or misapplications.
This Air Dryer operates with high voltage and hot surfaces during operation. In addition, this air
dryer has high speed rotating fan and motor, which can cause serious injury upon accidental contact.
It is advised that you contact the factory or SMC authorized dealer for spare parts or other servicing
needs.
We strongly recommend that any one who is working with this air dryer need to read and understand
the instructions in this manual beforehand. Often, it’s necessary for the people involved, to receive
training in order to address the issues of safety and proper application.
When short period power shortage (including instantly recovered shortage) is recovered, it may take a
longer starting period than usual starting or may not start due to the protective devices.
In this case, turn off the Switch with lamp on dryer panel and wait 3 minutes. After this step, turn on
the switch to restart. When the cover panel of this unit is open, the Switch with lamp must be in the
off position, because dryer may start itself when the power supply is recovered.
Connections to a power source where the product is exposed to transient stresses exceeding
overvoltage category II (as defined in IEC60664-1).
Only connect to TN-S power distribution systems with N conductively connected to PE.
This manual must be kept available to operators whenever necessary.
1.1.1 Danger, Warning, and Caution Used in This Manual
This product is designed with the first priority on safety. However, there are some inherent risks that
cannot be eliminated. This manual classifies these risks into the following three categories according
to the severity: DANGER, WARNING and CAUTION.Read these statements carefully and thoroughly
understand them before operating or performing maintenance on the unit.
Be sure to read and comprehend important cautionary notifications in
this operation manual before use.
“DANGER”indicates that there is an imminent hazard that will cause serious injury
or death if not avoided.
DANGER
“WARNING”indicates that there is a hazard that may cause serious injury or death if
not avoided.
WARNING
“CAUTION”indicates that there is a hazard that may cause minor injury.
CAUTION

IDX-OM-U010
Chapter 1 Safety Instructions
1.2 Hazard Classifications & Position of Hazard warning Labels IDFC60/70/80/90 Series
1-2
1.2 Hazard Classifications & Position of Hazard
warning Labels
To help you recognize the hazards, the unit utilizes special graphics to indicate different hazards.
Confirm the contents of the hazards and the location of the labels before operation.
1.2.1 Hazard of Electricity
1.2.2 Hazard of Hot Surface
1.2.3 Danger of Compressed Air Circuit
- Only properly trained, qualified personnel are allowed to perform tasks such as:
Operation, installation, relocation of product and maintenance works.
- Should any problem occurs, address it according to instruction in this manual.
- Identify problems following the guidelines in Chapter 6 for Troubleshooting before
proceed with maintenance works.
- In the event of any problems the product should not be turned on. When the
product fails or a fault occurs, shut down immediately, and contact for service.
WARNING
Inside of this product, there is a power-supplying section with high voltage
separated by the cover panel. Do not operate the product with the cover panel off.
WARNING
Since this product has parts that become hot during operation, there is a possible
risk of burn-associated injuries. These parts remain hot even after power is off.
Wait until the unit has cooled down before touching.
WARNING
Before replacing or cleaning parts, be sure to relief the pressure remained inside of
the product until the gauge indicates “0”. High pressure can propel object at high
velocity and cause injury.
WARNING

IDX-OM-U010
Chapter 1 Safety Instructions
IDFC60/70/80/90 Series 1.2 Hazard Classifications & Position of Hazard warning Labels
1-3
1.2.4 Positions of Hazard Warning Labels
- Read with caution and pay attention to the notations of hazard warning labels.
- Do not remove or modify hazard warning labels.
- Confirm the positions of hazard warning labels.
WARNING
Front

IDX-OM-U010
Chapter 1 Safety Instructions
1.2 Hazard Classifications & Position of Hazard warning Labels IDFC60/70/80/90 Series
1-4
1.2.5 Model no. Label
It is an example of model "IDFC60-23".
How to see the serial number. WR0001 (April 2018)
W
R
0001
Year
Symbol
Remarks
Month
Symbol
Remarks
Serial No.
2017
2018
2019
2020
↓
V
W
X
y
↓
Repeated
from A to Z in
alphabetical
order
1
2
3
4
↓
o
P
Q
R
↓
Repeated
from A to Z in
alphabetical
order, with o
for January
and Z for
December
-
Front
200/200,220VAC 1PH 50/60Hz

IDX-OM-U010
Chapter 1 Safety Instructions
IDFC60/70/80/90 Series 1.3 Disposal
1-5
1.3 Disposal
When you dispose of the product, you should collect the refrigerant and the compressor oil inside the
refrigerant circuit.
.
- This product contains Fluorocarbon HFC.
- It is strictly forbidden to emit Fluorocarbon into the atmosphere. Before you repair
the refrigerant circuit, you should collect the refrigerant with proper evacuation
system. The collected refrigerant should be properly recycled by qualified agency.
Only personnel with proper credentials are allowed to handle refrigerant.
- Only properly trained and qualified personnel are allowed to remove the cover
panel of the product.
- The quantity and the type of Fluorocarbon are mentioned on the model no. label.
See Page 1-5.
CAUTION
- Dispose of the refrigerant and compressor oil according to the regulation of local
government.
- Only personnel with proper credentials are allowed to collect refrigerant and
compressor oil.
- Only properly trained and qualified personnel are allowed to remove the cover
panel of the product.
- For any questions, please contact an SMC authorized dealers.
CAUTION

IDX-OM-U010
Chapter 1 Safety Instructions
1.4 Limited warranty and Disclaimer / Compliance Requirements IDFC60/70/80/90 Series
1-6
1.4 Limited warranty and Disclaimer / Compliance
Requirements
The product used subject to the following “Limited warranty and Disclaimer“and “Compliance
Requirements.
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or 1.5 years after the product is delivered.
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our responsibility, a
replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage incurred
due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers noted
in the specified catalog for the particular products.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are govemed by the
relevant security laws and regulation of the countries involved in the transaction. Prior to the
shipment of a SMC product of a SMC product to another country, assure that all local rules
goveming that export are known and followed.
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries. If
considering using the product in other industries, consult SMC beforehand and exchange
specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
CAUTION
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval
tests relevant to the metrology (measurement) laws of each country. Therefore, SMC products cannot
be used for business or certification ordained by the metrology (measurement) laws of each country.
CAUTION

IDX-OM-U010
Chapter 2 Parts Name and Functions
IDFC60/70/80/90 Series 2.1 Parts Name and Functions
2-1
Chapter 2 Parts Name and Functions
2.1 Parts Name and Functions
Switch with Lamp
(ON / OFF Switch)
The lamp is continuously ON
during normal operation.
Ball Valve
Auto Drain
Check if drained correctly once a day.
Thermal Relay
(The thermal relay is placed at the
inside of a front panel.) Refer to page
6-4 to reset the thermal relay.
Ventilation Grille (Exhaust)
Hot air will be exhausted by
condenser fan. Do not block
these vents.
Refrigerant pressure gauge
Indicates the high pressure of
refrigerant.
During normal operation, the
indicator remains below red zone.
High Pressure Switch
(The high pressure switch is
placed at the inside of a front
panel.)
Refer to page 6-4 to reset the
high pressure switch.
Power cable holder
Signal cable entry
Terminal block
You can see the terminal block when you remove
this cover. Connect the power cable through the
rubber grommet.
Customer connection side
Refer to page 3-6 for electrical wiring.
L
N
PE
（）
Compressed Air (OUT)
Compressed Air (IN)

IDX-OM-U010
Chapter 2 Parts Name and Functions
2.1 Parts Name and Functions IDFC60/70/80/90 Series
2-2
Ventilation Grille (Suction) with Dust proof filter
Ambient air will be sucked by condenser fan.
Do not block these vents.

IDX-OM-U010
Chapter 3 Transportation/Installation
IDFC60/70/80/90 Series 3.1 Transportation
3-1
Chapter 3 Transportation/Installation
3.1 Transportation
When you transport the product, you should follow the instructions below:
- You should lift the product from the base surface with careful attention to prevent tipping over.
- Do not lay the product sideways, or you will damage the product.
- Do not suspend the product from the ceiling or hang from the wall.
- Do not transport the product with any part such as an air filter mounted on the fittings at the air inlet or
outlet port of the product. If it is unavoidable to transport the product with such a part mounted, support
the mounted part with a bracket to prevent the product from being affected by vibration during
transportation.
Use the product in the right way. During Installation, operation, maintenance, and
check, you should be careful in keeping the safety of human body.
WARNING
Transportation, installation, and maintenance including dangerous work must be
done by a personnel who has enough knowledge and experience about the product
and the system.
CAUTION
This product is heavy. Make sure to follow above instruction.
As each model weights more than 50kg incl package, a forklift is necessary.
Transportation using forklift should be done by personnel who has the license.
WARNING

IDX-OM-U010
Chapter 3 Transportation/Installation
3.2 Installation IDFC60/70/80/90 Series
3-2
3.2 Installation
3.2.1 Location
The product should not be used or stored in the circumstances as follows. Those circumstances will
cause not only malfunction but also failures.
- Locations where the air dryer will be in direct contact with wind and rain. (Locations where relative
humidity is 85% or more.)
- Locations where the product is exposed to water, moisture vapor, salty water, oil and so on.
- Locations where dust or particles are.
- Locations where inflammable or explosive gas are.
- Locations where corrosive gas, solvent, combustible gas are.
- Locations that receive direct sunlight or where radiant heat is generated.
- Locations where ambient temperature is beyond following range:
On-stream: 20 to 45oC
Storage: 0 to 50oC (when there is no drain water inside of the piping)
- Locations where temperature changes rapidly.
- Locations where strong electromagnetic noise is generated (locations where electromagnetic field,
strong magnetic field, surge is generated)
- Circumstances where static electricity is produced or discharged through the body of the product.
- Locations where strong high frequency wave is generated.
- Locations where danger of thunder is apparent.
- Locations by loading on vehicles, marine vessels, and so on.
- Locations whose altitude is higher than 2,000 meters.
- Circumstances where strong vibration or impact are transmitted.
- Circumstances where too much force and weight are put on the body of the product that causes it to
deform.
- Circumstances where enough spaces cannot be taken to do maintenance (in the plant where the
product is operated).
Spaces needed for maintenance
Front: 600 mm / Rear: 600 mm / Top: 600 mm / Right: 600 mm / Left: 600 mm
- Locations the ventilation grille of the product can be blocked.
- Place where rejection style air of air compressor or other driers (hot wind) is inhaled.
- Place where rapid pressure fluctuation and fluid velocity variation happen.
3.2.2 Anchorage
- The air dryer should be installed on a vibration-free, stable, horizontal flat surface.
- Refer to “Chapter7 7.3 Dimensions” for the dimensions.
- This model should be installed using anchor bolts (not included) to prevent shifting during a potential
earthquake. (The anchor bolts are available separately as a set.)
Parts No.
Description
Qty.
IDF-AB500
Foundation bolt set
1 set (4 pcs/set)
- Do not use this product with compressed air which contains, or store this product
in an environment which contains the following substance avoid malfunction and
also to avoid injury to the user due to broken parts:
- Corrosive gas, solvents and other harmful chemicals.
WARNING

IDX-OM-U010
Chapter 3 Transportation/Installation
IDFC60/70/80/90 Series 3.2 Installation
3-3
3.2.3 Air piping
- Connection to the inlet and outlet of compressed air should be made removable by using union and so
on.
- Secure the piping coupling section with a pipe wrench, connect the air piping fittings.
- Do not allow the weight of the piping to lie directly on the air dryer. When mounting any part such as an
air filter on the fitting at the compressed air inlet or outlet port, support the part to prevent excessive
force from being applied to the product.
- Be careful not to let the vibration of the air compressor transmit.
- Surface temperature of piping will reach to the same temperature as the inlet compressed air. Apply
thermal insulation around the piping when the inlet compressed air is higher than 60 oC.
- If the temperature of compressed air on the inlet side is higher than 65oC, place an after-cooler after
the air compressor. Or, make the temperature of the place where the air compressor is installed lower
than 65oC.
- If the air supply makes high pressure fluctuation (pulsation), take any countermeasures such as
installing air tank.
- Flash the piping sufficiently in order to avoid any foreign substances such as dust, sealing tape, liquid
gasket, etc. when piping before piping connection. Foreign substances in the piping can cause cooling
failure or drainage failure.
- Use pipes and fittings that have enough endurance against the operating pressure and temperature.
And connect it firmly to prevent air leakage.
- Provide bypass piping to make it possible to do maintenance without stopping the air compressor.
- When tightening the inlet/outlet air piping, firmly hold the port on the air dryer with a pipe wrench, etc.
- If a metallic flexible tubing is used for the air gateway piping, the allophone might be generated in
piping. In that case, please change to the piping of the steel pipe.
- Please set up the filter in the dryer secondary for the drain dispersion prevention when a rapid
pressure fluctuation and the fluid velocity variation happen.
- Variations in operating conditions may cause condensation to form on the surface of the outlet piping.
Apply thermal insulation around the piping to prevent condensation from forming.
Compressed Air (OUT)
Valve (OUT)
Union joint
Compressed Air (IN)
Valve (IN)
Bypass valve
Union joint
OUT
IN
Do not remove
screws at the side
of pipe connection
ports.
Front

IDX-OM-U010
Chapter 3 Transportation/Installation
3.2 Installation IDFC60/70/80/90 Series
3-4
3.2.4 Auto Drain tube
- A tube (12mm) O.D. is attached as the auto drain. The end of the tube is open to atmosphere to let
drain flow through the tube into a collector or drain pipe.
(When the drain tube to be changed by customer, the tube length should be 5m or shorter and the I.D.
8mm or larger for proper working of auto drain.)
- The compressed air is used to push out the drain periodically. Fix the outlet end of the tube in order to
prevent whipping action during discharge.
- Install the drain tube in such a way so that no drain is trapped.
- During installation, make sure the dryer does not sit on the drain tube which is at the bottom of the unit.
Be careful to avoid the dryer from crushing the tube during installation.
- In case the drain tube to be arranged behind the dryer, please use the attached holder.
- To handle drain discharge, follow the safety guidelines such as wearing protective
goggles, apron, and gloves.
- In cases where oil is mixed in the wastewater discharged from the auto drain, the
liquid would be considered as toxic waste and treatment is necessary in
accordance with local regulations.
WARNING
Holder
Drain tube
Open
O Ｓ
- Keep the ball valve “OPEN”during in operation. If the ball valve is closed, drain
cannot be discharged.
- Keep the drain cock “S”side. If the drain cock is “O”side, compressed air is blown
out continuously.
CAUTION

IDX-OM-U010
Chapter 3 Transportation/Installation
IDFC60/70/80/90 Series 3.2 Installation
3-5
3.2.5 Electric Wiring
Specification of power cable
- Prepare following power cable.
- Three-cores (including the ground cable)
IDFC60-23
IDFC70-23
IDFC80-23
IDFC90-23
16AWG (1.25mm2)
14AWG (2.0mm2)
External diameter: about 9 to 11mm.
External diameter: about 18 to 23mm.
*Additional length of about 0.2m is needed to wire inside of the product.
Connecting to the power supply
- Connect the power cable and the ground to the terminal block. Make sure to use the ring terminals for
terminal screws.
IDFC60-23
IDFC70-23
IDFC80-23
IDFC90-23
Terminal screws
M3.5
M4.0
Applicable crimped terminal
1.25-3.5
2-4
(Width: 8.5mm and below)
(Width: 9.5mm and below)
Wiring procedure
- Only properly trained and qualified personnel are allowed to perform wiring work.
- Before wiring, be sure to shut off the power supply. Never perform wiring work
while the product is energized.
- Supply power of the product should meet the specifications on page 7-1.
- Ensure a stable power supply with no voltage surges.
- Take care not to overload the power supply by connecting multiple units to one
supply.
- Supply power from a system that has emergency stop measures.
- Ensure that a Ground Fault Circuit Interrupter (GFCI) with appropriate capacity for
earth leakage and load is used in the power supply of the product to prevent
electrical shock and burnout of the compressor motor. See “7-1 List of
specifications” for details.
- Be sure to install the circuit breaker correctly so that it disconnects all live
conductors and so that the operating handle can be easily accessible.
- Circuit breaker must be properly selected to meet safety standard of local
regulations.
- The product must be grounded for safety.
- Be sure that the protective conductor has some additional length in respect to the
live conductors, so that it is not subject to mechanical stresses.
- Always be sure to connect the protective conductor first, disconnect it last in
respect to the other connections.
- Do not connect ground wire to a water pipe, a gas pipe, or a lightening rod.
- Do not modify the electrical wiring of the power supply.
WARNING

IDX-OM-U010
Chapter 3 Transportation/Installation
3.2 Installation IDFC60/70/80/90 Series
3-6
1) Remove the front panel.
2) Insert the cable through the strain relief and connect it to the terminal block (refer to the label on the
terminal block).
M3.5 screw tightening torque: 1.0 to 1.3Nm
M4 screw tightening torque: 1.4 to 2.0Nm
During wiring work, do not touch other sections except terminal block.
3) Replace the front panel after wiring is done.
Terminal block
Front panel
Strain relief
Power cable entry
【Terminal block】
LN

IDX-OM-U010
Chapter 3 Transportation/Installation
IDFC60/70/80/90 Series 3.3 Cautions for Reinstallation
3-7
3.3 Cautions for Reinstallation
If the product is moved and reinstalled in another place after some trial operations, the following
instructions must be followed as well as procedures in Chapter 3.
Removing the power cable
Disconnect the power source before removing the power cable.
Disconnecting air pipes
Remove the seal tape completely after removing the piping. Loose seal tape can clog up the system.
Releasing residual pressure
1) Open the bypass valve during air dryer removal, only when compressed air is required.
2) Close the compressed air inlet and outlet valve.
3) Ensure that the ball valve of the auto drain is opened.
4) Remove the drain cock holding clip.
5) Rotate the drain cock of the auto drain to "O" side, and exhaust the compressed pneumatic air from
the product.
Only properly trained, qualified personnel are allowed to perform reinstallation.
CAUTION
- Only properly trained, qualified personnel are allowed to perform wiring.
- Disconnect the power source before wiring. Do not work under energized
condition.
WARNING
Drain cock
“O”: Open
Remove the clip
- Only properly trained, qualified personnel are allowed to perform piping works.
- Separate the compressed air source from the product before disconnecting the air
pipe.
- Do not disconnect any piping when there is residual air pressure inside of the pipe.
WARNING

IDX-OM-U010
Chapter 3 Transportation/Installation
3.3 Cautions for Reinstallation IDFC60/70/80/90 Series
3-8
