Breville Easy Glide VIN255 User manual

2200W easy glide
steam iron
®
™
™

2
!Never use this appliance for anything other than its intended use. This appliance is
for household use only. Do not use this appliance outdoors.
!Always ensure that hands are dry before handling the plug or switching on the
appliance.
!Do not touch the metal parts of the appliance during use as they may become very
hot.
!This appliance must not be placed on or near any potentially hot surfaces (such as
a gas or electric hob).
!Always allow the appliance to cool before cleaning or storing.
!Never immerse any part of the appliance or power cord and plug in water or any
other liquid.
!Never let the power cord hang over the edge of a worktop, touch hot surfaces or
become knotted, trapped or pinched.
Important Safety Information
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
Keep the appliance and its cord out of reach of
children less than 8 years old when it is switched on or
cooling down.
The appliance must not be left unattended when it is
connected to the mains supply.
The appliance must be unplugged from the mains
supply socket before lling the water tank with water.
Always use the appliance on a stable, secure, dry and
level surface. When placing the appliance on its stand,
ensure that the surface on which the stand is placed is
stable.
Do not use the appliance if it has been dropped, if
there are any visible signs of damage or if it is leaking.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.

3
1 Water tank inlet cover
2 Steam control
3 Shot of steam button
4 Spray button
5 Temperature control
6 Temperature indicator light
7 Stainless steel soleplate
8 Water tank
9 Temperature control index mark
10 Safe-Store™ heat indicator
11 Water level maximum indicator
12 Spray nozzle
Before using for the rst time
Warning: Remove all packaging including any soleplate protection before using
your iron.
Wipe over the soleplate with a cloth moistened with methylated spirit. Wipe off the
methylated spirit with a damp cloth then dry the soleplate thoroughly.
Before connecting your iron to the mains supply, make sure your supply voltage is the
same as the one indicated on your iron.
When you rst use your iron, there may be a slight odour and it may smoke slightly for
the rst few minutes of operation. This is quite normal and will disappear.
Cleaning your iron before use
Follow these simple steps to remove any impurities or residues inside your steam iron
that may be left over from the manufacturing process.
1. Follow the instructions under lling your iron and ll the water tank as described.
2. Empty the water tank to rinse out any foreign particles then rell it.
3. Follow the instructions under steam ironing. Set the temperature to the MAX
setting and the steam control to the high steam setting.
4. Iron an old piece of cloth (cotton or towelling is ideal) for a few minutes. While
ironing, press the steam button 4 or 5 times.
5. Any impurities will be ushed from your iron by the steam and absorbed by the
cloth. Your iron is now ready for use.
MAX
wertq
o
sa
y
u
d

4
Filling your iron
1. Unplug your iron
2. Set the steam control wto the no steam position (0).
3. Open the water tank inlet cover q.
4. Fill the water tank with ordinary tap water.
5. Don’t ll above the MAX level mark. Check the level by standing your iron on its
heel.
6. Close the water tank inlet cover.
Ironing without steam
Important: Your iron takes time to heat up and cool down. If you change the
temperature setting on your iron, you must give it time to adjust to the new setting.
1. Set the steam control to the no steam position (0).
2. Plug your iron in.
3. Rotate the temperature control dial tuntil the desired setting is aligned with the
index mark o.
4. When the temperature indicator light ygoes out, your iron is ready to use.
Ironing with steam
Warning: During steam ironing, if you do not allow your iron to reach the selected
temperature water may drip from the soleplate.
1. Fill your iron with water.
2. Plug your iron in.
3. The temperature control dial t must be set within the ll and lll setting.
The hotter your iron, the more steam is generated.
4. When the temperature indicator light y goes out your iron is ready to use. The
temperature indicator light will turn on and off during ironing.
5. Adjust the steam control w to select the desired steam output.
6. The steam can be shut off at any time by setting the steam control to the no
steam position (0).
Vertical ironing
Warning: Never iron garments when they are being worn.
1. Prepare your iron as for steam ironing.
2. Hold your iron 15cm from the fabric.
3. Press the shot of steam button e as required. Wait several seconds between
each press of the button.
Shot of steam
Press the shot of steam button ewhenever you have a stubborn crease that needs
extra steam. Steam will burst from the holes in the soleplate of your iron into the fabric.
The temperature control dial t must be set within the ll and lll setting. Wait
several seconds between each press of the steam button.
Spray feature
The water spray can be used to help iron heavy fabrics or difcult areas (collars,
pockets, sleeves, creases, etc). It can also be used when ironing delicate fabrics which
cannot be steam ironed.
Make sure there is water in the tank. Press the spray button r to produce a spray of
water.

5
Care and cleaning
Warning: Do not use harsh abrasives, chemical cleaners or solvents to clean the
exterior of your iron.
Allow your iron to completely cool down and wipe the soleplate with a soft damp cloth. If
polyester has burnt to the soleplate, iron a damp cotton cloth while your iron is still hot.
Wipe over the rest of your iron with a soft damp cloth then wipe dry.
Self clean feature
Use the self-clean function once every two weeks. If the water in your area is very hard,
the self clean function should be used more frequently.
1. Unplug your iron then set the steam control w to the no steam position (0).
2. Fill your iron with water to the MAX mark.
3. Plug your iron in then set the temperature control dial to the highest (MAX)
setting. Allow your iron to heat up until the temperature indicator light goes out.
4. Unplug your iron and hold it over a sink with the soleplate facing downwards.
5. Turn the steam control to the SC setting and then pull the steam control out of the
iron. Shake the iron vigorously while continuing to hold it over the sink.
6. Ret the steam control after ve minutes or when the water tank is empty.
7. Iron an old piece of cloth to allow any remaining water to escape.
8. After use, unplug your iron and allow it to fully cool. Empty out any remaining
water.
Cleaning the steam holes
Use a cotton wool tip moistened with methylated spirits. Wipe off the methylated spirits
with a damp cloth then dry the soleplate.
Storing
Warning: Allow your iron to completely cool before storing. Always store your iron on its
heel rest. Do not store your iron resting on its soleplate.
The Safe-Store™ heat indicator shows you when the soleplate of your iron has
cooled sufciently for it to be safe to store. If the strip is red, your iron is too hot. When
the words SAFE-STORE appear on the strip against a solid black background, the
soleplate is at a safe temperature for storing.
Never wrap the power cord around the soleplate. The cord can be neatly wrapped
around the heel of your iron.

6
Blue
(Neutral)
Brow n
(Live)
Fuse 13A
Green/Y ellow
(Earth)
Plug should be ASTA approved to BS1363
Fuse should be ASTA approved to BS1362
Ensure that the outer sheath of
the cable is firmly held by the cord grip
After sales service
To return a faulty appliance to our Customer Service Department:
1. Pack it carefully (preferably in the original carton). Ensure the unit is clean.
2. Enclose your name and address and quote the model number on all
correspondence. Give the reason why you are returning it.
3. If within the guarantee period, state when and where it was purchased and include
proof of purchase (e.g. till receipt).
4. Send it to our Customer Service Department at the address below:
Customer Service Department
Jarden Consumer Solutions (Europe) Limited
Middleton Road, Royton, Oldham
OL2 5LN, UK
Telephone: [phone] Fax: [phone]
e-mail: [email protected]
Replacement parts
For additional or replacement parts, please visit www.breville.co.uk or call us on
0161 621 6900.
Troubleshooting
For troubleshooting and FAQs visit www.breville.co.uk/faqs
Turn on your Creativity™
Let the Breville®team help you turn on your creativity with a gateway to a world of food
and drinks without limits. You don’t have to travel far—just to your computer, tablet or
mobile—where you will discover our FREE website with top tips and recipes to inspire
your imagination. Join us now at www.turnonyourcreativity.com
™
™
Electrical safety
This appliance must be earthed.
This appliance is tted with either a moulded or rewirable BS1363, 13 amp plug. The
fuse should be rated at 13 amps and be ASTA approved to BS1362. If the fuse in a
moulded plug needs to be changed, the fuse cover must be retted. The appliance must
not be used without the fuse cover tted.
If the plug is unsuitable, it
should be dismantled and
removed from the supply
cord and an appropriate plug
tted as detailed below. If you
remove the plug it must not be
connected to a 13 amp socket
and the plug must be disposed
of immediately.
If any other plug is used, a 13
amp fuse must be tted either
in the plug or adaptor or at the
distributor board.

7
Guarantee
Please keep your receipt as this will be required for any claims under this guarantee.
This appliance is guaranteed for 1 year after your purchase as described in this
document.
During this guaranteed period, if in the unlikely event the appliance no longer functions
due to a design or manufacturing fault, please take it back to the place of purchase,
with your till receipt and a copy of this guarantee.
The rights and benets under this guarantee are additional to your statutory rights,
which are not affected by this guarantee. Only Jarden Consumer Solutions (Europe)
Limited (“JCS (Europe)”) has the right to change these terms.
JCS (Europe) undertakes within the guarantee period to repair or replace the appliance,
or any part of appliance found to be not working properly free of charge provided that:
• you promptly notify the place of purchase or JCS (Europe) of the problem; and
• the appliance has not been altered in any way or subjected to damage, misuse,
abuse, repair or alteration by a person other than a person authorised by JCS
(Europe).
Faults that occur through improper use, damage, abuse, use with incorrect voltage, acts
of nature, events beyond the control of JCS (Europe), repair or alteration by a person
other than a person authorised by JCS (Europe) or failure to follow instructions for use
are not covered by this guarantee. Additionally, normal wear and tear, including, but not
limited to, minor discoloration and scratches are not covered by this guarantee.
The rights under this guarantee shall only apply to the original purchaser and shall not
extend to commercial or communal use.
If your appliance includes a country-specic guarantee or warranty insert please refer
to the terms and conditions of such guarantee or warranty in place of this guarantee or
contact your local authorized dealer for more information.
Waste electrical products should not be disposed of with Household
waste. Please recycle where facilities exist. E-mail us at enquiries
[email protected] for further recycling and WEEE information.
Jarden Consumer Solutions (Europe) Limited
5400 Lakeside
Cheadle Royal Business Park
Cheadle
SK8 3GQ
UK

VIN301_VIN304_VIN357_VIN369_VIN370_IIN330_Rev6 05/15 93612-5 UKPUL
P.N. 183735
Jarden Consumer Solutions (Europe) Limited
Cheadle Royal Business Park, Cheadle, SK8 3GQ, United Kingdom
e-mail: [email protected]
Telephone: [phone]
For Customer Service details, please see the website.
www.breville.co.uk
© 2015 Jarden Consumer Solutions (Europe) Limited
All rights reserved. Imported and distributed by Jarden Consumer Solutions (Europe) Limited,
Cheadle Royal Business Park, Cheadle, SK8 3GQ, United Kingdom.
The product supplied may differ slightly from the one illustrated due to continuing product
development.
Printed in China
®
