NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS WITH
THE GRILL OWNER FOR FUTURE
REFERENCE.
AVISO PARA EL INSTALADOR:
ENTREGUE ESTAS
INSTRUCCIONES AL PROPIETARIO
DE LA PARRILLA PARA
REFERENCIA FUTURA.
ASSEMBLY AND OPERATING INSTRUCTIONS
INSTRUCCIONES DE ARMADO Y OPERACIÓN
SAVE THIS MANUAL FOR FUTURE REFERENCE
GUARDE ESTE MANUAL PARA REFERENCIA FUTURA
WARNING/ADVERTENCIA
HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS ARE
IGNORED. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS MANUAL TO AVOID
PERSONAL INJURY, INCLUDING DEATH OR PROPERTY DAMAGE.
SE PUEDE PRODUCIR UNA EXPLOSIÓN PELIGROSA SI SE HACE CASO OMISO A ESTAS
ADVERTENCIAS E INSTRUCCIONES. LEAY SIGA TODAS LAS ADVERTENCIAS E
INSTRUCCIONES EN ESTE MANUAL PARA EVITAR LESIONES PERSONALES, INCLUSO LA
MUERTE, O LOS DAÑOS MATERIALES.
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 1

1
IMPORTANT SAFETY WARNINGS
WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE.
THE PURPOSE OF THIS SAFETY ALERT SYMBOL
IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL.
WHEN YOU SEE THE SAFETY ALERT SYMBOL, PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS!
READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
WARNING
• Only use this grill on a hard, level, non-combustible, stable surface (concrete, ground, etc.) capable of supporting the weight of
the grill. Never use on wooden or other surfaces that could burn.
• DO NOT use grill without charcoal ash tray in place. DO NOT attempt to remove charcoal ash tray while tray contains hot coals.
• Proper clearance of 10 feet (3.1 m) between the grill and combustible material (bushes, trees, wooden decks, fences, buildings,
etc.) or construction should be maintained at all times when grill is in use. Do not place grill under a roof overhang or other
enclosed area.
• For outdoor use only. Do not operate grill indoors or in an enclosed area.
• For household use only. Do not use this grill for other than its intended purpose.
• We recommend the use of a Charcoal Chimney Starter to avoid the dangers associated with charcoal lighting fluid. If you choose
to use charcoal lighting fluid, only use lighting fluid approved for lighting charcoal. Carefully read manufacturer’s warnings and
instructions on the charcoal lighting fluid and charcoal prior to the use of their product. Store charcoal lighting fluid safely away
from grill.
• When using charcoal lighting fluid, allow charcoal to burn with grill lid and doors open until covered with a light ash
(approximately 20 minutes). This will allow charcoal lighting fluid to burn off. Failure to do this could trap fumes from charcoal
lighting fluid in grill and may result in a flash fire or explosion when lid is opened.
• Only use charcoal chimney starter if starting fire in second section after 1st fire is already burning. Lighter fluid may ignite from
heat causing flash fire. Otherwise, fires must be started in both cooking chambers at the same time.
• Do not use gasoline, kerosene or alcohol for lighting charcoal. Use of any of these or similar products could cause an explosion
possibly leading to severe bodily injury.
• Never add charcoal lighting fluid to hot or even warm coals as flashback may occur causing severe burns.
• Place grill in an area where children and pets cannot come into contact with unit. Close supervision is necessary when grill is in
use.
• Do not leave grill unattended when in use.
• When adding charcoal and/or wood, use extreme caution and follow instructions in “Adding Charcoal/Wood During Cooking”
section of this manual.
• Do not store or use grill near gasoline or other flammable liquids, gases or where flammable vapors may be present.
• Do not store lighter fluid or other flammable liquids or material under the grill.
• Use caution when adjusting charcoal grate height. Handle may be hot when in use.
• Never raise or lower charcoal grate when water smoking as hot water may splash onto coals creating a burst of hot steam and
coals.
Grill is hot when in use. To avoid burns:
• DO NOT attempt to move the grill.
• Lock the casters so the unit does not accidentally move.
• Wear protective gloves or oven mitts.
• DO NOT touch any hot grill surfaces.
• DO NOT wear loose clothing or allow hair to come in contact with grill.
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 2

2
WARNING
• When grilling, grease from meat may drip into the charcoal and cause a grease fire. If this should happen close lid to suffocate
the flame. Do not use water to extinguish grease fires.
• Use caution since flames can flare-up when fresh air suddenly comes in contact with fire. When opening the lid, keep hands, face
and body a safe distance from hot steam and flame flare-ups.
• Never place more than 15 pounds (6.8 kg) on side tables. Do not lean on the side tables. Always ensure side tables are properly
seated.
• Do not exceed a temperature of 400°F (205°C). Do not allow charcoal and/or wood to rest on the walls of grill. Doing so will
greatly reduce the life of the metal and finish of your grill.
• Use caution when assembling and operating your grill to avoid scrapes or cuts from sharp edges of metal parts. Use caution
when reaching into or under grill.
• When opening lid, make sure it is pushed all the way open. If lid is not fully open, it could fall back to a closed position and cause
bodily injury.
• In windy weather, place grill in an outdoor area that is protected from the wind.
• Close lid and doors to suffocate flame.
• Never leave coals and ashes in grill unattended. Before grill can be left unattended, remaining coals and ashes must be removed
from grill. Use caution to protect yourself and property. Carefully place remaining coals and ashes in a non-combustible metal
container and saturate completely with water. Allow coals and water to remain in metal container 24 hours prior to disposing.
• Extinguished coals and ashes should be placed a safe distance from all structures and combustible materials.
• With a garden hose, completely wet the surface beneath and around grill to extinguish any ashes, coals or embers which may
have fallen during the cooking or cleaning process.
• After each use, clean the grill thoroughly and apply a light coat of vegetable oil to interior to prevent rusting. Cover the grill to
protect it from excessive rusting.
• Use caution when lifting or moving grill to prevent strains and back injuries.
• We advise that a fire extinguisher be on hand. Refer to your local authority to determine proper size and type of fire extinguisher.
• Accessory attachments not manufactured by The Brinkmann Corporation for this particular product are not recommended and
may lead to personal injury or property damage.
• Store the grill out of reach of children and in a dry location when not in use.
• Do not attempt to service grill other than normal maintenance as explained in “After-Use Safety” and “Proper Care &
Maintenance” sections of this manual. Repairs should be performed by The Brinkmann Corporation only.
• Properly dispose of all packaging material.
USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR GRILL.
FAILURE TO ADHERE TO SAFETY WARNING AND GUIDELINES IN THIS MANUAL COULD RESULT
IN BODILY INJURY OR PROPERTY DAMAGE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 3

3
PARTS LIST - PROFESSIONAL GRILL:
2 Temperature Gauges
1 Handle
2 Handle Supports
1 Lid
2 Air Vent Dampers
1 Cooking Chamber Divider
2 Cranks
1 Door Bracket
2 Warming Racks
2 Cooking Grills
2 Side Tables
4 Legs - left front leg, right front leg,
left back leg, right back leg
1 Back Panel
2 Side Panels
1 Cart Base
1 Charcoal Ash Tray
2 Front Doors
4 Locking Casters
1 Door Stop
2 Door Handles
4 Door Handle Supports
13
12
11
10
9
8
7
6
5
4
3
2
1
ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT:
www.brinkmann.net
FOR GRILL WARRANTY REPLACEMENT PARTS, PLEASE VISIT US AT:
www.grillpartsonline.com
(Proof of purchase will be required.)
Inspect contents of the box to ensure all parts are included and undamaged.
We recommend two people work together
when assembling this unit.
The following tools are required to assemble
this Professional Dual Zone Grill:
• Pliers
• Phillips & Flathead Screwdrivers
• Adjustable Wrench
1
1
4
7
5
10
11
12
17
16
15
18
12
13
6
3
9
2
8
14
14
15
16
17
18
11
14
19
19
20
21
20
21
21
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 4

4
Parts Bag Contents
2 M10 Nuts
2 Door Locking Plates
2 Door Handles
2 Upper Hinges
2 Lower Hinges
14 M6 Nuts
8 M6 x 45mm Bolts
36 M6 x 12mm Bolts
2 Hitch Pins
2 Hood Pivot Pins
8 M6 x 28mm Bolts
2 Air Vent Dampers
2 Bottom Pivots
2 Top Pivots
4 M8 Nuts
2 Towel Racks
1 Hexagonal Nut Wrench
13
12
11
10
9
8
7
6
5
4
3
2
1
14
6
79
10
11
12345
8
15
12
13 14
16
17
15
16
17
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 5

5
Choose a good, cleared assembly area and get a
friend to help you put your grill together. Lay
cardboard down to protect grill finish and
assembly area. Turn the grill on its side to begin
assembly.
Step 1
Insert door handle through hole in door with
handle pointing down. Place door locking plate
over door handle pointing up and secure with a
M10 x 8mm hexagonal nut. Repeat for other
door.
Step 2
Attach steel casters to bottom of each leg.
Tighten caster bolts securely.
Step 3
Align the holes in the right back leg bracket with
the holes in the body of the grill. Insert two
M6 x 12mm bolts through the leg bracket and
secure to the grill body.
Step 4
Hang a shelf onto the lower stud of the leg that
you have attached to the grill body.
Locking
Casters
Legs
Door
Handle
Door
Locking
Plate
Nut
Door
Right Back LegM6 x 12mm Bolts
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 6

6
Step 5
Insert the lower stud of the right front leg
bracket into the opposite side of the shelf.
Align the holes in the leg bracket with the
holes in the grill body. Insert two
M6 x 12mm bolts through the leg bracket
and secure to the grill body.
Note: With the help of a friend, turn grill
onto opposite side. Try to minimize
stress on the legs and shelf. Repeat
steps 2 through 5 with the left side of
the grill.
Step 6
With the grill on it’s side, attach left side
panel to left legs using four M6 X 12mm
bolts. Repeat for right side.
Step 7
Attach the back panel to rear legs using
four M6 X 12mm bolts.
Right Front Leg
Right Back Leg
Bolts
Bolts
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 7

7
Note: With the help of a friend, turn grill
upright. Try to minimize stress on the
legs.
Step 8
Have a friend help you align holes in
bottom shelf with screw holes in legs.
Insert four M6 x 45mm bolts through the
legs and secure to the bottom shelf.
Step 9
Attach the door bracket to the cart front
legs using four M6 x 45mm bolts. Use two
M6 x 12mm bolts to attach the door stop to
the cart base.
Step 10
Attach the towel racks to the front of the
side shelves by inserting the towel rack
through the two holes in the shelf support.
Secure with two M8 nuts.
Bolts
Bottom Shelf
Door Stop
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 8

8
Step 11
Attach one handle stand using two
M6 x 12mm bolts and two
M6 nuts. Next insert hood handle into
handle stand. Place the other handle
stand over handle and attach by using
two M6 x 12mm bolts and two M6 nuts.
Step 12
Attach air vent dampers to the inside of lid.
Place air vent dampers on the inside of the
unit with the adjustment tab sticking
through one of the air vent holes. Using one
M6 X 12mm bolt and M6 nut, secure vent
cover to the unit. Do not over tighten the
nut as this will make the vent difficult to
open and close. Repeat for other air vent
damper.
Step 13
Attach one half of each hinge to the
outside back of the body using
M6 x 28mm bolts. Thread bolts into nuts
welded to the inside of the grill body but
do not tighten. Attach the other half of
each hinge to the outside back of the lid
using two M6 x 28mm bolts. Thread bolts
into nuts welded to the inside of the lid
but do not tighten. Repeat for other
hinge.
Step 14
Rest lid on the grill body and align hinges
to insert hood pivot pins. Insert hitch pins
into hood pivot pins. Tighten all hinge
screws on lid and grill body until secure.
Step 15
Insert adjuster cranks through front of
grill body and into crank brackets. Rotate
clockwise until cranks engage charcoal
grates.
Hitch Pin
Hood Pivot Pin
Handle
Handle
Stands
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 9

9
Step 16
Remove nut from temperature gauges.
Insert temperature gauges through the
openings on front of lid, tighten nuts.
Slide divider plate into groove in center
of grill body.
Step 17
Attach one handle stand using two
M6 x 12mm bolts and two
M6 nuts. Next insert door handle into
handle stand. Place the other handle
stand over handle and attach by using
two M6 x 12mm bolts and two M6 nuts.
Repeat steps for the second handle.
Step 18
Thread bottom door pivots into the holes
in at the bottom of both doors.
Step 19
Place bottom door pivot into the hole in
cart base. Align the top of the door with
the hole in the door bracket and insert top
door pivot, tighten securely. Repeat for the
other door.
Step 20
Place cooking grills on lip of body. Slide
charcoal ash tray into guides at bottom
of grill body.
WARNING: DO NOT use grill without
charcoal ash tray in place.
DO NOT attempt to remove
charcoal ash tray while tray
contains hot coals.
Lip
Charcoal Ash Tray
Bottom Pivots
Top Door Pivot
INS_810-3246-0_BI.qxd 12/28/07 3:24 PM Page 10
