Bristol PRESA V2 2013 User manual

PRESA V2
USER MANUAL
01 2013 Mechanism
02 KT Mechanism
03 MC Mechanism
04 CT100 Mechanism

PRESA V2
2013 MECHANISM
USER MANUAL
01 Seat Height Adjustment
02 Tilt Tension
03 Tilt Limiter
04 Seat Depth Adjustment
05 Armrest Adjustment
06 Lumbar Height Adjustment

01
Seat Height Adjustment
Lever under right side of seat
To raise / lower:
Take your weight o the seat,
lift lever up.
To lower:
Lift lever up and use your weight
while seated.
Allows you to adjust the height
of the seat, for good support and
blood circulation in the legs.

02
Tilt Tension
Knob below front side of seat
To increase:
Turn knob clockwise.
To decrease:
Turn knob counterclockwise.
Set the resistance when leaning
back to support and balance your
weight in any position.

To engage:
Push the lever in to lock the
tilting mechanism.
To release:
Pull out the lever to unlock the
tilting mechanism.
Allows you to sit in an upright
position or partially reclined
locked position.
01 Seat Height Adjustment
02 Tilt Tension
03 Tilt Limiter
04 Seat Depth Adjustment
05 Armrest Adjustment
06 Lumbar Height Adjustment
03
Tilt Limiter
Lever under right side of seat

04
Seat Depth Adjustment
Lever under left side of seat
To move forward / backward:
Press lever and adjust seat either
forward or backward.
Release lever to lock in position.
Allows you to adjust the position
of the seat, for good support and
blood circulation in the legs.

05
Armrest Adjustment
Lever under armrest pad
To raise or lower:
Press lever to unlock arm,
adjust arm, release lever to lock.
Adjust chair’s arm height to
support your arms and take
weight off your shoulders.
Saya Soul Armrest
• Armrest up-or-down,
forward-backward,
sideway adjustment
and angle adjustment
Presa Soul Armrest
• Armrest up-or-down
adjustment
Saya Armrest
• Armrest up-or-down
adjustment

06
Lumbar Height Adjustment
To raise or lower:
Hold lumbar support lever using
inger and move up and down to
adjust height.
Allows you to adjust the position
of the lumbar support, for good
support and blood circulation of
the back.
50mm

PRESA V2
KT MECHANISM
USER MANUAL
01 Seat Height Adjustment
02 Tilt Tension
03 Tilt Limiter
04 Seat Depth Adjustment
05 Armrest Adjustment
06 Lumbar Height Adjustment

01
Seat Height Adjustment
Lever under right side of seat
To raise / lower:
Take your weight o the seat,
lift lever up.
To lower:
Lift lever up and use your weight
while seated.
Allows you to adjust the height
of the seat, for good support and
blood circulation in the legs.

02
Tilt Tension
Knob below front side of seat
To increase:
Turn knob clockwise.
To decrease:
Turn knob counterclockwise.
Set the resistance when leaning
back to support and balance your
weight in any position.

01 Seat Height Adjustment
02 Tilt Tension
03 Tilt Limiter
04 Seat Depth Adjustment
05 Armrest Adjustment
06 Lumbar Height Adjustment
To engage:
Recline and twist lever counterclockwise
to lock the tilting mechanism.
To disengage:
Twist lever clockwise and lean backward
slightly to unlock the tilting mechanism.
03
Tilt Limiter
Lever under left side of seat
Allows you to sit in an upright
position or partially reclined
locked position.

04
Seat Depth Adjustment
Lever under left side of seat
To move forward / backward:
Press lever and adjust seat either
forward or backward.
Release lever to lock in position.
Allows you to adjust the position
of the seat, for good support and
blood circulation in the legs.

05
Armrest Adjustment
Lever under armrest pad
To raise or lower:
Press lever to unlock arm,
adjust arm, release lever to lock.
Adjust chair’s arm height to
support your arms and take
weight off your shoulders.
Saya Soul Armrest
• Armrest up-or-down,
forward-backward,
sideway adjustment
and angle adjustment
Presa Soul Armrest
• Armrest up-or-down
adjustment
Saya Armrest
• Armrest up-or-down
adjustment

06
Lumbar Height Adjustment
To raise or lower:
Hold lumbar support lever using
inger and move up and down to
adjust height.
Allows you to adjust the position
of the lumbar support, for good
support and blood circulation of
the back.
50mm

PRESA V2
MC MECHANISM
USER MANUAL
01 Seat Height Adjustment
02 Tilt Tension
03 Tilt Limiter
04 Seat Depth Adjustment
05 Armrest Adjustment
06 Lumbar Height Adjustment

01
Seat Height Adjustment
Lever under right side of seat
To raise
Take your weight o the seat,
lift lever up.
To lower:
Put your weight on seat and pull
lever up.
Allows you to adjust the height
of the seat, for good support and
blood circulation in the legs.

02
Tilt Tension
Knob located right side under seat
To increase:
Turn knob clockwise.
To decrease:
Turn knob counterclockwise.
Set the resistance when leaning
back to support and balance your
weight in any position.

To increase limit:
Turn knob clockwise.
To decrease limit:
Turn knob counterclockwise
Allows you to sit in an upright
position or partially reclined
locked position.
01 Seat Height Adjustment
02 Tilt Tension
03 Tilt Limiter
04 Seat Depth Adjustment
05 Armrest Adjustment
06 Lumbar Height Adjustment
03
Tilt Limiter
Lever located left side under seat

04
Seat Depth Adjustment
Lever under left side of seat
To move forward / backward:
Press lever and adjust seat either
forward or backward.
Release lever to lock in position.
Allows you to adjust the position
of the seat, for good support and
blood circulation in the legs.
