Bristol Team 2013 User manual

TEAM
USER MANUAL
01 2013 Mechanism
02 KT Mechanism
03 CT100 Mechanism
04 MC Mechanism

2013 MECHANISM
TEAM
USER MANUAL
01 Seat Height Adjustment
02 Seat Depth Adjustment
03 Tilt Tension
04 Tilt Limiter
05 Armrest Height Adjustment
06 Backrest Height Adjustment
07 Headrest Height Adjustment
08 Headrest Angle Adjustment
01 Seat Height Adjustment
02 Seat Depth Adjustment
03 Tilt Tension
04 Tilt Limiter
05 Armrest Height Adjustment
06 Backrest Height Adjustment
07 Headrest Height Adjustment
08 Headrest Angle Adjustment

2013 MECHANISM
To raise:
Take your weight off the seat,
lift lever up.
To lower:
Remain seated, lift lever up.
013 MECHANISM
Allows you to adjust the height of the
seat, for good support and blood
circulation in the legs.
01
Seat Height Adjustment
Lever under right side of seat

2013 MECHANISM
To move forward / backward
Press lever and adjust seat either
forward or backward. Release lever
to lock in position.
02
Seat Depth Adjustment
Lever under left side of seat
Allows you to adjust the depth of
the seat, for good support and blood
circulation in the legs.

CT100 MECHANISM
2013 MECHANISM
03
Tilt Tension
Knob below front side of seat
To increase:
Turn knob clockwise.
To decrease:
Turn knob counterclockwise
Set the resistance when leaning back
to support and balance your weight
in any position.

CT100 MECHANISM2013 MECHANISM
To engage:
Push the lever in to lock the tilting
mechanism.
To release:
Pull out the lever to unlock the tilting
mechanism.
Allows you to sit in an upright position
or partially reclined locked position.
04
Tilt Limiter
Lever under right side of seat

2013 MECHANISM
05
Armrest Adjustment
Lever under armrest pad
To raise or lower:
Press lever to unlock arm,
adjust arm, release lever to lock.
Adjust chair’s arm height to
support your arms and take
weight off your shoulders.
Saya Soul Armrest
• Armrest up-or-down,
forward-backward,
sideway adjustment
and angle adjustment
Presa Soul Armrest
• Armrest up-or-down
adjustment
Saya Armrest
• Armrest up-or-down
adjustment

2013 MECHANISM
06
Backrest Height Adjustment
Bottom corners of backrest
To raise:
Grasp and lift up the bottom portion
of the backrest and release to desired
height.
To lower:
Grasp and lift up the backrest to its
maximum height and release back to
its lowest postition.;
Allows you to adjust the height of the
,for goodbackrest support and blood
circulation of the back.

2013 MECHANISM
07
Headrest Height Adjustment
Rear of the headrest
To raise or lower headrest:
Grasp the rear of headrest and slide it
up or down to desired height.
Adjust headrest’s height to support
your head and neck when leaning
back.

08
Headrest Angle Adjustment
Side edges of headrest
To pivot headrest:
Grasp side edges of headrest and
pivot the angle to desired position.
Adjust headrest’s angle to support
your head and neck when leaning
back.
2013 MECHANISM

KT MECHANISM
TEAM
USER MANUAL
01 Seat Height Adjustment
02 Seat Depth Adjustment
03 Tilt Tension
04 Tilt Limiter
05 Armrest Height Adjustment
06 Backrest Height Adjustment
07 Headrest Height Adjustment
08 Headrest Angle Adjustment

KT MECHANISM
To raise:
Take your weight off the seat,
lift lever up.
To lower:
Remain seated, lift lever up.
013 MECHANISM
Allows you to adjust the height of the
seat, for good support and blood
circulation in the legs.
01
Seat Height Adjustment
Lever under right side of seat

To move forward / backward
Press lever and adjust seat either
forward or backward. Release lever
to lock in position.
Allows you to adjust the depth of
the seat, for good support and blood
circulation in the legs.
02
Seat Depth Adjustment
Lever under left side of seat
KT MECHANISM

CT100 MECHANISM
03
Tilt Tension
Knob below front side of seat
To increase:
Turn knob clockwise.
To decrease:
Turn knob counterclockwise.
Set the resistance when leaning back
to support and balance your weight
in any position.
KT MECHANISM

CT100 MECHANISM
To engage:
Recline and twist lever counter-
clockwise to lock the tilting mechanism.
To disengage:
Twist lever clockwise and lean backward
slightly to unlock the tilting mechanism.
Allows you to sit in an upright position
or partially reclined locked position.
04
Tilt Limiter
Lever under left side of seat
KT MECHANISM

KT MECHANISM
05
Armrest Adjustment
Lever under armrest pad
To raise or lower:
Press lever to unlock arm,
adjust arm, release lever to lock.
Adjust chair’s arm height to
support your arms and take
weight off your shoulders.
Saya Soul Armrest
• Armrest up-or-down,
forward-backward,
sideway adjustment
and angle adjustment
Presa Soul Armrest
• Armrest up-or-down
adjustment
Saya Armrest
• Armrest up-or-down
adjustment

06
Backrest Height Adjustment
Bottom corners of backrest
To raise:
Grasp and lift up the bottom portion
of the backrest and release to desired
height.
To lower:
Grasp and lift up the backrest to its
maximum height and release back to
its lowest postition.
Allows you to adjust the height of the
backrest, for good support and blood
circulation of the back.
KT MECHANISM

01 Seat Height Adjustment
02 Seat Depth Adjustment
03 Tilt Tension
04 Tilt Limiter
05 Armrest Height Adjustment
06 Backrest Height Adjustment
07 Headrest Height Adjustment
08 Headrest Angle Adjustment
07
Headrest Height Adjustment
Rear of the headrest
To raise or lower headrest:
Grasp the rear of headrest and
slide it up or down to desired height.
Adjust headrest’s height to support
your head and neck when leaning
back.
KT MECHANISM

08
Headrest Angle Adjustment
Side edges of headrest
To pivot headrest:
Grasp side edges of headrest and
pivot the angle to desired position.
Adjust headrest’s angle to support
your head and neck when leaning
back.
KT MECHANISM

CT100 MECHANISM
TEAM
USER MANUAL
01 Seat Height Adjustment
02 Tilt Tension
03 Tilt Limiter
04 Armrest Height Adjustment
05 Backrest Height Adjustment
06 Headrest Height Adjustment
07 Headrest Angle Adjustment
