Broadata LBC-H2CS-T/R-Lite User manual

LBC-H2CS-T/R-Lite
LINK BRIDGETM HDBASET
HDMI 2.0 EXTEDER 4 PLAY
BCI reserves the right to make changes to the products described herein without
prior notice or consent. No liability is assumed as a result of their use or
application. All rights reserved.
©2015 Broadata Communications, Inc.

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [e-mail] 3
SAFETY INSTRUCTIONS AND
COMPLIANCE DECLARATIONS
PLEASEOBSERVETHEFOLLOWINGSAFETY
PRECAUTIONS
SURGEPROTECTION DEVICERECOMMENDED
This product contains sensitive electrical components that may be
damaged by electrical spikes, surges, electric shock, lightning strikes,
etc. Use of surge protection systems is highly recommended in order
to protect and extend the life of your equipment.

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [phone]
4
TABLE OF CONTENTS
1.0 PRODUCT DESCRIPTION .............................................5
2.0 OPERATION CONTROLS AND FUNCTIONS ...............6
2.1 TRANSMITTER FRONT AND REAR PANELS...............6
2.2 RECEIVER FRONT AND REAR PANELS .......................7
3.0 IR......................................................................................8
3.1 IR BLASTER CABLE PINASSIGNMENT........................8
3.2 IR RECEIVER CABLE PINASSIGNMENT ......................8
4.0 MAINTENANCE AND TROUBLESHOOTING .................9
4.1 MAINTENANCE ................................................................9
4.2 TROUBLESHOOTING .....................................................9
5.0 SPECIFICATIONS..........................................................10
6.0 SERVICE PROCEDURE ...............................................11
6.1 REPLACEMENT POLICY .............................................11
6.2 RETURN AND REPAIR SERVICE.................................11
7.0 LIMITED WARRANTY ....................................................12

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [email protected] 5
1.0 PRODUCT DESCRIPTION
• Extend HDMI 2.0 Signals up to 40 meters Over One CAT 5e/6
Cable,basedonchromasubsampling
• SupportsTrueDDC/EDID/HDCP TransmissionOverOne
CAT5e/6Cable
• Video/Audio+IR+RS232,Over1CAT5e/6Cable
• Bi-directionalPoC(Power over Cable)

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [phone]
6
2.0 OPERATION CONTROLS AND FUNCTIONS
2.1 Transmitter Front and Rear Panels
1. LED: Power LED, Status LED, Link LED, HDCP LED
(a) Power LED: This LED light always shine is meant that
works fine.
(b) Signal LED: This LED light is always shine is meant
that video signal works fine.
(c) Link LED: This LED light always shine is meant that
works fine.
2. Latch-locking powerjack: Connect to12V DC powersupply
3. RJ45: Plug in a Cat-5/5e/6 cable that needs to be linked to
the receiving unit LBC-H2CS-R-Lite
4. IR Receiver: Infrared 3.5mm socket for plugging in the
extension cable of IR receiver
5. IR Blaster: Infrared 3.5mm socket for plugging in the
extension cable of IR blaster
6. RS-232(terminal block format): The order of RS-232 pin
are TX, RX, GND (from the left side to the right)
7. Dip Switch: for F/W update ([ON] F/W update Mode; [OFF]
Normal Mode)
8. HDMI IN: Connects to a HDMI source with HDMI male-male
cable
LBC-H2CS-T-Lite
Front
Rear
1
23456 7 8

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [email protected] 7
2.2 Receiver Front and Rear Panels
1. LED: Power LED, Status LED, Link LED, HDCP LED
(a) Power LED: This LED light always shine is meant that
works fine.
(b) Signal LED: This LED light always shine is meant that
video signal works fine.
(c) Link LED: This LED light always shine is meant that
works fine.
2. Latch-locking powerjack: Connect to12V DC powersupply
3. RJ45: Plug in a Cat-5/5e/6 cable that needs to be linked to
the transmitting unit LBC-H2CS-T-Lite
4. IR Receiver: Infrared 3.5mm socket for plugging in the
extension cable of IR receiver
5. IR Blaster: Infrared 3.5mm socket for plugging in the
extension cable of IR blaster
6. RS-232(terminal block format): The order of RS-232 pin
are TX, RX, GND (from the left side to the right)
7. Dip Switch: for F/W update ([ON] F/W update Mode; [OFF]
Normal Mode)
8. HDMI OUT: Connects to a HDMI display with HDMI male-
male cable
LBC-H2CS-R-Lite
Front
Rear
1
23456 7 8

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [phone]
8
3.0 IR EXTENDERS
3.1 IR Blaster Cable PinAssignment
3.3 IR Receiver Cable PinAssignment
IR Blaster IR Blaster Signal [20-60KHz]
NC
Grounding
IR Receiver
IR Signal
Grounding
Power

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [email protected] 9
4.0 MAINTENANCE AND TROUBLESHOOTING
4.1 Maintenance
Thereisnooperatormaintenanceotherthen keeping the units
clean. However, observe the following light indicators to make
sure that the unit is working properly:
4.2 Troubleshooting
If the LBC-H2CS-Lite units do not operate properly after
installation,checkfor possiblecablebreaks,loose connections,
and incorrect cable connections. If problems persist that may
be fiber related, contact BCI at 1-800-214-0222 for further
assistance.

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [phone]
10
5.0 SPECIFICATIONS
VIDEO/AUDIO SPECIFICATIONS
HDMI HDMI 2.0 with HDR (4K60Hz 4:2:0
10-bit)support
VideoResolution Upto4K2K@60Hz
Protocol DDC/EDID/HDCP1.4/2.2Capable
VideoBandwidth 600MHz/18Gbps
AudioOperatingMode StereoAudioorupto7.1 SuroundSound
HDMIConnector HDMIFemale plug
DATA/IR
SerialControl RS-232
DataRate Upto115.2Kbaud
Connector Terminal block
IRControl Infrared
DataRate 20 - 60KHz
In/OutConnectors 3.5mmStereo
PHYSICAL
DimensionsStandalone 4.7”(W) x 2.9”(D) x 0.8”(H)
PowerConsumption +12VDC @ 1.2Amps (Max.)
OperatingTemperature 0 to +40oC
Humidity 20to90%RH,Non-Condensing

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [email protected] 11
6.0 SERVICE PROCEDURE
6.1 Replacement Policy
Standard products found defective on arrival (DOA) will be
replaced,basedonavailability, within24to48hoursanywhere
in the U.S. Please call Customer Service at 800-214-0222 for
information.
6.2 Return/Repair Service
The LBC-H2CS-Lite System contains no user serviceable
components.If youhaveaproblemwithyourunit,pleasecontact
theCustomerServiceDepartment. Tofacilitateourreturn/repair
processing please contact Broadata Communications, Inc. to
obtain a Return MaterialAuthorization (RMA). Please include
thefollowinginformation:
• Productmodelnumber
• SerialNumber
• Completedescriptionofproblem
• Hardwareinstallationdescription
BroadataCommunications,Inc.
2545 West 237th Street, Suite K
Torrance, CA 90505
1-800-214-0222
[phone]
[phone](Facsimile)
e-mail:[email protected]
Website:www.broadatacom.com

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [phone]
12
7.0 LIMITED WARRANTY
Broadata Communications, Inc. (BCI) warrants, for a period of one
yearfromdateof shipment, eachproductsoldshall be free fromdefects
in material and workmanship. BCI will correct, either by repair, or at
BCI’s election, by replacement, any said products that in our sole
discretion prove to be defective and are returned to the manufacturing
location within 30 days after such defect is ascertained. All warranties
are limited to defects arising under normal use and do not include
malfunctionsorfailure resultingfrommisuse, abuse,neglect,alterations,
electrical power problems, usage not in accordance with product
instructions,improperinstallation, ordamagedetermined byBCItohave
been caused by the Buyer or repair made by a third party. Limited
warrantiesgrantedonproductsaretothe initial customer end-user and
arenot transferable. OURLIABILITYUNDERTHISWARRANTYSHALL
IN ANY CASE BE LIMITED TO THE INVOICE VALUE OF THE
PRODUCTSOLDAND BCISHALLNOTBE LIABLETOANYONEFOR
CONSEQUENTIALORINCIDENTALDAMAGESARISINGFROMTHE
USE OF ITS PRODUCTS OR THE SALE THEREOF. We make NO
WARRANTYAS TO THE MERCHANTABILITY OF ANY GOODS, OR
THAT THEY ARE FIT FOR ANY PARTICULAR PURPOSE OR END
APPLICATION NOR DO WE MAKEANY WARRANTY, EXPRESSED
OR IMPLIED OTHER THANAS STATEDABOVE.

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [email protected] 13

LBC-H2CS-T/R-LiteUserManual
LinkBridgeTM HDBaseTHDMI 2.0 Extender,4Play
Broadata Technical Support, [phone]
14

BroadataCommunications,Inc.
2545 West 237th Street, Suite K
Torrance, CA 90505
1-800-214-0222
[phone]
[phone](Facsimile)
e-mail:[email protected]
Website:www.broadatacom.com
60000-LBCH2CST/RLite
