Product Description
Broadcom®
March 28, 2014 • MMP920737TAG03-HWUM100-R Page 8
BCM920737TAG-03 WICED Smart Tag Hardware User Manual
Product Description
The BCM27036 and BCM20737 are Bluetooth Low Energy (BLE)-compliant, stand-alone baseband processors
with integrated 2.4 GHz transceivers. The Broadcom WICED Smart Tag (Figure 1) is an evaluation board that
makes various pins on the BCM2073X available for debug, evaluation, and troubleshooting.
Figure 1: WICED Smart Tag
Broadcom Confidential

Board Layout
Broadcom®
March 28, 2014 • MMP920737TAG03-HWUM100-R Page 9
BCM920737TAG-03 WICED Smart Tag Hardware User Manual
Board Layout
The Smart Tag evaluation board assembly top view is shown in Figure 2. The resistors for memory selection are
highlighted in red.
Figure 2: Board Assembly (Top View)
By default, the board is set to use the internal LPO for sleep, but it can be set to use external LPO by installing
R102 and R103, highlighted in Figure 2, above. Resistor values are listed in Table 1, below.
By default, the board is set to use EEPROM but can be set for serial flash by adjusting the resistors highlighted
in Figure 2 to the desired setting (shown in Table 2).
Table 1: Resistor Settings for External 32 KHz Crystal
Resistor Internal LPO External LPO
R102 DNI 0 Ohm
R103 DNI 0 Ohm
Table 2: Resistor Settings for Memory
Resistor Serial Flash EEPROM
RD2 B-C A-C
RD3 B-C A-C
RD4 B-C A-C
R100 Install DNI
R101 Install DNI
