Broan NuTone PM25 User manual

!
WARNING
TO REDUCETHE RISK OF FIRE,ELECTRIC SHOCK, OR INJURY
TO PERSONS, OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer.
If you have questions, contact the manufacturer at the address
or telephone number listed in the warranty.
2. Before servicing or cleaning unit, switch power off at service panel
and lock the service disconnecting means to prevent power from
being switched on accidentally. When the service disconnecting
means cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
3.Installationworkandelectricalwiringmustbedonebyaqualied
person(s) in accordance with all applicable codes and standards,
includingre-ratedconstructioncodesandstandards.
4.Sufcientairisneededforpropercombustionandexhaustingof
gasesthroughtheue(chimney)offuelburningequipmenttopre-
vent backdrafting. Follow the heating equipment manufacturer’s
guideline and safety standards such as those published by the
National Fire Protection Association (NFPA), and the American
Society of Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
5. When cutting or drilling into wall or ceiling, do not damage electri-
cal wiring and other hidden utilities.
6.Toreducetheriskofreorelectricshock,donotusethisrange
hood with an additional speed control device.
7. Ducted fans must always be vented to the outdoors.
8.Toreducetheriskofre,useonlymetalductwork.
9.Usewithapprovedcord-connectionkitonly.
10. This unit must be grounded.
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
1. Never leave surface units unattended at high settings. Boilovers
cause smoking and greasy spillovers that may ignite. Heat oils
slowly on low or medium settings.
2. Always turn hood ON when cooking at high heat or when cooking
amingfoods.
3. Clean ventilating fans frequently. Grease should not be allowed
toaccumulateonfanorlter.
4. Use proper pan size. Always use cookware appropriate for the
size of the surface element.
POWER
MODULE
READ AND SAVE THESE INSTRUCTIONS
WARNING
TO REDUCETHE RISK OF INJURYTO PERSONS INTHE EVENT
OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOW-
ING:*
1.SMOTHERFLAMESwithaclose-ttinglid,cookiesheet,or
metal tray, then turn off the burner. BE CAREFUL TO PREVENT
BURNS.Iftheamesdonotgooutimmediately,EVACUATE
AND CALL THE FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN — You may be burned.
3.DONOT USE WATER,including wet dishcloths ortowels -
violentsteamexplosionwillresult.
4.UseanextinguisherONLYif:
A. Youknowyouhavea Class ABCextinguisher and you
already know how to operate it.
B. Thereissmallandcontainedintheareawhereitstart-
ed.
C. Theredepartmentisbeingcalled.
D. Youcanghttherewithyourbacktoanexit.
* Based on “Kitchen Fire Safety Tips” published by NFPA.
CAUTION
1.Forgeneralventilatinguseonly.Donotusetoexhausthazard-
ousorexplosivematerialsandvapors.
2. To avoid motor bearing damage and noisy and/or unbalanced
impellers, keep drywall spray, construction dust, etc. off power
unit.
3. For best capture of cooking impurities, your range hood should be
mountedsothatthetopofthehoodis24-30”abovethecooking
surface.
4.Pleasereadspecicationlabelonproductforfurtherinformation
and requirements.
Installer: Leave this manual with the homeowner.
Homeowner: Operating and Cleaning information on page 2.
MODEL PM25
!
FOR DOMESTIC COOKING ONLY
!
To register this product visit
www.broan.com
www.nutone.com
or

WARRANTY
626846G
INSTALLATION
1.Lift exhaust unit into position and mark location for duct and
wiringcutout.Cutholesallowingatleast1/4”clearance.Note:
Make sure switches are accessible.
2. Cut out additional openings in cabinet and roof as required.
3.Removejunctionboxcoverfromexhaustunit.
4. Pull wiring through cutout in cabinet. Lift unit into position, feed
wiring through access hole, and secure unit to cabinet with four
(4) screws provided.
5. Install and align duct. The duct, round damper and roof cap
arenot included with your exhaustunit. These items can be
purchased from your dealer.
6. Make electrical connections according to the latest National
Electrical Code and applicable local ordinances.
ELECTRICAL GROUNDING
Permanently ground this unit in accordance with the latest National
Electrical code and applicable local codes and ordinances.
It is recommended that a permanent ground connection be made
to the unit using a conductor of appropriate size from a grounded
continuous metallic cold water pipe, a grounded lead in the service
panel, or a properly driven and electrically grounded ground rod.
Do not ground to a gas supply pipe.
CLEANING INFORMATION
FILTER
Forgreatest efciency, thepermanent type aluminumfoil lter
should be removed and cleaned periodically.
Toclean,theltershouldbesoakedinhotwateranddetergent
then thoroughly rinsed.
EXTERIOR SURFACE
YourExhaustUnitisabeautifullynishedadditiontoyourkitchen.
Clean with a mild detergent to preserve its lasting beauty.
Key No. Part No. Description
1 R730090 Motor/Fan Blade
2 R111447 Light Socket
3 R610027 Aluminum Filter
4 97016971 Motor Switch - White (Includes light switch)
97016970 Motor Switch - Black (Includes light switch)
5 97016971 Light Switch - White (Includes motor switch)
97016970 Light Switch - Black (Includes motor switch)
6 R668132 Cover Assembly
7 R602539 Screw
VERTICAL OR
TOP VENTING
CABINET
CEILING DUCT
ROOF CAP
NOTE:
ROUND DAMPER IS NOT INCLUDED.
2
Broan-NuTone One Year Limited Warranty
Broan-NuTone warrants to the original consumer purchaser of its products that such products
will be free from defects in materials or workmanship for a period of one year from the date
of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
During this one-year period, Broan-NuTone will, at its option, repair or replace, without charge,
any product or part which is found to be defective under normal use and service.
THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS AND TUBES.
This warranty does not cover (a) normal maintenance and service or (b) any products or parts
which have been subject to misuse, negligence, accident, improper maintenance or repair
(other than by Broan-NuTone), faulty installation or installation contrary to recommended
installation instructions.
The duration of any implied warranty is limited to the one-year period as specified for the
express warranty. Some states do not allow limitation on how long an implied warranty lasts,
so the above limitation may not apply to you.
BROAN-NUTONE’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN-NUTONE’S OP-
TION, SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS
WARRANTY.BROAN-NUTONE SHALLNOTBELIABLEFORINCIDENTAL,CONSEQUENTIAL
OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH PRODUCT USE
OR PERFORMANCE. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights, which vary
from state to state. This warranty supersedes all prior warranties.
To qualify for warranty service, you must (a) notify Broan-NuTone at the address or phone
number below, (b) give the model number and part identification and (c) describe the nature of
any defect in the product or part. At the time of requesting warranty service, you must present
evidence of the original purchase date.
Broan-NuTone LLC Hartford, Wisconsin www.broan.com 800-558-1711
Broan-NuTone Canada Mississauga, Ontario www.broan.ca 877-896-1119
SERVICE PARTS
1
2
3
45
6
7
