Broan UXT2030AA Series User manual

WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer. If you have questions,
contact the manufacturer at the address or telephone number listed in the warranty.
2. Before servicing or cleaning unit, switch power off at service panel and lock the service
disconnecting means to prevent power from being switched on accidentally. When
the service disconnecting means cannot be locked, securely fasten a prominent
warning device, such as a tag, to the service panel.
3. Installation work and electrical wiring must be done by a qualified person(s) in
accordance with all applicable codes and standards, including fire-rated construction
codes and standards.
4. Sufficient air is needed for proper combustion and exhausting of gases through the
flue (chimney) of fuel burning equipment to prevent backdrafting. Follow the heating
equipment manufacturer's guideline and safety standards such as those published by
the National Fire Protection Association (NFPA), and the American Society for Heating,
Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities.
5. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other
hidden utilities.
6. Ducted fans must always be vented to the outdoors.
7. Do not use this range hood with an additional speed control device.
8. To reduce the risk of fire, use only metal ductwork.
9. Use with approved cord-connection kit only.
10. This unit must be grounded.
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
1. Never leave surface units unattended at high settings. Boilovers cause smoking and
greasy spillovers that may ignite. Heat oils slowly on low or medium settings.
2. Always turn hood ON when cooking at high heat or when cooking flaming foods.
3. Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan
or filter.
4. Use proper pan size. Always use cookware appropriate for the size of the surface
element.
WARNING
TO REDUCE THE RISK OFINURY TO PERSONS IN THE EVENT OF A RANGE
TOP GREASE FIRE, OBSERVE THE FOLLOWING:*
1. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, turn off
the burner. BE CAREFUL TO PREVENT BURNS. If the flames do not go out
immediately, EVACUATE AND CALL THE FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN - You may be burned.
3. DO NOT USE WATER, including wet dishcloths or towels - a violent stream
explosion will result.
4. Use an extinguisher ONLY if:
A. You know you a Class ABC extinguisher and you already know how to operate
it.
B. The fire is small and contained in the area where it started.
C. The fire department is being called.
D. You can fight the fire with your back to an exit.
*Based on “Kitchen Firesafety Tips” published by NFPA.
CAUTION
!
1. For general ventilating use only. Do not use to exhaust hazardous or explosive
materials and vapors.
2. To avoid motor bearing damage and noisy/and or unbalanced impellers, keep
drywall spray, construction dust, etc. off power unit.
3. For best capture of cooking impurities, your range hood should be mounted
18-24" above the cooking surface.
4. Please read specification label on product for further information and
requirements.
READ AND SAVE THESE INSTRUCTIONS
UXT2030AA
UXT2036AA SERIES
ECONOMY RANGE HOOD
INSTALLATION INSTRUCTIONS
UXT3030AA
UXT3036AA SERIES UXT4030AA
UXT4036AA SERIES
Drill, electric or ratchet drive
1/8" drill bit for drilling pilot holes
1-1/4" wood bit for drilling electrical wiring access hole
One straight blade and one phillips head screwdriver
Pliers
Pencil and ruler and/or tape measure
Saber saw or keyhole saw for cutting 1" x 2" wood strips
to length and cutting wall or cabinet openings
Caulking, metal snips, duct tape, duct (with elbows and
transition, if necessary) and roof or wall cap, as required
Electrical wiring and supplies of type to comply with local
codes
The following materials are required only for installations on
recessed bottom kitchen cabinets:
Two 1" x 2" x 12" (approximate length) wood strips (pur-
chase locally)
Four 1-1/4" long flat head wood screws (purchase locally)
INSTALLER: Leave This Manual With Homeowner
HOMEOWNER: Use and Care Information on Page 6
TOOLS AND MATERIALS REQUIRED
!
INTENDED FOR DOMESTIC COOKING ONLY.
!
To register this
product visit
www.broan.com

2
PLANNING DUCTWORK INSTALLATION
PREPARE THE HOOD
In more complex ducting situations, a 3-1/4" x 10" rectangular
ducting range hood (UXT3030AA and UXT3036AA hoods) can be
converted to a round duct by means of a transition.
(This section for UXT2030AA, UXT2036AA, UXT3030AA, and
UXT3036AA hoods only. UXT4030AA and UXT4036AA hoods
skip this section and go on to "Prepare the Hood".)
Begin planning ductwork by deciding where duct will run between
the range hood and the outside. For best performance, use the
shortest possible duct run and a minimum numaber of elbows.
There are several choices shown - FIGS. A - F below.
FIG. A
Ducting directly through the wall (for range hoods mounted on an
exterior wall). Shown are two ways to duct through an outside wall.
If a wall cap is used directly off the back of the hood, special care
must be taken to make sure that the damper in the damper/duct
connector on the hood damper in the wall cap do not interfere with
each other when the hood is operating. This could result in either
inadequate air delivery or backdrafts. If this condition does exist,
remove the hood damper flap. Sometimes when using a wall cap it
is easier to duct vertically and then use an elbow as shown FIG. B.
FIG. 1
1. Unpack hood and check contents. You should receive:
1 - Aluminum Filter (UXT3030AA, UXT3036AA, UXT2030AA
and UXT2036AA hoods only)
1 - 3¼" x 10" Damper/Duct Connector (mounted inside of
hood for shipping only) ((UXT3030AA and UXT3036AA
hoods only)
1 - Ductfree Filter (UXT4030AA and UXT4036AA hoods only)
2. Remove wiring box cover. Under cover find:
1 - Plastic Bag containing loose mounting hardware
ALUMINUM FILTER
(UXT3030AA, UXT3036AA,
UXT2030AA, UXT2036AA)
WIRING
BOX
COVER
KEYHOLE SLOTS
DUCTFREE FILTER
(UXT4030AA &
UXT4036AA HOODS
ONLY)
DAMPER/DUCT CONNECTOR
(UXT3030AA & UXT3036AA HOODS ONLY)
FIG. C. Straight up through the roof us-
ing 7" round duct (for single story instal-
lations - UXT2030AA and UTX2036AA
only)
FIG. D. Ducting straight up through the
roof using 3¼" x 10" rectangular duct. (For
single story installations UXT3030AA and
UXT3036AA hoods only.)
FIG. E. Ducting between the ceiling joists
(for multi-story installations) or through the
soffit space above the cabinets (where the
soffit connects to an outside wall).
FIG. F. Straight up through the roof
using 6" round duct (for single-story
installations).

3
PREPARE THE HOOD - CONT.
PREPARE THE INSTALLATION LOCATION
FIG. 2
FIG. 3
FIG. 5A FIG. 5B
UXT2030AA
UXT2036AA
FIG. 4
UXT3030AA
UXT3036AA
UXT4030AA
UXT4036AA
3. Remove top or rear electrical knockout. (FIG. 2)
4. (UXT3030AA and UXT3036AA hoods ONLY) Remove duct
knockout. Insert screwdriver under edge of knockout, break tabs,
and peel knockout back with pliers. (FIG. 3)
5. (UXT3030AA AND UXT3036AA ONLY). Install damper/duct
connector over opening made in STEP 4. Use #8B sheet metal
screws provided. (FIG. 3)
UXT2030AA and UXT2036AA hoods ONLY) Install Model 87
damper (purchase separately) over opening in top of hood.
Omit STEP 1 if hood will be installed under cabinets with flush
bottom.
1. (For installation on recessed bottom cabinets only)
Attach a wood filler strip at each side of recessed are under
cabinet. Use two 1" x 2" strips cut to length. If recess is deeper
than 1" use thicker strips. Attach strips with 1-1/4'' wood screws,
3" from end end of strip. See FIG. 4.
2. Measure and mark the following (FIGS. 5A & 5B):
a.) Electrical wiring opening in wall or cabinet.
b.) Duct opening in wall or cabinet. (UXT2030AA, UXT2036AA,
UXT3030AA, and UXT3036AA ONLY)

4
INSTALL THE DUCTWORK
PREPARE THE INSTALLATION LOCATION - CONT.
WARNING
WHEN CUTTING OR DRILLING INTO WALL OR CABINET,
BE CAREFUL NOT TO CUT EXISTING ELECTRICAL
WIRING.
FIG. 6
FIG. 8
FIG. 7
3. Use 1-1/4" bit to drill opening for electric wiring.
4. Cut out duct opening in wall or cabinet with saber saw or keyhole
saw.
5. Center hood in installation opening and trace keyhole slots onto
wood filler strips on cabinet bottom.
6. Screw four #10 x 7/8 wood screws into exact center of narrow
end of traced keyhole slots. Allow 3/8" of screws to project, so
that hood can be fitted into place later.
(This section for UXT2030AA, UXT2036AA, UXT3030AA, and
UXT3036AA hoods ony. UXT4030AA and UXT4036AA hoods
skip this section and go on to "Install Range Hood".)
NOTE
These instructions will follow plans made on Page 2. Start
at the exterior and run ductwork back to the range hood.
For best possible performance, use the shortest possible
duct run and a minimum number of elbows. Do not vent a
range hood into an attice space. A buildup of grease in the
attic could become a fire hazard.
Use only metal ductwork. DO NOT USE PLASTIC DUCT.
Assemble duct run securely so that in case of a grease
fire on the range, the fire will be contained inside metal
ductwork.
Tape all duct connections.
2. Follow appropriate directions below for type of duct run you
install.
a.) Wall Cap Discharge; (FIG. 7) Use saber saw or keyhole
saw to to cut hole slightly larger than duct size used so that
duct will line up easily with damper/duct connector on hood.
Install casing strips if cap will be installed on siding. Attach
required amount of duct to wall cap and run duct back to
hood. Fasten cap to wall and caulk well.
b.) Roof Cap Discharge: (FIG. 8) Cut a hole in roof slightly
larger than duct size being used. Run ductwork down to
hood location. Leave 3/4" of duct projecting above roof
surface on high side.
Trim duct parallel to roof pitch and seal all around duct
with roof cement.
Carefully trim shingles and slide back of roof sheet under
shingles. Nail roof sheet to roof under shingles at top
two comers and two sides. Nail sheet directly to roof in
four places at bottom.
Using roof cement, seal all nail heads and shingles which
were cut or lifted. Do not seal bottom edge of roof sheet.

5
INSTALLING RANGE HOOD
WARNING
TURN OFF THE PROPER CIRCUIT AT THE SERVICE
ENTRANCE BEFORE WIRING THIS RANGE HOOD.
1. Run electric wiring through hole drilled in wall or cabinet. Split
wiring for 6" and install proper connector for type of wire used.
(FIG. 9)
FIG. 9
FIG. 11
6. Strip 1/2" of insulation foam wires. Connect white to white, black
to black, and green to prepared hole with green ground screw
provided. (FIG. 11)
2. Position hood so that:
a.) Wiring is routed through knockout opening. (FIG. 10)
b.) Large part of keyhole slots fit over hood mounting screws.
(FIG. 10)
c.) Damper/duct connector slides into ductwork.
(UXT3030AA, UXT3036AA, UXT4030AA, and UXT4036AA.
WARNING
ALL ELECTRICAL CONNECTIONS MUST BE IN
ACCORDANCE WITH LOCAL CODES, ORDINANCES, OR
NATIONAL ELECTRICAL CODE. IF YOU ARE UNFAMILIAR
WITH METHODS OF INSTALLING ELECTRICAL WIRING,
SECURE THE SERVICES OF A QUALIFIED ELECTRICIAN.
FIG. 10
3. Adjust hood so that hood front is flush with cabinet frame.
4. Tighten hood mounting screws firmly.
5. Fasten wiring to hood with proper electrical connector for type
of wiring being used.
7. Replace wiring box cover and screw. Make sure that all wiring is
safely contained inside.
8. Install light (75 Watt maximum) For easier installation, squeeze
plastic lens and remove it from hood. Remember to reinstall
lens (FIG. 12)
FIG. 12
9. Turn on power and check operation of fan and light. Make sure
that damper operates freely.

6
USE AND CARE
SWITCHES
The fan and light are each controlled by a rocker switch. The light
switch has two positions, "ON" AND "OFF". The fan switch has
three positions - "HIGH", "LOW" and "OFF". ("OFF" is the middle
position.)
FILTERS
UXT3030AA, UXT3036AA, UXT2030AA, and UXT2036AA
Hoods Only:
Remove aluminum filter by turning filter retainer to one side. (FIG.
13) Filter should be washed once a month in a hot detergent
solution. Aluminum filters are dishwasher safe. when installing filter,
make sure that filter slides under retaining tabs on back of fan
housing. Turn filter retainer so that arrows on retainer point toward
front and back of hood.
FIG. 13
UXT4030AA and UXT4036AA Hoods Only:
The UXT4030AA and UXT4036AA hoods are equipped with a
ductfree filter. Remove filter by turning filter retainer to one side.
(FIG. 13). The ductfree filter is not washable, and will last up to
twelve months with normal use. Replace the filter when colored
side becomes noticeably dirty or discolored.
When installing filter, make sure that filter slides under retaining
tabs on back of fan housing. MAKE SURE THAT COLORED SIDE
OF FILTER IS NEXT TO FAN WHEN FILTER IS INSTALLED. Turn
filter retainer so that arrows on retainer point toward front and back
of hood.
WARNING
ALWAYS DISCONNECT ELECTRIC POWER BEFORE
SERVICING RANGE HOOD.
FAN ASSEMBLY
Remove filter. Remove two screws holding motor bracket to range
hood, and unplug fan assembly. Be careful not to allow fan assembly
to drop when screws are removed. (FIG. 15)
FIG. 15
CLEANING
Clean your hood with a mild detergent suitable for painted surfaces.
DO NOT USE ABRASIVE CLOTH, STEEL WOOL PADS OR
SCOURING POWDERS.
Fan assembly may be vacuumed. Fan assembly is lifetime
lubricated, and never needs oiling.
HOW TO AVOID A COMMON RANGE-TOP GREASE FIRE
• Your range hood provides a protective barrier between the
cooking surface and the cabinets.
• Keep fan, filters and grease laden surfaces CLEAN according
to instructions.
• Always turn hood ON when cooking at high heat to keep the
cooking area and the hood cooler.
• Use high heat settings only when necessary.
• Never leave cooking surface unattended. Boil-over causes
smoking and greasy spillovers that may ignite.
• Always use adequate-sized utensils.
• If preparing flaming foods, such as Cherries Jubliee, always
turn hood ON to HIGH to prevent a high heat situation which
can cause damage or fire.
HOW TO EXTINGUISH A COMMON RANGE-TOP GREASE
FIRE
• Never pick up a flaming pan. If dropped flames can spread
quickly.
• DO NOT USE WATER! A violent stream explosion may result.
Wet dishcloths or towels are also dangerous.
• Smother flames with a close fitting lid, cookie sheet or metal
tray.
• Flaming grease can also be a extinguished with baking soda
or multi-purpose dry chemical extinguisher.
• Turn off surface units - if you can do so without getting burned.

3¼" x 10"
Ducted
Hood
Only
Ductfree
Hood
Only
7
SERVICE PARTS
Service parts for your range hood are shown (with part numbers).
List the hood model number (on spec label located on inside of
hood) and the part numbers of all parts being ordered.
FIG. 16
UXT3030AA UXT4030AA UXT2030AA
UXT3036AA UXT4036AA UXT2036AA
Series Series Series
3-1/4" X 10" Ductfree 7" Round
Ducted Hood Hood Ducted Hood
Key No. Part Number Part Number Part Number Description
1 47001055 47001055 47001055 Outlet Box Cover
2 706189 706189 706189 #8-18 x 3/8 Phillips Truss Sheet Metal Screws*
3 47001056 47001056 47001056 Bulb Holder with Wires
4 47001057 47001057 47001057 Light Lens
5 47001080 47001080 47001080 Screw/Nut Kit (Includes 2 - #10-16 x .500 screws
and 2 - #10-16 sheet metal nuts)
6 47001059 47001074 47001059 Fan Blade
7 03050041 03050041 03050041 #6-32 Locking Nuts* (2 Required)
8 47001060 47001060 47001060 Motor Mounting Bracket
9 47001088 47001075 47001088 Motor Assembly (Includes Key Nos. 6, 7, & 8)
10 47001062 47001076 47001062 Filter
11 47001063 47001063 47001063 Filter Retainer
12 706189 — — #8B x 1/4 Hex Head Sheet Metal Screws* (2 Required)
13 47001078 — — Damper Flap
14 47001079 — — Damper Bushing
15 47001064 — — Damper Assembly (Includes Key Nos. 13 & 14)
16 47001065 47001065 47001065 Nameplate - Black
47001083 47001083 47001083 Nameplate - White
17 47001066 47001066 47001066 2-Speed Motor Switch - Black
47001081 47001081 47001081 2-Speed Motor Switch - White
18 47001067 47001067 47001067 Light Switch - Black
47001082 47001082 47001082 Light Switch - White
19 47001068 47001068 47001068 Motor Receptacle with Wires
20 71001171 71001171 71001171 #10-32 x 1/2 Green Ground Screw*
** — — — Light Bulb, 75 Watt (not included)
* Standard hardware. May be purchased locally.
** Not shown.

99043046C
Warranty
Limited One Year Warranty -
Parts and Labor
For one (1) Year from the original retail purchase
date, any part that fails in normal home use will be
repaired or replaced free of charge.
Canadian Residents
The above warranties only cover an appliance
installed in Canada that has been certified or list-
ed by appropriate test agencies for a compliance
to a National Standard of Canada unless the
appliance was brought into Canada due to trans-
fer of residence from the United States to Canada.
The specific warranties expressed above are the
ONLY warranties provided by the manufacturer.
These warranties give you specific legal rights, and
you may also have other rights which vary from
state to state.
Warranty & Service
What is Not Covered By These Warranties
1. Conditions and damages resulting from any of the following:
a. Improper installation, delivery, or maintenance.
b. Any repair, modification, alteration, or adjustment not
authorized by the manufacturer or an authorized servicer.
c. Misuse, abuse, accidents, unreasonable use, or acts of God.
d. Incorrect electric current, voltage, electrical and/or gas supply.
e. Improper setting of any control.
2. Warranties are void if the original serial numbers have been removed,
altered or cannot be readily determined.
3. Light bulbs, water filters and air filters.
4. Products purchased for commercial or industrial use.
5. The cost of service or service call to:
a. Correct installation errors. For products requiring ventilation, rigid
metal ducting must be used.
b. Instruct the user on the proper use of the product.
c. Transport the appliance to and from the servicer.
6. Any food loss due to refrigerator or freezer product failures.
7. Expenses for travel and transportation for product service in remote
locations.
8. Outside of the United States and Canada this warranty does not apply.
Contact your dealer to determine if another warranty applies.
9. Consequential or incidental damages sustained by any person as a
result of any breach of these warranties. Some states do not allow the
exclusion or limitation of consequential or incidental damages, so the
above exclusion may not apply.
If You Need Service
First see the Troubleshooting section in your Use and Care Guide or call the
dealer from whom your appliance was purchased or call Maytag Services,
LLC, Customer Assistance at 1-800-688-9900 USA and 1-800-688-2002
Canada to locate an authorized servicer.
• Be sure to retain proof of purchase to verify warranty status. Refer to WAR-
RANTY for further information on owner’s responsibilities for warranty
service.
• If the dealer or service company cannot resolve the problem, write to
Maytag Services LLC, Attn: CAIR
®
Center, P.O. Box 2370, Cleveland, TN
37320-2370, or call 1-800-688-9900 U.S.A. and 1-800-688-2002
Canada. U.S. customers using TTY for deaf, hearing impaired or speech
impaired, call 1-800-688-2080.
• User’s guides, service manuals and parts information are available from
Maytag Services LLC, Customer Assistance.
Notes: When contacting about a service problem, please include
a. Your name, address and telephone number.
b. Model number and serial number.
c. Name and address of your dealer or servicer.
d. A clear description of the problem you are having.
e. Proof of purchase (sales receipt).
CUSTOMER’S SOLE AND EXCLUSIVE
REMEDY UNDER THIS LIMITED WARRANTY
SHALL BE PRODUCT REPAIR AS PROVIDED
HEREIN. IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED TO ONE YEAR OR THE SHORTEST
PERIOD ALLOWED BY LAW. MAYTAG
CORPORATION SHALL NOT BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL
DAMAGES. SOME STATES AND PROVINCES
DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, OR
LIMITATIONS ON THE DURATION OF
IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS, SO THESE
EXCLUSIONS OR LIMITATIONS MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS AND YOU MAY
ALSO HAVE OTHER RIGHTS, WHICH VARY
STATE TO STATE OR PROVINCE TO
PROVINCE.
